YWCCS705A7 INCH CAPACITIVE TYPE TOUCH PANEL MID

Customer Support: 1-888-999-42151 Step 1. Charging Step 2. Connecting to the Internet 1. Press the Settings Icon. 2. Locate the Wi-Fi setting and slide it to the On position. 3. Select a network from the list of available networks. To refresh the list of available networks, press the Scan button. To manually add a network, select the Add Network button. 4. Select Connect from the pop up menu. 5. If the network is secured with a password, enter the password to continue. 6. Once finished connecting, the display will show Connected under the name of the network. Connecting to Wireless Internet QUICKSTART GUIDE Before using your new Zeki tablet, it needs to be fully charged. Connect the tablet to an AC outlet using the included adaptor. Initial charge time will be about 10 hours. Charging VOLUME POWER SERIAL NO.: MODEL NO. : TB782B INPUT : DC5V 2.0A MADE IN CHINA FID : IT DC IN 5V MICRO SD HDMI R Customer Support: 1-888-999-42152 Step 3. Installing the Pre-loaded Apps while Congratulations! You are now ready to use your new Zeki tablet. For the full version of the User’s Manual, visit: www.zekitablet.com Your Zeki tablet comes with a number of important and useful pre-loaded apps as well as a detailed user’s manual. These include: - Amazon App Store - Aldiko E-book Reader - Es Explorer To install these apps and access the user’s manual, follow the steps below. 1. Press the App Menu button in the upper right hand corner. 2. Press the Zeki Icon. 3. A pop up menu will appear on the screen. 4. Select Install the Apps and press Ok when prompted. 5. The message Apps are installing, please wait will appear. Please wait until all apps are installed before beginning to use the tablet. 6. To access the user’s manual, open the Aldiko E-book Reader app, press Shelf View and select the user’s manual. How to Install the Pre-loaded Apps connected to the Wi-Fi FCC Warning: z This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: z (1) this device may not cause harmful interference, and z (2) this device must accept any interference received, including interference that may cause undesired operation. z Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. z NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: z -- Reorient or relocate the receiving antenna. z -- Increase the separation between the equipment and receiver. z -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. FCC RF warning statement: The device has been evaluated to meet general RF exposure requirement.The device can be used in portable exposure condition without restriction.

ITONE DIGITAL SHENZHEN CO., LTD. B3, NO.3, 2nd Row, Xinfa lndustrial Zone, Xinqiao, Shajing, Baoan District, Shenzhen, China Date: August 02, 2012 We, ITONE DIGITAL SHENZHEN CO., LTD. declare that this EUT (FCC ID: YWCCS705A) doesn’t have Ad Hoc Mode function on “non-US/Canada frequencies”. In addition, the frequency selection feature is disabled by firmware for devices marketed to the US/Canada. For DTS part of this device, only channels 1-11 will used in North America. Country code selection is disabled. EUT just only have WIFI function. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely yours, Signature Contact Person: Chen guanli / R&D Manager Company: ITONE DIGITAL SHENZHEN CO., LTD. Chen guanli / R&D Manager E-mail: [email protected] Phone: +86-0755-61119000-858 Fax: +86-0755-61119222 Address B3, NO.3, 2nd Row, Xinfa lndustrial Zone, Xinqiao, Shajing, Baoan District, Shenzhen, China

ITONE DIGITAL SHENZHEN CO., LTD. Date: 2012-08-02 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: YWCCS705A To Whom It May Concern: This letter is to ascertain that ITONE DIGITAL SHENZHEN CO., LTD. 7 INCH CAPACITIVE TYPE TOUCH PANEL MID, MODEL NO.: CS705A, TB782B has been the units used for conducting FCC compliance testing, the DoC part will be tested by FCC recognized test lab. If you have any question or concerns, pls. contact us. Sincerely, Signature Chen guanli / R&D Manager E-mail: [email protected] Phone: +86-0755-61119000-858 Fax: +86-0755-61119222 Address B3, NO.3, 2nd Row, Xinfa lndustrial Zone, Xinqiao, Shajing, Baoan District, Shenzhen, China

Confidentiality Request Letter Page 1 of 2 Rev 3.0 Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 Confidentiality Request Letter Page 2 of 2 Rev 3.0 ITONE DIGITAL SHENZHEN CO., LTD. (2012-8-02) To: Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality Request for FCC ID: YWCCS705A We hereby request confidential treatment of information accompanying this application as outlined below: - Block diagram - Operation description - Schematic The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signature Chen guanli / R&D Manager E-mail: [email protected] Phone: +86-0755-61119000-858 Fax: +86-0755-61119222 Address B3, NO.3, 2nd Row, Xinfa lndustrial Zone, Xinqiao, Shajing, Baoan District, Shenzhen, China

ITONE DIGITAL SHENZHEN CO., LTD. 7 INCH CAPACITIVE TYPE TOUCH PANEL MID FCC ID: YWCCS705A MODEL No.: CS705A, TB782B Made in China This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Label Location Proposed Label Location on EUT

Antenna WIFI Module

FCC ID : YWCCS705A WLAN (Portable device) According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB 447498 (2)(a)(i) Frequency Range Low Frequency (MHz) High Frequency(MHz) Center frequency (MHz) 60/f SAR Limitation (mw) 2412 2462 2437 25 Maximum measured transmitter power: 802.11b Conducted Power (dBm) Conducted Power (mw) Max Antenna Gain (dBi) EIRP (mw) 11.90 15.79 1.75 23.17 Maximum measured transmitter power: 802.11g Conducted Power (dBm) Conducted Power (mw) Max Antenna Gain (dBi) EIRP (mw) 11.26 13.37 1.75 20.00 Maximum measured transmitter power: 802.11n HT20 Conducted Power (dBm) Conducted Power (mw) Max Antenna Gain (dBi) EIRP (mw) 10.52 11.27 1.75 16.87 Maximum measured transmitter power: 802.11n HT40 Conducted Power (dBm) Conducted Power (mw) Max Antenna Gain (dBi) EIRP (mw) 9.55 9.02 1.75 13.49 Threshold at which no SAR required is 25 mw. Maximum Tx power is 23.17 mw EIRP Conclusion: No SAR is required. Sincerely, Signature Chen guanli / R&D Manager E-mail: [email protected] Phone: +86-0755-61119000-858 Fax: +86-0755-61119222 Address B3, NO.3, 2nd Row, Xinfa lndustrial Zone, Xinqiao, Shajing, Baoan District, Shenzhen, China
