YWCER701EBOOK

ITONE DIGITAL SHENZHEN CO.,LTD.

Click to zoom

Application Details

Equipment Class: JBP - Part 15 Class B Computing Device Peripheral
Date of Grant: Aug 08, 2011
Application Purpose: Original Equipment
Date of Application: Aug 07, 2011
Equipment Note: EBOOK
Company: ITONE DIGITAL SHENZHEN CO.,LTD.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Contents Page 1.Contents 2.In the box 3.Location of controls 4.Basic operation 6.Installing the Kobo Desktop App 10.Purchasing & syncing eBooks 15.Reading eBooks 22.Home screen (Library) 24. Favorites 26. Bookmarks 28. Transferring media files 30. Video 31. Music 33. Photo 35. File explorer 37. Settings 38.Legal information 40.Limited Warranty User Guide Casee-Reader USB Cable User Guide In the box 1. 3. 2.4. 12.13. 5.6.7.8. 11. 9. 10. Location of controls 1. 7" color display2. Headphone jack3. [MENU] : Displays the function menu for each mode 4. [TEXT ZOOM] : Text zoom option 5. [PLAY/PAUSE] : Play/pause audio 6. [RETURN] : Return to previous screen 7. [OK] : Confirm the selection 8. [ARROW KEYS] : Multi-functional key 9. [PREVIOUS/NEXT PAGE] : Go to previous/next page 10. Charging indicator11. [ Ђ ] : Power on/off 12. Mini USB port13. Micro SD card slot Menu button:The [MENU] button opens the menu options for the different modes of the e-Reader. Library, Reading, Music, Video, Photos, etc. all have their own unique menus that can be accessed by pressing the [MENU] button. PC USB cable e-Reader Basic operation Charging the battery: Connect the e-Reader to the computer using the included USB cable ( mini USB port of the e-Reader to USB port of the computer). While charging, the indicator light is red, it will turn blue after it is fully charged (6-8 hours). Turning on or off: Make sure the e-Reader is fully charged before turning it on. Press and hold [ Ђ ]until the Home screen appears or the e-Reader shuts down. Briefly press [ Ђ ]for standby mode (the display will shut but the device will still be powered on - this will conserve battery time). Charging indicator Note:For faster charging, use the optional AC adaptor (see included accessories order form). Inserting the Micro SD card (not included): The e-Reader includes 2GB internal memory. To expand the memory capacity, use Micro SD cards to save eBooks, audio, video and picture files. To install the Micro SD card into the e-Reader, follow the steps below: 1. Turn off the e-Reader. 2. Insert the Micro SD card (metal contacts facing up as shown) into the card slot until it clicks and locks into place. 3. To remove the card, gently push it in until it pops out. To access the Micro SD card, select “File Explorer” in the Home menu. Micro SD card t"DBSEDBOPOMZCFJOTFSUFEPOFXBZEPOPUVTFGPSDFXIFOJOTFSUJOHUIFDBSE t*OTFSUJOHPSSFNPWJOHBDBSEXIJMFUIFF3FBEFSJTPONBZEBNBHFUIFDBSE öMFTTUPSFEPOUIFDBSE PSUIFF3FBEFS PC USB cable e-Reader Installing the Kobo Desktop App The Kobo Desktop App is a great place to buy the latest books and bestsellers or browse from over 1 million free titles. Once an account is created (setting up the account is free), it is easy to purchase, download and sync books to the e-Reader. Follow the instructions below to install the Kobo Desktop App on your computer. 1. Make sure the computer is connected to the internet to download and use the Kobo Desktop App. 2. Connect the e-Reader to the computer using the included USB cable. 3. In the window that pops up, click on “Open folder to view files” 4. Click on “Desktop Installers” 5. Select either “Windows”, or “Mac OS X” depending on which computer you are using, and double click the “DesktopInstaller” icon to launch the installer. 6. Follow the setup wizard to install the app. 7. Click “Finish” to complete the installation. 8. The screen below appears after the setup is completed, click “Sign in to your account”. 9. If this is your first time trying to connect to the Kobo store, select “I am a new customer” and create an account (It’s free). Store Purchasing & syncing eBooks 1. In the store, browse and select the eBook you are interested in. 2. Click the “Buy Now” button. 3. Fill out the billing information and check out. 4. The purchased item will be downloaded shortly and saved in your Library. Click on the “Library” tab to access all the downloaded eBooks. Library “Get online” 5. Connect the e-Reader to the computer, and click on the “e-Reader” tab. Click the “Sync” button to copy the books in your Library to the e-Reader. 6. When syncing eBooks to the e-Reader for the first time, the following screen appears. You will be asked to enter your Adobe ID to transfer protected eBooks between computers and mobile devices. If you need to create a new Adobe ID account, click “Get online” on the Setup Assistant page. e-Reader Sync 7. Follow the instructions to create an Adobe ID which will authorize your computer to transfer books to the e-Reader. 8. The eBooks in your Library will be copied to the e-Reader. Certain eBooks (depending on the file type or format) may not be able to transfer to the e-Reader, in this case a pop up window will appear while syncing the e-Reader which will alert you regarding this issue (these eBooks may still be downloaded, synced and read on the Kobo Desktop App). 9. When the sync is completed, click eject before disconnecting the e-Reader from the computer. For more information regarding the Kobo Desktop App, please visit: www.kobo.com/help To avoid the syncing process, stay logged-in to your Kobo account. Continue Reading Library 2/3 Grimms' Fairy Tales.epub The Brothers Grimm Last read 02:44 07/03/2011 Page 1 Adventures of Huckleberry.epub Mark Twain INTEPUB [PREVIOUS/NEXT] skip to previous/next page of the Library [ARROW KEYS] Move the selector [OK] Select Reading eBooks Books stored on the e-Reader can be accessed from one of the below options on the Home screen: t$POUJOVF3FBEJOH Book you are currently reading t-JCSBSZ All books stored on the e-Reader [ARROW KEYS][] or [] to move the selector. [PREVIOUS/NEXT][] or [] to skip to the previous or next page of the Library. Press [OK] to start reading the book. OK )PNFTDSFFO -JCSBSZQBHFJOEJDBUPS Adventures of Huckleberry Finn.epub 2/3 Tom he made a sign to me--kind of a little noise with his mouth--and we went creeping away on our hands and knees. …

Text truncated - open the document above for the full version.

Cover Letter(s)

ITONE DIGITAL SHENZHEN CO., LTD. FCC Authorization Letter Number: CF304 Version: V01 Date: 01-02-2010 We, (the approval holder) Company name ITONE DIGITAL SHENZHEN CO., LTD. Addresss B3, NO.3, 2nd Row, Xinfa lndustrial Zone, Xinqiao, Shajing, Baoan District, Shenzhen, China City Shenzhen Country China declare that the following representative (agent): Name (person) M. Koop Company name Teleconformity Addresss Rietven 31 City 7534NH Enschede Country The Netherlands is hereby authorized to apply the following equipment for certification on our behalf: Product Description EBOOK Type or Model(s) BK7019, ER701 Tradename or Brand(s) N/A Attestation: City and Country: Date: Name: (this must be a person) Function: Signature: (or official company stamp) Shenzhen China 2011-8-6 Chen guanli Manager

External Photos

External of EUT

ID Label/Location Info

Label Location Proposed Label Location on EUT

ID Label/Location Info

FCC ID: YWCER701 Model Number: ER701 Made in China This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation

Internal Photos

Internal of EUT

Test Report

FCC ID: YWCER701 SHENZHEN EMTEK CO., LTD. Report No.: ES110808023F Page 1 of 31 TEST REPORT For ITONE DIGITAL (SHENZHEN) CO., LTD. EBOOK Model No.: BK7019, ER701 FCC ID: YWCER701 Report Number : ES110808023F Date of Test : July 05, 2011 to July 08, 2011 Date of Report : August 8, 2011 Prepared for : ITONE DIGITAL (SHENZHEN) CO., LTD. Address : B3, NO.3, 2nd Row, Xinfa Industrial Zone, Xinqiao, Shajing, Bao’an District, Shenzhen, China Prepared by : SHENZHEN EMTEK CO., LTD. Address : Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China Tel: (0755) 26954280 Fax: (0755) 26954282 FCC ID: YWCER701 SHENZHEN EMTEK CO., LTD. Report No.: ES110808023F Page 2 of 31 TABLE OF CONTENT Test Report Description Page 1. SUMMARY OF TEST RESULT ..................................................................................................... 4 2. GENERAL INFORMATION........................................................................................................... 5 2.1. DESCRIPTION OF DEVICE (EUT) ................................................................................................... 5 2.2. D ESCRIPTION OF SUPPORT DEVICE................................................................................................ 5 2.3. DESCRIPTION OF TEST FACILITY................................................................................................... 6 2.4. M EASUREMENT UNCERTAINTY..................................................................................................... 6 3. MEASURING DEVICE AND TEST EQUIPMENT ..................................................................... 7 3.1. F OR POWER LINE CONDUCTED EMISSION MEASUREMENT........................................................... 7 3.2. F OR RADIATED EMISSION MEASUREMENT(3M CHAMBER) ........................................................... 7 4. POWER LINE CONDUCTED EMISSION MEASUREMENT .................................................. 8 4.1. B LOCK DIAGRAM OF TEST SETUP................................................................................................. 8 4.2. M EASURING STANDARD................................................................................................................ 8 4.3. POWER LINE CONDUCTED EMISSION LIMITS (CLASS B) ............................................................... 8 4.4. EUT CONFIGURATION ON MEASUREMENT.................................................................................... 8 4.5. O PERATING CONDITION OF EUT ................................................................................................... 8 4.6. TEST PROCEDURE.......................................................................................................................... 9 4.7. MEASURING RESULTS................................................................................................................... 9 5. RADIATED EMISSION MEASUREMENT................................................................................ 10 5.1. BLOCK DIAGRAM OF TEST SETUP............................................................................................... 10 5.2. M EASURING STANDARD.............................................................................................................. 10 5.3. RADIATED EMISSION LIMITS (CLASS B)...................................................................................... 11 5.4. EUT CONFIGURATION ON MEASUREMENT.................................................................................. 11 5.5. O PERATING CONDITION OF EUT ................................................................................................. 11 5.6. T EST PROCEDURE........................................................................................................................ 11 5.7. M EASURING RESULTS................................................................................................................. 12 6. PHOTOGRAPHS............................................................................................................................ 13 6.1. P HOTOS OF CONDUCTED EMISSION MEASUREMENT................................................................... 13 6.2. PHOTOS OF RADIATION EMISSION MEASUREMENT...................................................................... 14 APPENDIX I (2 Pages) APPENDIX II (6 Pages) APPENDIX III (Photos of EUT) (4 Pages) FCC ID: YWCER701 SHENZHEN EMTEK CO., LTD. Report No.: ES110808023F Page 3 of 31 TEST REPORT DESCRIPTION Applicant : ITONE DIGITAL (SHENZHEN) CO., LTD. Manufacturer : ITONE DIGITAL (SHENZHEN) CO., LTD. EUT : EBOOK Model No. : BK7019, ER701 FCC ID : YWCER701 Power Supply : DC 3.7V from Li-ion Battery and DC 5V from USB Port Measurement Procedure Used: FCC Rules and Regulations Part 15 Subpart B Class B October 2009 & FCC / ANSI C63.4-2009 The device described above is tested by SHENZHEN EMTEK CO., LTD. to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The measurement results are contained in this test report and SHENZHEN EMTEK CO., LTD. is assumed full of responsibility for the accuracy and completeness of these measurements. Also, this report shows that the EUT (Equipment Under Test) is technically compliant with the FCC requirements. This report applies to above tested sample only and shall not be reproduced in part without written approval of SHENZHEN EMTEK CO., LTD. Date of Test : July 05, 2011 to July 08, 2011 Prepared by : (Engineer) Reviewer : (Quality Manager) Approved & Authorized Signer : (Manager) FCC ID: YWCER701 SHENZHEN EMTEK CO., LTD. Report No.: ES110808023F Page 4 of 31 1. SUMMARY OF TEST RESULT EMISSION Description of Test Item Standard & Limits Results Conducted Disturbance at Mains Terminals FCC Part 15, Subpart B, Class B ANSI C63.4: 2009 Pass Radiated Disturbance FCC Part 15, Subpart B, Class B ANSI C63.4: 2009 Pass Note: N/A is an abbreviatio…

Text truncated - open the document above for the full version.

Test Setup Photos

RADIATED EMISSION TEST CONDUCTED EMISSION TEST
