YYOTX1IN-US59Cell Phone Signal Booster

Consumer Signal Booster Warning Label: If the booster has this label (all consumer boosters sold after March 1, 2014, and some sold prior will have this labe从 ＿ BEFORE USE, you MUST REGISTER THIS DEVICE with your wineless provider and have your provider's consent Most wi氓essproviders consent to the use of signal boosters. Some e rovide「smay not consent to the use of面s devrce on their networ , If you are unsure, contact your provider. You MUST operate而s device with approved antennas and cables as specified浮the manufacturer. Antenna MUST be installed at least 20 cm (inches) from any person You MUST cease operating this device immediately tf requested by the FCC or a licensed wireless service provider WARNING. E911 location information may not be provided or may be inaccurate for calls served by using !hrs device. This device may be operated ONLY in a fixed location阮in-buildinguse No坛Vo,i,o,Wir�m. AT&T, $prim, "'T书obiloh,,,.,叩"""'"'比心stmthatoo,tai, tholabot, 沁沁donot ,.,. to got app心,,,,,,, 1.Verify that your provider has given permission (e.g., AT&T, Sprint, T-Mobile, Verizon) , or else get permission from your wireless provider to use it 2.Register your booster with your wireless provider before turning it on. Each wireless provider that gives permission for boosters to be used must provide a free registration system Note: V erizon Wireless, AT&T, Sprint, and T-Mobile have approved all boosters that contain the label, so you do not need to get approval again. You c an learn more about the FCC's new rules by following the link: https://www.fcc.gov/wireless/bureau-divisions/mobility-division/signal-boosters/consumer-signal-boosters 。 N otes： Booster transmitting in 1710-1755 MHz should be install/operate in one of two ways: (i) the antenna for the device must be installed to comply with the 10 meter above ground maximum antenna height limitation OR (ii) the antenna for the device has a 10 meter above ground maximum antenna height limitation when the device is used with a handset that covers the 1710-1755 MHz band and that owners could be subject to potential FCC enforcement action for noncompliance.

Phonetone Technology (Shenzhen) Co., Ltd. 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – EquipmentType Company name: Phonetone Technology (Shenzhen) Co., Ltd. Address: Room 404, Building 12, Qianlong Garden, Minzhi Street, Bao'an District, Shenzhen, 518031 China Product Name: Cell Phone Signal Booster FCC ID: YYOTX1IN-US59 Model(s): TX1IN-US59 2.911(d)(5)(i) EquipmentType We, [Phonetone Technology (Shenzhen) Co., Ltd.] (“the applicant”) certify that the equipment for which authorization is sought through certification is not: • Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules. • Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Guangwei Zhang Date: 2024-06-28 Title and Company name: General Manager / Phonetone Technology (Shenzhen) Co., Ltd. NOTE 1 “Covered List ”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Phonetone Technology (Shenzhen) Co., Ltd. 2.911 (d)(5)(ii) Applicant Attestation v1.3 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: Phonetone Technology (Shenzhen) Co., Ltd. Address: Room 404, Building 12, Qianlong Garden, Minzhi Street, Bao'an District, Shenzhen, 518031 China Product Name: Cell Phone Signal Booster FCC ID: YYOTX1IN-US59 Model(s): TX1IN-US59 2.911(d)(5)(ii) Applicant filing We, [Phonetone Technology (Shenzhen) Co., Ltd.] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 ,established pursuant to §1.50002 of this chapter,as an entity producing coveredcommunications equipment. Yours sincerely, Name: Guangwei Zhang Date: 2024-04-28 Title and Company name: General Manager / Phonetone Technology (Shenzhen) Co., Ltd. NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List ”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Phonetone Technology (Shenzhen) Co., Ltd. U.S. Agent Designation for Service of Process (Applicant and U.S. Agent are Separate Parties) TO: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 ATTENTION: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name: Baihetian Innovative Solutions FRN: 0033401605 Contact Name: Kenneth Young Street Address: 6837 Chase Rd City/Province/Zip: Dearborn, MI 48126 Telephone No: 313-395-3113 Email: [email protected] This letter is to confirm that we (“Baihetian Innovative Solutions) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. U.S. Agent Signature: Date: July 1, 2024 Signed by (Printed Name/Title): Kenneth Young/Manager The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: Phonetone Technology (Shenzhen) Co., Ltd. Grantee Code: YYO FRN: 0020320701 FCC ID: YYOTX1IN-US59 Contact Name: Guangwei Zhang Street Address: Room 404, Building 12, Qianlong Garden, Minzhi Street, Bao'an District City/Province/Zip: Shenzhen, 518031 China Telephone No: 86-013510329652 Email: [email protected] Applicant Signature: Date:2024-06-28 Signed by (Printed Name/Title): Guangwei Zhang /General Manager July 2024

Phonetone Technology (Shenzhen) Co., Ltd. Room 404, Building 12, Qianlong Garden, Minzhi Street, Bao'an District, Shenzhen, 518031 China Agent Authorization Company: Phonetone Technology (Shenzhen) Co., Ltd. Address: Room 404, Building 12, Qianlong Garden, Minzhi Street, Bao'an District, Shenzhen, 518031 China Product Name: Cell Phone Signal Booster Model Number(s): TX1IN-US59 Product Description: Cell Phone Signal Booster We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2024-6-28 Name: Guangwei Zhang Title: General Manager Company: Phonetone Technology (Shenzhen) Co., Ltd.

Phonetone Technology (Shenzhen) Co., Ltd. Jun 28, 2024 Attestation for Cell Phone Signal booster: FCC ID: YYOTX1IN-US59 Each Signal Booster certificated under FCC ID: YYOTX1IN-US59 is manufactured and individually tested to ensure FCC compliance: ( 1) Licensee consent for Fixed consumer booster has been obtained (consent be made available upon FCC/TCB request) (2) NPS and other compliance/safeguard features have been implemented (3) NPS and other compliance/safeguard features are defaulted to “ON” configuration (in operation) (4) NPS and other compliance/safeguard features cannot be field reconfigured, disabled or removed (5)This Consumer booster is not user programmable, does not need fine tuning or adjustment, does not require professional installation. (6) Future software upgrade will not cause non-compliance. Yours sincerely, Guangwei Zhang

Phonetone Technology (Shenzhen) Co., Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2024-06-28 Subject; Request for Long Term Confidentiality FCC ID: YYOTX1IN-US59 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Guangwei Zhang Title: General Manager

Phonetone Technology (Shenzhen) Co., Ltd. Jun 28, 2024 Subject: Tuning and Adjustment of Signal booster, FCC ID: YYOTX1IN-US59 There are no external tuning adjustments, the amplifier is f actory set not exceed maximum gains, power levels, and downlink dependent region (RSSI) set points as provided in t he test results. Y ours sincerely, Guangwei Zhang

Page 1 of 7 Appendix B: Photographs of EUT Product: Cell Phone Signal Booster Model: TX1IN-US59 External Photos Page 2 of 7 Page 3 of 7 Page 4 of 7 Page 5 of 7 Page 6 of 7 Page 7 of 7

LABEL AND LOCATION Model: TX1IN-US59 Model label Warning label Dimension: 45*25mm Dimension: 60*45mm Model label Warning label Dimension: 45*25mm Dimension: 60*45mm

Page 1 of 18 Appendix B: Photographs of EUT Product: Cell Phone Signal Booster Model: TX1IN-US59 Internal Photos Page 2 of 18 Page 3 of 18 Page 4 of 18 Page 5 of 18 Page 6 of 18 Page 7 of 18 Page 8 of 18 Page 9 of 18 Page 10 of 18 Page 11 of 18 Page 12 of 18 Page 13 of 18 Page 14 of 18 Page 15 of 18 Page 16 of 18 Page 17 of 18 Page 18 of 18

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID. ............................ : YYOTX1IN-US59 Test Report No. ............... : TCT240428E019 Date of issue ................... : Jun. 27, 2024 Testing laboratory .......... : SHENZHEN TONGCE TESTING LAB Testing location/ address: 2101 & 2201, Zhenchang Factory Renshan Industrial Zone, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, 518103, People's Republic of China Applicant's name ............ : Phonetone Technology (Shenzhen) Co., Ltd. Address ........................... : Room 404, Building 12, Qianlong Garden, Minzhi Street, Bao'an District, Shenzhen, 518031 China Manufacturer's name ... : Phonetone Technology (Shenzhen) Co., Ltd. Address ........................... : Room 404, Building 12, Qianlong Garden, Minzhi Street, Bao'an District, Shenzhen, 518031 China Standard(s) ..................... : FCC Part §1.1310 Product Name ................. : Cell Phone Signal Booster Trade Mark ...................... : Model/Type reference..... : TX1IN-US59 Rating(s).......................... : Adapter Information: MODEL: SK03T1-1200200U INPUT: AC 100-240V, 50/60Hz, 0.6A OUTPUT: DC 12V, 2A Date of receipt of test item ......................................... : Apr. 28, 2024 Date (s) of performance of test ................................... : Apr. 28, 2024 ~ Jun. 27, 2024 Tested by (+signature) ... : Aaron MO Check by (+signature) .... : Beryl ZHAO Approved by (+signature): Tomsin General disclaimer: This report shall not be reproduced except in full, without the written approval of SHENZHEN TONGCE TESTING LAB. This document may be altered or revised by SHENZHEN TONGCE TESTING LAB personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT240428E019 Page 2 of 7 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Table of Contents 1. General Product Information .................................................................. 3 1.1. EUT description ..................................................................................................... 3 1.2. Model(s) list ............................................................................................................ 3 2. General Information ................................................................................. 4 2.1. Test environment and mode ................................................................................. 4 2.2. Description of Support Units ................................................................................ 4 3. Facilities and Accreditations .................................................................. 5 3.1. Facilities ................................................................................................................. 5 3.2. Location ................................................................................................................. 5 4. Test Results and Measurement Data ..................................................... 6 4.1. Requirements ......................................................................................................... 6 4.2. MPE Calculation .................................................................................................... 6 4.3. Test Result ............................................................................................................. 7 Report No.: TCT240428E019 Page 3 of 7 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. General Product Information 1.1. EUT description Product Name ....................... : Cell Phone Signal Booster Model/Type reference........... : TX1IN-US59 Sample Number....................: TCT240428E018-0101 Operation Frequency ........... : PCS Uplink: 1850MHz - 1915MHz, Downlink: 1930MHz - 1995MHz AWS Uplink: 1710MHz - 1755MHz, Downlink: 2110MHz - 2155MHz Cellular Uplink: 824MHz - 849MHz, Downlink: 869MHz - 894MHz Lower700MHz Uplink: 698MHz - 716MHz, Downlink: 728MHz - 746MHz Upper700MHz Uplink: 776MHz - 787MHz, Downlink: 746MHz - 757MHz Signal Booster Type ............. : Mobile Consumer Signal Booster Emission Designator ........... : F9W, G7D, G7W, GXW, W7D FCC Classification ............... : B2W/Wideband Consumer Booster(CMRS) Rating(s)................................ : Adapter Information: MODEL: SK03T1-1200200U INPUT: AC 100-240V, 50/60Hz, 0.6A OUTPUT: DC 12V, 2A Note: The antenna gain listed in this report is provided by applicant, and the test laboratory is not responsible for this parameter. 1.2. Model(s) list None. Report No.: TCT240428E019 Page 4 of 7 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. General Information 2.1. Test environment and mode Item Normal condition Temperature +25ºC Voltage DC 12V Humidity 56% Atmospheric Pressure: 1008 mbar Test Mode: Engineering mode: Keep the EUT in continuous transmitting by select channel 2.2. Description of Support Units The EUT has been tested as an independent unit together with other necessary accessories or support units. The following support units or accessories were used to form a representative test configuration during the tests. Equipment Model No. Serial No. FCC ID Trade Name / / / / / Report No.: TCT240428E019 Page 5 of 7 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 3. Facilities and Accreditations 3.1. Facilities The test facility is recognized, certified, or accredited by the following organizations: ● FCC - Registration No.: 645098 SHENZHEN TONGCE TESTING LAB Designation Number: CN1205 The testing lab has been registered and fully described in a report with the (FCC) Federal Communications Commission. The acceptance letter from the FCC is maintained in our files. ● IC - Registration No.: 10668A-1 SHENZHEN TONGCE TESTING LAB CAB identifier: C…
