Z26-CTIntelligent Robotic Trolley Handset

DECLARATION DE CONFORMITE D'INDUSTRIE CANADA Ce périphérique a été testé et reconnu conforme aux limites spécifiées dans RSS-210. Son utilisation est soumise aux deux conditions suivantes : (1) il ne doit pas provoquer d'interférences gênantes et (2) il doit tolérer les interférences re.ues, notamment cellessusceptibles d'en perturber le fonctionnement.

Authorization Letter We, (the approval holder) Company name FTR System (Shanghai), Inc. Addresss #500, Suite 108, Bi-Bo Rd, Hi-Tech Park, Pudong City Shanghai Country China declare that the following representative (agent): Name (person) Bovey.yang Company name NTEK Testing Technology Co., Ltd. Addresss 1/F, Building E, Fenda Science Park Sanwei Community, Xixiang Street, Baoan District City Shenzhen Country China to act on our behalf on all matters concerning the application and documents submitted to PHOENIX TEST-LAB for product certification below Product Description Intelligent Robotic Trolley Type or Model(s) CT-2000;CT2000;CT2000-AA;CT2000-AB;CT2000-AC;CT2000-BA;CT2000-BB; CT2000-BC;CT2000-CA;CT2000-LJ;CT2000-MJ; Tradename or Brand(s) N/A We also authorize BZT – TCP Certification GmbH, Ms.Wanida Patthanavoj (address: Hermann - Loens - Weg 6, 15859 Storkow b. Berlin Germany) to process the application. Attestation: City and Country: Date: Name: (this must be a person) Function:Signature: (or official company stamp) Shanghai 2011/12/10 Jinlong Ye PM

FCC Confidentiality Request To the FCC and FCC TCB handling this application for certification Pursuant to 47 CFR Section 0.459(a) & (b), we, (the applicant / grantee) Company name FTR System (Shanghai), Inc. Addresss #500, Suite 108, Bi-Bo Rd, Hi-Tech Park, Pudong City Shanghai Country China request non-disclosure and confidential treatment for our certification under: Grantee Code Product Number FCC ID: Z26 -CT of the following materials submitted within this certification application: (please cross what is applicable, or add other documents) x Operational Description x Block Diagrams x Schematics Diagrams Bill of Materials Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. We understand that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Attestation: City and Country: Date: Name: (this must be a person) Function:Signature: (or official company stamp) Shanghai 2011/12/10 Jinlong Ye PM

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8 Photo 9 (battery) Photo 10

Photo 11 Photo 12 Photo 13 Photo 14 Photo 15 Photo 16 Photo 17 Photo 18 Photo 19 Photo 20 Photo 21 Photo 22 Photo 23 Photo 24

Page 1 of 39 Report No.: NTEK-2011NT1207763F ` FCC RADIO TEST REPORT Report Reference No. ............... : NTEK-2011NT1207763F Compiled by (+ signature) ........... Tom Zhang Approved by (+ signature) ........... Bovey Yang Applicant’s name ........................... : FTR System (Shanghai), Inc. Address ....................................... : #500, Suite 108, Bi-Bo Rd, Hi-Tech Park, Pudong, Shanghai, 201203 China Manufacture's Name ...................... : FTR System (Shanghai), Inc. Address ....................................... : #500, Suite 108, Bi-Bo Rd, Hi-Tech Park, Pudong, Shanghai, 201203 China Test specification: Standard ..................................... : FCC Part15.249 Test procedure ............................... : ANSI C63.4-2003 Test item description Product name ........................ : Intelligent Robotic Trolley FCC ID Z26-CT Trademark ............................ : N/A Model and/or type reference : CT-2000;CT2000;CT2000-AA;CT2000-AB; CT2000-AC;CT2000-BA;CT2000-BB; CT2000-BC;CT2000-CA;CT2000-LJ;CT2000-MJ Rating(s) ................................ : DC 24V Testing Laboratory information: Testing Laboratory Name ..... : NTEK Testing Technology Co., Ltd Address ................................ : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao ＇an District, Shenzhen P.R. China. This device described above has been tested by NTEK Testing Technology Co., Ltd, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK Testing Technology Co., Ltd, this document may be altered or revised by NTEK Testing Technology Co., Ltd, personal only, and shall be noted in the revision of the documen Testing .................................................... : Date of receipt of test item ...................... : 08 Dec. 2011 Date (s) of performance of tests ............. : 08 Dec. 2011 ~13 Dec. 2011 Date of Issue ........................................... : 13 Dec. 2011 Test Result ............................................... : Pass Page 2 of 39 Report No.: NTEK-2011NT1207763F ` Table of Contents Page 1 . SUMMARY OF TEST RESULTS 3 1.1 TEST FACILITY 4 1.2 MEASUREMENT UNCERTAINTY 4 2 . GENERAL INFORMATION 5 2.1 GENERAL DESCRIPTION OF EUT 5 2.2 DESCRIPTION OF TEST MODES 7 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 8 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 9 3 . TEST RESULT 11 3.1 ANTENNA REQUIREMENT 11 3.1.1 STANDARD REQUIREMENT 11 3.1.2 EUT ANTENNA 11 3.2 CONDUCTED EMISSION MEASUREMENT 12 3.2.1 POWER LINE CONDUCTED EMISSION LIMITS 12 3.2.2 TEST PROCEDURE 13 3.2.3 DEVIATION FROM TEST STANDARD 13 3.2.4 TEST SETUP 13 3.2.5 TEST RESULT 14 3.3 RADIATED EMISSION MEASUREMENT 16 3.3.1 RADIATED EMISSION LIMITS 16 3.3.2 TEST PROCEDURE 17 3.3.3 DEVIATION FROM TEST STANDARD 17 3.3.4 TEST SETUP 18 3.3.5 TEST RESULTS (BLOW 30MHZ) 20 3.3.6 TEST RESULTS (BETWEEN 30 – 1000 MHZ) 21 3.3.7 TEST RESULTS (ABOVE 1000 MHZ) 25 4 . BANDWIDTH TEST 35 4.1 TEST PROCEDURE 35 4.2 DEVIATION FROM STANDARD 35 4.3 TEST SETUP 35 4.4 TEST RESULTS 36 5 . EUT TEST PHOTO 38 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 3 of 39 Report No.: NTEK-2011NT1207763F ` 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15, Subpart C (15.249) Standard Section Test Item Judgment Remark 15.207 Conducted Emission Pass 15.203 Antenna Requirement Pass 15.249 Radiated Spurious Emission Pass 15.249 Occupied Bandwidth Pass Page 4 of 39 Report No.: NTEK-2011NT1207763F ` 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC FRN Registration Nombre:238937; IC Registration Nombre:9270A-1 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 Radiated Emission Test ±3.17dB 3 RF power,conducted ±0.16dB 4 Spurious emissions,conducted ±0.21dB 5 All emissions,radiated(<1G) ±4.68dB 6 All emissions,radiated(>1G) ±4.89dB Page 5 of 39 Report No.: NTEK-2011NT1207763F ` 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Intelligent Robotic Trolley Trade Name N/A Model Name CT-2000;CT2000;CT2000-AA;CT2000-AB; CT2000-AC;CT2000-BA;CT2000-BB; CT2000-BC;CT2000-CA;CT2000-LJ; CT2000-MJ OEM Brand/Model Name N/A Model Difference All the model are the same circuit and RF module, except the appearance and colour . Product Description The EUT is a Intelligent Robotic Trolley Operation Frequency: 2403-2480 MHz Modulation Type: QPSK Antenna Designation: Printed ANT Antenna Gain(Peak) 1.0 dBi Out Power 99.43dBuV/m@3m Channel List Note 3 Power Source DC Voltage supplied from battery Power Rating DC 24V by battery, Battery charging by adapter, Adapter: AC Power Input: 100-240V~, 50/60Hz, 1.4A Output: 29.4V 1.8A Connecting I/O Port(s) Please refer to the User's Manual Products Covered N/A EUT Modification(s) N/A Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. Page 6 of 39 Report No.: NTEK-2011NT1207763F ` 2. 3. Table for Filed Antenna Ant . Brand Model Name Antenna Type Connector Gain (dBi) NOTE 1 N/A N/A Printed AntennaNA 1.0 Antenna Channel List Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 27 2429 54 2456 01 2403 28 2430 55 2457 02 2404 29 2431 56 2458 03 2405 30 2432 57 2459 04 2406 31 2433 58 2460 05 2407 32 2434 59 2461 06 2408 33 2435 60 2462 07 2409 34 2436 61 2463 08 2410 35 2437 62 2464 09 2411 36 2438 63 2465 10 2412 37 2439 64 2466 11 2413 38 2440 65 2467 12 2414 39 2441 66 2468 13 2415 40 2…

Text truncated - open the document above for the full version.

Page 38 of 39 Report No.: NTEK-2011NT1207763F ` 5. EUT TEST PHOTO Radiated Measurement Photos Page 39 of 39 Report No.: NTEK-2011NT1207763F `
