Z26-CT2000Intelligent Robotic Trolley Handset

HANDSET USER MANUAL CT-2000-HS FTR SYSTEM (SHANGHAI),INC 1 CT-2000-HS handset user manual 1.Description CT-2000-HS is made only for intelligent golf cart CaddyTrekCT-2000. 2. Working Parameter Voltage：3.7v current：30mA dimension：110*45*22mm Battery：lithium battery 3. Button Description 4.function instruction ①Power Button：Long Press power on/down. ②Mode Lamp： 4 light shining：out of communication SB shining: standby mode RC shining: remote control mode FL shining: follow mode FL&OA shining: follow with OA mode 2 ③Stop Button: When press “follow”and show“RC shining”， cart will stop. 当 standby mode or out of communication 时，long time press this button,will shown chargelamp ④direction button：long time press any direction button enter remote control mode，continue press direction button，cart will move according to direction. ⑤Follow Button:press ‘Follow Button’enter follow mode； again‘Follow Button’quit follow mode ； long time press “follow “3s，enter follow with mode。 Matters and Attention： 1、 When the handset beep sound every 30 seconds, please charge the battery or replace the battery 2、 Please prevent water intrusion 3、 For a long time when not in use, remove the battery FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter. 3 INDUSTRY CANADA CONFORMITY This device has been tested and found to comply with the limits specified in RSS-210. Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This device must accept any interference, including interference thatmay cause undesired operation of the device. DECLARATION DE CONFORMITE D’INDUSTRIE CANADA Ce périphérique a été testé et reconnu conforme aux limites spécifiées dans RSS-210. Son utilisation est soumise aux deux conditions suivantes : (1) il ne doit pas provoquer d’interférences gênantes et (2) il doit tolérer les interférences re.ues, notamment cellessusceptibles d’en perturber le fonctionnement.

FCC Confidentiality Request To the FCC and FCC TCB handling this application for certification Pursuant to 47 CFR Section 0.459(a) & (b), we, (the applicant / grantee) Company name FTR System (Shanghai), Inc. Addresss #500, Suite 108, Bi-Bo Rd, Hi-Tech Park, Pudong City Shanghai Country China request non-disclosure and confidential treatment for our certification under: Grantee Code Product Number FCC ID: Z26 -CT2000 of the following materials submitted within this certification application: (please cross what is applicable, or add other documents) x Operational Description x Block Diagrams x Schematics Diagrams Bill of Materials Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. We understand that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Attestation: City and Country: Date: Name: (this must be a person) Function:Signature: (or official company stamp) Shanghai 2011/12/10 Jinlong Ye PM

FCC label: 30*20mm

Page 1 of 39 Report No.: NTEK-2011NT1207764E ` FCC RADIO TEST REPORT Report Reference No. ............... : NTEK-2011NT1207764E Compiled by (+ signature) ........... Tom Zhang Approved by (+ signature) ........... Bovey Yang Applicant’s name ........................... : FTR System (Shanghai), Inc. Address ....................................... : #500, Suite 108, Bi-Bo Rd, Hi-Tech Park, Pudong, Shanghai, 201203 China Manufacture's Name ...................... : FTR System (Shanghai), Inc. Address ....................................... : #500, Suite 108, Bi-Bo Rd, Hi-Tech Park, Pudong, Shanghai, 201203 China Test specification: Standard ..................................... : FCC Part15.249, RSS-210 Issue 8 Test procedure ............................... : ANSI C63.4-2003, RSS-Gen Issue 3 Test item description Product name ........................ : Intelligent Robotic Trolley Handset FCC ID Z26-CT2000 IC ID 10073A-CT2000 Trademark ............................ : N/A Model and/or type reference : CT-2000-HS,CT2000-HS, CT2000-AA-HS,CT2000-AB-HS, CT2000-AC-HS, CT2000-BA-HS,CT2000-BB-HS, CT2000-BC-HS, CT2000-CA-HS,CT2000-LJ-HS, CT2000-MJ-HS Rating(s) ................................ : DC 3.7V Testing Laboratory information: Testing Laboratory Name ..... : NTEK Testing Technology Co., Ltd Address ................................ : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao ＇an District, Shenzhen P.R. China. This device described above has been tested by NTEK Testing Technology Co., Ltd, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK Testing Technology Co., Ltd, this document may be altered or revised by NTEK Testing Technology Co., Ltd, personal only, and shall be noted in the revision of the documen Testing .................................................... : Date of receipt of test item ...................... : 08 Dec. 2011 Date (s) of performance of tests ............. : 08 Dec. 2011 ~13 Dec. 2011 Date of Issue ........................................... : 13 Dec. 2011 Test Result ............................................... : Pass Page 2 of 39 Report No.: NTEK-2011NT1207764E ` Table of Contents Page 1 . SUMMARY OF TEST RESULTS 3 1.1 TEST FACILITY 4 1.2 MEASUREMENT UNCERTAINTY 4 2 . GENERAL INFORMATION 5 2.1 GENERAL DESCRIPTION OF EUT 5 2.2 DESCRIPTION OF TEST MODES 7 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 8 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 9 3 . TEST RESULT 11 3.1 ANTENNA REQUIREMENT 11 3.1.1 STANDARD REQUIREMENT 11 3.1.2 EUT ANTENNA 11 3.2 CONDUCTED EMISSION MEASUREMENT 12 3.2.1 POWER LINE CONDUCTED EMISSION LIMITS 12 3.2.2 TEST PROCEDURE 13 3.2.3 DEVIATION FROM TEST STANDARD 13 3.2.4 TEST SETUP 13 3.2.5 TEST RESULT 14 3.3 RADIATED EMISSION MEASUREMENT 16 3.3.1 RADIATED EMISSION LIMITS 16 3.3.2 TEST PROCEDURE 17 3.3.3 DEVIATION FROM TEST STANDARD 17 3.3.4 TEST SETUP 18 3.3.5 TEST RESULTS (BLOW 30MHZ) 20 3.3.6 TEST RESULTS (BETWEEN 30 – 1000 MHZ) 21 3.3.7 TEST RESULTS (ABOVE 1000 MHZ) 25 4 . BANDWIDTH TEST 35 4.1 TEST PROCEDURE 35 4.2 DEVIATION FROM STANDARD 35 4.3 TEST SETUP 35 4.4 TEST RESULTS 36 5 . EUT TEST PHOTO 38 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 3 of 39 Report No.: NTEK-2011NT1207764E ` 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15, Subpart C (15.249) & RSS-Gen Issue 3 & RSS-210 Issue 8 Standard Section Test Item Judgment Remark 15.207 Conducted Emission Pass 15.203 Antenna Requirement Pass 15.249 Radiated Spurious Emission Pass 15.249 Occupied Bandwidth Pass Page 4 of 39 Report No.: NTEK-2011NT1207764E ` 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC FRN Registration Nombre:238937; IC Registration Nombre:9270A-1 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 Radiated Emission Test ±3.17dB 3 RF power,conducted ±0.16dB 4 Spurious emissions,conducted ±0.21dB 5 All emissions,radiated(<1G) ±4.68dB 6 All emissions,radiated(>1G) ±4.89dB Page 5 of 39 Report No.: NTEK-2011NT1207764E ` 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Intelligent Robotic Trolley Handset Trade Name N/A Model Name CT-2000-HS,CT2000-HS, CT2000-AA-HS, CT2000-AB-HS,CT2000-AC-HS, CT2000-BA-HS, CT2000-BB-HS, CT2000-BC-HS, CT2000-CA-HS, CT2000-LJ-HS, CT2000-MJ-HS OEM Brand/Model Name N/A Model Difference All the model are the same circuit and RF module, except the appearance and colour . Product Description The EUT is a Intelligent Robotic Trolley Handset Operation Frequency: 2403-2480 MHz Modulation Type: QPSK Antenna Designation: Printed ANT Antenna Gain(Peak) 1.0 dBi Out Power 98.51dBuV/m@3m Channel List Note 3 Power Source DC Voltage supplied from battery Power Rating DC 3.7V by battery DC5V by adapter(charge) Connecting I/O Port(s) USB port only used to charge, Please refer to the User's Manual Products Covered N/A EUT Modification(s) N/A Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. Page 6 of 39 Report No.: NTEK-2011NT1207764E ` 2. 3. Table for Filed Antenna Ant . Brand Model Name Antenna Type Connector Gain (dBi) NOTE 1 N/A N/A Printed AntennaNA 1.0 Antenna Channel List Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 27 2429 54 2456 01 2403 28 2430 55 2457 02 2404 29 2431 56 2458 03 2405 30 2432 57 2459 04 2406 31 2433 58 2460 05 2407 32 2434 59 2461 06 2408 33 2435 60 2462 07 240…

Text truncated - open the document above for the full version.

Page 27 of 28 Report No.: NTEK-2011NT0919188E ` 5. EUT TEST PHOTO Radiated Measurement Photos Page 28 of 28 Report No.: NTEK-2011NT0919188E `
