Z64TRF7960ATBThe TRF7960ATB and TRF7970ATB modules are development platforms for integrated analog front end and data-framing device operating as 13.56-MHz RFID Near Field Communication systems.

T E X A S I N S T R U M E N T S Originator: Joshua Wyatt R F I D SYSTEMS S P E C I F I C A T I O N Revision: 0 Page 1 of 25 xx-xx-xx-xxx TRF79x0ATB NFC/HF RFID Reader Module Users Guide/Application Note PRINTED COPIES OF THIS SPECIFICATION ARE NOT CONTROLLED DOCUMENTS. VERIFY THEIR CORRECT REVISION BEFORE USE. TI PROPRIETARY T E X A S I N S T R U M E N T S INFORMATION - Revision: INTERNAL DATA R F I D SYSTEMS 0 S P E C I F I C A T I O N Page 2 of 25 xx-xx-xx-xxx Printed copies are not controlled documents - verify the correct revision before use. TABLE OF CONTENTS PAGE 1. Purpose ................................................................................................................. 3 2. Scope ..................................................................................................................... 3 3. References ............................................................................................................ 3 4. TRF79x0ATB Module Description ................................................................... 4 5. TRF79x0ATB Connections/Technical Details .................................................. 6 6. TRF79x0ATB Module Schematic ...................................................................... 7 7. MSP-EXP430F5438 Experimenters Board ...................................................... 8 8. DK-LM3S9B96-EM2-TRF7960R ARM Cortex M-3 Development Board . 10 9. Quick Start ........................................................................................................ 11 10. Base Application Firmware ............................................................................. 11 11. Platform Specific Details .................................................................................. 11 12. Mechanical/Physical Information .................................................................... 12 13. Antenna Tuning Details .................................................................................... 13 14. TRF79x0ATB Module Read Ranges ............................................................... 17 15. Revision History ................................................................................................ 18 TI PROPRIETARY T E X A S I N S T R U M E N T S INFORMATION - Revision: INTERNAL DATA R F I D SYSTEMS 0 S P E C I F I C A T I O N Page 3 of 25 xx-xx-xx-xxx Printed copies are not controlled documents - verify the correct revision before use. 1. Purpose This document is intended to provide direction for TRF7960A/-70A users who desire to implement a 13.56MHz NFC/RFID reader solution using the TRF79x0A IC connected to a Texas Instruments embedded microcontroller or microprocessor development platform. Examples of such development platforms are: the MSP-EXP430F5438 board, MSP- EXP430F5529 board, the ARM Cortex-M3/M4 based board, or any other TI embedded microcontroller platform with the EM socket headers populated. 2. Scope This document will cover TRF79x0ATB module as it relates to using the module for evaluation and development purposes in conjunction with Texas Instruments Embedded Development platforms. This manual does not cover the in-depth details of the TRF79x0A NFC/RFID IC families, as those details are well documented in the data sheets for those parts, along with app notes that can be found on the product pages (see hyperlinks in References section below). 3. References  TRF7960A Product Page: http://www.ti.com/product/trf7960A  TRF7970A Product Page: http://www.ti.com/product/trf7970A  TRF7960A Full Data Sheet: http://www.ti.com/lit/gpn/trf7960a  TRF7970A Full Data Sheet: http://www.ti.com/lit/gpn/trf7970a  TRF7960ATB Schematic, BOM and Design files: http://www.ti.com/litv/zip/sloc221  MSP-EXP430F5438 Users Guide: http://www.ti.com/lit/pdf/slau263  LM3S9B96 DK Users Guide: http://www.ti.com/litv/pdf/spmu036d  TPS61222DCKT Product Page: http://www.ti.com/product/tps61222  TI ISO15693/ISO18000-3 Inlays/Tags Parametric Search: o http://focus.ti.com/paramsearch/docs/parametricsearch.tsp?family=rfid&sectionId=4 75&tabId=2102&familyId=1352  Samtec Header and Mate Information: o https://www.samtec.com/ProductInformation/TechnicalSpecifications/Overview.aspx?series=SFM o https://www.samtec.com/ProductInformation/TechnicalSpecifications/Overview.aspx?series=TFM  Smith Chart Simulation Tool (licensed copy): http://www.fritz.dellsperger.net/ TI PROPRIETARY T E X A S I N S T R U M E N T S INFORMATION - Revision: INTERNAL DATA R F I D SYSTEMS 0 S P E C I F I C A T I O N Page 4 of 25 xx-xx-xx-xxx Printed copies are not controlled documents - verify the correct revision before use. 4. TRF79x0ATB Module(s) Description The TRF79x0ATB Evaluation Modules are intended to allow the software application developer to get familiar with the functionalities of either of the TRF79x0A Multi- Standard Fully Integrated 13.56 MHz NFC/RFID reader ICs with the freedom to develop on their Texas Instruments Embedded microcontroller development platform of choice. The TRF79x0ATB module is also intended to allow customer driven antenna tuning with onboard coil and customer driven antenna form factor design. The module is hard wired for SPI communications, supports Slave Select and TRF79x0A Direct Mode 2 (default), Direct Mode 1 and Direct Mode 0 operations. The user also has access to and full control over the TRF79x0A EN2 and EN lines, allowing for design and development of ultra low power NFC/HF RFID systems. The module has an onboard boost converter (TPS61222DCKT) which boosts +3.3VDC in to +5VDC out to TRF79x0A IC for +23dBm (full transmitter power out) operations. An impedance matching circuit from 4Ω to 50Ω is populated on the module and this is connected to a tuned 50Ω antenna circuit which consists of onboard four turn coil with series and parallel passive elements (capacitors and a resistor). Test points are available on the board for checking firmware operations with oscilloscope or logic analyzer, impedance matching and …

Text truncated - open the document above for the full version.

TRF7960/-60A Transceiver IC Inductive Loop 13.56MHz SPI 13.56MHz crystal (fc) Bi-Directional Communication to MSP430F5xx TX Impedance Matching/RX filter stage TX Out RX_IN1RX_IN2 TRF7960/-60A TB Mo dule Block Diagram

Texas InstrumentsAEC-RFIDTRF7960TB Rev BAugust 10, 2010 DNI = Do not install. Item Qty Value PCB Footprint Part Reference Manufacturer Manufacturer Part Number Note 1 1 0.950uH RFID_ANT_COIL_1p4x1p0 ANT1 No part. 2 5 2.2uF 0603 C1 C3 C5 C7 C9 Kemet C0603C225K8PACTU 3 5 0.01uF 0603 C2 C4 C6 C8 C10 Panasonic - ECG ECJ-1VB1E103K 4 3 27pF 0603 C11 C12 C22 Panasonic - ECG ECJ-1VC1H270J 5 2 1500pF 0603 C13 C14 Panasonic - ECG ECJ-1VB1H152K 6 2 1200pF 0603 C15 C16 Panasonic - ECG ECJ-1VB1H122K 7 2 680pF 0603 C17 C20 Panasonic - ECG ECJ-1VC1H681J 8 1 10pF 0603 C18 Panasonic - ECG ECJ-1VC1H100D 9 1 220pF 0603 C19 Panasonic - ECG ECJ-1VC1H221J 10 1 100pF 0603 C21 Panasonic -ECG ECJ-1VC1H101J 11 1 68pF 0603 C23 Panasonic - ECG GRM1885C2A680JA01D 12 1 82pF 0603 C24 Panasonic -ECG GRM1885C2A820JA01D 13 2 10uF 0603 C25 C26 Taiyo Yuden JMK107BJ106MA-T 14 1 1pF 0603 C27 Panasonic - ECG ECJ-1VC1H270D DNI 15 1 2pF 0603 C28 Panasonic -ECG ECJ-1VC1H100D DNI 16 1 COAXIAL CON_COAXIAL_UFL-R-SMT J1 Hirose U.FL-R-SMT-1 17 1 150nH IND_1008PS L1 Coilcraft 1008CS-151XJLB 18 1 330nH IND_1008PS L2 Coilcraft 1008CS-331XJLB 19 1 4.7uH IND_SM_EPL3015 L4 Coilcraft, Inc. EPL3015-472MLB 20 1 13.560MHz OSC_4_SM_132x104x47 OSC1 ITTI Company 1300225-13.560MHz 21 2 SFM-110-02-L-D-A CON_SMVT_2x10_50_F_SFM_FLIP_CC P1 P2 SAMTEC SFM-110-02-L-D-A 22 4 10k 0603 R1 R2 R3 R4 Panasonic - ERJ ERJ-3GEYJ103V 23 1 0 0603 R5 Panasonic - ERJ ERJ-3GEYJ0R00V 24 1 680 0603 R6 Rohm ESR03EZPJ681 25 6 TESTVIA_018 TP_VIA_018RND008 TP1 TP2 TP3 TP4 TP9 TP11 No part. 26 2 Black TP_THVT_060_RND TP5 TP12 Components Corporation TP-105-01-00 27 3 TESTPAD_018 TP_VIA_018RND TP6 TP7 TP8 No part - SMD pad only. 28 1 Gray TP_THVT_060_RND TP10 Components Corporation TP-105-01-08 29 1 Blue TP_THVT_060_RND TP13 Components Corporation TP-105-01-06 30 1 Green TP_THVT_060_RND TP14 Components Corporation TP-105-01-05 31 1 Brown TP_THVT_060_RND TP15 Components Corporation TP-105-01-01 32 1 TRF7960RHB PQFN_32_203x203x40_p5mm U1 Texas Instruments TRF7960RHB 33 1 TPS61222DCKT SOP_6_85x55_26 U2 Texas Instruments TPS61222DCKT Customer:Group:Board:Date: 6/17/2013 Page 1 of 1 TRF7960TB-B_BOM.XLS

Nemko Canada Inc RF Exposure Compliance (Annex C of RSS-102) Nemko Canada Inc, 303 River Road, Ottawa, Ontario, Canada, K1V 1H2 Tel: +1 (613) 737 9680, Fax: +1 (613) 737 9691 Email : [email protected] RSS 102 Annex C March 2010 Annex C – Declaration of RF Exposure Compliance for Exemption from Routine Evaluation Limits ATTESTATION: I attest that the radiocommunication apparatus meets the exemption from the routine evaluation limits in Section 2.5 of this standard; that the Technical Brief was prepared and the information contained therein is correct; that the device evaluation was performed or supervised by me; that applicable measurement methods and evaluation methodologies have been followed; and that the device meets the SAR and/or RF field strength limits of RSS-102. RSS 102, paragraph 2.5.2 RF exposure evaluation is required if the separation distance between the user and the device’s radiating element is greater than 20 cm, except when the device operates as follows: below 1.5 GHz and the maximum e.i.r.p. of the device is equal to or less than 2.5 W; at or above 1.5 GHz and the maximum e.i.r.p. of the device is equal to or less than 5 W. E.I.R.P. = V 2 R 2 /30 V = maximum measured field strength (V/m) R = 3 metres E.I.R.P. = (0.0016 2 x 9)/30 = 7.68 x 10 -7 watts E.I.R.P. = 0.768 uW Signature: Date: 3/17/2013 NAME: (Please print or type): David Light TITLE: (Please print or type): Senior Radio Test Engineer COMPANY: (Please print or type): Nemko USA, Inc.

55 44 33 22 11 D D C C B B A A Antenna Tuning Example Tuning components willchange for different inductance values Fixed +5VDC out Device Options:TRF7960RHBTRF7970RHB This Schematic will drive two seperate layouts.TRF7960ATB.brdTRF7970ATB.brdThe only difference is the bottom side silkscreen BG VDD VDD_X LD VIN +5VDC GND TitleSize Document Number Rev Date: Sheet of <Doc> C TRF79x0ATB B 1 1 Tuesday, February 28, 2012 RFIDTitleSize Document Number Rev Date: Sheet of <Doc> C TRF79x0ATB B 1 1 Tuesday, February 28, 2012 RFIDTitleSize Document Number Rev Date: Sheet of <Doc> C TRF79x0ATB B 1 1 Tuesday, February 28, 2012 RFID U2 TPS61222DCKT VIN 1 FB 2 VOUT 4 L 5 GND 3 EN 6 C8 0.01uF C2 0.01uF TP11 SYS_CLK C22 27pF C7 2.2uF C12 27pF C21 100pF C1 2.2uF TP3 BG C3 2.2uF C4 0.01uF U1A TRF796xRHBT TRF7960RHB I/O_2 19 I/O_1 18 MOD 14 VSS 10 I/O_0 17 SYS_CLK 27 VSS_D 29 RX_IN2 9 RX_IN1 8 VDD_X 32 VSS_A 15 OSC_OUT 30 VSS_PA 6 TX_OUT 5 OSC_IN 31 VDD_RF 3 DATA_CLK 26 IRQ 13 VSS_RX 7 ASK/OOK 12 EN2 25 VIN 2 VDD_A 1 EN 28 VDD_I/O 16 VDD_PA 4 MOSI 24 MISO 23 I/O_5 22 SLAVE SELECT 21 BAND_GAP 11 I/O_3 20 TH_PAD 33 TP5GND OSC1 13.560MHz GND 2 GND 4 XTAL2 3 XTAL1 1 C15 1200pF TP15 DATA_CLK C17 680pF J1COAXIALTST_PORT 1 2 3 C24 82pF TP12MISO R310k TP6 RX_IN1 C23 68pF TP8 50 Ohm C20680pF TP7 RX_IN2 C14 1500pF R6680 C18 10pF R410k C10 0.01uF C26 10uF C9 2.2uF TP4 ASK/OOK C13 1500pF C5 2.2uF C6 0.01uF R110k C27 1pF DNI C282pF DNI TP13MOSI L4 4.7uH TP14SS TP2 VDD_X R210k C2510uF L1 150nH P1 SFM-110-02-L-D-A RF1 2018161412108642 1917151311 97531 ANT1 0.950uH IN 1 GND 2 R5 0 C11 27pF C161200pF TP1 +5VDC TP9 MOD C19220pF P2 SFM-110-02-L-D-A RF2 2018161412108642 1917151311 97531 L2 330nH TP10IRQ

Master: NemkoPT15209 Date: June 3, 1999 Nemko Test Report: 10211699RUS3 Line 37 Rev 1 Applicant: Texas Instruments, Inc. 12500 TI Blvd. Dallas, TX 75243 USA Equipment Under Test: TRF7960ATB (E.U.T.) FCC ID: Z64TRF7960ATB In Accordance With: FCC Part 15, Subpart C, Paragraph 15.225 Operation within the band 13.110-14.010 MHz Tested By: Nemko USA Inc. 802 N. Kealy Lewisville, TX 75057 TESTED BY: DATE: 17-Aug-2011 David Light, Senior Wireless Engineer Date APPROVED BY: DATE: 22-Feb-2013 Mike Cantwell, Reviewer Date Total Number of Pages: 17 Nemko USA, Inc. FCC PART 15.225 Operation within the band 13.110-14.010 MHz EQUIPMENT: TRF7960ATB Test Report No.: 10211699RUS3 Page 2 of 17 Table Of Contents SECTION 1. SUMMARY OF TEST RESULTS 3 SECTION 2. GENERAL EQUIPMENT SPECIFICATION 5 SECTION 3. POWERLINE CONDUCTED EMISSIONS 6 SECTION 4. FIELD STRENGTH 8 SECTION 5. RADIATED EMISSIONS 9 SECTION 6. FREQUENCY STABILITY 11 SECTION 7. TEST EQUIPMENT LIST 12 ANNEX A TEST DIAGRAMS 13 ANNEX B TEST DETAILS 15 Nemko USA, Inc. FCC PART 15.225 Operation within the band 13.110-14.010 MHz EQUIPMENT: TRF7960ATB Test Report No.: 10211699RUS3 Page 3 of 17 Section 1. Summary Of Test Results Manufacturer: Texas Instruments, Inc. Model No.: TRF7960ATB Serial No.: None General: All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 15, Subpart C, Paragraph 15.225 for operation in the band 13.110-14.010 MHz. All tests were conducted using measurement procedure ANSI C63.4-2003. New Submission Production Unit Class II Permissive Change Pre-Production Unit THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “ Summary of Test Data”. Nemko USA, Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety, for use by the company’s employees only. This report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. Nemko USA, Inc. is a NVLAP accredited laboratory. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko USA, Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. Nemko USA, Inc. FCC PART 15.225 Operation within the band 13.110-14.010 MHz EQUIPMENT: TRF7960ATB Test Report No.: 10211699RUS3 Page 4 of 17 Summary Of Test Data NAME OF TEST PARA. NO. RESULT Powerline Conducted Emissions 15.207 Complies Field Strength 15.225(a) Complies Radiated Emissions 15.225(d)/15.209 Complies Frequency Stability 15.225(e) Complies Footnotes: Engineering Judgment: This report was reviewed and found to still be in compliance with the stated rules. A letter of attestation from the manufacturer also states that the TRF7960ATB is electrically identical to the TRF7960TB, the unit originally tested; and the report has been re-issued with only a change in the model number. Michael Cantwell, PE, NCE Nemko USA, Inc. FCC PART 15.225 Operation within the band 13.110-14.010 MHz EQUIPMENT: TRF7960ATB Test Report No.: 10211699RUS3 Page 5 of 17 Section 2. General Equipment Specification Frequency Range: 13.56 MHz Fixed Operating Frequency(ies) of Sample: 13.56 MHz Fixed Supply Power: 3.3 Vdc via USB Integral Antenna: Yes No Description of EUT 13.56 MHz RFID evaluation module. The unit was tested with both the Texas Instruments MSP-EXP430F5438 and the Stellaris DK-LM3S9B96 development boards. 99% Occupied Bandwidth = 425 kHz 14.01 MHz 13.11MHz Nemko USA, Inc. FCC PART 15.225 Operation within the band 13.110-14.010 MHz EQUIPMENT: TRF7960ATB Test Report No.: 10211699RUS3 Page 6 of 17 Section 3. Powerline Conducted Emissions NAME OF TEST: Powerline Conducted Emissions PARA. NO.: 15.207 TESTED BY: Brian BoyeaTom Tidwell / Debbie Jensen DATE: 17 August 2011 Test Results: Complies. The worst case emission was 54.4 dBμV at 656 kHz. This is 1.6 dB below the quasi-peak specification limit of 56.0 dBμV. Test Data: Refer to attached plots Equipment Used: 674-704-1258-1663-1988-1548 Measurement Uncertainty: +/- 1.7 dB Temperature: 22 C Relative Humidity: 35 % Nemko USA, Inc. FCC PART 15.225 Operation within the band 13.110-14.010 MHz EQUIPMENT: TRF7960ATB Test Report No.: 10211699RUS3 Page 7 of 17 Test Data – Powerline Conducted Emissions Frequency FCCB FCCB AVG AVG QP QP MHz QP LIMIT AVG LIMIT Meas MarginMeas Margin 0.328 60.9 50.9 42.6 -8.4 54.8 -6.1 0.343 60.5 50.5 40.7 -9.8 54.2 -6.3 0.356 60.1 50.1 39.2 -10.9 55.7 -4.5 0.369 59.7 49.7 40.8 -9.0 55.9 -3.9 0.376 59.5 49.5 42.5 -7.1 56.4 -3.1 0.379 59.5 49.5 42.8 -6.6 56.8 -2.6 0.383 59.3 49.3 43.1 -6.2 57.3 -2.1 0.395 59.0 49.0 42.2 -6.8 56.1 -2.9 0.656 56.0 46.0 41.3 -4.7 54.4 -1.6 0.685 56.0 46.0 39.5 -6.5 53.0 -3.0 0.83 56.0 46.0 36.0 -10.0 44.8 -11.2 0.91 56.0 46.0 38.5 -7.5 52.7 -3.3 0.94 56.0 46.0 38.8 -7.2 52.8 -3.2 1.21 56.0 46.0 39.4 -6.7 50.6 -5.4 1.92 56.0 46.0 38.8 -7.2 47.4 -8.6 2.1 56.0 46.0 38.3 -7.7 46.6 -9.4 2.1 56.0 46.0 38.2 -7.9 46.4 -9.6 2.1 56.0 46.0 38.2 -7.8 46.5 -9.5 2.11 56.0 46.0 38.1 -7.9 46.7 -9.3 2.12 56.0 46.0 35.9 -10.2 44.4 -11.6 2.13 56.0 46.0 38.1 -7.9 46.4 -9.6 2.15 56.0 46.0 37.2 -8.8 43.8 -12.3 2.16 56.0 46.0 37.9 -8.1 45.6 -10.4 2.29 56.0 46.0 37.9 -8.1 46.9 -9.1 2.31 56.0 46.0 37.3 -8.7 46.5 -9.5 Nemko USA, Inc. FCC PART 15.225 Operation within the band 13.110-14.010 MHz EQUIPMENT: TRF7960ATB Test Report No.: 10211699RUS3 Page 8 of 17 Section 4. Field Strength NAME OF TEST: Field Strength PARA. NO.: 15.225(a) TESTED BY: David LightTom Tidwell / Debbie Jensen DATE: 09 August 2011 Test Results: Complies. Measurement Data: Freq.Meter Antenna CableCorrectedSpec.Pol. Comments: Reading FactorLossReadingLi…
