ZK8-BFS23NMIPC

IP Camera User Manual For further help, please visit www.zmodo.com Preface: Dear customer, thank you for choosing to purchase and use our IP camera products. This series of IP monitoring product is the integrated IP network camera which is researched for network video surveillance monitoring. The series includes network bullet camera, network IR bullet camera, and network dome camera, etc. High performance, monolithic SOC chip is utilized as media processor which integrates video capture, compress and transmission. Standard H.264 main profile encoding algorithm ensures more clear and smooth video transmission. Embedded web server allows user to view real-time footage and remote control via IE browser. This series of IP camera is well suited for home and small business, as well as any situation which needs to apply remote network transmission and remote network control. It's easy to install and operate. Statement: The content in this manual may be different from the product version you are using. If you met any problem which can't be solved according to this manual, please contact our tech-support or product supplier. The content will be updated time to time. Our company reserves the right to update without notice. Intended Reader: This manual is mainly suitable for below kinds of engineer: System planner Onsite tech-support and maintenance personnel Administrator for system installation, configuration and maintenance Users for business operation on product functions Terms in this manual: IP Camera or IPC in this manual means network camera including network bullet camera, network dome camera, network PT camera, and network IR camera, etc. Click: Click with left button of mouse. Double Click: Double click with left button of mouse. Right click: Right click with right button of mouse. The[ ]symbol indicates the windows name, menu name, or data table; such as [Download Address]. 1 ® Contents 1 Product Introduction........................................................................................2 1.1 BRIEF INTRODUCTION..............................................................................2 1.2 MAIN FEATURES........................................................................................2 1.3 INSTALLATION STATEMENT......................................................................2 1.4 NETWORK IP CAMERA CONNECTION.....................................................3 2 Log in...............................................................................................................3 3 Preview............................................................................................................5 4 System Setting................................................................................................6 4.1 LOCAL CONFIGURATION...........................................................................6 4.2 REMOTE CONFIGURATION.......................................................................7 4.2.1 Video Setting.............................................................................................7 4.2.2 Network Parameter..................................................................................10 4.2.3 Alarm setting............................................................................................19 4.2.4 System Information.................................................................................20 4.2.5 Advanced setting.....................................................................................21 4.2.6 Serial port set up.....................................................................................24 5 Appendix.......................................................................................................25 2 ® 1 Product Introduction 1.1Brief Introduction This product is digitally monitored with a traditional analog camera and web video service. Efficient Linux system, code in flash and small size that’s reliable and steady. Figure 1-1 Network IP Camera Figure 1-2 Camera Cable Ports 1.2 Main Features * The highest pixels for 30 W, 2M frame rate, real-time image * Advanced video compression standard, high compression rate and flexible operation * 1/4’’CMOS sensor, fluid motion pics * Automatic snapshot in all circumstance * One key rescue system, dual stream and mobile phone live monitor * Build-in WEB browser supports IE access * Support multiple user simultaneously, multi-level management ensures high system security. * Support motion detection alarm (area, sensitivity configurable) and e-mail alert function * Support online system upgrade by remote control * Automatic recovery function when the system temporarily loses internet connection. * Support PPPOE, DDNS, LAN, and Internet (ADSL, Cable Modem) 1.3 Installation Statement During installation and operation, please pay attention to the following items: 1.When you received the package product, please check the equipment and accessories according to the packing list inside the packing case. Power Network Reset 3 ® 2.Before installation please carefully read this user manual. 3.When you install the IP camera, please close the power source of all the related devices. 4.Check the voltage of the power source, to prevent device damage by mismatching of voltage. Installation environment: please do not use equipment under high humidity or temperature. Make sure there is good ventilation and no blocking of air-vent. Place it on a flat floor. Do not install it under violent vibration. 1.4 Network IP Camera Connection Figure 1-3 Device Connection of Network IP Camera Step one: Connect the IP Camera to your router or NVR using a network LAN cable. Step two: Connect the related power adapter to the IP Camera so that the camera powers on. Step three: Insert the Software CD into the PC computer that is connected to the same local network as the IP Camera. Note: It can also apply the way of IP Camera directly connecting with PC. Note: When using IE browser to visit …

Text truncated - open the document above for the full version.

1 Photographs - EUT Constructional Details

1 Photographs - EUT Constructional Details

SGS-CSTC Standards Technical Services Co., Ltd. No. 1 W orkshop, M-10, Middle section, Science & Technology Park, Nanshan District, Shenzhen, Guangdong, China 518057 Telephone: +86 (0) 755 2601 2053 Fax: +86 (0) 755 2671 0594 Email: [email protected] Report No.: SZEM140100019402 Page: 1 of 6 Authorized Signature: Jack Zhang EMC Laboratory Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. All test results in this report can be traceable to National or International Standards. “This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm . Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only.” 1 Cover page RF Exposure Evaluation Report Application No.: SZEM1401000194RF Applicant: Zmodo Technology Shenzhen Corp. Ltd Manufacturer: Zmodo Technology Shenzhen Corp. Ltd Factory Zmodo Technology Shenzhen Corp. Ltd Product Name: IPC Model No.(EUT): ZMD-ISV-BFS23NM Add Model No.: Zx-lxxyy- x(1 st x=h,p,s;2 nd x=D,B,Z,X,O;3 rd x=AtoZ,1 st y=0,1,2,3,5,7; 2 nd y=0 to 9 or A to Z;4 th x=W,A,P,C,S,WC,PA,WC-T,WAC or null).ZMD-lSx-xxxyyxx(1 st x=V,E,S;2 nd x=B,D,Z,O;3 rd x=A to Z; 4 th x=S,M,L,H;1 st y=0 to 9;2 nd y=1 to 9;5 th x=N,P,6 th X=A,M). FCC ID: ZK8-BFS23NM Standards: 47 CFR Part 1.1307(2013) 47 CFR Part 1.1310(2013) Date of Receipt: 2014-01-17 Date of Test: 2014-03-26 to 2014-05-27 Date of Issue: 2014-06-05 Test Result : PASS* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Report No.: SZEM140100019402 Page: 2 of 6 “This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only.” 2 Contents Page 1 COVER PAGE ..................................................................................................................................................... 1 2 CONTENTS ......................................................................................................................................................... 2 3 GENERAL INFORMATION ................................................................................................................................ 3 3.1 CLIENT INFORMATION ......................................................................................................................................... 3 3.2 GENERAL DESCRIPTION OF EUT .......................................................................................................................... 3 3.3 TEST LOCATION .................................................................................................................................................. 4 3.4 TEST FACILITY.................................................................................................................................................... 4 3.5 DEVIATION FROM STANDARDS ............................................................................................................................. 5 3.6 ABNORMALITIES FROM STANDARD CONDITIONS .................................................................................…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Ltd. No. 1 W orkshop, M-10, Middle section, Science & Technology Park, Nanshan District, Shenzhen, Guangdong, China 518057 Telephone: +86 (0) 755 2601 2053 Fax: +86 (0) 755 2671 0594 Email: [email protected] Report No.: SZEM140100019401 Page: 1 of 122 Authorized Signature: Jack Zhang EMC Laboratory Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. All test results in this report can be traceable to National or International Standards. “This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only.” 1 Cover page FCC REPORT Application No: SZEM1401000194RF Applicant: Zmodo Technology Shenzhen Corp. Ltd Manufacturer: Zmodo Technology Shenzhen Corp. Ltd Factory: Zmodo Technology Shenzhen Corp. Ltd Product Name: IPC Model No.(EUT): ZMD-ISV-BFS23NM Add Model No.: Zx-lxxyy- x(1 st x=h,p,s;2 nd x=D,B,Z,X,O;3 rd x=AtoZ,1 st y=0,1,2,3,5, 7;2 nd y=0 to 9 or A to Z;4 th x=W,A,P,C,S,WC,PA,WC-T,WAC or null).ZMD-lSx-xxxyyxx(1 st x=V,E,S;2 nd x=B,D,Z,O;3 rd x=A to Z; 4 th x=S,M,L,H;1 st y=0 to 9;2 nd y=1 to 9;5 th x=N,P,6 th X=A,M). FCC ID: ZK8-BFS23NM Standards: 47 CFR Part 15, Subpart C (2013) Date of Receipt: 2014-01-17 Date of Test: 2014-03-26 to 2014-05-27 Date of Issue: 2014-06-05 Test Result: PASS * . * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Ltd. Report No.: SZEM140100019401 Page: 2 of 122 “This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only.” 2 Test Summary Test Item Test Requirement Test method Result Antenna Requirement 47 CFR Part 15, Subpart C Section 15.203/15.247 (c) ANSI C63.10 2009 PASS AC Power Line Conducted Emission 47 CFR Part 15, Subpart C Section 15.207 ANSI C63.10 2009 PASS Conducted Peak Output Power 47 CFR Part 15, Subpart C Section 15.247 (b)(3) KDB558074 D01 v03r01 PASS 6dB Occupied Bandwidth 47 CFR Part 15, Subpart C Section 15.247 (a)(2) KDB558074 D01 v03r01 PASS Power Spectral Density 47 CFR Part 15, Subpart C Section 15.247 (e) KDB558074 D01 v03r01 PASS Band-edge for RF Conducted Emissions 47 CFR Part 15, Subpart C Section 15.247(d) KDB558074 D01 v03r01 PASS RF Conducted Spurious Emissions 47 CFR Part 15, Subpart C Section 15.247(d) KDB558074 D01 v03r01 PASS Radiated Spurious Emissions 47 CFR Part 15, Subpart C Section 15.205/15.209 ANSI C63.10 2009 PASS Restricted bands around fundamental frequency (Radiated Emission) 47 CFR Part 15, Subpart C Section 15.205/15.209 ANSI C63.10 2009 PASS Remark: Model No.: ZMD-ISV-BFS23NM, Zx-lxxyy- x(1 st x=h,p,s;2 nd x=D,B,Z,X,O;3 rd x=AtoZ,1 st y=0,1,2,3,5, 7; 2 nd y=0 to 9 or A to Z;4 th x=W,A,P,C,S,WC,PA,WC-T,WAC or null).ZMD-lSx-xxxyyxx(1 st x=V,E,S; 2 nd x=B,D,Z,O;3 rd x=A to Z; 4 th x=S,M, L,H;1 st y=0 to 9;2 nd y=1 to 9;5 th x=N,P,6 th X=A,M). Only the model ZMD-ISV-BFS23NM was tested, since the circuit design, PCB layout, electrical components used, internal wiring and functions were identical for the above models, with diffe…

Text truncated - open the document above for the full version.

1 Photographs - EUT Test Setup Test model No.: ZMD-ISV-BFS23NM 1.1 Radiated Spurious Emission 1.2 Conducted Emission
