ZLZTD608FETelemetry Transmitter

BeneVision TMS60 Telemetry Monitoring System Operator’s Manual Introduction TMS60 Operator’s ManualI © Copyright 2015 Shenzhen Mindray Bio-Medical Electronics Co., Ltd. All rights reserved. For this Operator’s Manual, the issue date is 2015-06. Intellectual Property StatementIntroduction IITMS60 Operator’s Manual Intellectual Property Statement SHENZHEN MINDRAY BIO-MEDICAL ELECTRONICS CO., LTD. (hereinafter called Mindray) owns the intellectual property rights to this Mindray product and this manual. This manual may refer to information protected by copyrights or patents and does not convey any license under the patent rights of Mindray, nor the rights of others. Mindray intends to maintain the contents of this manual as confidential information. Disclosure of the information in this manual in any manner whatsoever without the written permission of Mindray is strictly forbidden. Release, amendment, reproduction, distribution, rental, adaption and translation of this manual in any manner whatsoever without the written permission of Mindray is strictly forbidden. , , and are the registered trademarks or trademarks owned by Mindray in China and other countries. All other trademarks that appear in this manual are used only for editorial purposes without the intention of improperly using them. They are the property of their respective owners. Manufacturer’s Responsibility Contents of this manual are subject to changes without prior notice. All information contained in this manual is believed to be correct. Mindray shall not be liable for errors contained herein nor for incidental or consequential damages in connection with the furnishing, performance, or use of this manual. Mindray is responsible for the effects on safety, reliability and performance of this product, only if: ■all installation operations, expansions, changes, modifications and repairs of this product are conducted by Mindray authorized personnel; ■the electrical installation of the relevant room complies with the applicable national and local requirements; ■the product is used in accordance with the instructions for use. IntroductionWarranty TMS60 Operator’s ManualIII Warranty Mindray warrants that components within its products will be free from defects in workmanship and materials for a period of three years from the date of purchase except that disposable or one-time use products are warranted to be free from defects in workmanship and materials up to a date one year from the date of purchase or the date of first use, whichever is sooner. This warranty does not cover consumable items such as, but not limited to, batteries, external cables, and sensors. Mindray shall not be liable for any incidental, special, or consequential loss, damage, or expense directly or indirectly arising from the use of its products. Liability under this warranty and the buyer’s exclusive remedy under this warranty is limited to servicing or replacing the affected products, at Mindray option, at the factory or at an authorized distributor, for any product which shall under normal use and service appear to Mindray to have been defective in material or workmanship. Recommended preventative maintenance, as prescribed in the service manual, is the responsibility of the user and is not covered by this warranty. No agent, employee, or representative of Mindray has any authority to bind Mindray to any affirmation, representation, or warranty concerning its products, and any affirmation, representation or warranty made by any agent, employee, or representative shall not be enforceable by buyer or user. THIS WARRANTY IS EXPRESSLY IN LIEU OF, AND MINDRAY EXPRESSLY DISCLAIMS, ANY OTHER EXPRESS OR IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY, NON-INFRINGEMENT, OR FITNESS FOR A PARTICULAR PURPOSE, AND OF ANY OTHER OBLIGATION ON THE PART OF MINDRAY. Damage to any product or parts through misuse, neglect, accident, or by affixing any non-standard accessory attachments, or by any customer modification voids this warranty. Mindray makes no warranty whatsoever in regard to trade accessories, such being subject to the warranty of their respective manufacturers. A condition of this warranty is that the equipment or accessories which are claimed to be defective be returned when authorized, freight prepaid to Mindray DS USA, Inc., Mahwah, New Jersey 07430 or its authorized representative. Mindray shall not have any responsibility in the event of loss or damage in transit. WARNING •Only skilled/trained clinical professionals should operate this equip- ment. •It is important for the hospital or organization that employs this equip- ment to carry out a reasonable service/maintenance plan. Neglect of this may result in machine breakdown or personal injury. Company ContactIntroduction IVTMS60 Operator’s Manual Exemptions Mindray's obligation or liability under this warranty does not include any transportation or other charges or liability for direct, indirect or consequential damages or delay resulting from the improper use or application of the product or the use of parts or accessories not approved by Mindray or repairs by people other than Mindray authorized personnel. This warranty does not extend to: ■Malfunction or damage caused by improper use or man-made failure. ■Malfunction or damage caused by unstable or out-of-range power input. ■Malfunction or damage caused by force majeure events, such as (i) flood, fire and earthquake or other similar elements of nature or acts of God; (ii) riots, war, civil disorders, rebellions, or revolutions in any country; or (iii) any other cause beyond the reasonable control of Mindray. ■Malfunction or damage caused by improper operation or repair by unqualified or unauthorized service people. ■Malfunction of the instrument or part whose serial number is not legible. ■Others not caused by instrument or part itself. Company Contact Manufacturer:Shenzhen Mindray Bio-Medical Electronics Co., Ltd. Address:Mindray B…

Text truncated - open the document above for the full version.

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 <July 13, 2015> TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name ZLZTD608FE TD60 For the product stated above, we request permanent confidentiality for exhibits which contain Operational Description, Block Diagram, Schematics, Parts Lists or Tune Up Information. The above exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. If you have any questions, please feel free to contact me at the address shown below. Sincerely, (signed) Name: leo Shao Company: Shenzhen Mindray BIO-Medical electronics Co.,LTD. Address: Mindray Building, Keji 12th Road South,Hi-tech Ind, Shenzhen,China Phone: 86-755-81885333 Fax: 86-755-26582680 Email: [email protected]

External Photo

Internal Photos BT Antenna 608M Antenna

Report No.: SET2015-09560 CCIC-SET/T（00） Page 1 of 32 RF TEST REPORT Report No.: SET2015-09560 Product Name: Telemetry transmitter FCC ID: ZLZTD608FE Model No. : TD60 Applicant: Shenzhen Mindray Bio-Medical Electronics Co.,Ltd. Address: Mindray Buiding,Keji 12th Road South,High-tech Industrial Park,Nanshan,Shenzhen,P.R.China Dates of Testing: 03/20/2015 — 07/14/2015 Issued by: CCIC-SET Lab Location: Electronic Testing Building, Shahe Road, Xili, Nanshan District, Shenzhen, 518055, P. R. China Tel: 86 755 26627338 Fax: 86 755 26627238 This test report consists of 32 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CCIC-SET. The test results in the report only apply to the tested sample. The test report shall be invalid without all the signatures of testing engineers, reviewer and approver. Any objections must be raised to CCIC-SET within 20 days since the date when the report is received. It will not be taken into consideration beyond this limit. Report No.: SET2015-09560 CCIC-SET/T（00） Page 2 of 32 Test Report Product Name ...................... : Telemetry transmitter Brand Name ......................... : Mindray Trade Name .......................... : Applicant .............................. : Shenzhen Mindray Bio-Medical Electronics Co.,Ltd. Applicant Address ............... : Mindray Buiding,Keji 12th Road South,High-tech Industrial Park,Nanshan,Shenzhen,P.R.China Manufacturer ........................ : Shenzhen Mindray Bio-Medical Electronics Co.,Ltd. Manufacturer Address ........ : Mindray Buiding,Keji 12th Road South,High-tech Industrial Park,Nanshan,Shenzhen,P.R.China Test Standards ..................... : 47 CFR Part 15 Subpart C：Radio Frequency Devices ANSI C63.10-2009：American National Standard for Testing Unlicensed Wireless Devices KDB558074 D01 DTS Meas Guidance v03r03 Test Result ........................... : PASS Tested by ............................ : 2015.07.14 Lu Lei, Test Engineer Reviewed by ......................... : 2015.07.14 Zhu Qi, Senior Egineer Approved by ........................ : 2015.07.14 Wu Li’an, Manager Report No.: SET2015-09560 CCIC-SET/T（00） Page 3 of 32 TABLE OF CONTENTS 1. GENERAL INFORMATION ................................................................................................. 4 1.1. EUT Description .................................................................................................................... 4 1.2. Test Standards and Results ..................................................................................................... 5 1.3. Facilities and Accreditations .................................................................................................. 6 2. 47 CFR PART 15C REQUIREMENTS ................................................................................. 7 2.1. Antenna requirement .............................................................................................................. 7 2.2. Peak Output Power................................................................................................................. 9 2.3. 6dB & 99%Bandwidth ......................................................................................................... 10 2.4. Conducted Band Edges and Spurious Emissions ................................................................. 14 2.5. Power spectral density (PSD) .............................................................................................. 19 2.6. Radiated Band Edge and Spurious Emission ....................................................................... 22 2.7. Conducted Emission ............................................................................................................ 30 3. LIST OF MEASURING EQUIPMENT .............................................................................. 32 Change History Issue Date Reason for change 1.0 2015.07.14 First edition Report No.: SET2015-09560 Page 4 of 32 1. General Information 1.1. EUT Description EUT Type Telemetry transmitter Hardware Version 02-02-/ Software Version 01.00.00 EUT supports Radios application Bluetooth V4.0 BLE Frequency Range Bluetooth BLE 4.0 2402MHz~2480MHz Channel Number Bluetooth BLE 4.0 40 Bit Rate of Transmitter Bluetooth BLE 4.0 1Mbps Modulation Type Bluetooth BLE 4.0 GFSK Antenna Type Tape Antenna(short) Antenna Gain Tape Antenna(short): 1dBi Note 1: The EUT is a Telemetry transmitter, it contain Bluetooth 4.0 BLE Module operating at 2.4GHz ISM band; the frequencies allocated for the Bluetooth 4.0 BLE is F(MHz)=2402+2*n (0<=n<=39). The lowest, middle, highest channel numbers of the Bluetooth Module used and tested in this report are separately 0 (2402MHz), 20(2442MHz) and 39 (2480MHz). Note 2: For a more detailed description, please refer to Specification or User’s Manual supplied by the applicant and/or manufacturer. Note 3: The EUT was programmed to be in continuously transmitting mode and the transmit duty cycle is not less than 98%.” Report No.: SET2015-09560 Page 5 of 32 1.2. Test Standards and Results The objective of the report is to perform testing according to 47 CFR Part 15 Subpart C (Bluetooth, 2.4GHz ISM band radiators) for the EUT FCC Certification: No. Identity Document Title 1 47 CFR Part 15 Subpart C 2013 Radio Frequency Devices 2 ANSI C63.10-2009 American National Standard for Testing Unlicensed Wireless Devices Test detailed items/section required by FCC rules and results are as below: No. Section in CFR 47 Description Result 1 15.203 Antenna Requirement PASS 2 15.247(b) Peak Output Power PASS 3 15.247(a) Bandwidth PASS 4 15.247(d) Conducted Band Edges and Spurious Emission PASS 5 15.247(e) Power spectral density (PSD) PASS 6 15.207 Conducted Emission PASS 7 15.209 15.247(d) Radiated Band Edges and Spurious Emission PASS 8 1.1307(b…

Text truncated - open the document above for the full version.

Radiated Emission Test setup photos Below 1GHz Above 1GHz Conducted Test setup photo
