ZMOSC162NA

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
1	22H	829 MHz - 844 MHz	169.00 mW	8M98G7D	0.024ppm
2	22H	829 MHz - 844 MHz	134.00 mW	8M97W7D	0.024ppm
3	22H	824.7 MHz - 848.3 MHz	135.00 mW	1M10W7D	0.024ppm
4	22H	831.5 MHz - 841.5 MHz	143.00 mW	13M5G7D	0.024ppm
5	22H	831.5 MHz - 841.5 MHz	117.00 mW	13M4W7D	0.024ppm
6	22H	829 MHz - 844 MHz	145.00 mW	8M97G7D	0.024ppm
7	22H	825.5 MHz - 847.5 MHz	122.00 mW	2M71W7D	0.024ppm
8	24E	1.86 GHz - 1.90 GHz	460.00 mW	17M9G7D	0.011ppm
9	24E	1.86 GHz - 1.90 GHz	372.00 mW	17M9W7D	0.011ppm
1	24E	1.86 GHz - 1.91 GHz	440.00 mW	17M9G7D	0.011ppm
11	24E	1.86 GHz - 1.91 GHz	361.00 mW	17M9W7D	0.011ppm
12	27	1.72 GHz - 1.75 GHz	472.00 mW	17M9G7D	0.012ppm
13	27	1.72 GHz - 1.75 GHz	388.00 mW	17M9W7D	0.012ppm
14	27	2.51 GHz - 2.56 GHz	406.00 mW	17M9G7D	0.008ppm
15	27	2.51 GHz - 2.56 GHz	336.00 mW	17M9W7D	0.008ppm
16	27	704 MHz - 711 MHz	179.00 mW	8M97G7D	0.028ppm
17	27	704 MHz - 711 MHz	145.00 mW	8M96W7D	0.028ppm
18	27	782 MHz - 782 MHz	179.00 mW	8M95G7D	0.026ppm
19	27	782 MHz - 782 MHz	152.00 mW	8M94W7D	0.026ppm
2	27	709 MHz - 711 MHz	167.00 mW	8M96G7D	0.028ppm
21	27	709 MHz - 711 MHz	139.00 mW	8M96W7D	0.028ppm
22	27	2.51 GHz - 2.68 GHz	390.00 mW	17M9G7D	0.008ppm
23	27	2.51 GHz - 2.68 GHz	310.00 mW	17M9W7D	0.008ppm
24	27	2.50 GHz - 2.69 GHz	312.00 mW	8M98W7D	0.008ppm
25	27	1.72 GHz - 1.77 GHz	479.00 mW	17M9G7D	0.013ppm
26	27	1.72 GHz - 1.77 GHz	384.00 mW	18M0W7D	0.013ppm
27	27	673 MHz - 688 MHz	166.00 mW	17M9G7D	0.013ppm
28	27	673 MHz - 688 MHz	138.00 mW	17M9W7D	0.013ppm
29	9	793 MHz - 793 MHz	195.00 mW	8M99G7D	0.025ppm
3	9	793 MHz - 793 MHz	156.00 mW	8M97W7D	0.025ppm
31	9	790.5 MHz - 795.5 MHz	157.00 mW	4M51W7D	0.025ppm
32	9	819 MHz - 819 MHz	135.00 mW	8M97G7D	0.027ppm
33	9	819 MHz - 819 MHz	128.00 mW	8M95W7D	0.027ppm
34	9	816.5 MHz - 821.5 MHz	161.00 mW	4M49G7D	0.027ppm
35	9	815.5 MHz - 822.5 MHz	129.00 mW	2M71W7D	0.027ppm

Modular Type

Single Modular Approval

Confidentiality

Long Term

Grant Notes

Single Modular Approval is filing. Output power listed for LTE Band 5/12/13/14/17/26/71 are maximum ERP. Output power listed for LTE Band 2/4/7/25/41/66 are maximum EIRP. It supports LTE (QPSK, 16QAM, 64QAM), LTE B2, B4, B5, B7, B12, B13, B14, B17, B25, B26, B41, B66, B71, Channel Bandwidth (5/10 MHz) for LTE B13, B14, B17, Channel Bandwidth (1.4/3/5/10 MHz) for LTE B5, B12, Channel Bandwidth (5/10/15/20 MHz) for LTE B7, B41, B71, Channel Bandwidth (1.4/3/5/10/15 MHz) for LTE B26, Channel Bandwidth (1.4/3/5/10/15/20 MHz) for LTE B2, B4, B25, B66, This device contains functions that are not operational in U.S. Territories; this filing is only applicable for U.S. operations. This device has integrated DSS, DTS, NII and PCB transmitters certified under the same FCC ID. The module antenna(s) must be installed to meet the RF exposure compliance separation distance of 20 cm and any additional testing and authorization process as required. Co-location of this module with other transmitters that operate simultaneously are required to be evaluated using the FCC multi-transmitter procedures. Approved for OEM integration only. The grantee must provide OEM integrators, or end-users if marketed directly to end-users, with installation and operating instructions for satisfying FCC multi-transmitter product guidelines. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. External Antenna: LTE Band 2: 3.10dBi LTE Band 4: 3.10dBi LTE Band 5: 1.17dBi LTE Band 7: 1.17dBi LTE Band 12: 1.17dBi LTE Band 13: 1.17dBi LTE Band 14: 1.17dBi LTE Band 17: 1.17dBi LTE Band 25: 3.10dBi LTE Band 26: 1.17dBi LTE Band 41: 2.56dBi LTE Band 66: 3.10dBi LTE Band 71: 1.17dBi
