CUb BLIND SPOT DETECTION SYSTEM User Manual & Installation Guide VS-95A043 For Passenger Cars Blind Spot Detection I Lane Change Alert 1 1. Precautions ......................................................................................................... 2 2. Introduction ........................................................................................................ 5 2.1 System block ................................................................................................................ 5 2.2 Product specifications ......................................................................................... 5 3. Installation Guide .................................................................................... 6 3.1 Installation diagram ............................................................................................... 6 3.2 Package contents ................................................................................................... 6 3.3 Installation steps ....................................................................................................... 7 3.4 Reinstallation ............................................................................................................... 9 4. User Manual ....................................................................................................... 10 4.1 System startup and shut off .......................................................................... 10 4.1.1 System startup ........................................................................................................... 10 4.1.2 System shut off .......................................................................................................... 10 4.2 Function ............................................................................................................................. 10 4.2.1 Detection zone ........................................................................................................... 11 4.2.2 Blind Spot Detection (BSD) .......................................................................... 11 4.2.3 Lane Change Alert (LCA) ..................................................................... 11 4.3 System abnormalities .......................................................................................... 12 4.3.1 Malfunction prompts ............................................................................................. 12 4.3.2 Troubleshooting ........................................................................................................ 12 Contents 2 1 Blind Spot Detection System Precautions Before using this device, please read this instruction manual carefully before installing or removing it to ensure that the device is safe to use. The Company shall not be liable for any damage arising from failure to comply with the following matters. Before installing If you wish to laminate your car’s rear windshield with or it has already laminated with a heat insulation film, please contact the dealer to ensure that the heat insulation film does not technically contain metal components. If it contains the metal components, it is recommended not to install this device. If your car has the following conditions, please consult a professional technician to evaluate whether or not to install this device： • If the angle between the rear windshield and the horizon is not within 20 - 60 degrees, it is recommended not to install this device. • If the third brake light is on top of the interior rear windshield, it may affect the radar installation position. • If there is a rear spoiler, rear spare tire, or a bicycle, it may block the radar and affect the system performance. Due to the highly sensitive detection performance of this device, please ensure to follow the installation procedures and precautions during installation to avoid affecting the device performance, and please ensure to hide the wires properly according to the layout of the car to avoid the wiring harness from affecting driving safety, and obstructing you from getting in and off the car. It is recommended that you consult a professional technician for installation. Please follow the preparatory works before installation： Please wear protective goggles. Please work with an assistant. Please tighten with a specified torque. wrench (1) (2) (3) (4) 3 If the connector is dislocated, please replace the connector to its original position. Please do not pull the connector apart by pulling the harness. Please do not pull the harness by force. Connect the connector and terminal tightly. Cut off the excessive length of the cable tie. RF Standard (1) (2) NCC low-power radio waves radiated device management methods： Companies, stores, or users are prohibited from changing the frequency, increasing the power, or modifying the characteristics and functions of the original design of the certified low-power radio waves radiated device without permission. The use of low-power RF devices must not affect the safety of aviation and interfere with legal communications. If any interference occurs, they should be stopped immediately and improved to the extent of no interference before users can use the legal communications mentioned in the previous paragraph, i.e., radio communications under the provisions of the Telecommunications Act. Low- power RF devices must endure interference from legal communications or industrial, scientific, and medical radio wave-radiated electrical equipment. Article 12: Article 14: FCC regulations： This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference, and • This device must accept any interference received, including interference that may cause undesired operation. 4 NOTE : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. Thes…
