ZQWGIT000001RFID Transponder Module

User Manual rev1_1.doc Pag. 1 di 9 TECHNOGYM S.p.A. Via G. Perticari, 20 - 47035 Gambettola (FC) - Italia Tel.: +39 (0) 547- 56047 Rev. 1.1 FCC ID: TGSGIT000001 Data di stampa: 14/03/13 Technogym ® Mifare Reader User / Integration Manual User Manual rev1_1.doc Pag. 2 di 9 TECHNOGYM S.p.A. Via G. Perticari, 20 - 47035 Gambettola (FC) - Italia Tel.: +39 (0) 547- 56047 Rev. 1.1 FCC ID: TGSGIT000001 Data di stampa: 14/03/13 Revision History Release Date Description Author 1.0 20/12/2011 Initial releaseAlessandro Cevoli Table of contents 1 General overview ................................................................................................. 3 2 Description .......................................................................................................... 3 3 Communication and connector .............................................................................. 4 4 Operational functionality ....................................................................................... 4 5 Developing tools ................................................................................................... 7 6 Installation .......................................................................................................... 8 7 FCC / Industry Canada (IC) Statements .................................................................. 9 User Manual rev1_1.doc Pag. 3 di 9 TECHNOGYM S.p.A. Via G. Perticari, 20 - 47035 Gambettola (FC) - Italia Tel.: +39 (0) 547- 56047 Rev. 1.1 FCC ID: TGSGIT000001 Data di stampa: 14/03/13 1 General overview The TGS Mifare Reader is an accessory of Technogym Equipments that let them to identify, read and write an RFID transponder, named Technogym Wellness System Keys, in a contactless way. Technogym Wellness System Keys are Mifare transponders customized with a private password to access data inside it. By means of the system made by “TGS Mifare Reader” + “Technogym Wellness System Keys” each equipment may identify the user, propose its specific training and save a log of the training executed on the equipment. 2 Description The TGS Mifare Reader is made by 2 boards inside a plastic housing that may change depending of the equipment where the TGS Mifare Reader must fit. The TGS Mifare Reader may be connected to the host by means of a cable that allows: - Device powering; - Data communication (the host SW drives the TGS Mifare Reader managing the reading of the RFID transponder). The module antenna is a PCB antenna type and is embedded into the module itself. 2 LEDs communicate powering and read/write communication. LEDs Cable versus host system Main board Second board User Manual rev1_1.doc Pag. 4 di 9 TECHNOGYM S.p.A. Via G. Perticari, 20 - 47035 Gambettola (FC) - Italia Tel.: +39 (0) 547- 56047 Rev. 1.1 FCC ID: TGSGIT000001 Data di stampa: 14/03/13 Fig. 1 – Pictures of Mifare Reader 3 Communication and connector Connector of TGS Mifare Reader has the following signals and pinout: Picoblade Molex on the device (on board) Description AMP modu II (on adapting cable) 1 +12Vdc 1 2 TX out 8 3 RX in 7 4 RTS out 2 5 CTS in 6 6 Relè out 5 7 N.C. 4 8 GND 3 Data communication is standard RS232 with next parameters:  Baud rate: 9600 or 38400bps (self recognizing);  Data bits: 8;  Parity: None;  Stop Bit: 1; Over this serial communication Technogym has developed a proprietary communication protocol implemented on every host that may be connected to this device. The SW driver for the TGS Mifare Reader is developed by Technogym an integrated into Operating System of the HOST. 4 Operational functionality At the beginning the User Interface ask for the Technogym Wellness System Keys for enabling the unit. User Manual rev1_1.doc Pag. 5 di 9 TECHNOGYM S.p.A. Via G. Perticari, 20 - 47035 Gambettola (FC) - Italia Tel.: +39 (0) 547- 56047 Rev. 1.1 FCC ID: TGSGIT000001 Data di stampa: 14/03/13 User Manual rev1_1.doc Pag. 6 di 9 TECHNOGYM S.p.A. Via G. Perticari, 20 - 47035 Gambettola (FC) - Italia Tel.: +39 (0) 547- 56047 Rev. 1.1 FCC ID: TGSGIT000001 Data di stampa: 14/03/13 After the Technogym Wellness System Keys is read and the end user recognized, the access to the unit is granted. User Manual rev1_1.doc Pag. 7 di 9 TECHNOGYM S.p.A. Via G. Perticari, 20 - 47035 Gambettola (FC) - Italia Tel.: +39 (0) 547- 56047 Rev. 1.1 FCC ID: TGSGIT000001 Data di stampa: 14/03/13 5 Developing tools For developing purpose a DOS tool (TgsKeManager.exe) can be used to verify the basic functionalities of a TGS Mifare Reader connected to a serial port of a PC in the following package: TgsKeyManager.exe In the follow the command list supported by the SW Tool:  Check key: check if any Technogym Wellness System Keys is present in the working range of the Mifare Reader;  Check key (extended): like the previous command, but it returns more information about the transponder (tipology and size);  Set baud rate: force the serial RS232 baud rate 9600bps or 38400bps;  Turn on red LED: turns the red LED on;  Turn off red LED: turns the red LED off;  Read key at address: read 16 bytes from the memory of the transponder inside a Wellness System Key;  Write key at address: writes 16 bytes in the memory of the transponder inside a Wellness System Key;  Fast read at address: read up to 2064 bytes from the memory of the transponder inside a Wellness System Key;  Fast write at address: writes up to 2064 bytes in the memory of the transponder inside a Wellness System Key;  Ask UID: get the Unique Identifier Number of the Mifare transponder;  Ask dimension: get the size in bytes of memory reserved with the private Technogym password;  Format Standard key: reserves a size of 2064 bytes with a private Technogym password;  Format custom key: reserves a custom size in bytes with a private Technogym password;  Reset key: writes passwords and access bits at the factory default values;  Alloc sector: reserves a specific sector of memory with private Technogym password;  Dealloc sector: frees a sp…

Text truncated - open the document above for the full version.

130209 - FCC Antenna Information Pag. 1 di 3 TECHNOGYM S.p.A. Via G. Perticari, 20 - 47035 Gambettola (FC) - Italia Tel.: +39 (0) 547- 56047 Fax.: +39 (0) 547-650505 Rev. 1.0 Data Natura modifica Data di stampa: 09/02/13 Preparazione Alessandro Cevoli Verifica Approvazione TECHNOGYM © - DOCUMENTO RISERVATO - VIETATA LA RIPRODUZIONE Technogym ® Mifare Reader Antenna Information 130209 - FCC Antenna Information Pag. 2 di 3 TECHNOGYM S.p.A. Via G. Perticari, 20 - 47035 Gambettola (FC) - Italia Tel.: +39 (0) 547- 56047 Fax.: +39 (0) 547-650505 Rev. 1.0 Data Natura modifica Data di stampa: 09/02/13 Preparazione Alessandro Cevoli Verifica Approvazione TECHNOGYM © - DOCUMENTO RISERVATO - VIETATA LA RIPRODUZIONE Index 1 Block Diagram (showing all freq. of oscillators) and schematics Errore. Il segnalibro non è definito. 130209 - FCC Antenna Information Pag. 3 di 3 TECHNOGYM S.p.A. Via G. Perticari, 20 - 47035 Gambettola (FC) - Italia Tel.: +39 (0) 547- 56047 Fax.: +39 (0) 547-650505 Rev. 1.0 Data Natura modifica Data di stampa: 09/02/13 Preparazione Alessandro Cevoli Verifica Approvazione TECHNOGYM © - DOCUMENTO RISERVATO - VIETATA LA RIPRODUZIONE 1 Antenna Information Antenna is printed on the PCB of the main board, it has size of 14mm x 14mm, it is tuned on 13.56MHz and has the following layout: On PCB one ferrite is mounted: Laird MP0433-000. It is positioned as the following picture (orange highlighted), always present and fixed with a double sticky tape:

FCC, Request for non-disclosure Date: 16-Jul-10 RF_501, Issue 6 Page 1 of 1 Company Name: TECHNOGYM SPA Address : VIA G. PERTICARI, 20 City: 47035, GAMBELLOTA (FC) Country: ITALY To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: ZQWGIT000001 Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, a pplicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: This information would give an unjustified advantage to competitors when release before the product is on the market. Planned Release Date STC: 180 days (notes 2, 3, 4, 5) Date: 14/03/13 Name and signature of applicant: Patrick Lomax Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

RF_734_00, Issue 1 Modular Approval Request FCC (per DA 00-1407) FCC ID: SGI T000001 Items to be covered Answer from applicant 1. The modular transmitter must have its own RF shielding. Yes 2. The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. Yes 3. The modular transmitter must have its own power supply regulation. Yes 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable).. Yes 5. The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing. This is intended to demonstrate that the module is capable of complying with Part 15 emission limits regardless of the device into which it is eventually installed. Yes 6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. Yes 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. For example, there are very strict operational and timing requirements that must be met before a transmitter is authorized for operation under Section 15.231. For instance, data transmission is prohibited, except for operation under Section 15.231(e), in which case there are separate field strength level and timing requirements. Compliance with these requirements must be assured. Yes 8. The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 2.1091, 2.1093 and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require that Unlicensed PCS, UNII and millimeter wave devices perform routine environmental evaluation for RF Exposure to demonstrate compliance. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF Exposure compliance in accordance with Section 15.247(b)(4). Modular transmitters approved under other Sections of Part 15, when necessary, may also need to address certain RF Exposure concerns, typically by providing specific installation and operating instructions for users, installers and other interested parties to ensure compliance. Yes Note: If compliance with one or more of the numbered requirements, listed above, cannot be demonstrated, it may be possible to obtain a “Limited Modular Approval” (LMA). Name and surname of applicant (or authorized representative): Patrick Lomax RF_734_00, Issue 1 Date: 21 Feb. 13 Signature:

130209 - FCC External Photos Pag. 1 di 3 TECHNOGYM S.p.A. Via G. Perticari, 20 - 47035 Gambettola (FC) - Italia Tel.: +39 (0) 547- 56047 Fax.: +39 (0) 547-650505 Rev. 1.0 Data Natura modifica Data di stampa: 09/02/13 Preparazione Alessandro Cevoli Verifica Approvazione TECHNOGYM © - DOCUMENTO RISERVATO - VIETATA LA RIPRODUZIONE Technogym ® Mifare Reader External Photos 130209 - FCC External Photos Pag. 2 di 3 TECHNOGYM S.p.A. Via G. Perticari, 20 - 47035 Gambettola (FC) - Italia Tel.: +39 (0) 547- 56047 Fax.: +39 (0) 547-650505 Rev. 1.0 Data Natura modifica Data di stampa: 09/02/13 Preparazione Alessandro Cevoli Verifica Approvazione TECHNOGYM © - DOCUMENTO RISERVATO - VIETATA LA RIPRODUZIONE Index 1 External Photos ..................................................................................................... 3 130209 - FCC External Photos Pag. 3 di 3 TECHNOGYM S.p.A. Via G. Perticari, 20 - 47035 Gambettola (FC) - Italia Tel.: +39 (0) 547- 56047 Fax.: +39 (0) 547-650505 Rev. 1.0 Data Natura modifica Data di stampa: 09/02/13 Preparazione Alessandro Cevoli Verifica Approvazione TECHNOGYM © - DOCUMENTO RISERVATO - VIETATA LA RIPRODUZIONE 1 External Photos

TECHNOGYM S.p.A FCC ID: ZQWGIT000001 Model: MIFARE TGS READER

130209 - FCC Internal Photos Pag. 1 di 4 TECHNOGYM S.p.A. Via G. Perticari, 20 - 47035 Gambettola (FC) - Italia Tel.: +39 (0) 547- 56047 Fax.: +39 (0) 547-650505 Rev. 1.0 Data Natura modifica Data di stampa: 09/02/13 Preparazione Alessandro Cevoli Verifica Approvazione TECHNOGYM © - DOCUMENTO RISERVATO - VIETATA LA RIPRODUZIONE Technogym ® Mifare Reader Internal Photos 130209 - FCC Internal Photos Pag. 2 di 4 TECHNOGYM S.p.A. Via G. Perticari, 20 - 47035 Gambettola (FC) - Italia Tel.: +39 (0) 547- 56047 Fax.: +39 (0) 547-650505 Rev. 1.0 Data Natura modifica Data di stampa: 09/02/13 Preparazione Alessandro Cevoli Verifica Approvazione TECHNOGYM © - DOCUMENTO RISERVATO - VIETATA LA RIPRODUZIONE Index 1 External Photos ............................................ Errore. Il segnalibro non è definito. 130209 - FCC Internal Photos Pag. 3 di 4 TECHNOGYM S.p.A. Via G. Perticari, 20 - 47035 Gambettola (FC) - Italia Tel.: +39 (0) 547- 56047 Fax.: +39 (0) 547-650505 Rev. 1.0 Data Natura modifica Data di stampa: 09/02/13 Preparazione Alessandro Cevoli Verifica Approvazione TECHNOGYM © - DOCUMENTO RISERVATO - VIETATA LA RIPRODUZIONE 1 Internal Photos 130209 - FCC Internal Photos Pag. 4 di 4 TECHNOGYM S.p.A. Via G. Perticari, 20 - 47035 Gambettola (FC) - Italia Tel.: +39 (0) 547- 56047 Fax.: +39 (0) 547-650505 Rev. 1.0 Data Natura modifica Data di stampa: 09/02/13 Preparazione Alessandro Cevoli Verifica Approvazione TECHNOGYM © - DOCUMENTO RISERVATO - VIETATA LA RIPRODUZIONE

Operational description rev1_0 Pag. 1 di 1 TECHNOGYM S.p.A. Via G. Perticari, 20 - 47035 Gambettola (FC) - Italia Tel.: +39 (0) 547- 56047 Rev. 1.0 FCC ID: TGSGIT000001 Data di stampa : 14/01/13 Operational Description FCC ID: ZQWGIT000001 The device is a contactless reader based on the ISO/IEC 14443 Type A 13.56MHz standard. It supports Mifare Classic protocol, a NXP-semiconductor owned trademark and is able to recognize, read and write Mifare Classic transponders. RF antenna is a PCB antenna embedded into the module itself and typical operating distance is 5mm. This device is not stand alone, it is a slave device of a master-slave system. It must be connected to a master device by a cable. This cable allows: •Powering: 12VDC by the master; •Data communication: oBased on standard RS232 interface with the following settings:
Speed (baud): 9600 or 38400bps (self recognizing);
Parity: None;
Data bit: 8;
Stop bit: 1;
Flow Control: None; Serial software protocol is a Technogym owned protocol. The device continuously checks if a Mifare transponder is in its working range performing time interleaved broadcasting interrogation. In case a transponder answers at the device, the data contained in the former is read by the module and communicated to the master.

Test Laboratory: Borsigstr. 11 Germany 7Layers AG 40880 Ratingen Note: The following test results relate only to the devices specified in this document. This report shall not be reproduced in parts without the written approval of the test laboratory. 7 layers AG Aufsichtsratsvorsitzender Registergericht registered in: Borsigstrasse 11 Chairman of the Supervisory Board:Düsseldorf, HRB 44096 4 0880 Ratingen, Germany Ralf Mertens USt-IdNr  VAT No.: Phone: +49 (0) 2102 749 0Vorstand  Board: DE 203159652 Fax: +49 (0) 2102 749 350 Dr. H.-J. Meckelburg TAX No. 147/5869/0385 www.7Layers.com FCC Measurement/Technical Report on RFID module Model:MIRARE TGS READER Report Reference: MDE_TGYM_1101_FCCa FCC ID:ZQWGIT000001 Test report Reference: MDE_TGYM_1101_FCCa Page 2 of 29 Table of Contents 0 Summary 3 0.1 Technical Report Summary 3 0.2 Measurement Summary 4 1 Administrative Data 5 1.1 Testing Laboratory 5 1.2 Project Data 5 1.3 Applicant Data 5 1.4 Manufacturer Data 5 2 Test object Data 6 2.1 General EUT Description 6 2.2 EUT Main components 7 2.3 Ancillary Equipment 7 2.4 Auxiliary Equipment 7 2.5 EUT Setups 8 2.6 Operating Modes 8 2.7 Special software used for testing 8 2.8 Product labelling 8 3 Test Results 9 3.1 Spurious radiated emissions 9 3.2 Occupied bandwidth 13 3.3 Spectrum mask 14 3.4 Frequency tolerance 15 4 Test Equipment 17 5 Photo Report 25 6 Setup Drawings 25 7 FCC and IC Correlation of measurement requirements 26 8 Annex measurement plots 27 8.1 Occupied bandwidth 27 8.2 Spectrum mask 29 Test report Reference: MDE_TGYM_1101_FCCa Page 3 of 29 0 Summary 0.1 Technical Report Summary Type of Authorization Certification for an intentional radiator operating at 13.56 MHz Applicable FCC Rules Prepared in accordance with the requirements of FCC Rules and Regulations as listed in 47 CFR Ch.1 Parts 2 (10-1-11 Edition) and 15 (10-1-11 Edition). The following subparts are applicable to the results in this test report. Part 2, Subpart J - Equipment Authorization Procedures, Certification Part 15, Subpart C – Intentional Radiators § 15.205 Restricted bands of operation § 15.207 Conducted limits § 15.209 Radiated emission limits; general requirements § 15.215 Additional provisions to the general radiated emission limitations § 15.225 Operation within the band 13.110-14.010 MHz Summary Test Results: The EUT complied with all performed tests as listed in chapter 0.2 Measurement Summary. Test report Reference: MDE_TGYM_1101_FCCa Page 5 of 29 1 Administrative Data 1.1 Testing Laboratory Company Name: 7Layers AG Address Borsigstr. 11 40880 Ratingen Germany This facility has been fully described in a report submitted to the FCC and accepted under the registration number 96716. The test facility is also accredited by the following accreditation organisation: Laboratory accreditation no.: DAkkS D-P L-12140-01-01 Responsible for Accreditation Scope: Dipl.-Ing. Bernhard Retka Dipl.-Ing. Robert Machulec Dipl.-Ing. Andreas Petz Report Template Version: 2012-03-14 1.2 Project Data Responsible for testing and report: Dipl.-Ing. Marco Kullik Date of Test(s): 2012-06-06 to 2012-07-26 Date of Report: 2013-02-19 1.3 Applicant Data Company Name: TECHNOGYM SPA Address: Via G. Perticari, 20 Gambettola (FC) Italy Contact Person: Mr. Pietro Lotti 1.4 Manufacturer Data Company Name: please see applicant data Address: Contact Person: Test report Reference: MDE_TGYM_1101_FCCa Page 6 of 29 2 Test object Data 2.1 General EUT Description Equipment under Test RFID transceiver Type Designation: MIFARE TGS KEY READER Kind of Device: (optional) RFID transceiver operating at 13.56 MHz Voltage Type: DC Voltage level: 12 V / General product description: The MIFARE TGS KEY READER is a 13.56 MHz contactless smartcard reader and encoder for PC for reading RFID tags. Specific product description for the EUT: The EUT is a module, which can be built-in to TECHNOGYM equipment to enable the use of RFID tags. The EUT provides the following ports: Ports Power and control connector Enclosure The main components of the EUT are listed and described in Chapter 2.2. Test report Reference: MDE_TGYM_1101_FCCa Page 7 of 29 2.2 EUT Main components Type, S/N, Short Descriptions etc. used in this Test Report Short Description Equipment under Test Type Designation Serial No. HW Status SW Status Date of Receipt EUT A (Code: VJ010A01) Technogym RFID reader MIFARE TGS KEY READER 001 0WQ00340 1.29.00 2011-10-02 NOTE: The short description is used to simplify the identification of the EUT in this test report. 2.3 Ancillary Equipment For the purposes of this test report, ancillary equipment is defined as equipment which is used in conjunction with the EUT to provide operational and control features to the EUT. It is necessary to configure the system in a typical fashion, as a customer would normally use it. But nevertheless Ancillary Equipment can influence the test results. Short Descri ption Equipment under Test Type Designation Serial No. HW Status SW Status FCC ID – – – – – – – 2.4 Auxiliary Equipment For the purposes of this test report, auxiliary equipment is defined as equipment which is used temporarily to enable operational and control features especially used for the tests of the EUT which is not used during normal operation or equipment that is used during the tests in combination with the EUT but is not subject of this test report. It is necessary to configure the system in a typical fashion, as a customer would normally use it. But nevertheless Auxiliary Equipment can influence the test results. Short Descri ption Equipment under Test Type Designation Serial no. HW Status SW Status FCC ID AUX 1 AC/DC supply Mean Well GS18A12 – – –. – AUX 2 Serial Cable RS232 Serial cable – – – – Test report Reference: MDE_TGYM_1101_FCCa Page 8 of 29 2.5 EUT Setups This chapter describes the combination of EUTs and equipment used for testing. The rationale for selecting the EUTs, ancillary and auxiliary equipment and interconnecting cables, is to test a repr…

Text truncated - open the document above for the full version.

Test Laboratory: Borsigstr. 11 Germany 7Layers AG 40880 Ratingen Note: The following test results relate only to the devices specified in this document. This report shall not be reproduced in parts without the written approval of the test laboratory. 7 layers AG Aufsichtsratsvorsitzender  Registergericht registered in: Borsigstrasse 11 Chairman of the Supervisory Board: Düsseldorf, HRB 44096 40880 Ratingen, Germany Ralf Mertens USt-IdNr  VAT No.: Phone: +49 (0) 2102 749 0 Vorstand Board: DE 203159652 Fax: +49 (0) 2102 749 350 Dr. H.-J. Meckelburg TAX No. 147/5869/0385 www.7Layers.com Photo Report on Test Setups Report Reference: MDE_TGYM_1101_FCCa_Photo_Setups Test Setup photos for report MDE_TGYM_1101_FCCa Test report Reference: MDE_TGYM_1101_FCCa_Photo_Setups Page 2 of 3 Photo 1: Test setup for radiated measurements (Enclosure, below 30 MHz, intentional radiator §15) Test report Reference: MDE_TGYM_1101_FCCa_Photo_Setups Page 3 of 3 Photo 2: Test setup for radiated measurements (Enclosure, semi-anechoic chamber, 30 MHz to 1 GHz, intentional radiator §15)
