ZTT-RE1750AHigh Power AC1750 Wi-Fi Range Extender

User’s Guide RE1750A HIGHPOWER TM AC1750 WI-FI ® RANGE EXTENDER RE1750A USER’S GUIDE 1 CONTENTS INTRODUCTION .......................................................................... 2 GETTING STARTED ...................................................................... 3 Package Contents ............................................................................. 3 LED Indicators, Ports and Buttons .................................................... 4 Back Panel Description ..................................................................... 5 SETUP GUIDE .............................................................................. 6 Find a Setup Location ....................................................................... 6 Connect your PC or Tablet to the Range Extender ............................ 7 Welcome to the Dashboard .............................................................. 9 Scan for a Wireless Network........................................................... 10 Connecting to a Secure Network .................................................... 11 Extended Network Settings (SSID and Security) .............................. 12 Connect to the new Extended Network .......................................... 14 Setup Summary .............................................................................. 15 5.0GHz WI-FI SETTINGS .............................................................. 18 Home Network Settings (5.0GHz) ................................................... 18 Extended Network Settings (5.0GHz) .............................................. 19 Security (5.0GHz) ............................................................................ 21 Wi-Fi Protected Setup – WPS (5.0GHz) ........................................... 22 User Access (5.0GHz) ...................................................................... 23 Wireless Coverage Controls (5.0GHz) ............................................. 24 Access Schedule (5.0GHz) ............................................................... 25 Advanced Settings (5.0GHz) ........................................................... 26 2.4GHz WI-FI SETTINGS .............................................................. 28 Home Network Settings (2.4GHz) ................................................... 28 Extended Network Settings (2.4GHz) .............................................. 29 Security (2.4GHz) ............................................................................ 31 Wi-Fi Protected Setup – WPS (2.4GHz) ........................................... 32 User Access (2.4GHz) ...................................................................... 33 Wireless Coverage Controls (2.4GHz) ............................................. 34 Access Schedule (2.4GHz) ............................................................... 34 Advanced Settings (2.4GHz) ........................................................... 36 BOOSTBAND™ TECHNOLOGY ..................................................... 38 NETWORK SETTINGS.................................................................. 39 IP Settings ....................................................................................... 39 Wired Port Routing ......................................................................... 41 MANAGEMENT FEATURES ......................................................... 42 Device Status .................................................................................. 43 Network Statistics........................................................................... 45 System Clock ................................................................................... 46 System Logs .................................................................................... 47 Upgrade Firmware ......................................................................... 48 Save/Reload Settings ...................................................................... 50 Password Settings .......................................................................... 51 TECHNICAL SPECIFICATIONS....................................................... 51 DEFAULT SETTINGS .................................................................... 53 TROUBLESHOOTING AND SUPPORT INFORMATION .................... 54 WARRANTY AND REGULARTORY INFORMATION ........................ 68 LEGAL NOTICES & DISCLAIMERS ................................................. 76 RE1750A USER’S GUIDE 2 2 INTRODUCTION Thank you for purchasing this Amped Wireless product. At Amped Wireless we strive to provide you with the highest quality products through innovation and advanced technology. We pride ourselves on delivering products that outperform and go beyond your expectations. If you have any questions please feel free to contact us. We’d love to hear from you and thank you for your support! Email: [email protected] Call: 888-573-8830 Web: www.ampedwireless.com RE1750A USER’S GUIDE 3 3 GETTING STARTED Package Contents Check to make sure you have all the contents within your package:  High Power AC1750 Wi-Fi Range Extender  3 x Detachable High Gain Antennas  Power Adapter  Setup Guide  CD: User’s Guide, Installation Video, Setup Guide, Wi-Fi Analytics Android App RE1750A USER’S GUIDE 4 4 LED Indicators, Ports & Buttons Power: Indicates when the Range Extender is powered on. The LED will remain on. WPS: Blinks when Wi-Fi Protected Setup (WPS) is activated and the Range Extender awaits a connection. 5.0GHz Wireless Activity: Blinks rapidly when wireless data traffic is transmitted or received over the 5GHz wireless network. 2.4GHz Wireless Activity: Blinks rapidly when wireless data traffic is transmitted or received over the 2.4GHz wireless network. Internet Connection: Indicates when the Range Extender is connected to the Internet. The LED will blink rapidly when Internet traffic is transmitted or received. Gigabit Wired Ports 1-4: Indicates when a networking device is connec…

Text truncated - open the document above for the full version.

Registration number: W6D21504-14946-FCC FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 2 of 16 External Photos Registration number: W6D21504-14946-FCC FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 3 of 16 Registration number: W6D21504-14946-FCC FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 4 of 16 Registration number: W6D21504-14946-FCC FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 5 of 16 Registration number: W6D21504-14946-FCC FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 6 of 16 Registration number: W6D21504-14946-FCC FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 7 of 16 Registration number: W6D21504-14946-FCC FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 8 of 16 Registration number: W6D21504-14946-FCC FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 9 of 16

Registration number: W6D21504-14946-FCC FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 10 of 16 Internal Photos Registration number: W6D21504-14946-FCC FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 11 of 16 Registration number: W6D21504-14946-FCC FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 12 of 16

Registration number: W6D21504-14946-C-1 FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Page 34 of 96 3.2 Equivalent isotropic radiated power FCC Rule: 15.247(b)(3) For systems using digital modulation in the 2.4 GHz – 2.4835 GHz bands: 1 Watt. The conducted output power limit specified in paragraph (b) of this section is based on the use of antennas with directional gains that do not exceed 6dBi. Except as shown in paragraph (c) of this section, if transmitting antennas of directional gain greater than 6 dBi are used, the conducted output power from the intentional radiator shall be reduced below the stated values in paragraphs (b)(1), (b)(2), and (b)(3) of this section, as appropriate, by the amount in dB that the directional gain of the antenna exceeds 6 dBi. Test equipment used: ETSTW-RE 055 3.3 RF Exposure Compliance Requirements Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.25 m normally can be maintained between the user and the device. FCC OET Bulletin 65 Edition 97.01 determines the equations for predicting RF fields and applicable limits. The prediction for power density in the far-field but will over-predict power density in the near field, where it could be used for walking a “worst case” or conservative prediction. PG S = --------- 4πR 2 S – Power Density P – Output power ERP R – Distance D – Cable Loss AG – Antenna Gain Item Unit Value Remarks P mW 429.53 Peak value D dB AG dBi 9.77 G 9.4842 Calculated Value R cm 20 Assumed value S mW/cm 2 0.8104 Calculated value Limits: Limit for General Population / Uncontrolled Exposure Frequency (MHz) Power Density (mW/cm 2 ) 1500 – 100.000 1.0 Registration number: W6D21504-14946-C-54 FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Page 107 of 113 3.8 Equivalent isotropic radiated power, FCC 15.407 (f) FCC Rule: 15.407(b)(3) For systems using digital modulation in the 5.725 GHz-5.850 GHz bands: 1 Watt. The conducted output power limit specified in paragraph (b) of this section is based on the use of antennas with directional gains that do not exceed 6dBi. Except as shown in paragraph (c) of this section, if transmitting antennas of directional gain greater than 6 dBi are used, the conducted output power from the intentional radiator shall be reduced below the stated values in paragraphs (b)(1), (b)(2), and (b)(3) of this section, as appropriate, by the amount in dB that the directional gain of the antenna exceeds 6 dBi. Test equipment used: ETSTW-RE 055 3.9 RF Exposure Compliance Requirements ystems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.25 m normally can be maintained between the user and the device. FCC OET Bulletin 65 Edition 97.01 determines the equations for predicting RF fields and applicable limits. The prediction for power density in the far-field but will over-predict power density in the near field, where it could be used for walking a “worst case” or conservative prediction. PG S = --------- 4πR 2 S – Power Density P – Output power ERP R – Distance D – Cable Loss AG – Antenna Gain Band 1 Item Unit Value Remarks P mW 281.8383 Peak value D dB AG dBi 9.77 G 9.4842 Calculated Value R cm 20 Assumed value S mW/cm2 0.5318 Calculated value Band 4 Item Unit Value Remarks P mW 100 Peak value D dB AG dBi 9.77 G 9.4842 Calculated Value R cm 20 Assumed value S mW/cm2 0.1887 Calculated value

of Applicant: Amped Wireless Address: 13089 Peyton Dr. #C307 Chino Hills, California 91709 United State Tested and Prepared by Worldwide Testing Services (Taiwan) Co., Ltd. FCC Registration No.: 930600 Industry Canada filed test laboratory Reg. No. IC 5679A-1, IC 5107A-1 A2LA Accredited No.: 2732.01 Report No.: W6D21504-14946-C-54 6F, NO. 58, LANE 188, RUEY-KUANG RD., NEIHU TAIPEI 114, TAIWAN, R.O.C. TEL: 886-2-66068877 FAX: 886-2-66068879 E-mail: [email protected] FCC PART 15 SUBPART E TEST REPORT For High Power AC1750 Wi-Fi Range Extender Model No.: RE1750A FCC ID: ZTT-RE1750A Registration number: W6D21504-14946-C-54 FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Page 1 of 113 TABLE OF CONTENTS 1 GENERAL INFORMATION ..........................................................................................................2 1.1 N OTES..........................................................................................................................................2 1.2 TESTING LABORATORY................................................................................................................3 1.2.1 Location ..............................................................................................................................3 1.2.2 Details of accreditation status ............................................................................................3 1.3 D ETAILS OF APPROVAL HOLDER...................................................................................................3 1.4 APPLICATION DETAILS.................................................................................................................4 1.5 G ENERAL INFORMATION OF TEST ITEM........................................................................................4 1.6 T EST STANDARDS.........................................................................................................................9 2 TECHNICAL TEST .......................................................................................................................10 2.1 SUMMARY OF TEST RESULTS......................................................................................................10 2.2 TEST ENVIRONMENT..................................................................................................................10 2.3 TEST EQUIPMENT LIST...............................................................................................................11 2.4 TEST PROCEDURE......................................................................................................................13 3 TEST RESULTS (ENCLOSURE) ................................................................................................16 3.1 P EAK TRANSMIT POWER, FCC 15.407 (A) .................................................................................17 3.2 26DB EMISSION BANDWIDTH, 99% OCCUPIED BANDWIDTH, FCC 15.407 (A) ...........................46 3.3 6DB EMISSION BANDWIDTH, 99% OCCUPIED BANDWIDTH, FCC 15.407 (A) .............................60 3.3 PEAK POWER SPECTRAL DENSITY, FCC 15.407 (A) ..................................................................74 3.4 UNDESIRABLE EMISSION LIMITS, FCC 15.407 (B) ....................................................................104 3.5 A UTOMATIC DISCONTINUATION OF TRANSMISSION, FCC 15.407 (C).......................................106 3.6 R ESERVED, FCC 15.407 (D).....................................................................................................106 3.7 INDOOR OPERATION RESTRICTION, FCC 15.407 (E) ................................................................106 3.8 E QUIVALENT ISOTROPIC RADIATED POWER, FCC 15.407 (F) ...................................................107 3.9 RF EXPOSURE COMPLIANCE REQUIREMENTS..........................................................................107 3.10 T RANSMIT POWER CONTROL (TPC) ........................................................................................108 3.11 RADIATED EMISSIONS FROM RECEIVER PART..........................................................................109 3.12 POWER LINE CONDUCTED EMISSION.......................................................................................110 Registration number: W6D21504-14946-C-54 FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Page 2 of 113 1 General Information 1.1 Notes The purpose of conformity testing is to increase the probability of adherence to the essential requirements or conformity specifications, as appropriate. The complexity of the technical specifications, however, means that full and thorough testing is impractical for both technical and economic reasons. Furthermore, there is no guarantee that a test sample which has passed all the relevant tests conforms to a specification. Neither is there any guarantee that such a test sample will interwork with other genuinely open systems. The existence of the tests nevertheless provides the confidence that the test sample possesses the qualities as maintained and that is performance generally conforms to representative cases of communications equipment. The test results of this test report relate exclusively to the item tested as specified in 1.5. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the Worldwide Testing Services(Taiwan) Co., Ltd. Specific Conditions: Usage of the hereunder tested device in combination with other integrated or external antennas requires at least additional output power measurements, spurious emission measurements, conducted emission measurements (AC supply lines) and radio frequency exposure evaluations for each individual configuration performed, for certification by FCC. Tester: April 22, 2015 Rick Chen Date WTS-Lab. Name Signature Technical responsibility for area of testing: April 22, 2015 Kevin Wang Date WTS Name Sign…

Text truncated - open the document above for the full version.

Registration number: W6D21504-14946-C-54 FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Page 46 of 113 3.2 26dB emission bandwidth, 99% Occupied Bandwidth, FCC 15.407 (a) According to §15.407(a). No Limit required. Band 1 ANT0 Registration number: W6D21504-14946-C-54 FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Page 47 of 113 Registration number: W6D21504-14946-C-54 FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Page 48 of 113 Registration number: W6D21504-14946-C-54 FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Page 49 of 113 Registration number: W6D21504-14946-C-54 FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Page 50 of 113 Registration number: W6D21504-14946-C-54 FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Page 51 of 113 ANT1 A Att 25 dB * Offset 11 dB LVL Ref 25 dBm Center 5.18 GHzSpan 60 MHz6 MHz/ * * 3DB RBW 300 kHz VBW 1 MHz SWT 20 ms 1 PK VIEW -70 -60 -50 -40 -30 -20 -10 0 10 20 1 Marker 1 [T1 ] -12.54 dB m 5.191400000 GHz 2 Marker 2 [T1 ] 13.92 dB m 5.177211538 GHz 1 Delta 1 [T1 ] -0.74 dB -23.136000000 MHz OBW 17.019230769 MHz T1 Temp 1 [T1 OBW] 5.94 dB m 5.171442308 GHz T2 Temp 2 [T1 OBW] 5.09 dB m 5.188461538 GHz D1 -12.082 dBm 99% OBW & 26DB BANDWIDTH ANT1_11a_CH36 Date: 2.APR.2015 14:16:09 A Att 25 dB * Offset 11 dB LVL Ref 25 dBm Center 5.2 GHzSpan 60 MHz6 MHz/ * * 3DB RBW 300 kHz VBW 1 MHz SWT 20 ms 1 PK VIEW -70 -60 -50 -40 -30 -20 -10 0 10 20 1 Marker 1 [T1 ] -14.08 dB m 5.211900000 GHz 2 Marker 2 [T1 ] 14.18 dB m 5.203461538 GHz 1 Delta 1 [T1 ] 1.36 dB -23.136000000 MHz OBW 16.923076923 MHz T1 Temp 1 [T1 OBW] 6.05 dB m 5.191442308 GHz T2 Temp 2 [T1 OBW] 6.06 dB m 5.208365385 GHz D1 -11.823 dBm 99% OBW & 26DB BANDWIDTH ANT1_11a_CH40 Date: 2.APR.2015 14:17:42 Registration number: W6D21504-14946-C-54 FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Page 52 of 113 A Att 25 dB * Offset 11 dB LVL Ref 25 dBm Center 5.24 GHzSpan 60 MHz6 MHz/ * * 3DB RBW 300 kHz VBW 1 MHz SWT 20 ms 1 PK VIEW -70 -60 -50 -40 -30 -20 -10 0 10 20 1 Marker 1 [T1 ] -12.56 dB m 5.251500000 GHz 2 Marker 2 [T1 ] 14.81 dB m 5.235288462 GHz 1 Delta 1 [T1 ] 2.50 dB -22.560000000 MHz OBW 16.923076923 MHz T1 Temp 1 [T1 OBW] 6.86 dB m 5.231442308 GHz T2 Temp 2 [T1 OBW] 6.77 dB m 5.248365385 GHz D1 -11.186 dBm 99% OBW & 26DB BANDWIDTH ANT1_11a_CH48 Date: 2.APR.2015 14:19:21 A Att 25 dB * Offset 11 dB LVL Ref 25 dBm Center 5.18 GHzSpan 60 MHz6 MHz/ * * 3DB RBW 300 kHz VBW 1 MHz SWT 20 ms 1 PK VIEW -70 -60 -50 -40 -30 -20 -10 0 10 20 1 Marker 1 [T1 ] -14.42 dB m 5.191600000 GHz 2 Marker 2 [T1 ] 11.77 dB m 5.183173077 GHz 1 Delta 1 [T1 ] 1.27 dB -22.944000000 MHz OBW 18.076923077 MHz T1 Temp 1 [T1 OBW] 3.29 dB m 5.170865385 GHz T2 Temp 2 [T1 OBW] 3.43 dB m 5.188942308 GHz D1 -14.227 dBm 99% OBW & 26DB BANDWIDTH ANT1_11n20_CH36 Date: 2.APR.2015 14:54:33 Registration number: W6D21504-14946-C-54 FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Page 53 of 113 A Att 25 dB * Offset 11 dB LVL Ref 25 dBm Center 5.2 GHzSpan 60 MHz6 MHz/ * * 3DB RBW 300 kHz VBW 1 MHz SWT 20 ms 1 PK VIEW -70 -60 -50 -40 -30 -20 -10 0 10 20 1 Marker 1 [T1 ] -13.72 dB m 5.211600000 GHz 2 Marker 2 [T1 ] 11.60 dB m 5.203846154 GHz 1 Delta 1 [T1 ] -1.00 dB -23.232000000 MHz OBW 18.076923077 MHz T1 Temp 1 [T1 OBW] 3.50 dB m 5.190865385 GHz T2 Temp 2 [T1 OBW] 3.25 dB m 5.208942308 GHz D1 -14.399 dBm 99% OBW & 26DB BANDWIDTH ANT1_11n20_CH40 Date: 2.APR.2015 14:52:32 A Att 25 dB * Offset 11 dB LVL Ref 25 dBm Center 5.24 GHzSpan 60 MHz6 MHz/ * * 3DB RBW 300 kHz VBW 1 MHz SWT 20 ms 1 PK VIEW -70 -60 -50 -40 -30 -20 -10 0 10 20 1 Marker 1 [T1 ] -16.17 dB m 5.251800000 GHz 2 Marker 2 [T1 ] 12.26 dB m 5.233846154 GHz 1 Delta 1 [T1 ] 2.35 dB -23.424000000 MHz OBW 18.076923077 MHz T1 Temp 1 [T1 OBW] 4.11 dB m 5.230865385 GHz T2 Temp 2 [T1 OBW] 3.97 dB m 5.248942308 GHz D1 -13.738 dBm 99% OBW & 26DB BANDWIDTH ANT1_11n20_CH48 Date: 2.APR.2015 14:51:15 Registration number: W6D21504-14946-C-54 FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Page 54 of 113 A Att 25 dB * Offset 11 dB LVL Ref 25 dBm Center 5.19 GHzSpan 120 MHz12 MHz/ * * 3DB RBW 500 kHz VBW 2 MHz SWT 20 ms 1 PK VIEW -70 -60 -50 -40 -30 -20 -10 0 10 20 1 Marker 1 [T1 ] -15.28 dB m 5.212400000 GHz 2 Marker 2 [T1 ] 10.65 dB m 5.195000000 GHz 1 Delta 1 [T1 ] 0.13 dB -44.736000000 MHz OBW 36.730769231 MHz T1 Temp 1 [T1 OBW] 4.65 dB m 5.171538462 GHz T2 Temp 2 [T1 OBW] 4.92 dB m 5.208269231 GHz D1 -15.351 dBm 99% OBW & 26DB BANDWIDTH ANT1_11n40_CH38 Date: 9.APR.2015 10:16:27 A Att 25 dB * Offset 11 dB LVL Ref 25 dBm Center 5.23 GHzSpan 120 MHz12 MHz/ * * 3DB RBW 500 kHz VBW 2 MHz SWT 20 ms 1 PK VIEW -70 -60 -50 -40 -30 -20 -10 0 10 20 1 Marker 1 [T1 ] -15.51 dB m 5.252800000 GHz 2 Marker 2 [T1 ] 11.04 dB m 5.242307692 GHz 1 Delta 1 [T1 ] 0.98 dB -45.504000000 MHz OBW 36.730769231 MHz T1 Temp 1 [T1 OBW] 5.14 dB m 5.211538462 GHz T2 Temp 2 [T1 OBW] 5.09 dB m 5.248269231 GHz D1 -14.962 dBm 99% OBW & 26DB BANDWIDTH ANT1_11n40_CH46 Date: 9.APR.2015 10:19:29 Registration number: W6D21504-14946-C-54 FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Page 55 of 113 A Att 25 dB * Offset 11 dB LVL Ref 25 dBm Center 5.2 GHzSpan 200 MHz20 MHz/ * * 3DB RBW 1 MHz VBW 3 MHz SWT 20 ms 1 PK VIEW -70 -60 -50 -40 -30 -20 -10 0 10 20 1 Marker 1 [T1 ] -15.22 dB m 5.243700000 GHz 2 Marker 2 [T1 ] 8.84 dB m 5.207051282 GHz 1 Delta 1 [T1 ] -3.57 dB -88.000000000 MHz OBW 76.282051282 MHz T1 Temp 1 [T1 OBW] 3.99 dB m 5.161858974 GHz T2 Temp 2 [T1 OBW] 5.33 dB m 5.238141026 GHz D1 -17.164 dBm 99% OBW & 26DB BANDWIDTH ANT1_11ac80_CH40 Date: 2.APR.2015 15:36:04 ANT2 A Att 25 dB * Offset 11 dB LVL Ref 25 dBm Center 5.18 GHzSpan 60 MHz6 MHz/ * * 3DB RBW 300 kHz VBW 1 MHz SWT 20 ms 1 PK VIEW -70 -60 -50 -40 -30 -20 -10 0 10 20 1 Marker 1 [T1 ] -11.65 dB m 5.191200000 GHz 2 Marker 2 [T1 ] 13.93 dB m 5.177884615 GHz 1 Delta 1 [T1 ] 0.82 dB -22.368000000 MHz O…

Text truncated - open the document above for the full version.

Registration number: W6D21504-14946-C-54 FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Page 90 of 113 A Att 25 dB ** Offset 11 dB LVL Ref 30 dBm 3DB RBW 500 kHz * * VBW 2 MHz SWT 100 ms * Center 5.745 GHzSpan 50 MHz5 MHz/ * 1 RM AVG -70 -60 -50 -40 -30 -20 -10 0 10 20 30 SWP 100 of 100 1 Marker 1 [T1 ] 7.70 dBm 5.747500000 GHz POWER DENSITY CDD ANT0_VHT20CH149 Date: 25.NOV.2014 22:12:16 A Att 25 dB ** Offset 11 dB LVL Ref 30 dBm 3DB RBW 500 kHz * * VBW 2 MHz SWT 100 ms * Center 5.785 GHzSpan 50 MHz5 MHz/ * 1 RM AVG -70 -60 -50 -40 -30 -20 -10 0 10 20 30 SWP 100 of 100 1 Marker 1 [T1 ] 7.35 dBm 5.791200000 GHz POWER DENSITY CDD ANT0_VHT20CH157 Date: 25.NOV.2014 22:17:24 Registration number: W6D21504-14946-C-54 FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Page 91 of 113 A Att 25 dB ** Offset 11 dB LVL Ref 30 dBm 3DB RBW 500 kHz * * VBW 2 MHz SWT 100 ms * Center 5.825 GHzSpan 50 MHz5 MHz/ * 1 RM AVG -70 -60 -50 -40 -30 -20 -10 0 10 20 30 SWP 100 of 100 1 Marker 1 [T1 ] 7.82 dBm 5.822400000 GHz POWER DENSITY CDD ANT0_VHT20CH165 Date: 25.NOV.2014 22:20:40 A Att 25 dB ** Offset 11 dB LVL Ref 30 dBm 3DB RBW 500 kHz * * VBW 2 MHz SWT 100 ms * Center 5.755 GHzSpan 70 MHz7 MHz/ * 1 RM AVG -70 -60 -50 -40 -30 -20 -10 0 10 20 30 SWP 100 of 100 1 Marker 1 [T1 ] 4.76 dBm 5.743660000 GHz POWER DENSITY CDD ANT0_VHT40CH151 Date: 25.NOV.2014 23:26:03 Registration number: W6D21504-14946-C-54 FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Page 92 of 113 A Att 25 dB ** Offset 11 dB LVL Ref 30 dBm 3DB RBW 500 kHz * * VBW 2 MHz SWT 100 ms * Center 5.795 GHzSpan 70 MHz7 MHz/ * 1 RM AVG -70 -60 -50 -40 -30 -20 -10 0 10 20 30 SWP 100 of 100 1 Marker 1 [T1 ] 4.57 dBm 5.787300000 GHz POWER DENSITY CDD ANT0_VHT40CH159 Date: 25.NOV.2014 23:30:43 Registration number: W6D21504-14946-C-54 FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Page 93 of 113 ANT1 Registration number: W6D21504-14946-C-54 FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Page 94 of 113 Registration number: W6D21504-14946-C-54 FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Page 95 of 113 Registration number: W6D21504-14946-C-54 FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Page 96 of 113 Registration number: W6D21504-14946-C-54 FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Page 97 of 113 ANT2 Registration number: W6D21504-14946-C-54 FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Page 98 of 113 Registration number: W6D21504-14946-C-54 FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Page 99 of 113 Registration number: W6D21504-14946-C-54 FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Page 100 of 113 Registration number: W6D21504-14946-C-54 FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Page 101 of 113 Registration number: W6D21504-14946-C-54 FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Page 102 of 113 Band 1 mW dBm ANT0 Ch Low Ch Mid Ch High Ch Low Ch Mid Ch High 802.11n 20MHz 6.577 5.715 6.026 8.18 7.57 7.80 802.11n 40MHz 3.357 -- 3.266 5.26 -- 5.14 802.11ac 0.662 -- -- -1.79 -- -- mW dBm ANT1 Ch Low Ch Mid Ch High Ch Low Ch Mid Ch High 802.11n 20MHz 5.821 5.957 7.079 7.65 7.75 8.50 802.11n 40MHz 2.972 -- 3.388 4.73 -- 5.3 802.11ac 0.685 -- -- -1.64 -- -- mW dBm ANT2 Ch Low Ch Mid Ch High Ch Low Ch Mid Ch High 802.11n 20MHz 6.486 7.096 7.379 8.12 8.51 8.68 802.11n 40MHz 3.214 -- 3.681 5.07 -- 5.66 802.11ac 0.628 -- -- -2.02 -- -- mW dBm Combine Ch Low Ch Mid Ch High Ch Low Ch Mid Ch High 802.11n 20MHz 18.884 18.768 20.484 12.76 12.73 13.11 802.11n 40MHz 9.543 -- 10.335 9.80 -- 10.14 802.11ac 1.975 -- -- 2.96 -- -- Registration number: W6D21504-14946-C-54 FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Page 103 of 113 Band 4 mW dBm ANT0 Ch Low Ch Mid Ch High Ch Low Ch Mid Ch High 802.11n 20MHz 5.888 5.433 6.053 7.70 7.35 7.82 802.11n 40MHz 2.992 -- 2.864 4.76 -- 4.57 802.11ac 0.535 -- -- -2.72 -- -- mW dBm ANT1 Ch Low Ch Mid Ch High Ch Low Ch Mid Ch High 802.11n 20MHz 6.855 5.808 5.346 8.36 7.64 7.28 802.11n 40MHz 3.524 -- 2.958 5.47 -- 4.71 802.11ac 0.589 -- -- -2.30 -- -- mW dBm ANT2 Ch Low Ch Mid Ch High Ch Low Ch Mid Ch High 802.11n 20MHz 6.266 6.223 5.848 7.97 7.94 7.67 802.11n 40MHz 3.236 -- 3.192 5.10 -- 5.04 802.11ac 0.585 -- -- -2.33 -- -- mW dBm Combine Ch Low Ch Mid Ch High Ch Low Ch Mid Ch High 802.11n 20MHz 19.009 17.464 17.247 12.79 12.42 12.37 802.11n 40MHz 9.752 -- 9.014 9.89 -- 9.55 802.11ac 1.709 -- -- 2.33 -- -- Test equipment used: ETSTW-RE 055, ETSTW-RE 050 Registration number: W6D21504-14946-C-54 FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Page 104 of 113 3.4 Undesirable emission limits, FCC 15.407 (b) 1. For transmitters operating in the 5.15–5.25 GHz band: all emissions out-side of the 5.15–5.35 GHz band shall not exceed an EIRP of –27 dBm/MHz. 2. For transmitters operating in the 5.25–5.35 GHz band: all emissions out-side of the 5.15–5.35 GHz band shall not exceed an EIRP of –27 dBm/MHz. De-vices operating in the 5.25–5.35 GHz band that generate emissions in the 5.15–5.25 GHz band must meet all appli-cable technical requirements for operation in the 5.15–5.25 GHz band (including indoor use) or alternatively meet an out-of-band emission EIRP limit of -27 dBm/MHz in the 5.15–5.25 GHz band. 3. For transmitters operating in the 5.47–5.725 GHz band: all emissions out-side of the 5.47–5.725 GHz band shall not exceed an EIRP of -27 dBm/MHz. 4. For transmitters operating in the 5.725–5.825 GHz band: all emissions within the frequency range from the band edge to 10 MHz above or below the band edge shall not exceed an EIRP of -17 dBm/MHz; for frequencies 10 MHz or greater above or below the band edge, emissions shall not exceed an EIRP of -27 dBm/MHz. 5. The emission measurements shall be performed using a minimum resolution bandwidth of 1 MHz. A lower resolution ba…

Text truncated - open the document above for the full version.

Registration number: W6D21504-14946-C-54 FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Measurement diagrams Spurious Emissions radiated Registration number: W6D21504-14946-C-54 FCC ID: ZTT-RE1750A Worldwide Testing Services(Taiwan) Co., Ltd. Band 1 (ANT0) (a) Operator: Temperature:24 °C File :1Data :#1Date: 2015/3/22 Radiated Emission Measurement Address:6F.,No.58,Ln 188,Ruey Kuang Rd,Neihu,Taipei Leon Tel:+886-2-6606-8877 Fax:+886-2-6606-8875 Humidity:60 % Time: 上午 07:45:30 Condition : EUT : M/N: Note : TX 802.11a CH36 FCC_part 15 RE-Class E_30-1000MHz W6M21410-14564-R1 Test Mode : Polarization: Hori…
