ZTT-SR10000-2High Power Wireless-N 600mW Range Extender

SR10000-CA High Power Wireless-N 600mW Range Extender Rev 1.1 User’s Guide SR10000 USER’S GUIDE 1 CONTENTS INTRODUCTION ........................................................... 2 GETTING STARTED ....................................................... 3 Package Contents ........................................................... 3 LED Indicators ................................................................. 4 Back Panel Description ................................................... 5 SETUP GUIDE .................................................................. 6 Welcome to the Dashboard ............................................ 9 Scan for a Home Network to Extend............................. 10 Connecting to a Secure Network .................................. 11 Extended Network Settings .......................................... 12 Connect to the new Extended Network........................ 14 Setup Summary ............................................................. 15 WI-FI SETTINGS.......................................................... 17 Home Network Settings ................................................ 17 Extended Network Settings .......................................... 19 Security ......................................................................... 21 Advanced Settings ......................................................... 23 SMART FEATURES ......................................................25 Access Schedule ............................................................ 26 User Access Control ...................................................... 27 Wi-Fi Coverage Controls ............................................... 28 IP SETTINGS ...............................................................29 MANAGEMENT FEATURES .........................................31 Device Status................................................................. 32 Statistics ........................................................................ 34 System Clock ................................................................. 35 System Logs .................................................................. 36 Upgrade Firmware ........................................................ 37 Save and Reload Settings .............................................. 38 Password Settings ......................................................... 39 TECHNICAL SPECIFICATIONS .......................................40 DEFAULT SETTINGS ....................................................41 TROUBLESHOOTING ...................................................42 WARRANTY / REGULATORY INFORMATION ...............51 SR10000 USER’S GUIDE 2 INTRODUCTION Thank you for purchasing this Amped Wireless product. At Amped Wireless we strive to provide you with the highest quality products through innovation and advanced technology. We pride ourselves on delivering products that outperform the competition and go beyond your expectations. If you have any questions please feel free to contact us. We’d love to hear from you and thank you for your support! Email: [email protected] Call: 888-573-8830 Web: www.ampedwireless.com SR10000 USER’S GUIDE 3 GETTING STARTED Package Contents Check to make sure you have all the contents within your package:  High Power 600mW Wi-Fi Range Extender  Two Detachable 5dBi High Gain Antennas  Setup Guide  CD: User’s Manual, Installation Video  Vertical Mounting Base SR10000 USER’S GUIDE 4 LED Indicators (From Top to Bottom) Power: Indicates when the High Power Range Extender is powered on. The LED will stay lit when power adapter is plugged into Range Extender. Wireless Activity: Blinks rapidly when wireless data traffic is passing through the Range Extender. When there is a problem with the Wi-Fi connection this LED will remain off or blink steadily. Wired Devices (1-5): Indicates when a networking device is connected to a wired port on the back of the High Power Range Extender. The LED blinks rapidly when wired data traffic is transmitted or received. WPS: Wi-Fi Protected Setup activity. When the WPS mode is activated the WPS LED blinks as it awaits a connection. SR10000 USER’S GUIDE 5 Back Panel Description Antenna Connectors (1-2): RJ-SMA antenna connectors. Compatible with all antennas that have RP-SMA connectors. Upgradable to high gain antennas for more range. Reset: Push down once to reboot the High Power Range Extender. Hold down for 5-10 seconds to reset the Range Extender back to factory settings. WPS: Hold down for 3 seconds to enable WPS push button configuration. Wired Devices: RJ-45 ports for connecting wired computers or network devices. Power: Power adapter port. DC 12V 1A. SR10000 USER’S GUIDE 6 6 SETUP GUIDE Find a Setup Location The location of where you install the Range Extender is very important to how it will function. The optimal setup location should be somewhere no more than halfway between your Wi-Fi router and your Wi-Fi dead zone. SR10000 USER’S GUIDE 7 7 Connect your PC or Tablet to the Range Extender a. Attach the two included antennas. b. Attach the Power Adapter to the Range Extender’s PWR Port and an available power outlet. c. Connect your PC or Tablet to the Range Extender’s Wi-Fi network: Amped_SR SR10000 USER’S GUIDE 8 8 Open your Web Browser to Access the Setup Wizard a. Open your web browser. b. Type in: http://setup.ampedwireless.com into the web address bar c. If the web menu fails to open, type in the following IP address into your web address bar: http://192.168.1.240 a. Disconnect your PC from all Wi-Fi networks b. Attach an Ethernet cable between the PC and the Range Extender c. Open your web browser and go to http://setup.ampedwireless.com again. SR10000 USER’S GUIDE 9 9 Welcome to the Dashboard The Dashboard will provide you with the current status of the Range Extender. Click SCAN to find an available network to extend. The diagram on this page displays the terms used to describe: 1) The network you are trying to exten…

Text truncated - open the document above for the full version.

Return Loss Frequency (GHz) 2.30 2.35 2.40 2.45 2.50 2.55 2.60 -30-25-20-15-10 -5 0 sleeve dipole Phi 0 ° -30 -25 -20 -15 -10 -5 0 5 10 -30 -25 -20-15-10 -5 05 10 -30 -25 -20-15 -10 -5 05 10 -30 -25-20 -15 -10 -5 05 10 -90 -60 -30 0 30 60 90 120 150 180 210 240 sleeve dipole3 -25 -20 -15 -10 -5 0 5 10 15 -25 -20 -15-10 -5 0 5 10 15 -25 -20 -15-10 -5 0 5 10 15 -25 -20-15 -10 -5 0 5 10 15 -90 -60 -30 0 30 60 90 120 150 180 210 240 sleeve dipole3 Theta 90 ° Efficiency Peak Gain Frequency (GHz) 2.30 2.35 2.40 2.45 2.50 2.55 2.60 Efficiency 0.00.20.40.60.81.0 sleeve dipole5 Frequency (GHz) 2.30 2.35 2.40 2.45 2.50 2.55 2.60 Peak Gain(dBi) -1 012345 sleeve dipole5

CERPASS TECHNOLOGY CORP. Report No.: TEFI1309134 Cerpass Technology Corp.Issued Date:Oct. 17, 2013 Tel:886-2-2655-8100 Fax:886-2-2655-8200Page No.:A1 of A6 FCC ID:ZTT-SR10000-2 Appendix A. Photographs of EUT CERPASS TECHNOLOGY CORP. Report No.: TEFI1309134 Cerpass Technology Corp.Issued Date:Oct. 17, 2013 Tel:886-2-2655-8100 Fax:886-2-2655-8200Page No.:A2 of A6 FCC ID:ZTT-SR10000-2 CERPASS TECHNOLOGY CORP. Report No.: TEFI1309134 Cerpass Technology Corp.Issued Date:Oct. 17, 2013 Tel:886-2-2655-8100 Fax:886-2-2655-8200Page No.:A5 of A6 FCC ID:ZTT-SR10000-2 CERPASS TECHNOLOGY CORP. Report No.: TEFI1309134 Cerpass Technology Corp.Issued Date:Oct. 17, 2013 Tel:886-2-2655-8100 Fax:886-2-2655-8200Page No.:A6 of A6 FCC ID:ZTT-SR10000-2

Label & Location

CERPASS TECHNOLOGY CORP. Report No.: TEII1309134 Cerpass Technology Corp.Issued Date:Oct. 17, 2013 Tel:886-2-2655-8100 Fax:886-2-2655-8200Page No.:A3 of A6 IC ID:10233A-SR100002 CERPASS TECHNOLOGY CORP. Report No.: TEII1309134 Cerpass Technology Corp.Issued Date:Oct. 17, 2013 Tel:886-2-2655-8100 Fax:886-2-2655-8200Page No.:A4 of A6 IC ID:10233A-SR100002 CERPASS TECHNOLOGY CORP. Report No.: TEII1309134 Cerpass Technology Corp.Issued Date:Oct. 17, 2013 Tel:886-2-2655-8100 Fax:886-2-2655-8200Page No.:A5 of A6 IC ID:10233A-SR100002

CERPASS TECHNOLOGY CORP. Report No.: TEFI1309134 Cerpass Technology Corp.Issued date:Oct. 17, 2013 Tel: 886-2-2655-8100 Fax: 886-2-2655-8200Page No.:1 of 4 FCC ID:ZTT-SR10000-2 Radio Frequency Exposure LIMIT According to §15.247(i), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission's guidelines. See § 1.1307(b)(1) of this chapter. EUT Specification EUTHigh Power Wireless-N 600mW Gigabit Dual Band Router Frequency band (Operating) WLAN: 2.412GHz ~ 2.462GHz WLAN: 5.150GHz ~ 5.250GHz WLAN: 5.725GHz ~ 5.850GHz Bluetooth: 2.402GHz ~ 2.480 GHz Device category Portable (<20cm separation) Mobile (>20cm separation) Exposure classification Occupational/Controlled exposure (S = 5mW/cm 2 ) General Population/Uncontrolled exposure (S=1mW/cm 2 ) Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power 802.11b:27.77dBm (598.61mW) 802.11g:27.83dBm (606.78mW) 802.11n (20MHz):27.93dBm (620.82mW) 802.11n (40MHz):27.86dBm (611.01mW) Antenna gain (Max)802.11b/g/n: 5 dBi Evaluation applied MPE Evaluation* SAR Evaluation N/A Remark: 1. The maximum output power is 27.93 dBm (620.82 mW)at 2412MHz(withnumeric 5.0 antenna gain.) 2. DTS device is not subject to routine RF evaluation; MPE estimate is used to justify the compliance. 3. For mobile or fixed location transmitters, no SAR consideration applied. The maximum power density is 1.0 mW/cm 2 even if the calculation indicates that the power density would be larger. CERPASS TECHNOLOGY CORP. Report No.: TEFI1309134 Cerpass Technology Corp.Issued date:Oct. 17, 2013 Tel: 886-2-2655-8100 Fax: 886-2-2655-8200Page No.:2 of 4 FCC ID:ZTT-SR10000-2 TEST RESULTS No non-compliance noted. Calculation Given d GP E   30 & 3770 2 E S WhereE = Field strength in Volts / meter P = Power in Watts G = Numeric antenna gain d = Distance in meters S = Power density in milliwatts / square centimeter Combining equations and re-arranging the terms to express the distance as a function of the remaining variables yields: 2 3770 30 d GP S   Changing to units of mW and cm, using: P (mW) = P (W) / 1000 and d (cm) = d(m) / 100 Yields   2 2 0796.0 100/3770 1000/30 d GP d GP S     Equation 1 Whered = Distance in cm P = Power in mW G = Numeric antenna gain S = Power density in mW / cm 2 CERPASS TECHNOLOGY CORP. Report No.: TEFI1309134 Cerpass Technology Corp.Issued date:Oct. 17, 2013 Tel: 886-2-2655-8100 Fax: 886-2-2655-8200Page No.:3 of 4 FCC ID:ZTT-SR10000-2 Maximum Permissible Exposure ANT A Modulation Mode Frequency band (MHz) Max. Conducted output power(dBm) Antenna gain (dBi) Distance (cm) Power density (mW/cm2) Limit (mW/cm2) 802.11b2412-246224.915.0200.1951 802.11g2412-246224.815.0200.1901 802.11n (20MHz)2412-246224.725.0200.1871 802.11n (40MHz)2422-245224.815.0200.1901 ANT B Modulation Mode Frequency band (MHz) Max. Conducted output power(dBm) Antenna gain (dBi) Distance (cm) Power density (mW/cm2) Limit (mW/cm2) 802.11b2412-246224.695.0200.1851 802.11g2412-246224.835.0200.1911 802.11n (20MHz)2412-246224.665.0200.1841 802.11n (40MHz)2422-245224.925.0200.1951 CERPASS TECHNOLOGY CORP. Report No.: TEFI1309134 Cerpass Technology Corp.Issued date:Oct. 17, 2013 Tel: 886-2-2655-8100 Fax: 886-2-2655-8200Page No.:4 of 4 FCC ID:ZTT-SR10000-2 ANT A+B Modulation Mode Frequency band (MHz) Max. Conducted output power(dBm) Antenna gain (dBi) Distance (cm) Power density (mW/cm2) Limit (mW/cm2) 802.11b2412-246227.775.0200.3761 802.11g2412-246227.835.0200.3821 802.11n (20MHz)2412-246227.935.0200.3911 802.11n (40MHz)2422-245227.865.0200.3841 NOTE: Total (Chain0+Chain1) , the formula of calculated the MPE is: CPD1 / LPD1 + CPD2 / LPD2 + ......etc. < 1 CPD = Calculation power density LPD = Limit of power density

CERPASS TECHNOLOGY CORP. Report No.: TEFI1309134 Cerpass Technology Corp.Issued date:Oct. 17, 2013 Tel:886-2-2655-8100 Fax:886-2-2655-8200Page No.:1 of 108 FCC ID:ZTT-SR10000-2 FCC TEST REPORT According to FCC Rules and Regulations Part 15 Subpart C Applicant:Amped Wireless Address:13089 Peyton Dr. #C307 Chino Hills CA 91709 Equipment:High Power Wireless-N 600mW Range Extender Model No.:SR10000 Trade Name:Amped Wireless FCC ID:ZTT-SR10000-2 The test result refers exclusively to the test presented test model / sample., Without written approval ofCerpass Technology Corp.,the test report shall not be reproduced except in full. The EUT is also considered as a kind of computer peripheral, because the connection to computer is necessary for typical use. It has been verified to comply with the requirements of FCC Part 15, Subpart B, Class B (DoC). The test report has been issued separately. CERPASS TECHNOLOGY CORP. Report No.: TEFI1309134 Cerpass Technology Corp.Issued date:Oct. 17, 2013 Tel:886-2-2655-8100 Fax:886-2-2655-8200Page No.:2 of 108 FCC ID:ZTT-SR10000-2 Contents 1.Report of Measurements and Examinations ....................................................................................6 1.1List of Measurements and Examinations ...................................................................................6 2.Test Configuration of Equipment under Test ...................................................................................7 2.1Feature of Equipment under Test...............................................................................................7 2.2Carrier Frequency of Channels ..................................................................................................7 2.3Test Mode and Test Software.....................................................................................................8 2.4Description of Test System.........................................................................................................8 2.5General Information of Test........................................................................................................9 2.6Measurement Uncertainty ..........................................................................................................9 3.Antenna Requirements.....................................................................................................................10 3.1Standard Applicable .................................................................................................................10 3.2Antenna Construction and Directional Gain.............................................................................10 4.Test of Conducted Emission............................................................................................................ 11 4.1Test Limit .................................................................................................................................. 11 4.2Test Procedures ....................................................................................................................... 11 4.3Typical Test Setup ....................................................................................................................12 4.4Measurement Equipment .........................................................................................................12 4.5Test Result and Data ................................................................................................................13 4.6Test Photographs .....................................................................................................................19 5.Test of Radiated Emission ...............................................................................................................20 5.1Test Limit ..................................................................................................................................20 5.2Test Procedures .......................................................................................................................20 5.3Typical Test Setup ....................................................................................................................21 5.4Measurement Equipment .........................................................................................................21 5.5Test Result and Data ................................................................................................................22 5.6Test Photographs (30MHz~1000MHz).....................................................................................58 5.7Test Photographs (1000MHz~25000MHz)...............................................................................59 6.6dB Bandwidth Measurement Data .................................................................................................60 6.1Test Limit ..................................................................................................................................60 6.2Test Procedures .......................................................................................................................60 6.3Test Setup Layout ....................................................................................................................60 6.4Measurement Equipment .........................................................................................................60 6.5Test Result and Data ................................................................................................................60 7.Maximum Peak and Average Output Power ...................................................................................73 7.1Test Limit ..................................................................................................................................73 7.2Test Procedures .......................................................................................................................73 7.3Te…

Text truncated - open the document above for the full version.

CERPASS TECHNOLOGY CORP. Report No.: TEFI1309134 Cerpass Technology Corp.Issued date:Oct. 17, 2013 Tel:886-2-2655-8100 Fax:886-2-2655-8200Page No.:19 of 108 FCC ID:ZTT-SR10000-2 4.6 Test Photographs Front View Rear View CERPASS TECHNOLOGY CORP. Report No.: TEFI1309134 Cerpass Technology Corp.Issued date:Oct. 17, 2013 Tel:886-2-2655-8100 Fax:886-2-2655-8200Page No.:58 of 108 FCC ID:ZTT-SR10000-2 5.6 Test Photographs (30MHz~1000MHz) Front View Rear View CERPASS TECHNOLOGY CORP. Report No.: TEFI1309134 Cerpass Technology Corp.Issued date:Oct. 17, 2013 Tel:886-2-2655-8100 Fax:886-2-2655-8200Page No.:59 of 108 FCC ID:ZTT-SR10000-2 5.7 Test Photographs (1000MHz~25000MHz) Front View Rear View
