ZTT-TAPEX2High Power Touch Screen AC750 Wi-Fi Range Extender

User’s Guide TAP-EX2 HIGHPOWER TM TOUCH SCREEN AC750 WI-FI ® RANGE EXTENDER TAP-EX2 USER’S GUIDE 1 CONTENTS INTRODUCTION ..................................................................... 3 GETTING STARTED ................................................................. 4 Package Contents ...................................................................... 4 Product Description ................................................................... 5 SETUP GUIDE (TOUCH SCREEN) .............................................. 6 Find a Setup Location ................................................................ 6 Navigating the Touch Screen Menu .......................................... 8 Welcome to the Dashboard ...................................................... 9 Select a 2.4GHz Home Network to Extend .............................. 10 Connecting to a Secure Network (2.4GHz) .............................. 11 Select a 5GHz Home Network to Extend ................................ 12 Connecting to a Secure Network (5GHz) ................................. 13 Extended Network Settings ..................................................... 14 Applying Settings ..................................................................... 16 Setup Summary ....................................................................... 17 MORE SETTINGS (TOUCH SCREEN) ....................................... 19 2.4GHz WI-FI SETTINGS (TOUCH SCREEN) ............................. 20 Home Network Settings .......................................................... 20 Extended Network Settings ..................................................... 21 Connected Devices .................................................................. 23 Wi-Fi Coverage Controls .......................................................... 24 Access Schedule ...................................................................... 25 Wi-Fi Protected Setup (WPS) ................................................... 26 User Access .............................................................................. 27 5GHz WI-FI SETTINGS (TOUCH SCREEN) ................................ 28 Home Network Settings ........................................................... 28 Extended Network Settings ..................................................... 29 Connected Devices................................................................... 31 Wi-Fi Coverage Controls .......................................................... 32 Access Schedule ....................................................................... 33 Wi-Fi Protected Setup (WPS) ................................................... 34 User Access .............................................................................. 35 BOOSTBAND TECHNOLOGY (TOUCH) .................................... 36 NETWORK SETTINGS (TOUCH) .............................................. 37 IP Settings ................................................................................ 37 Wired Port Routing .................................................................. 38 MANAGEMENT SETTINGS (TOUCH) ...................................... 39 Screen Settings ........................................................................ 39 Clock / Date ............................................................................. 40 System Details.......................................................................... 41 Statistics ................................................................................... 43 USB Storage ............................................................................. 44 System Logs ............................................................................. 48 Upgrade Firmware ................................................................... 49 TAP-EX2 USER’S GUIDE 2 Reset Settings .......................................................................... 50 ACCESSING THE WEB MENU ................................................ 51 SETUP GUIDE (WEB MENU) .................................................. 52 Find a Setup Location .............................................................. 52 Open your Web Browser to Access the Setup Wizard ............. 54 Welcome to the Dashboard .................................................... 55 Scan for a Home Network to Extend ....................................... 56 Connecting to a Secure Network ............................................. 57 Extended Network Settings (SSID and Security) ...................... 58 Setup Summary ....................................................................... 61 5GHz WI-FI SETTINGS (WEB MENU) ..................................... 64 Home Network Settings ......................................................... 64 Extended Network Settings .................................................... 65 Security ................................................................................... 67 Wi-Fi Protected Setup – WPS ................................................. 68 User Access ............................................................................ 69 Wireless Coverage Controls .................................................... 70 Access Schedule ..................................................................... 71 Advanced Settings .................................................................. 72 2.4GHz WI-FI SETTINGS (WEB MENU) ................................... 74 Home Network Settings ......................................................... 74 Extended Network Settings .................................................... 75 Security ................................................................................... 77 Wi-Fi Protected Setup – WPS ................................................. 78 User Access ............................................................................ 79 Wireless Coverage Controls .................................................... 80 Acce…

Text truncated - open the document above for the full version.

Registration number: W6D21410-14563-FCC FCC ID: ZTT-TAPEX2 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 2 of 24 External Photos Registration number: W6D21410-14563-FCC FCC ID: ZTT-TAPEX2 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 3 of 24 Registration number: W6D21410-14563-FCC FCC ID: ZTT-TAPEX2 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 4 of 24 Registration number: W6D21410-14563-FCC FCC ID: ZTT-TAPEX2 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 5 of 24 Registration number: W6D21410-14563-FCC FCC ID: ZTT-TAPEX2 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 6 of 24 Registration number: W6D21410-14563-FCC FCC ID: ZTT-TAPEX2 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 7 of 24 Registration number: W6D21410-14563-FCC FCC ID: ZTT-TAPEX2 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 8 of 24 Registration number: W6D21410-14563-FCC FCC ID: ZTT-TAPEX2 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 9 of 24 Registration number: W6D21410-14563-FCC FCC ID: ZTT-TAPEX2 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 10 of 24 Registration number: W6D21410-14563-FCC FCC ID: ZTT-TAPEX2 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 11 of 24 Registration number: W6D21410-14563-FCC FCC ID: ZTT-TAPEX2 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 12 of 24 Registration number: W6D21410-14563-FCC FCC ID: ZTT-TAPEX2 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 13 of 24

Registration number: W6D21410-14563-FCC FCC ID: ZTT-TAPEX2 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 14 of 24 Internal Photos Registration number: W6D21410-14563-FCC FCC ID: ZTT-TAPEX2 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 15 of 24 Registration number: W6D21410-14563-FCC FCC ID: ZTT-TAPEX2 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 16 of 24 Registration number: W6D21410-14563-FCC FCC ID: ZTT-TAPEX2 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 17 of 24 Registration number: W6D21410-14563-FCC FCC ID: ZTT-TAPEX2 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 18 of 24 Chip Antenna Registration number: W6D21410-14563-FCC FCC ID: ZTT-TAPEX2 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 19 of 24 Registration number: W6D21410-14563-FCC FCC ID: ZTT-TAPEX2 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 20 of 24

Amped Wireless 13089 Peyton Dr. #C307 Chino Hills California 91709 United States Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Applicant’s declaration concerning RF Radiation Exposure We hereby indicate that the product Product description: High Power Touch Screen AC750 Wi-Fi Range Extender Model No: TAP-EX2 The equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. The integral antennas used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter within the host device. A safety statement concerning minimum separation distances from enclosure of the Product : High Power Touch Screen AC750 Wi-Fi Range Extender will be integrated in the user’s manual to provide end-users with transmitter operating conditions for satisfying RF exposure compliance. The appropriate information can be drawn from the test report no: W6D21410-14563-C-1 and W6D21410-14563-C-54 and the accompanying calculations. Company: Amped Wireless Address: 13089 Peyton Dr. #C307 Chino Hills California 91709 United States Registration number: W6D21410-14563-C-1 FCC ID: ZTT-TAPEX2 Worldwide Testing Services(Taiwan) Co., Ltd. Page 26 of 69 3.2 Equivalent isotropic radiated power FCC Rule: 15.247(b)(3) For systems using digital modulation in the 2.4 GHz – 2.4835 GHz bands: 1 Watt. The conducted output power limit specified in paragraph (b) of this section is based on the use of antennas with directional gains that do not exceed 6dBi. Except as shown in paragraph (c) of this section, if transmitting antennas of directional gain greater than 6 dBi are used, the conducted output power from the intentional radiator shall be reduced below the stated values in paragraphs (b)(1), (b)(2), and (b)(3) of this section, as appropriate, by the amount in dB that the directional gain of the antenna exceeds 6 dBi. Test equipment used: ETSTW-RE 055 3.3 RF Exposure Compliance Requirements Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.25 m normally can be maintained between the user and the device. FCC OET Bulletin 65 Edition 97.01 determines the equations for predicting RF fields and applicable limits. The prediction for power density in the far-field but will over-predict power density in the near field, where it could be used for walking a “worst case” or conservative prediction. PG S = --------- 4πR 2 S – Power Density P – Output power ERP R – Distance D – Cable Loss AG – Antenna Gain Item Unit Value Remarks P mW 612.3504 Peak value D dB AG dBi 6.41 G 4.3752 Calculated Value R cm 20 Assumed value S mW/cm 2 0.5330 Calculated value Limits: Limit for General Population / Uncontrolled Exposure Frequency (MHz) Power Density (mW/cm 2 ) 1500 – 100.000 1.0 Registration number: W6D21410-14563-C-54 FCC ID: ZTT-TAPEX2 Worldwide Testing Services(Taiwan) Co., Ltd. Page 47 of 50 3.9 Radio Frequency Radiation Exposure, FCC 15.407 (f) FCC Rule: 15.407(b)(3) EIRP = max. conducted output power + antenna gain Band 1 EIRP = 19.85 dBm + 2.76 dBi = 22.61 dBm Band 4 EIRP = 16.79 dBm + 3.13 dBi = 19.92 dBm Limit: EIRP = +36 dBm for Antenna gain <6dBi Test equipment used: ETSTW-RE 055 3.10 RF Exposure Compliance Requirements FCC OET Bulletin 65 Edition 97.01 determines the equations for predicting RF fields and applicable limits. The prediction for power density in the far-field but will over-predict power density in the near field, where it could be used for walking a “worst case” or conservative prediction. PG S = --------- 4πR 2 S – Power Density P – Output power ERP R – Distance D – Cable Loss AG – Antenna Gain Band 1 Item Unit Value Remarks P mW 96.6051 Peak value D dB AG dBi 2.76 G 1.8880 Calculated Value R cm 20 Assumed value S mW/cm2 0.0363 Calculated value Band 4 Item Unit Value Remarks P mW 47.7529 Peak value D dB AG dBi 3.13 G 2.0559 Calculated Value R cm 20 Assumed value S mW/cm2 0.0195 Calculated value

of Applicant: Amped Wireless Address: 13089 Peyton Dr. #C307 Chino Hills California 91709 United States Tested and Prepared by Worldwide Testing Services (Taiwan) Co., Ltd. FCC Registration No.: 930600 Industry Canada filed test laboratory Reg. No. IC 5679A-1 A2LA Accredited No.: 2732.01 Report No.: W6D21410-14563-C-1 6F, NO. 58, LANE 188, RUEY-KUANG RD., NEIHU TAIPEI 114, TAIWAN, R.O.C. TEL: 886-2-66068877 FAX: 886-2-66068879 E-mail: [email protected] FCC PART 15 SUBPART C TEST REPORT for High Power Touch Screen AC750 Wi-Fi Range Extender Model No.: TAP-EX2 FCC ID: ZTT-TAPEX2 Registration number: W6D21410-14563-C-1 FCC ID: ZTT-TAPEX2 Worldwide Testing Services(Taiwan) Co., Ltd. Page 1 of 69 TABLE OF CONTENTS 1 GENERAL INFORMATION ..........................................................................................................2 1.1 N OTES..........................................................................................................................................2 1.2 T ESTING LABORATORY................................................................................................................3 1.2.1 Location ..............................................................................................................................3 1.2.2 Details of accreditation status ............................................................................................3 1.3 DETAILS OF APPROVAL HOLDER...................................................................................................3 1.4 A PPLICATION DETAILS.................................................................................................................4 1.5 G ENERAL INFORMATION OF TEST ITEM........................................................................................4 1.6 TEST STANDARDS.........................................................................................................................6 2 TECHNICAL TEST .........................................................................................................................7 2.1 SUMMARY OF TEST RESULTS........................................................................................................7 2.2 T EST ENVIRONMENT....................................................................................................................7 2.3 TEST EQUIPMENT LIST.................................................................................................................8 2.4 GENERAL TEST PROCEDURE......................................................................................................10 3 TEST RESULTS (ENCLOSURE) ................................................................................................12 3.1 P EAK OUTPUT POWER (TRANSMITTER) ......................................................................................13 3.2 E QUIVALENT ISOTROPIC RADIATED POWER................................................................................26 3.3 RF EXPOSURE COMPLIANCE REQUIREMENTS............................................................................26 3.4 T RANSMITTER RADIATED EMISSIONS IN RESTRICTED BANDS....................................................27 3.5 S PURIOUS EMISSIONS (TX) .........................................................................................................28 3.6 R ADIATED EMISSION ON THE BAND EDGE..................................................................................31 3.7 MINIMUM 6 DB BANDWIDTH.....................................................................................................40 3.8 PEAK POWER SPECTRAL DENSITY.............................................................................................53 3.9 RADIATED EMISSION FROM DIGITAL PART................................................................................66 3.10 P OWER LINE CONDUCTED EMISSION.........................................................................................67 A PPENDIX..............................................................................................................................................69 Registration number: W6D21410-14563-C-1 FCC ID: ZTT-TAPEX2 Worldwide Testing Services(Taiwan) Co., Ltd. Page 2 of 69 1 General Information 1.1 Notes The purpose of conformity testing is to increase the probability of adherence to the essential requirements or conformity specifications, as appropriate. The complexity of the technical specifications, however, means that full and thorough testing is impractical for both technical and economic reasons. Furthermore, there is no guarantee that a test sample which has passed all the relevant tests conforms to a specification. Neither is there any guarantee that such a test sample will interwork with other genuinely open systems. The existence of the tests nevertheless provides the confidence that the test sample possesses the qualities as maintained and that is performance generally conforms to representative cases of communications equipment. The test results of this test report relate exclusively to the item tested as specified in 1.5. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the Worldwide Testing Services(Taiwan) Co., Ltd. Specific Conditions: Usage of the hereunder tested device in combination with other integrated or external antennas requires at least additional output power measurements, spurious emission measurements, conducted emission measurements (AC supply lines) and radio frequency exposure evaluations for each individual configuration performed, for certification by FCC. The test sample is able to work according IEEE 802.11 b/g/n. This report is related to FCC Part 15 C (DSSS and OFDM device). Tester: April 13, 2015 Spencer Yang Date WTS-Lab. Name Signature Technical responsibility for area of testing: April 13, 2015 Kevin Wang Date WTS Name Signa…

Text truncated - open the document above for the full version.

Registration number: W6D21410-14563-FCC FCC ID: ZTT-TAPEX2 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 21 of 24 Set Up Photo of Radiated Emission EMI Below 1GHz Registration number: W6D21410-14563-FCC FCC ID: ZTT-TAPEX2 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 22 of 24 Above 1GHz Registration number: W6D21410-14563-FCC FCC ID: ZTT-TAPEX2 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 23 of 24 RF Registration number: W6D21410-14563-FCC FCC ID: ZTT-TAPEX2 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 24 of 24 Set Up Photo of Conducted Emission
