ZW5008Head Mount Dispay System for Sports Goggles

1 RECON Snow2 – USER MANUAL 2 Table of Contents Welcome In the Box Overview System Requirements Setup Get Started Connect to your Smartphone Recon Engage App Engage Website On the Recon HUD Dashboard Radar ‐ Navigation ‐ Buddy Tracking Music Live Feed Apps ‐ Tracker ‐ Stopwatch Settings Tips Battery Shortcut to Music Compass Calibration Status Bar Troubleshooting GPS Factory Reset Remote Pairing Maintenance Storing your Device Charging Firmware Updates Technical Specifications Support Warranty Battery Disposal Information Compliance Information 3 Welcome Welcome to your Recon Snow2 Heads‐up Display (HUD). Snow2 tracks your activity while you’re on any mountain, whether skiing, snowboarding, etc. and delivers essential information like speed, altitude, navigation and more, direct‐to‐eye, in real‐time. The experience doesn’t end on the hill. Access the Engage website and connect your HUD to review and relive your trips. Here you can track, compare and share socially what you’ve been up to during all your alpine adventures. In the Box The following items should be included in the box: 4 Overview Recon HUD Remote 5 System Requirements To use Snow2, you will need: ‐ Apple Mac OS X v10.6 or later, Microsoft Windows Vista, or Windows 7, or later. - Optional: Android Smartphone Version 2.3.5 (or later) or Apple iPhone 4S (or later). 6 Setup Get Started You will need to activate your Recon HUD before you use it. To get started, use your computer’s internet browser and go to engage.reconinstruments.com/getstarted 1. Get Started engage.reconinstruments.com/getstarted will guide you through the activation process of your Recon HUD. Download the Engage browser plugin, learn how to update firmware, create an Engage account, and hit the slopes! 2. Customize Fit  Adjust the goggle Fit. Adjust the strap sliders on your goggle’s strap, so that goggle fits comfortably and securely.  Turn on the Recon HUD by pushing the power button on the right‐side of the goggle.  Adjust the Recon HUD orientation With your fingers gently adjust the orientation of the Recon HUD until the screen is fully visible when you are comfortably wearing the goggle.  Pick a Remote Strap and activate the remote Choose your preferred remote strap (wrist or goggle) and snap‐fit it onto the remote. Press any button on remote to turn it on. 3. Engage Keep track of your activity with the Engage website and the Recon Engage app. Check your trip history, compare your best all‐time stats, track your buddies, and share your alpine experience with all your friends. Visit engage.reconinstruments.com for more info. 7 Connect to your Smartphone To unlock additional features on your Recon HUD, download the Recon Engage app to your smartphone. Connect your Android Smartphone 1. Download the free Recon Engage app from Google Play. 2. On your Recon HUD, go to Settings > Smartphone Connection > Android. Follow the onscreen instructions on your Recon HUD to begin set up. 3. On your Android smartphone, open Recon Engage app and select Device Pairing. Follow the instructions on Recon Engage app to complete setup. Connect your iPhone 4S or Later 1. Download the free Recon Engage app for iPhone from the App Store. 2. On your Recon HUD, go to Settings > Smartphone Connection > iPhone. Follow the onscreen instructions on your Recon HUD to begin set up. 8 Recon Engage App Recon Engage app (for Android and iOS) provides your Recon HUD with expanded functionality such as music control and buddy tracking. You can use Recon Engage app to see a list of your accomplishments and share them on your favorite social networks. Engage Website Engage website enables you to install apps to your Recon HUD in the Recon App Center, customize your Dashboard, and update firmware. 9 On the Recon HUD Features Your Recon HUD comes with 5 main display screens providing you with essential information as you take off down the mountain. Use your remote to navigate through each of the following screens. 10 Dashboard At the center of your Recon HUD sits the customizable Dashboard. This is your home screen and central point of reference displaying real‐time information while you’re on the slopes. The Dashboard comes with 3 preset screens with information including speed, altitude, vertical, and more, direct to your eye. Radar Built‐in precision GPS makes Radar come to life giving you information on your current location, full 3D ski resort maps, and buddies in your area. Navigation: When you’re at the resort, find chair lifts, restaurants, and other points of interest near you. Buddy Tracking: Find and track where your friends and family are on the hill so you can easily meet up. Music Control your favorite tracks by connecting your Recon HUD to your smartphone. Change songs and adjust volume using the remote while you carve through the snow – there is no need to take your phone out of your pocket again. Notification Center Notification Center automatically populates new achievements, incoming alerts, and much more so you can stay informed in one place while you’re on the slopes. Apps This is where you can personalize your Recon HUD. Start with Snow2’s preset apps, like Stopwatch. 11 Stopwatch Record and save timed activity with Stopwatch. Lap your runs and compete against the clock across selected distance markers or completed runs. Settings Adjust your settings for your Recon HUD. ‐ Brightness – Here you can alter the brightness of your HUD screen to the suit your current surroundings ‐ Smartphone Connection – Connect your Android or iPhone to access the advanced features on your Recon HUD ‐ Bluetooth – Enable Bluetooth to connect third‐party devices to your HUD (ex: action sports cameras, heart rate monitors, etc) ‐ Set Time – Automatically or manually set the time on your HUD ‐ Reset Stats – Clear your stats from all previously recorded runs and start fresh ‐ Set Units – Choose Metric or Imperial units to measure and display your real‐ time stats ‐ Software Update ‐ Manually assis…

Text truncated - open the document above for the full version.

7/25/2013 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Request for Confidentiality Company name: Recon Instruments Inc. FCC ID: ZW5008 FCC Part 15.247 Certification Dear Madam/Sir, Pursuant to 47 CFR 0.457(d)(1)(ii) and 0.459 Recon Instruments Inc. hereby requests permanent confidentiality of the following documents for the subject application: Exhibit Type File Name Description Diagram Block Diagram Block Diagram Description Operational Description Operational Description Schematics Schematics Schematics List Parts List BOM Reason why the material should be withheld from public inspection: These documents contain detailed system, equipment description and related information about the product which Recon Instruments Inc. considers proprietary, confidential, and a custom design not otherwise available to the general public. Reason why the information is a “trade secret;” Since the design is a basis from which future products will evolve, Recon Instruments Inc. considers that this information would be of significant benefit to its competitors and that disclosure would give competitors an unfair advantage in the marketplace. Sincerely, Signature: Name: Andrei Moldavanov Company: QAI Title: EMC/RF Engineer

Letter of Authorization Company: QAI Address: 211 Schoolhouse Street Product Name: Head mount display system for sports goggles Model Number: RI-SNOW2 We authorize MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566, USA, to act on our behalf on all matters concerning the above named equipment. Any individual within MiCOM Labs is authorized to act on our behalf and take action on the application. This shall include the following: • Approval applications (includes complete product documentation package, including Confidential information) and procedures • Payment of approval fees We declare that MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566, USA, is allowed to forward all information related to the approval project to the applied notified body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Name: Andrei Moldavanov Date: June 21, 2013 Title: EMC/RF Engineer Signature of applicant:

External Photos FCCID: ZW5008 IC: 9717A-008 Recon Instruments, Inc. Date: July 8, 2013 Labs: 19473 Fraser Way, Pitt Meadows, BC, Canada V3Y 2V4 Andrei Moldavanov EMC Engineer Supplemental Exhibit Recon Instruments. Inc. Page 2 of 3 A.1 External Photos ** Supplemental Exhibit Recon Instruments. Inc. Page 3 of 3

SNOW2 Certification Label Location

4) Closeupofthecompleteunitoutsideofthegoggleswiththeblackcoversoffshowinginternal batterycompartment,DisplaycompartmentandprocessorcompartmentFrontview    5) Closeupofthecompleteunitoutsideofthegoggleswiththeblackcoversoffshowinginternal batterycompartment,Displaycompartmentandprocessorcompartmentbackview    6) FrontviewcloseͲupofprocessorcompartmentwithRFshieldsremoved      7) backview     8) CloseupofdisplaycompartmentFrontView      9) CloseͲupBackviewofdisplay    10) CloseupofbatterycompartmentFrontView   11) CloseͲupofbatterycompartmentbackview             12) CloseupofboardFrontViewwithoutshield            13) CloseupofboardBackViewwithoutshield             14) CloseupofboardFrontViewwithshield               15) CloseupofboardBackViewwithshield

RF Exposure Evaluation FCCID: ZW5008 Recon Instruments, Inc. Date: July 24, 2013 Labs: 19473 Fraser Way, Pitt Meadows, BC, Canada V3Y 2V4 Andrei Moldavanov EMC Engineer Supplemental Exhibit Recon Instruments. Inc. Page 2 of 2 RF Exposure Evaluation Test Standard FCC KDB447498 FCC CFR 47, Part 1.1307, 1310 FCC CFR 47, Part 2, Subpart J 1091 MINIMUM STANDARD: KDB447498, sec. 4.3.1: Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied ... ...test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions. 22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander... TEST LIMIT: As per Appendix A “SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm” the limit is 29 mW/mm. EUT DESIGN PARAMETERS: Minimum separation distance – 14.5 mm; WiFi maximum transmit power: +4.43 dBm; Bluetooth maximum transmit power: -2.53 dBm; Antenna gain: -1.25 dBi. EVALUATION PROCEDURE: 1) The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f (GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,24 where • f(GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation 25 • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below . RATIONALE: Taking the EUT parameters referenced above, we have 1-g SAR in worst case(Bluetooth) is 0.045 mW/mm, which is less than limit of 29 mW/mm. RESULT: The EUT is satisfied to SAR Test Exclusion Threshold.

CANADA: 16 - 211 Schoolhouse Street Coquitlam, British Columbia Canada V3K 4X9 Company Name: Recon Instruments, Inc. Report Number: E10415-1305 Page 1 of 96 ELECTROMAGNETIC COMPATIBILITY TEST REPORT TO FCC 47 CFR Part 15 SUBPART C Class B & INDUSTRY CANADA RSS-210 Report Number: E1051415-1305 Issue: Release version 1.4 Date of Issue: July 26, 2013 Number of Pages: 96 Testing laboratory .................................. : Quality Auditing Institute Address ........................................................................................................................... : 16 – 211 Schoolhouse Street, Coquitlam, BC, V3K 4X9, Canada Accreditations (ISO 17025): Standard Council of Canada: Accredited Laboratory No. 743 International Accreditation Service Inc.: Accredited Laboratory: No. TL-239 This report has been completed in accordance with the requirements of ISO/IEC 17025. Test results contained in this report are within QAI Laboratories ISO/IEC 17025 accreditation. QAI Laboratories authorizes the applicant to reproduce this report provided it is reproduced in its entirety and for the use by the company’s employees only. Applicant’s name ............................ : Recon Instruments Inc. Address................................................................................................................................. : 100-1050 Homer St. Vancouver BC, V6B 2W9, Canada Contact................................................................................................................................. : Dominique Kwong, [email protected] Industry Canada Registration : 9717A-008 FCC Registration: ZW5008 Test specifications: Standard........................................... : RSS-Gen, Issue 3; RSS-210, Issue 8; FCC Part 15.247. Test procedure ................................. : As called by the standard above Non-standard te st method..............: N/A CANADA: 16 - 211 Schoolhouse Street Coquitlam, British Columbia Canada V3K 4X9 Company Name: Recon Instruments, Inc. Report Number: E10415-1305 Page 2 of 96 Test Item Description: Head Mounted Display system for sports goggles with Wi-Fi & Bluetooth Trade Mark: Manufacturer: Recon Instruments, Inc. Model Number: 008 Model Description: RI -SNOW2 CANADA: 16 - 211 Schoolhouse Street Coquitlam, British Columbia Canada V3K 4X9 Company Name: Recon Instruments, Inc. Report Number: E10415-1305 Page 3 of 96 Revision History Date Report Number Rev # Details Authors Initials Jun 21, 2013 E10415-1308 0.0 Draft Test Report AM Jun 28, 2013 E10415-1308 0.1 Bluetooth data added AM July 5, 2013 E10415-1308 0.2 Typos fixed AM July 9, 2013 E10415-1305 0.3 Report is segregated from Digital Circuitry report AM July 10, 2013 E10415-1305 0.4 Style is changed to be consistent with QAI one. AM July 10, 2013 E10415-1305 0.5 Revision number is changed to avoid version confusion AM July 11, 2013 E10415-1305 0.6 Data for hopping frequencies added AM July 15, 2013 E10415-1305 0.8 Corrupted version 0.7 fixed AM July 15, 2013 E10415-1305 0.9 Results for temperature testing added AM July 17, 2013 E10415-1305 0.10 Results for spurious conducted added AM July 18, 2013 E10415-1305 0.11 Document Cleanup DJ July 18, 2013 E10415-1305 0.12 Document Cleanup revision AM July 19, 2013 E10415-1305 0.13 Version numbers fixed AM July 22, 2013 E10415-1305 0.14 Client’s comments incorporated AM July 22, 2013 E10415-1305 1.0 Release version AM July 25, 2013 E10415-1305 1.1 Reviewer comments added AM July 26, 2013 E10415-1305 1.2 More reviewer comments fixed AM July 26, 2013 E10415-1305 1.3 Release version AM July 26, 2013 E10415-1305 1.4 IC comments fixed AM CANADA: 16 - 211 Schoolhouse Street Coquitlam, British Columbia Canada V3K 4X9 Company Name: Recon Instruments, Inc. Report Number: E10415-1305 Page 4 of 96 Table of Contents Section I. GENERAL TEST INFORMATION....................................................................................... 6 EMC TEST SUMMARY ....................................................................................................... 6 TEST RESULT CERTIFICATION ......................................................................................... 7 EUT DESCRIPTION ............................................................................................................. 7 FACILITIES AND ACCREDITATION .................................................................................. 8 ENVIROMENTAL CONDITIONS: INDOORS ...................................................................... 8 TESTING METHODOLOGY ................................................................................................ 8 EUT TESTING CONFIGURATION ...................................................................................... 8 MEASUREMENT UNCERTAINTY .................................................................................... 11 ANTENNA DESCRIPTION ............................................................................................... 11 TESTING EQUIPMENT ..................................................................................................... 12 Section II. Requirements for the Canadian Market: Industry Canada mark ...................................... 14 Part 1 - Antenna Requirements ........................................................................................ 16 Part 2 – RF Power Conducted .......................................................................................... 17 Part 3 - Radiated Spurious Emissions .............................................................................. 24 Part 4 – Power Spectral Density ....................................................................................... 31 Part 5 – AC Mains Conducted Emissions ......................................................................... 37 Part 6 – 20 dB Occupied Bandwidth ................................................................................. 41 Part 7 – Band Edge ......................…

Text truncated - open the document above for the full version.

Test Setup Photos FCCID: ZW5008 IC: 9717A-008 Recon Instruments, Inc. Date: July 8, 2013 Labs: 211 Schoolhouse Street, Coquitlam, BC, Canada V3K 4X9 Andrei Moldavanov EMC Engineer Supplemental Exhibit Recon Instruments. Inc. Page 2 of 3 Conducted emission test setup Radiated emission test setup Supplemental Exhibit Recon Instruments. Inc. Page 3 of 3 Radiated emission test setup Conducted emission test setup
