2A2P9-MTH101EcoFlow PowerInsight with Bluetooth and Wi-Fi

© 2023 EcoFlow Inc. All rights reserved. What’s In The Box Home Energy Management Contenu de la boîte | Lieferumfang | 包裝清單 Gestion de l'énergie domestique | Energiemanagement im Haushalt | 家庭能源管理 For details on supported devices and how to add devices, refer to the User Manual. Pour plus de détails sur les appareils pris en charge et comment ajouter des appareils, reportez-vous au Manuel d'utilisation. Einzelheiten zu den unterstützten Geräten und zum Hinzufügen von Geräten finden Sie im Benutzerhandbuch. 如需瞭解支援的裝置及新增裝置的詳細資訊，請參閱使用者手冊。 ×4 D ×4 E ×1 C ×1 B ×1 A All-in-one home energy control system Solar panel Generator EcoFlow home batteries EcoFlow portable power station EV charger Grid Home appliances EcoFlow distribution panel USB-C Vue latérale | Seitenansicht | 側視 Side View Mount Your PowerInsight Montez votre PowerInsight | Montieren Sie Ihr PowerInsight | 固定 PowerInsight USB-C 1 USB-C 2 D E ≥10W, USB-C charger Not in the box 12 B C 4× 4× 4× 30 mm (1.18") Ø 6 mm (0.23") Initialiser | Initialisieren | 初始化 Initialize New EcoFlow user? Download app on your phone Finish initializing and start using it! A 3 Use EcoFlow app to scan 4× For more details, please scan the QR code or visit: https://manuals.ecoflow.com/product/ powerinsight Manual EcoFlow PowerInsight Home Energy Manager Quick Start Guide Guide de démarrage rapide Schnellstartanleitung 快速入門指南 SAFETY INSTRUCTIONS DISCLAIMER Please read the product document and ensure that you understand it fully before using the product. After reading this document, keep it for future reference. Improper use of this product may cause serious injury to yourself or others, or cause product damage and property loss. Once you use this product, it is deemed that you understand, approve and accept all the terms and content in this document. EcoFlow is not liable for any loss caused by the user’s failure to use the product in compliance with the product document. WARNING 1. Follow all instructions and pay attention to all warnings. 2. Do not dispose of the battery built in this product by throwing it into fire, a hot oven, or mechanically crushing or cutting it, otherwise this can lead to an explosion. 3. Do not leave the battery built in this product in an environment with extremely high temperatures and low air pressure, otherwise this can potentially lead to an explosion or the leakage of flammable liquid or gas. 4. Avoid using this product in extremely high or low temperatures, or in areas with low air pressure such as high altitudes, during use, storage, or transportation. 5. Do not disassemble this product in any way or pierce the product with sharp objects. 6. Please contact the manufacture or retailer if this product does not function normally or damaged. 7. Risk of fire or explosion can occur if the battery is replaced with an incorrect type. CAUTION 1. The label is located on the rear surface of the product. 2. Only use attachments or accessories specified by the manufacture. 3. FCC and ISED compliance information can be seen by steps slide down the screen> Setting > Compliance information. 4. The WLAN function for this device is restricted to indoor use only when operating in the 5150 to 5350 MHz frequency range. FCC COMPLIANCE 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference,and (2) This device must accept any interference received, including interference that may cause undesired operation. 2. Any changes or modifications not expressly approved by the grantee of this device could void the user’s authority to operate the device. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. INDUSTRY CANADA COMPLIANCE This device contains licence-exempt transmitter(s)/ receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. The term “IC”: before the certification/registration number only signifies that the Industry Canada technical specifications were met. CAN ICES-003(B) / NMB-003(B) The device supports 5GHz U-NII 1 frequency band, which is 5.150 to 5.250 GHz. It will be restricted for use in the indoor environment only. This equipment has been tested and meets FCC&ISED limits for radio frequency (RF) SAR limits when used on body and Limb. ENGLISH ModelEF-MT-H10-1 Weight Approx. 6 20 g ( approx. 1.4 lb) Dimension 244.4 x 158.6 x 12.6 mm (9.6 x 6.2 x 0.5 in.) Input rating (USB-C) 5V2A Operating temperature −10°C to 45°C (14°F to 113°F) Storage temperature −15°C to 50°C (5°F to 122°F) Humidity 10% to 85% RH (non- condensing) Altitude≤3,000 m (9,842 ft) IP ratingIP42 Bluetooth ® Frequency range: 2,402-2,480 MHz Max. output power: < 10 dBm SPECIFICATIONS For indoor use only Hereb…

Text truncated - open the document above for the full version.

EcoFlow Inc. Date: 2023/12/04 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Ref: Attestation Statements Part 2.911(d)(5)(i) and Part 2.911(d)(5)(ii) Filing Re. KDB 986446 D01 FCC ID: 2A2P9‐MTH101 Dear Sir or Madam, [EcoFlow Inc.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. We also certify that, [EcoFlow Inc.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [ is not] identified on the Covered List ( as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment . If you have any questions, please contact us. Sincerely, Contact name: Vicky Guan Company name: EcoFlow Inc. Address: 1st Floor, Building 1, Plant E, Jiehe Industrial City, Shuitian Community, Shiyan Street, Bao'an District, Shenzhen City, Guangdong 518000, China E‐mail: [email protected] Tel: 18926578676

EcoFlow Inc. Date (2023/12/04) TUV SUD BABT UNLIMITED TCB Octagon House, Segensworth North, Fareham, Hampshire, PO15 5RL, United Kingdom Confidentiality Request FCC ID: 2A2P9-MTH101 Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, EcoFlow Inc. hereby requests permanent confidential treatment of information accompanying this application as outlined below: Schematics Bill of Materials/Parts List Block Diagrams Theory of Operation EcoFlow Inc. also hereby requests short-term confidential treatment of information accompanying this application as outlined below for a period of (up to 120) days: Internal Photos External Photos User Manual Test Set-up Photographs The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Company Officer: EcoFlow Inc. Telephone Number: 18926578676 Email: [email protected]

EcoFlow Inc. Date: 2023/12/04 To: Federal Communications Commission 7435 Oakland Mills Road Columbia MD FCC ID: 2A2P9‐MTH101 To Whom It May Concern: This letter is to ascertain that EcoFlow Inc. Product name: EcoFlow PowerInsight, Model: EF‐MT‐H10‐1 has been the units used for conducting FCC compliance testing, the SDoC part will be tested by FCC recognized test lab. If you have any question or concerns, please contact us. Sincerely, Contact name: Vicky Guan Company name: EcoFlow Inc. Address: 1st Floor, Building 1, Plant E, Jiehe Industrial City, Shuitian Community, Shiyan Street, Bao'an District, Shenzhen City, Guangdong 518000, China E‐mail: [email protected] Tel: 18926578676

Accessory:

Step1. Open the product screen Step2. Slide down fromthe top of the product desktop andclickthe Settingoption Step3. Clickthe “Complianceinformation”option

ANT_C (For ESP32-S3-WROOM-1U Module) ANT_B (For MT7663BSN Module) For MT7663BSN Module:) ANT_A (For MT7663BSN Module) For MT7663BSN Module:) Antenna: ANT_C ANT_B ANT_A Battery: Accessory: ---THE END---

. Test Laboratory: Shenzhen EMTEKCo.,Ltd.Date: 2023/11/10 System Check_H2450 DUT: Dipole 2450 MHz; Type:D2450V2; SN:927 Communication System: CW; Frequency: 2450 MHz;Duty Cycle: 1:1 Medium: H2450 Medium parameters used: f = 2450 MHz;σ=1.77S/m;ε r =40.12;ρ= 1000 kg/m 3 AmbientTemperature：22.1°C; LiquidTemperature：21.9 °C DASY5 Configuration: - Probe: EX3DV4 - SN3970; ConvF(8.06, 8.06, 8.06); Calibrated: 2023/5/17; -Sensor-Surface: 4mm (Mechanical Surface Detection) -Electronics: DAE4 Sn1418; Calibrated: 2023/4/25 -Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP:1231 -Measurement SW: DASY52, Version 52.8 (7); SEMCAD X Version 14.6.10 (7164) Pin=250mW/Area Scan (41x51x1):Interpolated grid: dx=2.000 mm, dy=2.000 mmMaximum value of SAR (interpolated) = 25.4 W/kg Pin=250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 116.8 V/m; Power Drift = 0.17 dB Peak SAR (extrapolated) = 30.4 W/kg SAR(1 g) = 13.1 W/kg; SAR(10 g) = 6.07 W/kg Maximum value of SAR (measured) = 23.0 W/kg . Test Laboratory: Shenzhen EMTEK Co.,Ltd.Date: 2023/12/29 System Check_H2450 DUT: Dipole 2450 MHz; Type:D2450V2; SN:927 Communication System: CW; Frequency: 2450 MHz;Duty Cycle: 1:1 Medium: H2450 Medium parameters used: f = 2450 MHz;σ=1.79S/m;ε r = 40.105;ρ=1000kg/m 3 AmbientTemperature：21.7°C; LiquidTemperature：21.5°C DASY5 Configuration: - Probe: EX3DV4 - SN3970;Calibrated: 2022/4/18; - Electronics: DAE4 Sn1418; Calibrated: 2022/3/24 - Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP:1231 - Measurement SW: DASY52, Version 52.8 (7); SEMCAD X Version 14.6.10 (7164) Pin=250mW/Area Scan (41x51x1):Interpolated grid: dx=2.000 mm, dy=2.000 mm Maximum value of SAR (interpolated) = 25.4 W/kg Pin=250mW/Zoom Scan (5x5x7)/Cube 0:Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 114.7 V/m; Power Drift = 0.10 dB Peak SAR (extrapolated) = 30.4 W/kg SAR(1 g) = 13.01 W/kg; SAR(10 g) = 6.09 W/kg Maximum value of SAR (measured) = 23.0 W/kg Test Laboratory: Shenzhen EMTEK Co.,Ltd.Date: 2023/12/30 System Check_H5250 DUT: Dipole 5GHzV2;Type:D5GHzV2; SN:1169 Communication System: CW; Frequency: 5250 MHz;Duty Cycle: 1:1 Medium: H5G Medium parameters used: f = 5250 MHz;σ=4.74S/m;ε r = 36.82;ρ= 1000 kg/m 3 AmbientTemperature：22.1°C; LiquidTemperature：21.9°C DASY5 Configuration: - Probe: EX3DV4 - SN3970; Calibrated: 2023/5/17; - Electronics: DAE4 Sn1418; Calibrated: 2023/4/25 - Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP:1231 - Measurement SW: DASY52, Version 52.8 (7); SEMCAD X Version 14.6.10 (7164) Pin=100mW/Area Scan (7x9x1):Interpolated grid: dx=2.000 mm, dy=2.000 mm Maximum value of SAR (interpolated) = 33.0 W/kg Pin=100mW/Zoom Scan (5x5x7)/Cube 0:Measurement grid: dx=4mm, dy=4mm, dz=2mm Reference Value = 58.461 V/m; Power Drift = 0.14 dB Peak SAR (extrapolated) = 36.1 W/kg SAR(1 g) =7.62 W/kg; SAR(10 g) = 2.13 W/kg Maximum value of SAR (measured) = 33.4 W/kg Test Laboratory: Shenzhen EMTEK Co.,Ltd.Date: 2023/12/30 System Check_H5600 DUT: Dipole 5GHzV2;Type:D5GHzV2; SN:1169 Communication System: CW; Frequency: 5600 MHz;Duty Cycle: 1:1 Medium: H5G Medium parameters used: f = 5600 MHz;σ=5.21S/m;ε r = 36.14;ρ= 1000 kg/m 3 AmbientTemperature：22.1°C; LiquidTemperature：21.9°C DASY5 Configuration: - Probe: EX3DV4 - SN3970; Calibrated: 2023/5/17; - Electronics: DAE4 Sn1418; Calibrated: 2023/4/25 - Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP:1231 - Measurement SW: DASY52, Version 52.8 (7); SEMCAD X Version 14.6.10 (7164) Pin=100mW/Area Scan (7x9x1):Interpolated grid: dx=2.000 mm, dy=2.000 mm Maximum value of SAR (interpolated) = 24.2 W/kg Pin=100mW/Zoom Scan (5x5x7)/Cube 0:Measurement grid: dx=4mm, dy=4mm, dz=2mm Reference Value = 64.812 V/m; Power Drift = 0.18 dB Peak SAR (extrapolated) = 42.1 W/kg SAR(1 g) = 7.80 W/kg; SAR(10 g) = 2.13 W/kg Maximum value of SAR (measured) = 29.6 W/kg Test Laboratory: Shenzhen EMTEK Co.,Ltd.Date: 2024/1/2 System Check_H5750 DUT: Dipole 5GHzV2;Type:D5GHzV2; SN:1169 Communication System: CW; Frequency: 5750 MHz;Duty Cycle: 1:1 Medium: H5G Medium parameters used: f = 5750 MHz;σ=5.42S/m;ε r = 35.85;ρ= 1000 kg/m 3 AmbientTemperature：22.4°C; LiquidTemperature：22.2°C DASY5 Configuration: - Probe: EX3DV4 - SN3970; Calibrated: 2023/5/17; - Electronics: DAE4 Sn1418; Calibrated: 2023/4/25 - Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP:1231 - Measurement SW: DASY52, Version 52.8 (7); SEMCAD X Version 14.6.10 (7164) Pin=100mW/Area Scan (7x9x1):Interpolated grid: dx=2.000 mm, dy=2.000 mm Maximum value of SAR (interpolated) = 21.4 W/kg Pin=100mW/Zoom Scan (5x5x7)/Cube 0:Measurement grid: dx=4mm, dy=4mm, dz=2mm Reference Value = 49.111 V/m; Power Drift = 0.12 dB Peak SAR (extrapolated) = 36.8 W/kg SAR(1 g) = 7.53 W/kg; SAR(10 g) = 2.12 W/kg Maximum value of SAR (measured) = 23.42 W/kg

Test Laboratory: Shenzhen EMTEK Co.,Ltd. Date: 2023/12/29 2.4GWIFI DUT:EF-MT-H10-1 Communication System: 802.11b ; Frequency: 2437 MHz;Duty Cycle: 1:1004 Medium: H2450 Medium parameters used: f = 2437 MHz;σ=1.75S/m;ε r = 40.42;ρ= 1000 kg/m 3 AmbientTemperature：21.7°C; LiquidTemperature：21.5°C DASY5 Configuration: - Probe: EX3DV4 - SN3970; Calibrated: 2023/5/17; - Electronics: DAE4 Sn1418; Calibrated: 2023/4/25 - Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP:1231 - Measurement SW: DASY52, Version 52.8 (7); SEMCAD X Version 14.6.10 (7164) BACK-ANTA/Area Scan (9x12x1):Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.841 W/kg BACK-ANTA/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 6.974V/m; Power Drift = -0.11 dB Peak SAR (extrapolated) = 1.43 W/kg SAR(1 g) = 0.321 W/kg; SAR(10 g) = 0.147 W/kg Maximum value of SAR (measured) = 0.648 W/kg Test Laboratory: Shenzhen EMTEK Co.,Ltd. Date: 2023/12/30 5.2GWIFI DUT:EF-MT-H10-1 Communication System: 802.11a ; Frequency: 5200 MHz;Duty Cycle: 1:1.03092 Medium: H5G Medium parameters used: f = 5200 MHz;σ=4.65S/m;ε r =36.83;ρ= 1000 kg/m 3 AmbientTemperature：22.1°C; LiquidTemperature：21.9°C DASY5 Configuration: - Probe: EX3DV4 - SN3970; Calibrated: 2023/5/17; - Electronics: DAE4 Sn1418; Calibrated: 2023/4/25 - Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP:1231 - Measurement SW: DASY52, Version 52.8 (7); SEMCAD X Version 14.6.10 (7164) Back-ANTA/Area Scan (9x12x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.336 W/kg Back-ANTA/Zoom Scan (5x5x7)/Cube 0:Measurement grid: dx=4mm, dy=4mm, dz=2mm Reference Value = 1.947 V/m; Power Drift = -0.13 dB Peak SAR (extrapolated) = 3.60 W/kg SAR(1 g) = 0.410 W/kg; SAR(10 g) = 0.190 W/kg Maximum value of SAR (measured) = 0.487 W/kg Test Laboratory: Shenzhen EMTEK Co.,Ltd. Date: 2023/12/30 5.3GWIFI DUT:EF-MT-H10-1 Communication System: 802.11a ; Frequency: 5300 MHz;Duty Cycle: 1:1.03092 Medium: H5G Medium parameters used: f = 5300 MHz;σ=4.80S/m;ε r =36.74;ρ= 1000 kg/m 3 AmbientTemperature：22.1°C; LiquidTemperature：21.9°C DASY5 Configuration: - Probe: EX3DV4 - SN3970; Calibrated: 2023/5/17; - Electronics: DAE4 Sn1418; Calibrated: 2023/4/25 - Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP:1231 - Measurement SW: DASY52, Version 52.8 (7); SEMCAD X Version 14.6.10 (7164) Back-ANTA/Area Scan (9x12x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.286 W/kg Back-ANTA/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=4mm, dy=4mm, dz=2mm Reference Value = 2.013 V/m; Power Drift = -0.00 dB Peak SAR (extrapolated) = 2.91 W/kg SAR(1 g) = 0.349 W/kg; SAR(10 g) = 0.121 W/kg Maximum value of SAR (measured) = 0.545 W/kg Test Laboratory: Shenzhen EMTEK Co.,Ltd. Date: 2024/1/2 5.6GWIFI DUT:EF-MT-H10-1 Communication System: 802.11a ; Frequency: 5580 MHz;Duty Cycle: 1:1.03092 Medium: H5G Medium parameters used: f = 5580 MHz;σ=5.22S/m;ε r =36.18;ρ= 1000 kg/m 3 AmbientTemperature：22.1°C; LiquidTemperature：21.9°C DASY5 Configuration: - Probe: EX3DV4 - SN3970; Calibrated: 2023/5/17; - Electronics: DAE4 Sn1418; Calibrated: 2023/4/25 - Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP:1231 - Measurement SW: DASY52, Version 52.8 (7); SEMCAD X Version 14.6.10 (7164) Back-ANTA/Area Scan (9x12x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.380 W/kg Back-ANTA/Zoom Scan (5x5x7)/Cube 0:Measurement grid: dx=4mm, dy=4mm, dz=2mm Reference Value = 1.351 V/m; Power Drift = -0.12 dB Peak SAR (extrapolated) = 2.11 W/kg SAR(1 g) = 0.394 W/kg; SAR(10 g) = 0.155 W/kg Maximum value of SAR (measured) = 0.409 W/kg Test Laboratory: Shenzhen EMTEK Co.,Ltd. Date: 2024/1/2 5.8GWIFI DUT:EF-MT-H10-1 Communication System: 802.11a ; Frequency: 5785 MHz;Duty Cycle: 1:1.03092 Medium: H5G Medium parameters used: f = 5785 MHz;σ=5.41S/m;ε r =35.61;ρ= 1000 kg/m 3 AmbientTemperature：22.4°C; LiquidTemperature：22.2°C DASY5 Configuration: - Probe: EX3DV4 - SN3970; Calibrated: 2023/5/17; - Electronics: DAE4 Sn1418; Calibrated: 2023/4/25 - Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP:1231 - Measurement SW: DASY52, Version 52.8 (7); SEMCAD X Version 14.6.10 (7164) Back-ANTA/Area Scan (9x12x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.228 W/kg Back-ANTA/Zoom Scan (5x5x7)/Cube 0:Measurement grid: dx=4mm, dy=4mm, dz=2mm Reference Value = 1.487 V/m; Power Drift = -0.19 dB Peak SAR (extrapolated) = 1.88 W/kg SAR(1 g) = 0.355 W/kg; SAR(10 g) = 0.143 W/kg Maximum value of SAR (measured) = 0.560 W/kg Test Laboratory: Shenzhen EMTEK Co.,Ltd.Date: 2023/12/29 2.4GWIFI DUT:EF-MT-H10-1 Communication System: 802.11b; Frequency: 2437 MHz;Duty Cycle: 1:1004 Medium: H2450 Medium parameters used: f = 2437 MHz;σ=1.75S/m;ε r = 40.42;ρ=1000kg/m 3 AmbientTemperature：21.7°C; LiquidTemperature：21.5°C DASY5 Configuration: - Probe: EX3DV4 - SN3970; Calibrated: 2023/5/17; - Electronics: DAE4 Sn1418; Calibrated: 2023/4/25 - Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP:1231 - Measurement SW: DASY52, Version 52.8 (7); SEMCAD X Version 14.6.10 (7164) BACK-ANTB/Area Scan (9x12x1):Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.299 W/kg BACK-ANTB/Zoom Scan (5x5x7)/Cube 0:Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 5.486 V/m; Power Drift = 0.09 dB Peak SAR (extrapolated) = 1.23 W/kg SAR(1 g) = 0.230W/kg; SAR(10 g) = 0.084 W/kg Maximum value of SAR (measured) = 0.537 W/kg Test Laboratory: Shenzhen EMTEK Co.,Ltd.Date: 2023/12/30 5.2GWIFI DUT:EF-MT-H10-1 Communication System: 802.11a; Frequency: 5200 MHz;Duty Cycle: 1:1.03092 Medium: H5G Medium parameters used: f = 5200 MHz;σ=4.65S/m;ε r = 36.83;ρ= 1000 kg/m 3 AmbientTemperature：22.1°C; LiquidTemperature：21.9°C DASY5 Configuration: - Probe: EX3DV4 - SN3970; Calibrated: 2023/5/17; - Electronics: DAE4 Sn1418; Calibrated: 2023/4/25 - Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP:1231 - Measurement SW: DASY52, Version 52.8 (7); SEMCAD X Version 14.6.10 (7164) BACK-AN…

Text truncated - open the document above for the full version.

Report No. ENS2307260157W03001R Page 1 of 52 Ver.1.0 TEST REPORT Product Name ： EcoFlow PowerInsight Model Number ： EF-MT-H10-1 FCC ID ： 2A2P9-MTH101 Prepared for : EcoFlow Inc. Address : 1st Floor,Building 1,Plant E, Jiehe Industrial City,Shuitian Community, Shiyan Street, Bao'an District,Shenzhen City,Guangdong Province, P.R.China Prepared by : EMTEK (SHENZHEN) CO., LTD. Address : Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China Tel: (0755) 26954280 Fax: (0755) 26954282 Report Number : ENS2307260157W03001R Date(s) of Tests : November 10, 2023 to January 2, 2024 Date of Issue : January 3, 2024 Report No. ENS2307260157W03001R Page 2 of 52 Ver.1.0 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION ............................................................................................................................ 4 2. Description of Equipment Under Test .................................................................................................................. 6 3. SAR Measurement System .................................................................................................................................... 7 3.1 Definition of SpecificAbsorptionRate (SAR) ..................................................................................................... 7 3.2 SPEAG DASY System ..................................................................................................................................... 7 3.2.1 Robot .................................................................................................................................................. 8 3.2.2 Probes ................................................................................................................................................ 9 3.2.3 Data Acquisition Electronics (DAE) .................................................................................................... 9 3.2.4 Phantoms ......................................................................................................................................... 10 3.2.5 Device Holder ................................................................................................................................... 11 3.2.6 System Validation Dipoles ................................................................................................................ 11 3.2.7 Tissue Simulating Liquids ................................................................................................................. 12 3.3 SAR System Verification ................................................................................................................................ 14 3.4 SAR Measurement Procedure ....................................................................................................................... 15 3.4.1 Area & Zoom Scan Procedure.......................................................................................................... 15 3.4.2 VolumeScan Procedure .................................................................................................................... 15 3.4.3 Power Drift Monitoring ...................................................................................................................... 16 3.4.4 Spatial Peak SAR Evaluation ........................................................................................................... 16 3.4.5 SAR Averaged Methods ................................................................................................................... 16 4. SARMeasurement Evaluation .............................................................................................................................. 17 4.1 Applicable Standards ..................................................................................................................................... 17 4.2 EUT Configuration and Setting ...................................................................................................................... 17 4.3 EUT Testing Position ...................................................................................................................................... 19 4.3.1 Body Exposure Conditions ............................................................................................................... 19 4.3.2 SAR Test Exclusion Evaluations ...................................................................................................... 21 4.4 Tissue Verification .......................................................................................................................................... 25 4.5 System Validation ........................................................................................................................................... 25 4.6 System Verification ......................................................................................................................................... 26 4.7 Maximum Output Power ................................................................................................................................. 27 4.7.1 Maximum Conducted Power ............................................................................................................ 27 4.7.2 Measured Conducted Power Result ................................................................................................ 29 4.8 SAR Testing Results ....................................................................................................................................... 35 4.8.1 SAR Test Reduction Considerations ................................................................................................ 35 4.8.2 SAR Results for Body Exposure Condition ...................................................................................... 36 4.8.3 2.4GHz 802.11g/n OFDM SAR Test Exclusion Consideration: ..................................…

Text truncated - open the document above for the full version.

Report Number: 68.950.23.0915.01 EMC_SZ_FR_23.06 FCC Release 2023-12-01 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12 & 13, Zhiheng Wisdomland Business Park, Guankou Erlu, Nantou, Nanshan District, Shenzhen, Guangdong, China Tel. +86 755 8828 6998, Fax: +86 755 8828 5299 Page 1 of 66 FCC/ISED - TEST REPORT Report Number : 68.950.23.0915.01 Date of Issue: 2023-12-06 Model/HVIN : EF-MT-H10-1 Product Type : EcoFlow PowerInsight Applicant : EcoFlow Inc. Address : 1st Floor, Building 1, Plant E, Jiehe Industrial City, Shuitian Community, Shiyan Street, Bao'an District, Shenzhen City, Guangdong 518000, China Manufacturer : EcoFlow Inc. Address : 1st Floor, Building 1, Plant E, Jiehe Industrial City, Shuitian Community, Shiyan Street, Bao'an District, Shenzhen City, Guangdong 518000, China Test Result : ◼ Positive  Negative Total pages including Appendices : 66 Any use for advertising purposes must be granted in writing. This technical report may only be quoted in full. This report is the result of a single examination of the object in question and is not generally applicable evaluation of the quality of other products in regular production. For further details, please see testing and certification regulation, chapter A-3.4. Report Number: 68.950.23.0915.01 EMC_SZ_FR_23.06 FCC Release 2023-12-01 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12 & 13, Zhiheng Wisdomland Business Park, Guankou Erlu, Nantou, Nanshan District, Shenzhen, Guangdong, China Tel. +86 755 8828 6998, Fax: +86 755 8828 5299 Page 2 of 66 1 Table of Contents 1 Table of Contents ..................................................................................................................................................2 2 Details about the Test Laboratory .........................................................................................................................3 3 Description of the Equipment Under Test .............................................................................................................4 4 Summary of Test Standards .................................................................................................................................5 5 Summary of Test Results ......................................................................................................................................6 6 General Remarks ..................................................................................................................................................7 7 Test Setups ...........................................................................................................................................................8 8 Systems Test Configuration ............................................................................................................................... 10 9 Technical Requirement ...................................................................................................................................... 11 9.1 Conducted Emission .................................................................................................................................. 11 9.2 Conducted Peak Output Power & EIRP ..................................................................................................... 14 9.3 20 dB Bandwidth and 99% Occupied Bandwidth ....................................................................................... 19 9.4 Carrier Frequency Separation .................................................................................................................... 27 9.5 Number of Hopping Frequencies ..............................................................................................................…

Text truncated - open the document above for the full version.
