USER’S MANUAL RB89 Contents --------------------------------------------------------------------------------01 -------------------------------------------------------------02 -------------------------------------------------------------------02 -----------------------------------------------------------------------05 -----------------------------------------------------------------06 -----------------------------------------------------------------------------07 W arning Familiar with this radio Function operation Factory setting Technical Indicators WARNING For downloading further resources: Brochures, Software/Firmware, Manual etc, Pls contact your direct reseller first OR go to website retevis.com and check “support” in the each product link to download it. W arning Please read this manual carefully before using this radio. Please do not charge the radio in flammable, explosive, and no radio signal places (such as gas stations and the airport). Please do not operate the radio without a license to the extent prohibitive by law . Please do not expose to sunlight for long and keep away from heating equipment. Please ensure this radio avoids any dusty, humid, and water-splashed place and avoids putting it near any heating distributor. If the radio is burning or smoking, please remove the battery from the radio, and contact your seller. The repair of this radio is in charge of professional technical; please do not disassembly by yourself. Charging notification Use the charger specified by this radio model to charge the battery. Please turn off the radio before charging. Please charge for at least 5 hours the first time to achieve the best battery performance. Please do not charge for a long time, nor if it will shorten the batteries' life. Stop charging when it is fully charging. The charger can charge this radio's battery; please do not charge other batteries. It will injure the charger and batteries. Please place the battery in a cool and dry place. Do not get close to the fire or exposed to the sun. Otherwise, there will be a safety hazard. Please do not transmit in charging. It is a normal phenomenon when charging heat. 01 Familiar with this radio. Charging instruction Charging mode: Plug the radio into a charger . The indicator flash red in charging, and fully charging turns green. 02 Antenna Indicator PTT button PF1 button / channel up PF2 button / channel down Volume / power knob Flashlight Speaker Mic remote headset / programming cable connector charging indicator Function operation 1. Power on/off 1.1 Turn the Power switch/Volume control clockwise. You will hear a click indicating the transceiver is ON. 1.2 Turn the Power switch fully counterclockwise to turn the radio OFF. 2. Volume adjustment 2.1 In receiving status, clockwise the volume/power knob to increase volume. 2.2 In receiving status, counterclockwise the volume/power knob to down the volume. 3. Transmitting/Receiving 3.1 In standby status, press the PTT button to transmit in the current channel, and the indicator flashes red. 3.2 Release the PTT button to receive the call on the current channel; the speaker reads the voice, and the LED indicator turns green. Notification: To transmit voice, press and hold the PTT button and speak into the microphone 1-2 inches (2.5-5 cm) away from your mouth in a normal tone of voice. Keep the radio from your head and body at least 1 inch (2.5cm) in transmitting. Please do not use it during many on-off actions; while the volume is adjusted to fit your listening feel the volume. Before speaking: Please set up the same frequency on the Transmitter and Receiver. Please set up the same CTCSS/DCS code on the Transmitter and Receiver. 4. Selecting the Channel In standby status, short press the PF1 or PF2 to switch the channel. You will hear and check the current channel number. 5. CTCSS/DCS Code 260 sets of CTCSS/DCS codes in total. You can set 50 sets of CTCSS codes and 105*2 sets (N-phase and I-phase) DCS codes in the software. 6. Battery Low Alert It reminds you that the battery needs recharging. The charging prompt will sound, and the red LED will blink. And now, transmitting and staying in standby and receiving mode is banned. Please recharge a new battery or charge the battery. 7. Squelch The purpose of the Squelch is to decide the signal strength when turning on the radio speaker. The lower the Squelch, the back noise is higher, and the communication range is extended, the weaker the anti-interference capability. You can choose the 0-9 squelch level in the software. The default squelch level is 3. 8. VOX VOX vice icon when the VOX feature is on. The walkie-talkie microphone detects sound input large enough, and the walkie-talkie will automatically start the launch and exit launch mode after stopping speaking. 8.1 The VOX function can be set up with programming software. (Menu check is always open, default off) 8.2 You can also turn on/off the VOX by PF1/PF2 button. Defined the PF1/PF2 button is the VOX function in the software. (Default PF1) Long press PF1 to turn on or off the VOX function Long press PF1 button repeatedly to adjust the VOX level (1-9 levels optional, level 9 is the most sensitive and default level 3) 9. VOX delay Defined the PF1/PF2 button is the VOX delay function in the software. Long press the PF1/PF2 button repeatedly to adjust the VOX delay level. (Level 1-6 optional and delay 0.5-3 seconds) 10. Monitor Defined the PF1/PF2 button is the Monitor function in the software. Long press PF1/PF2 to turn on the monitor, and release to turn off the monitor. 11. Flashlight Defined the PF1/PF2 button is a flashlight function in the software. Long press PF1/PF2 to turn on the flashlight, and repeat to turn off the flashlight. 12. Emergency Alarm function Defined the local emergency alarm or remote emergency alarm function in the software. Defined the PF1/PF2 button is an emergency alarm function in the software. Long press PF1/PF2 to turn on the emergency alarm function, and…
