2A46G-FRD2488Sensor System

1 说 明 书 User manual （24款感知模块） （Sensor System） 2024年5月20日 May 20, 2024 编制者：____陈锦贤_____________ Prepared by: __Chen Jin Xian__ 审 核：________________________ Reviewed by: _________________ 2 目录 Contents 一、 功能说明 ........................................................................................................................................... 3 I. Introduction...........................................................................................................................3 二、 关键性能 ........................................................................................................................................... 5 II. Specifications.......................................................................................................................5 三、 接口 ................................................................................................................................................... 8 III. Interfaces..............................................................................................................................8 四、 工作条件 ........................................................................................................................................... 9 IV. Operating Conditions.........................................................................................................9 五、 规范要求 ........................................................................................................................................ 10 V. Standards & Requirements ......................................................................................................... 10 六、 版本更新 ........................................................................................................................................ 11 VI. Version History .............................................................................................................................. 11 3 一、 功能说明 I. Introduction The sensing module is applied to the perception of agricultural operation environment, detecting the distance, speed and orientation of people, trees, wires, poles and other targets in the environment, and output 3D position point cloud information and speed information. The back-end processor uses the point cloud output by the radar for target detection and identification, and establishes a real-time map to provide agricultural UAVs with route planning and obstacle avoidance. The millimeter-wave radar has a head motor inside, which can realize the function of rocking scanning or maintaining a fixed Angle. The visual function produces images. 产品型号：FRD2488 Model: FRD2488 主要特性： Main Features: ⚫ Ranging range 0.3m~80m@ Swing Radar 0.3m~100m Ground Simulating Radar ⚫ Bluetooth communication distance 0m~10m ⚫ Visual distance 0m~100m ⚫ point cloud refresh rate：50Hz ⚫ CAN-FD port ⚫ LAN port ⚫ CAN-FD Interface ⚫ IP67 Waterproof ⚫ Operating Temperature: -40°C~+85°C 4 典型应用： Applications: - 无人机 Unmanned Aerial Vehicles - 无人车 Unmanned Ground Vehicles - 农机自驾仪 Autopilot Consoles 5 二、 关键性能 II. Specifications 表 1 主要性能 Table 1. Main Specifications 参数 Parameter 测试条件 Testing Condition 最小值 Min 典型值 Typical Value 最大值 Max 单位 Unit 频率特性 System 4D lmaaina Radar 发射频率 Transmit Frequency 24.15 24.15 GHz 调制方式 Modulation FMCW 刷新率 Refresh Rate 50 Hz Terrain Radar 发射频率 Transmit Frequency 24.15 24.15 GHz 调制方式 Modulation FMCW BLE 频率范围 Frequency BLE:<2MHz 2402 2480 Mhz 调制方式 BLE:GFSK Performance characteristic of 4D lmaaina Radar 测距范围 Distance Range @FOV：方位±40°，俯仰+90° ~-45° 0.3 80 M 6 @FOV: Azimuth: ±40°; Pitch Angle: +90°~-45° 测距精度 Distance Accuracy 非跟踪点目标 Non-tracking Point Target ±0.1 M 测速范围 Velocity Range 远离目标为“-”，靠近目标为 “+” Away from Target: “-”; Toward Target: “+” -13 +13 m/s 测速精度 Velocity Accuracy 点目标 Point Target ±0.1 m/s 测角范围 Angle Range 方位角 Azimuth -40 +40 ° 俯仰角 Pitch Angle -45 +90 ° 测角精度 Angle Accuracy 非跟踪点目标@方位角±50° Non-tracking Point Target @Azimuth: ±50° ±1 ° 非跟踪点目标@俯仰角±30° Non-tracking Point Target @Pitch Angle: ±30° ±1 ° 同时检测目标 Targets Tested Simultaneously 64 个 距离分辨率 Distance Resolution 非跟踪点目标，满足1.5到2 倍分辨率的条件下可以区分两 个物体 For Non-tracking Point Targets, two objects are distinguishable at 1.5x to 2x zoom 0.75 M 速度分辨率 Velocity 1 m/s 7 Resolution 角度分辨率 Angle Resolution 非跟踪点目标@方位角±40° Non-tracking Point Target @Azimuth: ±40° 9.5 ° 天线波束宽度 Beamwidth 方位角（-3dB） Azimuth (-3dB) 120 ° 俯仰角（-3dB） Pitch Angle (-3dB) 23 ° 天线增益 Antenna Gain 10 dBi Performance characteristics of Terrain Radar 测距范围 Distance Range 0.3 100 M 测距精度 Distance Accuracy ±0.3 M 天线波束宽度 Beamwidth 方位角（-3dB） Azimuth (-3dB) 40 ° 俯仰角（-3dB） Pitch Angle (-3dB) 30 ° 天线增益 Antenna Gain 10 dBi performance characteristics of BLE Communication distance 0 10 m Antenna polarization Circular polarization Antenna gain Antenna Gain 2.13 dBi 接口特性 Interface CAN-FD 通信速率 Communication Speed 4 Mbps 8 LAN 通信速率 Communication Speed 100 Mbps 供电 电源接口 12 24 26 V 结构特性 Structure 尺寸 Dimensions 宽*长*高 W*L*H - mm 材料 Material 雷达罩 Radar Housing PA66+30%GF 后壳 Rear Cover 铸铝 Cast Aluminum 重量 Weight 1200 g 9 三、 接口 III. Interfaces 感知模块与外部通信接口为CAN-FD，LAN口，接口定义12PIN接头、具体定义如下： 表 2 接口信号定义 Table 2. Interface Signal Definition 引脚 Pin 信号 Signal 类型 Type 定义 Definition 连接器 Connector 1 CAN_L I/O CAN-bus低位线 CAN-bus (Low Level) 1# Green 2# Green and white 3# blue 4# Blue and white 5# yellow 6# yellow and white 7# brown 8# black 9# brown and white 10# black and white 11# red 12# red and white X2026WVS-2x06D1- 46SN 2 CAN_H I/O CAN-bus高位线 CAN-bus (High Level) 3 DATA1_N I/O LAN CAN Data1 4 DATA1_P I/O LAN CAN Data 1 5 DATA2_N I/O LAN CAN Data 2 6 DATA2_P I/O LAN CAN Data 2 7 DATA3_N I/O LAN CAN Data 3 8 DATA3_P I/O LAN CAN Data 3 9 DATA4_N I/O LAN CAN Data 4 10 DATA4_P I/O LAN CAN Data 4 11 24V Power supply positive 12 GND Negative terminal 10 四、 工作条件 IV. Operating Conditions Normal use of the sensing module requires certain working conditions and working environment, beyond the range of working conditions may lead to abnormal work, burn, etc. Specific requirements are as follows: 表 …

Text truncated - open the document above for the full version.

PegasusSprayInc Date:4/9/2024 FederalCommunicationsCommissions AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 RE:CFR47§2.911(d)(7)FCCUSAgentLetterofAttestation FCCGranteeCode:2A46G Grantee’sFRN:0032030363 Towhomitmayconcern: FCCUSAgent AgentCompanyName:PegasusSprayInc FCCFRN:0033696949 AgentContactName:ArthurChen AgentUSAddress:223579thAveNE,Medina,WA98039 AgentEmailAddress:[email protected] ThisletteristoconfirmthatwehaveacceptedtheresponsibilitytoactasUSAgentonbehalf ofGuangzhouXaircraftTechnologyCO.,LTD(“theapplicant”)fortheaboveGranteecode. Weareawareoftherequirementsandresponsibilitiesoftheapplicant’sagentforserviceof processasoutlinedintheFCCsection2.911(d)(7)andReportandOrderFCC22-84 paragraph63. Sincerely, Signature AgentCompanyName:PegasusSprayInc AgentContactName:ArthurChen AgentUSAddress:223579thAveNE,Medina,WA98039 #

Guangzhou Xaircraft Technology CO.,LTD Date: 6/19/2024 Federal Communications Commissions Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 RE: CFR 47 §2.911 (d)(7) Agent Designation Attestation FCC Grantee Code: 2A46G-FRD2488 Grantee’s FRN: 0032030363 Guangzhou Xaircraft Technology CO.,LTD (“the applicant”) as required by section 2.911(d)(7), designates the following agent, located in the United States, for purposes of acting as the applicant’s agent for service of process. The applicant acknowledges that they will maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility under CFR 47 §2.929(c) to inform the FCC whenever the agent information changes. U.S. Agent Information: Contact Person: Arthur Chen/Chen Lei FRN: 0033696949 Company Name: Pegasus Spray Inc Company Address: 2235 79th Ave NE, Medina, WA 98039, USA Email: [email protected] Sincerely yours, (Signature) Company Name: Guangzhou Xaircraft Technology CO.,LTD Contact Name: Elaine Wu Title of Person: Product Certification Engineer Address: Block C, No.115, Gaopu Road, Tianhe District, GuangzhouCity, Guangdong, P.R. 510663 China Date: 06/19/2024

Guangzhou Xaircraft Technology CO.,LTD Date: 9/19/2024 Federal Communications Commissions Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 RE: CFR 47 §2.911 (d)(5) Attestation FCC ID: 2A46G-FRD2488 1. Guangzhou Xaircraft Technology CO.,LTD (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. 2. Guangzhou Xaircraft Technology CO.,LTD (“the applicant”) certifies that, the device does not havecybersecurity and / or anti-virus software produced or provided by Kaspersky Lab, Inc. orany of its successors and assignees, identified on the Covered List installed on thedevice, nor will it be installed by the applicant anytime after certification. 3. Guangzhou Xaircraft Technology CO.,LTD (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment and is not an affiliate or subsidiary of an entity identified on the Covered List. Sincerely yours, (Signature) Company Name: Guangzhou Xaircraft Technology CO.,LTD Contact Name: Elaine Wu Title of Person: Product Certification Engineer Address: Block C, No.115, Gaopu Road, Tianhe District, GuangzhouCity, Guangdong, P.R. 510663 China Date: 09/19/2024

GuangzhouXaircraftTechnologyCO.,LTD Date:04/09/2024 FederalCommunicationsCommission 7435OaklandMillsRoad ColumbiaMD21046 Towhomitmayconcern: I,theundersigned,herebyauthorizeULVerificationServicesInc.toactonourbehalfinall mannersrelatingtoapplicationforequipmentauthorization,includingsigningofalldocuments relatingtothesematters.AnyandallactscarriedoutbyULVerificationServicesInc.onour behalfshallhavethesameeffectasactsofourown. I,theundersigned,herebycertifythatwearenotsubjecttoadenialoffederalbenefits,that includesFCCbenefits,pursuanttoSection5301oftheAnti-DrugAbuseActof1988,21U.S.C. 853(a). InauthorizingULVerificationServicesInc.asourrepresentative,westillrecognizethatweare responsibleto: a)complywiththerelevantprovisionsofthecertificationprogram; b)makeallnecessaryarrangementsfortheconductoftheevaluation,including provisionforexaminingdocumentationandaccesstoallareas,records(including internalauditreports)andpersonnelforthepurposesofevaluation(e.g.testing, inspection,assessment,surveillance,reassessment)andresolutionofcomplaints; c)makeclaimsregardingcertificationonlyinrespectofthescopeforwhich certificationhasbeengranted; d)donotuseourproductcertificationinsuchamannerastobringtheCertification Divisionintodisreputeandnotmakeanystatementregardingourproduct certificationwhichtheCertificationDivisionmayconsidermisleadingor unauthorized; e)uponsuspensionorcancellationofcertification,discontinueuseofalladvertising matterthatcontainsanyreferencetheretoandreturnanycertificationdocuments asrequiredbytheCertificationDivision; f)usecertificationonlytoindicatetheproductsarecertifiedasbeinginconformity withspecifiedstandards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Signed by: (Signature) Company Name: Guangzhou Xaircraft Technology CO.,LTD Contact Name: Elaine Wu Title of Person: Product Certification Engineer Address: Block C, No.115, Gaopu Road, Tianhe District, GuangzhouCity, Guangdong, P.R. 510663 China

Guangzhou Xaircraft Technology CO.,LTD Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: 2A46G-FRD2488 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards (Signature) Company Name: Guangzhou Xaircraft Technology CO.,LTD Contact Name: Elaine Wu Title of Person: Product Certification Engineer Address: Block C, No.115, Gaopu Road, Tianhe District, GuangzhouCity, Guangdong, P.R. 510663 China Date: 04/09/2024

External Photographs Project No.:4791353869-1 Page 2 of 5 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. View of EUT-1 View of EUT-2 Page 3 of 5 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. View of EUT-3 View of EUT-4 Page 4 of 5 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. View of EUT-5 View of EUT-6 Page 5 of 5 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. View of EUT-7

Label： Label location：

Internal Photographs Project No.:4791353869-1 Page 2 of 14 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-1 Internal View of EUT-2 Page 3 of 14 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-3 Internal View of EUT-4 Page 4 of 14 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-5 Internal View of EUT-6 Antenna for terrain radar Page 5 of 14 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-7 Internal View of EUT-8 Antenna for 4D Imaging radar Page 6 of 14 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-9 Page 7 of 14 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-10 Page 8 of 14 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-11 Page 9 of 14 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-12 Page 10 of 14 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-13 Internal View of EUT-14 Page 11 of 14 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-15 Internal View of EUT-16 Page 12 of 14 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-17 Internal View of EUT-18 Page 13 of 14 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-19 Internal View of EUT-20 Page 14 of 14 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-21 Internal View of EUT-22

The results reported herein have been performed in accordance with the laboratory’s terms of accreditation. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report apply to the test sample(s) mentioned above at the time of the testing period only and are not to be used to indicate applicability to other similar products. FCC RF EXPOSURE REPORT For Sensor System MODEL NUMBER: FRD2488 REPORT NUMBER: 4791353869-1-RF-5 ISSUE DATE: September 5, 2024 FCC ID: 2A46G-FRD2488 Prepared for Guangzhou Xaircraft Technology CO., LTD Block C, No.115, Gaopu Road, Tianhe District, GuangzhouCity, Guangdong, P.R. 510663 China Prepared by UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch Building 10, Innovation Technology Park, No. 1, Li Bin Road, Song Shan Lake Hi- Tech Development Zone Dongguan, 523808, People’s Republic of China Tel: +86 769 22038881 Fax: +86 769 33244054 Website: www.ul.com REPORT NO.: 4791353869-1-RF-5 Page 2 of 7 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Revision History Rev. Issue Date Revisions Revised By V0 September 5, 2024 Initial Issue \ REPORT NO.: 4791353869-1-RF-5 Page 3 of 7 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS ................................................................................. 4 2. TEST METHODOLOGY ..................................................................................................... 5 3. FACILITIES AND ACCREDITATION ................................................................................. 5 4. REQUIREMENT ................................................................................................................. 6 REPORT NO.: 4791353869-1-RF-5 Page 4 of 7 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. 1. ATTESTATION OF TEST RESULTS Applicant Information Company Name: Guangzhou Xaircraft Technology CO., LTD Address: Block C, No.115, Gaopu Road, Tianhe District, GuangzhouCity, Guangdong, P.R. 510663 China Manufacturer Information1 Company Name: Guangzhou Xaircraft Technology CO., LTD Address: Block C, No.115, Gaopu Road, Tianhe District, GuangzhouCity, Guangdong, P.R. 510663 China EUT Information EUT Name: Sensor System Model: FRD2488 Sample Received Date: June 4, 2024 Sample Status: Normal Sample ID: 7284012-1 Date of Tested: June 26, 2024 to September 5, 2024 APPLICABLE STANDARDS STANDARD TEST RESULTS FCC 47CFR§2.1091 PASS KDB 447498 D01 PASS Prepared By: Checked By: James Qin Kebo Zhang Project Engineer Senior Project Engineer Approved By: Stephen Guo Operations Manager REPORT NO.: 4791353869-1-RF-5 Page 5 of 7 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. 2. TEST METHODOLOGY The tests documented in this report were performed in accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 and KDB447498 D01 v06. 3. FACILITIES AND ACCREDITATION Accreditation Certificate A2LA (Certificate No.: 4102.01) UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch. has been assessed and proved to be in compliance with A2LA. FCC (FCC Designation No.: CN1187) UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch. Has been recognized to perform compliance testing on equipment subject to the Commission's Delcaration of Conformity (DoC) and Certification rules ISED (Company No.: 21320) UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch. has been registered and fully described in a report filed with ISED. The Company Number is 21320 and the test lab Conformity Assessment Body Identifier (CABID) is CN0046. VCCI (Registration No.: G-20192, C-20153, T-20155 and R-20202) UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch. has been assessed and proved to be in compliance with VCCI, the Membership No. is 3793. Facility Name: Chamber D, the VCCI registration No. is G-20192 and R-20202 Shielding Room B, the VCCI registration No. is C-20153 and T-20155 Note 1: All tests measurement facilities use to collect the measurement data are located at Building 10, Innovation Technology Park, Song Shan Lake Hi tech Development Zone, Dongguan, 523808, China Note 2: The test anechoic chamber in UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch had been calibrated and compared to the open field sites and the test anechoic chamber is shown to be equivalent to or worst case from the open field site. Note 3: For below 30MHz, lab had performed measurements at test anechoic chamber and comparing to measurements obtained on an open field site. And these measurements below 30MHz had been correlated to measurements performed on an OFS. REPORT NO.: 4791353869-1-RF-5 Page 6 of 7 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. 4. REQUIREMENT LIMIT AND CALCULATION METHOD Systems operating under the provisions of FCC 47 CFR section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. In …
