2A46G-XAPC2AHBD25RXAG APC2 AutoPilot Console

XAG APC2 AutoPilot Console User Manual EN Version 1.1 To User Dear user, thank you for choosing XAG's product. For safety purposes and better user experience, it is highly recommended that you read this manual carefully and strictly follow the instructions hereof. Contact Us Manufacturer: Guangzhou Xaircraft Technology Co., Ltd. Add: XSpace, No.115, Gaopu Road, Guangzhou, Guangdong Province, China Technical Support Team: [email protected] Contents Safety Guidelines 1 Introduction 2 List of Items 2 Main Components 3 Installation 5 Motor Holder 5 Motor 6 Steering Wheel 7 Console 8 Wiring Guide 9 How to Use 10 Download "XAG AutoPilot" App 10 Add a Device 10 App Screen 11 Firmware Update 14 Create a Vehicle 14 Self-learning 14 Reference Line Operation 15 Create a Field 16 Field Operation 17 Operation Adjustment 18 Spacing Calibration 19 End Operation 19 SAFETY WARNINGS 20 Specifications 21 Disclaimer 23 Warning 24 1 www.xa.com/en Safety Guidelines ・ The operator should hold a driver's license for operating agricultural machinery and strictly observe local laws and regulations on driving farm vehicles. ・ It is mandatory to complete the operator training before using this product. Unauthorized operation is not allowed until training is completed. ・ Make sure the farm vehicle is well-functioning and co-frequency interference is avoided before use. ・ Check and make sure the device is in RTK status before use, otherwise it will be inoperable. ・ While planning a route, it is important to consider the distance between the vehicle and the field boundary, as well as the forest zone. Set a safe distance from the field boundary. ・ Make sure the console is securely attached to the top of the vehicle for a stable signal. ・ Make sure the antennas are not obstructed by anything while using the console, or it may not work properly. ・ If the RTK signal is weak, regain control of the vehicle immediately. ・ The driver should not enter or exit the vehicle during autonomous operation. ・ During autonomous driving, the driver should look ahead to identify obstacles and potential hazards. Be prepared to regain control of the vehicle as it approaches the destination. If the vehicle deviates from the planned route, immediately apply the brakes and stop the operation. ・ Before applying autonomous driving in towing operations, it is recommended to start with manual driving to save resources and ensure safe operations. ・ While planning the route with AB line mode in practice, please mark points based on the field shape to optimize land use. ・ Never drive while drowsy, drunk or in a poor mental state so as to prevent accidents. ・ Get acquainted with the driving environment, which should be kept clear of obstacles and crowds and free from hazardous conditions. ・ The distance between the operating field and the base station should be always maintained within 20km. ・ Stay clear of the machine while it is running. Never touch the spinning motor with your body or other components. ・ Keep the product away from heat to avoid damage to the electronic device and other components. ・ Never touch the spline under the middle of the steering wheel with any part of your body or other things to prevent personal injury and damage to the device. ・ The "Vehicle Parameters" referred to herein is an example to help you fully understand how to use the product and where it can be applied, rather than the reference data under practical conditions. You should review and specify the parameters based on your specific conditions and requirements. 2 www.xa.com/en Introduction The XAG APC2 AutoPilot Console (hereinafter referred to as "APC2") applies to a wide range of tractors and rice transplanters, enabling driving assistance, high- precision RTK navigation, and timed and quantified operations. It responds accurately to dynamic changes in the soil and crops. By connecting to a smartphone or tablet, it becomes much easier to control the vehicle, alleviating the fatigue experienced by the operator. In addition, it can autonomously control the towed implement to precisely perform farming operations, including land preparation, soil loosening, and seeding. Operation records are synchronized in real time with the XAG Smart Agriculture System, making your every effort worthwhile. List of Items Please see that all of the following items are present when unpacking the box. Should there be any item missing, please contact your dealer. Motor x 1 Console x 1 Mounting Bracket x 1 Steering Wheel x 1 Motor Holder x 1 Screw Pack x 1 3 www.xa.com/en Main Components Console Mounting Bracket Wi-Fi Antenna Slave Antenna Ant Port Rear View Status Indicator Control 1/C1 Port Internet/Eth Port Type-C Port SIM Card Slot 4 www.xa.com/en Steering Wheel Steering Wheel Motor Status Indicator Spindle Clamp Height- Adjustable Bolt Right Lever Left Lever Junction Box Steering Wheel Cap Motor Power Cord Control 1/C1 Cable 5 www.xa.com/en Installation Motor Holder Steps: ① Fix the clamp with an M10*100 hex bolt and an M10 nut. ② Combine the L-shaped bracket with two M10 nuts and loosely tighten the holder. ③ Adjust each part to finish the preliminary assembly of the motor holder. To prevent the bolts from loosening during use, it is recommended to apply thread adhesive to the three M10 nuts of the height-adjustable bolt before installation. Note 6 www.xa.com/en Motor Steps: ① Attach the spline [1] to the motor with six M4 * 20 screws. ② Attach the motor holder to the motor with two M6*12 screws. ③ Attach the motor (with the left and right levers facing the driver's seat) to the vehicle motor spindle with the nut that comes with the vehicle, and then loosely tighten the other spindle clamp to the spindle with two M6*120 bolts and two M6 nuts. ④ Tighten each part when everything is properly aligned. Please remove the original steering wheel and motor before installation. Splines vary with each model of the vehicle, and you will need to buy the spline that matches the vehicle. Note Fo…

Text truncated - open the document above for the full version.

Guangzhou Xaircraft Technology CO.,LTD Date: 4/9/2024 Federal Communications Commissions Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 RE: CFR 47 §2.911 (d)(5) Attestation FCC ID: 2A46G-XAPC2AHBD25RD 1. Guangzhou Xaircraft Technology CO.,LTD (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. 2. Guangzhou Xaircraft Technology CO.,LTD (“the applicant”) certifies that, as of the date of the filing of the application, the applicantis not identified on the Covered Listas an entity producing “covered” equipment andis notan affiliate or subsidiaryof an entity identified on the Covered List. Sincerely yours, (Signature) Company Name: Guangzhou Xaircraft Technology CO.,LTD Contact Name: Elaine Wu Title of Person: Product Certification Engineer Address: Block C, No.115, Gaopu Road, Tianhe District, GuangzhouCity, Guangdong, P.R. 510663 China Date: 04/09/2024

PegasusSprayInc Date:4/9/2024 FederalCommunicationsCommissions AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 RE:CFR47§2.911(d)(7)FCCUSAgentLetterofAttestation FCCGranteeCode:2A46G Grantee’sFRN:0032030363 Towhomitmayconcern: FCCUSAgent AgentCompanyName:PegasusSprayInc FCCFRN:0033696949 AgentContactName:ArthurChen AgentUSAddress:223579thAveNE,Medina,WA98039 AgentEmailAddress:[email protected] ThisletteristoconfirmthatwehaveacceptedtheresponsibilitytoactasUSAgentonbehalf ofGuangzhouXaircraftTechnologyCO.,LTD(“theapplicant”)fortheaboveGranteecode. Weareawareoftherequirementsandresponsibilitiesoftheapplicant’sagentforserviceof processasoutlinedintheFCCsection2.911(d)(7)andReportandOrderFCC22-84 paragraph63. Sincerely, Signature AgentCompanyName:PegasusSprayInc AgentContactName:ArthurChen AgentUSAddress:223579thAveNE,Medina,WA98039 #

GuangzhouXaircraftTechnologyCO.,LTD Date:4/9/2024 FederalCommunicationsCommissions AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 RE:CFR47§2.911(d)(7)AgentDesignationAttestation FCCGranteeCode:2A46G Grantee’sFRN:0032030363 GuangzhouXaircraftTechnologyCO.,LTD(“theapplicant”)asrequiredbysection 2.911(d)(7),designatesthefollowingagent,locatedintheUnitedStates,forpurposesof actingastheapplicant’sagentforserviceofprocess. Theapplicantacknowledgesthattheywillmaintainanagentfornolessthanoneyearafter thegranteehasterminatedallmarketingandimportationortheconclusionofany Commission-relatedproceedinginvolvingtheequipment.Theapplicantfurther acknowledgestheirresponsibilityunderCFR47§2.929(c)toinformtheFCCwheneverthe agentinformationchanges. U.S.AgentInformation: ContactPerson:ArthurChen FRN:0033696949 CompanyName:PegasusSprayInc CompanyAddress:223579thAveNE,Medina,WA98039 Email:[email protected] Sincerelyyours, (Signature) CompanyName:GuangzhouXaircraftTechnologyCO.,LTD ContactName:ElaineWu TitleofPerson:ProductCertificationEngineer Address:BlockC,No.115,GaopuRoad,TianheDistrict,GuangzhouCity,Guangdong,P.R. 510663China

GuangzhouXaircraftTechnologyCO.,LTD Date:04/09/2024 FederalCommunicationsCommission 7435OaklandMillsRoad ColumbiaMD21046 Towhomitmayconcern: I,theundersigned,herebyauthorizeULVerificationServicesInc.toactonourbehalfinall mannersrelatingtoapplicationforequipmentauthorization,includingsigningofalldocuments relatingtothesematters.AnyandallactscarriedoutbyULVerificationServicesInc.onour behalfshallhavethesameeffectasactsofourown. I,theundersigned,herebycertifythatwearenotsubjecttoadenialoffederalbenefits,that includesFCCbenefits,pursuanttoSection5301oftheAnti-DrugAbuseActof1988,21U.S.C. 853(a). InauthorizingULVerificationServicesInc.asourrepresentative,westillrecognizethatweare responsibleto: a)complywiththerelevantprovisionsofthecertificationprogram; b)makeallnecessaryarrangementsfortheconductoftheevaluation,including provisionforexaminingdocumentationandaccesstoallareas,records(including internalauditreports)andpersonnelforthepurposesofevaluation(e.g.testing, inspection,assessment,surveillance,reassessment)andresolutionofcomplaints; c)makeclaimsregardingcertificationonlyinrespectofthescopeforwhich certificationhasbeengranted; d)donotuseourproductcertificationinsuchamannerastobringtheCertification Divisionintodisreputeandnotmakeanystatementregardingourproduct certificationwhichtheCertificationDivisionmayconsidermisleadingor unauthorized; e)uponsuspensionorcancellationofcertification,discontinueuseofalladvertising matterthatcontainsanyreferencetheretoandreturnanycertificationdocuments asrequiredbytheCertificationDivision; f)usecertificationonlytoindicatetheproductsarecertifiedasbeinginconformity withspecifiedstandards; g)endeavortoensurethatnocertificateorreportnoranypartthereofisusedina misleadingmanner; h)ensurethatanyreferencetoourproductcertificationincommunicationmediasuchas documents,brochuresoradvertising,complieswiththerequirementsofthe CertificationDivision; i)keeparecordofallcomplaintsmadeknowntousrelatingtotheproduct’s compliancewithrequirementsoftherelevantstandardandtomaketheserecords availabletothewhenrequested; j)takeappropriateactionwithrespecttosuchcomplaintsandanydeficienciesfoundin productsorservicesthataffectcompliancewiththerequirementsforcertification; k)documenttheactionstaken. Thisauthorizationisvaliduntilfurtherwrittennoticefromtheapplicant. SincerelyYours, Signedby: (Signature) CompanyName:GuangzhouXaircraftTechnologyCO.,LTD ContactName:ElaineWu TitleofPerson:ProductCertificationEngineer Address:BlockC,No.115,GaopuRoad,TianheDistrict,GuangzhouCity,Guangdong,P.R. 510663China

Guangzhou Xaircraft Technology CO.,LTD Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: 2A46G-XAPC2AHBD25RD To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards (Signature) Company Name: Guangzhou Xaircraft Technology CO.,LTD Contact Name:Elaine Wu Title of Person: Product Certification Engineer Address: Block C, No.115, Gaopu Road, Tianhe District, GuangzhouCity, Guangdong, P.R. 510663 China Date: 04/09/2024

External Photographs Page 2 of 3 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. . Page 3 of 3 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. .

Note: 1. Product Label applied using permanent adhesive. It is user-accessible and non-detachable. 2. The FCC label statement will be included in the user manual which will be printed on a paper insert and sold with the device.

Internal Photographs Page 2 of 7 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. . Page 3 of 7 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. . Main Ant. Div. Ant. BT/WiFi Ant. Page 4 of 7 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. . Page 5 of 7 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. . Page 6 of 7 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. . Page 7 of 7 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. . Label Note: Product Label applied using permanent adhesive. It is user-accessible and non-detachable.

The results reported herein have been performed in accordance with the laboratory’s terms of accreditation. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report apply to the test sample(s) mentioned above at the time of the testing period only and are not to be used to indicate applicability to other similar products. FCC RF EXPOSURE REPORT For XAG APC2 AutoPilot Console MODEL NUMBER: XAPC2AHBD-2.5RD REPORT NUMBER: 4791318657-1-RF-6 ISSUE DATE: March 19, 2024 FCC ID: 2A46G-XAPC2AHBD25RD Prepared for Guangzhou Xaircraft Technology CO.,LTD Block C, No.115, Gaopu Road, Tianhe District, GuangzhouCity, Guangdong, P.R. 510663 China Prepared by UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch Building 10, Innovation Technology Park, No. 1, Li Bin Road, Song Shan Lake Hi- Tech Development Zone Dongguan, 523808, People’s Republic of China Tel: +86 769 22038881 Fax: +86 769 33244054 Website: www.ul.com REPORT NO.: 4791318657-1-RF-6 Page 2 of 8 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Revision History Rev. Issue Date Revisions Revised By V0 03/20/2024 Initial Issue \ REPORT NO.: 4791318657-1-RF-6 Page 3 of 8 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS ..................................................................................4 2. TEST METHODOLOGY ......................................................................................................5 3. FACILITIES AND ACCREDITATION ..................................................................................5 4. REQUIREMENT ..................................................................................................................6 REPORT NO.: 4791318657-1-RF-6 Page 4 of 8 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. 1. ATTESTATION OF TEST RESULTS Applicant Information Company Name: Guangzhou Xaircraft Technology CO., LTD Address: Block C, No.115, Gaopu Road, Tianhe District, GuangzhouCity, Guangdong, P.R. 510663 China Manufacturer Information1 Company Name: Guangzhou Xaircraft Technology CO., LTD Address: Block C, No.115, Gaopu Road, Tianhe District, GuangzhouCity, Guangdong, P.R. 510663 China EUT Information EUT Name: XAG APC2 AutoPilot Console Model: XAPC2AHBD-2.5RD Sample Received Date: February 28, 2024 Sample Status: Normal Sample ID: 7208081 Date of Tested: February 28, 2024 to March 19, 2024 APPLICABLE STANDARDS STANDARD TEST RESULTS FCC 47CFR§2.1091 PASS KDB-447498 D01 PASS Prepared By: Checked By: James Qin Denny Huang Project Engineer Senior Project Engineer Approved By: Stephen Guo Operations Manager REPORT NO.: 4791318657-1-RF-6 Page 5 of 8 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. 2. TEST METHODOLOGY The tests documented in this report were performed in accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 and KDB447498 D01 v06. 3. FACILITIES AND ACCREDITATION Accreditation Certificate A2LA (Certificate No.: 4102.01) UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch. has been assessed and proved to be in compliance with A2LA. FCC (FCC Designation No.: CN1187) UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch. Has been recognized to perform compliance testing on equipment subject to the Commission's Delcaration of Conformity (DoC) and Certification rules ISED (Company No.: 21320) UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch. has been registered and fully described in a report filed with ISED. The Company Number is 21320 and the test lab Conformity Assessment Body Identifier (CABID) is CN0046. VCCI (Registration No.: G-20192, C-20153, T-20155 and R-20202) UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch. has been assessed and proved to be in compliance with VCCI, the Membership No. is 3793. Facility Name: Chamber D, the VCCI registration No. is G-20192 and R-20202 Shielding Room B, the VCCI registration No. is C-20153 and T-20155 Note 1: All tests measurement facilities use to collect the measurement data are located at Building 10, Innovation Technology Park, Song Shan Lake Hi tech Development Zone, Dongguan, 523808, China Note 2: The test anechoic chamber in UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch had been calibrated and compared to the open field sites and the test anechoic chamber is shown to be equivalent to or worst case from the open field site. Note 3: For below 30MHz, lab had performed measurements at test anechoic chamber and comparing to measurements obtained on an open field site. And these measurements below 30MHz had been correlated to measurements performed on an OFS. REPORT NO.: 4791318657-1-RF-6 Page 6 of 8 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. 4. REQUIREMENT LIMIT AND CALCULATION METHOD Systems operating under the provisions of FCC 47 CFR section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in …

Text truncated - open the document above for the full version.

The results reported herein have been performed in accordance with the laboratory’s terms of accreditation. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report apply to the test sample(s) mentioned above at the time of the testing period only and are not to be used to indicate applicability to other similar products. CFR 47 FCC PART 15 SUBPART C TEST REPORT For XAG APC2 AutoPilot Console MODEL NUMBER: XAPC2AHBD-2.5RD REPORT NUMBER: 4791318657-1-RF-2 ISSUE DATE: March 19, 2024 FCC ID: 2A46G-XAPC2AHBD25RD Prepared for Guangzhou Xaircraft Technology CO.,LTD Block C, No.115, Gaopu Road, Tianhe District, GuangzhouCity, Guangdong, P.R. 510663 China Prepared by UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch Building 10, Innovation Technology Park, No. 1, Li Bin Road, Song Shan Lake Hi- Tech Development Zone Dongguan, 523808, People’s Republic of China Tel: +86 769 22038881 Fax: +86 769 33244054 Website: www.ul.com REPORT NO.: 4791318657-1-RF-2 Page 2 of 95 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM NO: 10-SL-F0035 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Revision History Rev. Issue Date Revisions Revised By V0 March 19, 2024 Initial Issue REPORT NO.: 4791318657-1-RF-2 Page 3 of 95 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM NO: 10-SL-F0035 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Summary of Test Results Test Item Clause Limit/Requirement Result Antenna Requirement N/A FCC 15.203 Pass AC Power Line Conducted Emission ANSI C63.10-2013 Clause 6.2 FCC Part 15.207 N/A Conducted Output Power ANSI C63.10-2013 Clause 7.8.5 FCC 15.247 (b) (1) Pass 20 dB Bandwidth and 99% Occupied Bandwidth ANSI C63.10-2013 Clause 6.9.2 FCC 15.247 (a) (1) Pass Carrier Hopping Channel Separation ANSI C63.10-2013 Clause 7.8.2 FCC 15.247 (a) (1) Pass Number of Hopping Frequency ANSI C63.10-2013 Clause 7.8.3 15.247 (a) (1) III Pass Time of Occupancy (Dwell Time) ANSI C63.10-2013 Clause 7.8.4 15.247 (a) (1) III Pass Conducted Bandedge and Spurious Emission ANSI C63.10-2013 Clause 6.10.4 & Clause 7.8.8 FCC 15.247 (d) Pass Radiated Band edge and Spurious Emission ANSI C63.10-2013 Clause 6.3 & 6.5 & 6.6 FCC 15.247 (d) FCC 15.209 FCC 15.205 Pass Duty Cycle ANSI C63.10-2013, Clause 11.6 None; for reporting purposes only. Pass Note: 1. N/A: In this whole report not applicable. *This test report is only published to and used by the applicant, and it is not for evidence purpose in China. *The measurement result for the sample received is <Pass> according to <CFR 47 FCC PART 15 SUBPART C> when <Simple Acceptance> decision rule is applied. REPORT NO.: 4791318657-1-RF-2 Page 4 of 95 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM NO: 10-SL-F0035 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. CONTENTS 1. ATTESTATION OF TEST RESULTS..................................................................................... 6 2. TEST METHODOLOGY......................................................................................................... 7 3. FACILITIES AND ACCREDITATION..................................................................................... 7 4. CALIBRATION AND UNCERTAINTY ................................................................................... 8 4.1. MEASURING INSTRUMENT CALIBRATION ........................................................... 8 4.2. MEASUREMENT UNCERTAINTY ............................................................................ 8 5. EQUIPMENT UNDER TEST .................................................................................................. 9 5.1. DESCRIPTION OF EUT ........................................................................................... 9 5.2. CHANNEL LIST ........................................................................................................ 9 5.3. MAXIMUM POWER .................................................................................................. 9 5.4. TEST CHANNEL CONFIGURATION ...................................................................... 10 5.5. THE WORSE CASE POWER SETTING PARAMETER .......................................... 10 5.6. DESCRIPTION OF AVAILABLE ANTENNAS ......................................................... 11 5.7. SUPPORT UNITS FOR SYSTEM TEST ................................................................. 12 6. MEASURING EQUIPMENT AND SOFTWARE USED......................................................... 13 7. ANTENNA PORT TEST RESULTS ..................................................................................... 16 7.1. CONDUCTED OUTPUT POWER .......................................................................... 16 7.2. 20 DB BANDWIDTH AND 99% OCCUPIED BANDWIDTH ..................................... 17 7.3. CARRIER HOPPING CHANNEL SEPARATION ..................................................... 19 7.4. NUMBER OF HOPPING FREQUENCY .................................................................. 21 7.5. TIME OF OCCUPANCY (DWELL TIME) ................................................................. 23 7.6. CONDUCTED BANDEDGE AND SPURIOUS EMISSION ...................................... 25 7.7. DUTY CYCLE ......................................................................................................... 27 8. RADIATED TEST RESULTS ............................................................................................... 28 8.1. RESTRICTED BANDEDGE .................................................................................... 35 8.2. SPURIOUS EMISSIONS(1 GHZ~3 GHZ) .…

Text truncated - open the document above for the full version.

广州极飞科技股份有限公司 样品承认书 产品料号： 产品版本 :A0 产品名称 ：双频内置PCB天线 产品规格： 2.4G/5G PCB 天线 1.13mm 灰色线 L =180mm+IPEX 原料牌号： 表面处理：丝印 供 应 商：东莞市海恒电子科技有限公司 极飞签核供应商签核 结构设计可靠性质量中试审批制作审核核准 邓文兵胡超陈鹏 说明：说明： ProductNumber:AN2450-PCB44AX ProductName:Antenna Page2 Index: 1.Specification(规格) 2.CharacteristicsandReliabilityTest(产品特性和可靠性测试标准) 3.Antenna-SParameterTestData(样品测试数据) 4.Antenna-RadiationPatternTestData(辐射模式测试数据) 5.MechanicalandPackingDrawing(图纸包装规范) RevisionHistory（变更履历） RevisionDateChangeNotificationDescription 1.02023.9.13 初版 ProductNumber:AN2450-PCB44AX ProductName:Antenna Page3 1.Specification SamplePhoto A.ElectricalCharacteristics Frequency 频率2400-250MHz/5150-5850MHz S.W.R. 驻波比<=2.0/<=2.0 AntennaGain增益2.89dBi/5.81dBi Polarization极化方式Linear Impedance阻抗50Ohm B.Material&MechanicalCharacteristics CableType 线材规格 OD1.13mm ， grey ConnectorType 连接器规格I-PEX C.Environmental StorageTemperature存储温度-30 ̊C~+80 ̊C OperationTemperature工作温度-30 ̊C~+80 ̊C ProductNumber:AN2450-PCB44AX ProductName:Antenna Page4 2.CharacteristicsandReliabilityTest TestItems测试 项目 TestConditionandProcedure测试方法Requirements要求Result 结果 1V.S.W.R. 电压驻波比 SetDUTonNetworkAnalyzer;makeindividual calibrationtotest设置网络分析仪参数进行测试 DirectiveDUTspecification 符合待测物规范 PASS 2Insertion Loss插入损 失 SetDUTonNetworkAnalyzer;makeindividual calibrationtotest设置网络分析仪参数进行测试 DirectiveDUTspecification 符合待测物规范 PASS 3Antenna Gain 天线增益 SetDUTonAntennaChamber;makeindividual calibrationtotest设置天线暗室参数进行测试 DirectiveDUTspecification 符合待测物规范 PASS 4Vibration 震动 GB/T2423.48-2008 Freq:50to80to50Hz10gacceleration, 12cyclesineachdirection 振动：55-80Hz，10g加速度，各方向12次循环 1.NoVisualDamage 2.FrequencyTol.≤5% 无明显外观不良;频率偏移≤5% PASS 5Dimension 尺寸 Inspectionofdimension,color,material,package, surfaceprocess.检查尺寸,颜色,材料,包装,表面处理 DirectiveDUTspecification 符合待测物规范 PASS 6SaltSpray盐 雾 GB/T2423.17-2008 Temp:35°C;RH:≥95%;NaClsolution:≥ 5%;Time:72H 温度35°C；湿度≥95%;盐水浓度≥5%；测试72H 1.NoVisualDamage 2.FrequencyTol.≤5% 无明显外观不良;频率偏移≤5% PASS 7Temperature and Humidity Chamber 恒温恒湿 GB/T2423.3-2006 Temp:40°C/12H;-RH:≥93%;Time:48H 温度40°C湿度≥93%；时间48H After2HoursRecovery 1.NoVisualDamage 2.FrequencyTol.≤5% 恢复2H后，无明显外观不良;频 率偏移≤5% PASS 8Thermal Shock 冷热冲击 GB/T2423.22-2008 -30°C(30minutes)to+80°C(30minutes)； Cycles:25 -30°C测试30分转80°C测试30分为一个周期； 共25周期 After2HoursRecovery 1.NoVisualDamage 2.FrequencyTol.≤5% 恢复2H后，无明显外观不良;频 率偏移≤5% PASS 9RoHSWithReferencetoIEC62321:2008withflowchart 参考IEC62321测试流程 DirectiveRoHS2015/863/EU 符合RoHS2015/863/EU标准 PASS ProductNumber:AN2450-PCB44AX ProductName:Antenna Page5 3.Antenna-SParameterTestData 4.Antenna-RadiationPatternTestData ProductNumber:AN2450-PCB44AX ProductName:Antenna Page6 2400MHz 2450MHz 2500MHz 5150MHz ProductNumber:AN2450-PCB44AX ProductName:Antenna Page7 5550MHz 5850MHz 5.MechanicalandPackingDrawing

Append…

Text truncated - open the document above for the full version.
