2A46G-M3BS5AHXAG XRTK S1 Station

XAG XRTK S1 Station User Manual Version 1.0 EN To User Dear user, thank you for choosing XAG's products. For safety purposes and better user experience, it is highly recommended that you read this manual carefully and strictly follow the instructions hereof. Contact Us Manufacturer: Guangzhou Xaircraft Technology Co., Ltd. Add: Building 1, No. 9 Xinrui Road, Huangpu District, Guangzhou, P.R.China Technical Support Team: [email protected] www.xa.com/en1 List of Items Introduction XAG XRTK S1 Station (hereinafter referred to as "XRTK S1") features PPP technology. It serves as a portable base station, providing positioning services to the APC4 AutoPilot Console via wireless communication, or as a cloud base station, offering positioning services to devices such as agricultural drones. It is a powerful tool for precision farming. When unboxing, check the package contents against this list. Immediately contact your seller regarding any missing items. Main Components XRTK S1 Station ×1 SIM Card Slot Indicator Rear View SIM Card Slot Reset Button Communication Antenna Reset Button Power Cable www.xa.com/en2 When the XRTK S1 is powered on, its status can be checked by observing the indicators. Status Indicator Connection Status Indicator Description Solid Green 4G connected Flashing GreenNot connected Solid Yellow High network latency Positioning Indicator Description Fast Flashing Green Positioning (Single) Slow Flashing GreenPositioning (Float) Solid GreenNormal (RTK) Double Flashing GreenNormal (Fix) Solid RedNo positioning (None) Before Use Install SIM Card ① Use a screwdriver to loosen the screw securing the SIM card slot cover. ② Insert the SIM card [1] into the slot (with the notched corner facing inward and the gold contacts facing downward), then reinstall the cover to complete the installation. Notched Corner [1]: The SIM card is not included with the XRTK S1 and must be purchased separately. www.xa.com/en3 Installation Mobile Deployment ① Align the threaded hole at the bottom of the XRTK S1 with the screw on the tripod [1] , then rotate clockwise to secure the XRTK S1 onto the tripod. ② Connect the Type‑C cable to the charging port of the XRTK S1, and connect the other end to an adapter plugged into a power source [2] . The mobile deployment of the XRTK S1 is now complete. [1]‑[2]: The tripod and portable power source are not included with the XRTK S1 and must be purchased separately. Tripod structures vary by model. It is recommended to select a tripod with a 1/4‑inch screw on the platform. The portable power source shown in this manual is for reference only. Refer to the actual product for installation. Ensure the tripod legs are firmly planted on the ground. The height may be adjusted as needed; 1.5 m or higher is recommended. Note Antenna Area 90° Portable Power Source www.xa.com/en4 Fixed Deployment ① Align the threaded hole at the bottom of the XRTK S1 with the screw at the top of the pole [1] , then rotate clockwise to secure the XRTK S1 onto the pole. ② Secure the pole to level ground using four expansion bolts. ③ Connect the Type‑C cable to the charging port of the XRTK S1, and connect the other end to a power source [2] . Feed any excess cable into the designated hole on the pole. The fixed deployment of the XRTK S1 is now complete. [1]‑[2]: The pole and solar power source are not included with the XRTK S1 and must be purchased separately. 90° Antenna Area Solar Power Source Solar Power Source For easier installation, it is recommended to use a pole with a 1/4‑inch screw on the top. The solar power source shown in this manual is for reference only. Refer to the actual product for installation. Note www.xa.com/en5 Firmware Update Always check for firmware updates before use. If an update is available, install the latest version. 1. Open the XAG AutoPilot app, tap the Personal Center icon " " in the upper‑left corner, then go to My Devices > Other Devices. Select the desired XRTK S1 to enter its Device Details screen, then tap Firmware Update to check for updates. 2. If an update is available, tap Download and Update. Once the update is complete, tap Done to return to the device list. Verify that all relevant devices have been updated to the latest firmware version. If not, repeat the update steps until complete. Add a Device The XRTK S1 must be added in the XAG AutoPilot app before first use. Follow the steps below. 1. Open the XAG AutoPilot app. On the home screen, tap the Personal Center icon" " in the upper‑left corner, then go to My Devices > Other Devices and tap Add Device. 2. Scan the XRTK S1 QR code, or enter the SN to add the device. (Alternatively, select Add via Bluetooth in the QR code scanning screen to add the device via Bluetooth.) 3. Name the device, then tap Confirm to complete the process. Scan the QR code above to download and install the "XAG AutoPilot" App How to Use Download "XAG AutoPilot" App Keep the antenna area away from metal objects to avoid signal interference. When setting up the XRTK S1, ensure it is exactly vertical. The base station site should feature firm, level ground and an unobstructed sky view. There should be no dense obstacles above a 15° elevation angle to ensure continuous satellite tracking and signal quality. Warning www.xa.com/en6 Add Reference When the XRTK S1 is used as the positioning base station for the AutoPilot Console, the XRTK S1 must be added as a reference in the XAG AutoPilot app. Follow the steps below. 1. After powering on the XRTK S1, open the XAG AutoPilot app on the AutoPilot Console. On the home screen, tap APC > Positioning, then scroll down to the Reference List and tap Add Reference on the right. 2. Tap Add XRTK S1, then select the XRTK S1 to be set as the positioning base station from the pop‑up list. 3. After that, the app will automatically return to the home screen. If the XRTK S1 to be added does not belong to you and is being added for the first time, you must contact the device owner to obtain and enter t…

Text truncated - open the document above for the full version.

Guangzhou Xaircraft Technology CO.,LTD Date: 4/3/2026 Federal Communications Commissions Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 RE: CFR 47 §2.911 (d)(5) Attestation FCC ID: 2A46G-M3BS5AH 1. Guangzhou Xaircraft Technology CO.,LTD certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. 2. Guangzhou Xaircraft Technology CO.,LTD certifies that the device does not have cybersecurity and / or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, identified on the Covered List installed on the device, nor will it be installed by the applicant anytime after certification. 3. Guangzhou Xaircraft Technology CO.,LTD certifies that the RF device is not a router “produced in a foreign country”. 4. Guangzhou Xaircraft Technology CO.,LTD certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment and is not an affiliate or subsidiary of an entity identified on the Covered List. Sincerely yours, Name:Junjie Zhu Job Title:Certification Engineer Company Name: Guangzhou Xaircraft Technology CO.,LTD

iCertifi Control Number - IC2026ASOP12374 certifies that, as of the contract effective date of 24/05/2026 Americas Compliance Consulting LLC dba iCertifi is our designated U.S. agent for service of process for all FCC equipment authorization filings submitted under the above referenced Grantee Code. accepts to maintain an agent for no less than one year after the grant has been terminated, or marketing and importation or the conclusion of any commission-related proceeding involving the equipment. This designation applies to all existing and future FCC IDs submitted under Grantee Code during the contract validity period of 24/05/2026 through 24/05/2027 iCertifi accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for all FCC equipment authorization filings submitted under Grantee Code during the contract validity period stated above. Designated U.S. Agent Information Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 24/05/2026 Ref: Attestation Statement Part 2.911(d)(7) Filing Grantee Code: 2A46G : Name: Americas Compliance Consulting LLC dba iCertifi FCC FRN: 0033399411 Address: 5809 US-2, Suite B Albeni Plaza, Priest River, ID 83856 United States Contact Person: Paul Preston Tel: 866-885-4575 Email: [email protected] Americas Compliance Consulting LLC dba iCertifi Paul Preston / President Signatur Sincerely, Gua ngzhou Xaircraft Technology CO.,LTD. FRN: 0038520540 [AUTHORIZ ED SIGNATORY NAME] Signature: e: FCC ID: 2A46G-M3BS5AH

Guangzhou Xaircraft Technology CO.,LTD DATE: 4/3/2026 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch， Room 101, Building 2, No.4, Information Road, Songshan Lake, Dongguan, Guangdong, China (Name of Agent company name and address) to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Guangzhou Xaircraft Technology CO.,LTD， Building 1, No. 9 Xinrui Road, Huangpu District, Guangzhou, P.R.China (Applicant Name and address) Sincerely yours, Name:Junjie Zhu Job Title:Certification Engineer Company Name:Guangzhou Xaircraft Technology CO.,LTD

Guangzhou Xaircraft Technology CO.,LTD 4/3/2026 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Compliance Testing, LLC to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). Sincerely yours, Name:Junjie Zhu Job Title:Certification Engineer Company Name:Guangzhou Xaircraft Technology CO.,LTD

Guangzhou Xaircraft Technology CO.,LTD DATE：4/3/2026 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2A46G-M3BS5AH Product Name: XAG XRTKS1 Station Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) •Schematics •Block diagram •Operation description •Bom list •Tune up exhibition These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Sincerel y yours, Name:Junjie Zhu Job Title:Certification Engineer Company Name:Guangzhou Xaircraft Technology CO.,LTD

External Photographs Project No.:4792198684-3 Page 2 of 4 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. View of EUT-1 View of EUT-2 Page 3 of 4 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. View of EUT-3 View of EUT-4 Page 4 of 4 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. View of EUT-5

XAG XRTK S1 Station Model:M3BS5AH Manufacturer:Guangzhou Xaircraft Technology Co Ltd Input:12V==3A;15V==3A;20V==2A FCC ID:2A46G-M3BS5AH Contain FCC ID: 2A46G-EG25-G This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Label location Note: This label will be permanently engraved on the product

Internal Photographs Project No.:4792198684-3 Page 2 of 8 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-1 Internal View of EUT-2 Page 3 of 8 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-3 Internal View of EUT-4 LTE Module Page 4 of 8 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-5 Internal View of EUT-6 LTE Module FCC ID: 2A46G-EG25-G Page 5 of 8 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-7 Internal View of EUT-8 WWAN Ant1 WWAN Ant2 BT/BLE/ WiFi Ant1 BT/BLE/ WiFi Ant2 GNSS Ant BT/BLE/ WiFi Module BT/BLE/ WiFi RF Chain to Ant1 BT/BLE/ WiFi RF Chain to Ant2 Page 6 of 8 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-9 Internal View of EUT-10 Page 7 of 8 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-11 Internal View of EUT-12 2.4G CSS/ 400M GMSK Ant Page 8 of 8 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-13

The results reported herein have been performed in accordance with the laboratory’s terms of accreditation. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report apply to the test sample(s) mentioned above at the time of the testing period only and are not to be used to indicate applicability to other similar products. FCC RF EXPOSURE REPORT For XAG XRTKS1 Station MODEL NUMBER: M3BS5AH REPORT NUMBER: 4792198684-3-RF-10 ISSUE DATE: May 27, 2026 FCC ID: 2A46G-M3BS5AH Prepared for Guangzhou Xaircraft Technology CO.,LTD Building 1, No. 9 Xinrui Road, Huangpu District, Guangzhou, P.R.China Prepared by UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch Room 101, Building 2, No.4, Information Road, Songshan Lake, Dongguan, Guangdong, China Tel: +86 769 22038881 Fax: +86 769 33244054 Website: www.ul.com REPORT NO.: 4792198684-3-RF-10 Page 2 of 8 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Revision History Rev. Issue Date Revisions Revised By V0 May 27, 2026 Initial Issue REPORT NO.: 4792198684-3-RF-10 Page 3 of 8 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS ................................................................................. 4 2. TEST METHODOLOGY ..................................................................................................... 5 3. FACILITIES AND ACCREDITATION ................................................................................. 5 4. REQUIREMENT ................................................................................................................. 6 REPORT NO.: 4792198684-3-RF-10 Page 4 of 8 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. 1. ATTESTATION OF TEST RESULTS Applicant Information Company Name: Guangzhou Xaircraft Technology CO., LTD Address: Building 1,No.9Xinrui Road, Huangpu District,Guangzhou,P.R.China Manufacturer Information Company Name: Guangzhou Xaircraft Technology CO., LTD Address: Building 1,No.9Xinrui Road, Huangpu District,Guangzhou,P.R.China EUT Information EUT Name: XAG XRTKS1 Station Model: M3BS5AH Sample Received Date: March 16, 2026 Sample Status: Normal Sample ID: 9609336 Date of Tested: March 17, 2026 to May 27, 2026 APPLICABLE STANDARDS STANDARD TEST RESULTS FCC 47CFR§2.1091 PASS KDB 447498 D01 PASS Prepared By: Checked By: Daniel Zhang Kebo Zhang Project Engineer Operations Leader Approved By: Stephen Guo Operations Manager REPORT NO.: 4792198684-3-RF-10 Page 5 of 8 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. 2. TEST METHODOLOGY The tests documented in this report were performed in accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 and KDB447498 D01 v06. 3. FACILITIES AND ACCREDITATION Accreditation Certificate A2LA (Certificate No.: 4102.01) UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch. has been assessed and proved to be in compliance with A2LA. FCC (FCC Designation No.: CN1187) UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch. Has been recognized to perform compliance testing on equipment subject to the Commission's Declaration of Conformity (DoC) and Certification rules. ISED (Company No.: 21320) UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch. has been registered and fully described in a report filed with ISED. The Company Number is 21320 and the test lab Conformity Assessment Body Identifier (CABID) is CN0046. VCCI (Registration No.: C-20202, G-20240, R-20248 and T-20202) UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch. has been assessed and proved to be in compliance with VCCI, the Membership No. is 3793. Facility Name: Chamber E, the VCCI registration No. is G-20240 and R-20248 Shielding Room F, the VCCI registration No. is C-20202 and T-20202 Note 1: All tests measurement facilities use to collect the measurement data are located at Room 101, Building 2, No.4, Information Road, Songshan Lake, Dongguan, Guangdong, China. Note 2: The test anechoic chamber in UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch had been calibrated and compared to the open field sites and the test anechoic chamber is shown to be equivalent to or worst case from the open field site. Note 3: For below 30 MHz, lab had performed measurements at test anechoic chamber and comparing to measurements obtained on an open field site. And these measurements below 30 MHz had been correlated to measurements performed on an OFS. REPORT NO.: 4792198684-3-RF-10 Page 6 of 8 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. 4. REQUIREMENT LIMIT AND CALCULATION METHOD Systems operating under the provisions of FCC 47 CFR section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as mobile device whereby a distance of 0.2m normally can be…

Text truncated - open the document above for the full version.

The results reported herein have been performed in accordance with the laboratory’s terms of accreditation. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report apply to the test sample(s) mentioned above at the time of the testing period only and are not to be used to indicate applicability to other similar products. FCC 47 CFR PART 15 SUBPART C TEST REPORT For XAG XRTKS1 Station MODEL NUMBER: M3BS5AH REPORT NUMBER: 4792198684-3-RF-5 ISSUE DATE: May 27, 2026 FCC ID: 2A46G-M3BS5AH Prepared for Guangzhou Xaircraft Technology CO., LTD Building 1,No.9Xinrui Road, Huangpu District,Guangzhou,P.R.China Prepared by UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch Room 101, Building 2, No.4, Information Road, Songshan Lake, Dongguan, Guangdong, China Tel: +86 769 22038881 Fax: +86 769 33244054 Website: www.ul.com REPORT NO.: 4792198684-3-RF-5 Page 2 of 87 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM NO: 10-SL-F0035 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Revision History Rev. Issue Date Revisions Revised By V0 May 27, 2026 Initial Issue REPORT NO.: 4792198684-3-RF-5 Page 3 of 87 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM NO: 10-SL-F0035 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Summary of Test Results Test Item Clause Limit/Requirement Result Antenna Requirement N/A FCC Part 15.203/15.247 (c) Pass AC Power Line Conducted Emission ANSI C63.10-2020, Clause 6.2 FCC Part 15.207 Pass Conducted Output Power ANSI C63.10-2020, Clause 11.9.2.3.1 FCC Part 15.247 (b)(3) Pass 6dB Bandwidth and 99% Occupied Bandwidth ANSI C63.10-2020, Clause 11.8.1 FCC Part 15.247 (a)(2) Pass Power Spectral Density ANSI C63.10-2020, Clause 11.10.5 & 11.10.3 FCC Part 15.247 (e) Pass Conducted Band edge and spurious emission ANSI C63.10-2020, Clause 11.11 FCC Part 15.247(d) Pass Radiated Band edge and Spurious Emission ANSI C63.10-2020, Clause 11.12 FCC Part 15.247 (d) FCC Part 15.205/15.209 Pass Duty Cycle ANSI C63.10-2020, Clause 11.6 None; for reporting purposes only. Pass Note 1: For FCC, C63.10:2020 + Cor.1:2023 is also considered for the corresponding test item which is needed. *This test report is only published to and used by the applicant, and it is not for evidence purpose in China. *The measurement result for the sample received is <Pass> according to <FCC 47 CFR PART 15 SUBPART C> when <Simple Acceptance> decision rule is applied. Decision rule for statement of conformity: The measurement uncertainty is not taken into account for statement of conformity. REPORT NO.: 4792198684-3-RF-5 Page 4 of 87 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM NO: 10-SL-F0035 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. CONTENTS 1. ATTESTATION OF TEST RESULTS ..................................................................................... 6 2. TEST METHODOLOGY ......................................................................................................... 7 3. FACILITIES AND ACCREDITATION ..................................................................................... 7 4. CALIBRATION AND UNCERTAINTY ................................................................................... 8 4.1. MEASURING INSTRUMENT CALIBRATION ........................................................... 8 4.2. MEASUREMENT UNCERTAINTY ............................................................................ 8 5. EQUIPMENT UNDER TEST .................................................................................................. 9 5.1. DESCRIPTION OF EUT ........................................................................................... 9 5.2. CHANNEL LIST ...................................................................................................... 10 5.3. MAXIMUM POWER ................................................................................................ 10 5.4. TEST CHANNEL CONFIGURATION ...................................................................... 10 5.5. THE WORSE CASE POWER SETTING PARAMETER .......................................... 11 5.6. DESCRIPTION OF AVAILABLE ANTENNAS ......................................................... 11 5.7. SUPPORT UNITS FOR SYSTEM TEST ................................................................. 12 6. MEASURING EQUIPMENT AND SOFTWARE USED......................................................... 13 7. ANTENNA PORT TEST RESULTS ..................................................................................... 16 7.1. CONDUCTED OUTPUT POWER ........................................................................... 16 7.2. 6DB BANDWIDTH AND 99% OCCUPIED BANDWIDTH ........................................ 17 7.3. POWER SPECTRAL DENSITY .............................................................................. 19 7.4. CONDUCTED BAND EDGE AND SPURIOUS EMISSION ..................................... 21 7.5. DUTY CYCLE ......................................................................................................... 23 8. RADIATED TEST RESULTS ............................................................................................... 24 8.1. RESTRICTED BANDEDGE .................................................................................... 31 8.2. SPURIOUS EMISSIONS(1 GHZ~3 GHZ) ............................................................... 36 8.3. SPURIOUS EMISSIONS(3 GHZ~18 GHZ) ............................................................. 42 8.4. SPURIOUS EMISSIONS(9 KHZ~30 MHZ) .......................................................…

Text truncated - open the document above for the full version.

The results reported herein have been performed in accordance with the laboratory’s terms of accreditation. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report apply to the test sample(s) mentioned above at the time of the testing period only and are not to be used to indicate applicability to other similar products. FCC 47 CFR PART 15 SUBPART C TEST REPORT For XAG XRTKS1 Station MODEL NUMBER: M3BS5AH REPORT NUMBER: 4792198684-3-RF-3 ISSUE DATE: May 27, 2026 FCC ID: 2A46G-M3BS5AH Prepared for Guangzhou Xaircraft Technology CO., LTD Building 1,No.9Xinrui Road, Huangpu District,Guangzhou,P.R.China Prepared by UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch Room 101, Building 2, No.4, Information Road, Songshan Lake, Dongguan, Guangdong, China Tel: +86 769 22038881 Fax: +86 769 33244054 Website: www.ul.com REPORT NO.: 4792198684-3-RF-3 Page 2 of 97 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM NO: 10-SL-F0035 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Revision History Rev. Issue Date Revisions Revised By V0 May 27, 2026 Initial Issue REPORT NO.: 4792198684-3-RF-3 Page 3 of 97 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM NO: 10-SL-F0035 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Summary of Test Results Test Item Clause Limit/Requirement Result Antenna Requirement N/A FCC Part 15.203/15.247 (c) Pass AC Power Line Conducted Emission ANSI C63.10-2020, Clause 6.2 FCC Part 15.207 Pass Conducted Output Power ANSI C63.10-2020, Clause 11.9.2.3.1 FCC Part 15.247 (b)(3) Pass 6dB Bandwidth and 99% Occupied Bandwidth ANSI C63.10-2020, Clause 11.8.1 FCC Part 15.247 (a)(2) Pass Power Spectral Density ANSI C63.10-2020, Clause 11.10.5 & 11.10.3 FCC Part 15.247 (e) Pass Conducted Band edge and spurious emission ANSI C63.10-2020, Clause 11.11 FCC Part 15.247(d) Pass Radiated Band edge and Spurious Emission ANSI C63.10-2020, Clause 11.12 FCC Part 15.247 (d) FCC Part 15.205/15.209 Pass Duty Cycle ANSI C63.10-2020, Clause 11.6 None; for reporting purposes only. Pass Note 1: For FCC, C63.10:2020 + Cor.1:2023 is also considered for the corresponding test item which is needed. *This test report is only published to and used by the applicant, and it is not for evidence purpose in China. *The measurement result for the sample received is <Pass> according to <FCC 47 CFR PART 15 SUBPART C> when <Simple Acceptance> decision rule is applied. Decision rule for statement of conformity: The measurement uncertainty is not taken into account for statement of conformity. REPORT NO.: 4792198684-3-RF-3 Page 4 of 97 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM NO: 10-SL-F0035 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. CONTENTS 1. ATTESTATION OF TEST RESULTS ...........................................…

Text truncated - open the document above for the full version.
