ShenZhen AZW Technology Co., Ltd. 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – Equipment Type Company name: ShenZhen AZW Technology Co., Ltd. Address: 701, Building 8, Hengda Shishang Huigu, next to Fulong Road, Shanghenglang Community,Dalang Street, Longhua District, ShenZhen, China Product Name: Mini PC FCC ID: 2A4J2-GTI Model(s): GTI,GTI Ultra,GTI Max,GTI Pro,GTR,GTR Max,GTR Pro,GTR Ultra,GTI14,GTI15,GTI16,GTR8,GTR9,GTR10 2.911(d)(5)(i) Equipment Type We, [ShenZhen AZW Technology Co., Ltd.] certify that the equipment for which authorization is sought through certification is not:  Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules.  Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Jerry Huang Date: Aug.24, 2024 Title and Company name: manager / ShenZhen AZW Technology Co., Ltd. NOTE 1 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

ShenZhen AZW Technology Co., Ltd. 2.911 (d)(5)(ii) Applicant Attestation v1.2 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List) Company name: ShenZhen AZW Technology Co., Ltd. Address: 701, Building 8, Hengda Shishang Huigu, next to Fulong Road, Shanghenglang Community,Dalang Street, Longhua District, ShenZhen, China Product Name: Mini PC FCC ID: 2A4J2-GTI Model(s): GTI,GTI Ultra,GTI Max,GTI Pro,GTR,GTR Max,GTR Pro,GTR Ultra,GTI14,GTI15,GTI16,GTR8,GTR9,GTR10 2.911(d)(5)(ii) Applicant filing We, [ShenZhen AZW Technology Co., Ltd.] certify that, as of the date of the filing of the application, the applicant is not identified on the “Covered List” NOTE 1 , established pursuant to § 1.50002 of this chapter, as an entity producing covered communications equipment. Yours sincerely, Name: Jerry Huang Date: Aug.24, 2024 Title and Company name: manager / ShenZhen AZW Technology Co., Ltd. NOTE 1 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

ShenZhen AZW Technology Co., Ltd. 2.911 (d)(7)USA Agent v1.5 Section 2.911(d)(7) USA Agent for Service of Process Company name: ShenZhen AZW Technology Co., Ltd. Address: 701, Building 8, Hengda Shishang Huigu, next to Fulong Road, Shanghenglang Community,Dalang Street, Longhua District, ShenZhen, China Product Name: Mini PC FCC ID: 2A4J2-GTI Model(s): GTI,GTI Ultra,GTI Max,GTI Pro,GTR,GTR Max,GTR Pro,GTR Ultra,GTI14,GTI15,GTI16,GTR8,GTR9,GTR10 2.911(d)(7) USA Designated Agent for Service of Process We, [ShenZhen AZW Technology Co., Ltd.] (“the applicant”) designate [[Electronic Mac, Inc.] NOTE1 for the purpose of accepting service of process on behalf of the applicant. Applicant consent: We acknowledge our consent to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address of the designated agent and acknowledge our acceptance of our obligation to maintain an agent for service of process in the United States for no less than one year after either we the grantee have permanently terminated all marketing and importation of the applicable equipment within the U.S., or at the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Agent obligation: We acknowledge our obligation to accept service of process in the United States for matters related to the applicable equipment at our physical U.S. address and email address for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or at the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. USA Agent Company name: Electronic Mac, Inc. USA Address: 6525 Crown Blvd, # 20805, San Jose, CA 95120 FRN Number: 0033414541 Contact Name: Ray Sia Telephone No: 408-332-2399 Email: [email protected] Applicant Company name: ShenZhen AZW Technology Co., Ltd. Address: 701, Building 8, Hengda Shishang Huigu, next to Fulong Road, Shanghenglang Community,Dalang Street, Longhua District, ShenZhen, China Grantee FRN Number: 0031976178 FCC Grantee Code: 2A4J2 Contact Name: Jerry Huang Telephone No: 13528413123 ShenZhen AZW Technology Co., Ltd. 2.911 (d)(7)USA Agent v1.5 Email: [email protected] Signature: Title: Manger Signature: Title: Manger Date: Aug.24, 2024 Date: Aug.24, 2024 NOTE 1: An applicant located in the United States may designate itself as the agent for service of process. Reference; Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-nation al-security-threats-to-the-communications-supply-chain-through-the

ShenZhen AZW Technology Co., Ltd. Agent Authorization Company: ShenZhen AZW Technology Co., Ltd. Address: 701, Building 8, Hengda Shishang Huigu, next to Fulong Road, Shanghenglang Community,Dalang Street, Longhua District, ShenZhen, China Product Name: Mini PC Model Number(s): GTI,GTI Ultra,GTI Max,GTI Pro,GTR,GTR Max,GTR Pro,GTR Ultra,GTI14,GTI15,GTI16,GTR8,GTR9,GTR10 Product Description: Mini PC We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: Aug.24, 2024 Name: Jerry Huang Title: Manger Company: ShenZhen AZW Technology Co., Ltd.

ShenZhen AZW Technology Co., Ltd. Family models declaration letter. Date: September 5, 2024 We ShenZhen AZW Technology Co., Ltd. Of 701, Building 8, Hengda Shishang Huigu, next to Fulong Road, Shanghenglang Community,Dalang Street, Longhua District, ShenZhen, China Product: Mini PC Model Name: GTI Serial Model: GTI Ultra,GTI Max,GTI Pro,GTR,GTR Max,GTR Pro, GTR Ultra,GTI14,GTI15,GTI16,GTR8,GTR9,GTR10 Difference description of series models: All the model are the same circuit and RF module, except the model names and colors Thanks Sincerely Signature Name: Jerry Huang Date: Aug.24, 2024 Title: Manger

ShenZhen AZW Technology Co., Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: September 5, 2024 Subject; Request for Confidentiality FCC ID: 2A4J2-GTI To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Software Security Requirements for UNII devices In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Jerry Huang Title: Manger

Model:GTI lnput:100-240V-,50/60Hz,1.9A MADE IN CHINA FCC ID :2A4J2-GTI 100mm*10mm

FCC ID: 2A4J2-GTI RF Exposure Evaluation Limits According to 447498 D01 General RF Exposure Guidance v06 The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. FCC ID: 2A4J2-GTI Test Result of RF Exposure Evaluation The source of the evaluation data results is based on the test report ET-24070973E01/02/03 2.4G WIFI Antenna gain=0.92dBi BT Antenna gain=3.37dBi 5G WIFI Antenna gain=2.74dBi FOR BLE Mode Output power (dBm) Output power (mW) Numeric antenna gain Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result GFSK 2.48 1.77 2.18 0.00077 1.0 PASS FOR 2.4GWIFI Mode Output power (dBm) Output power (mW) Numeric antenna gain Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 802.11b 14.73 29.72 1.24 0.0073 1.0 PASS 802.11g 16.11 40.83 1.24 0.0101 1.0 PASS 802.11n20 15.90 38.90 1.24 0.0096 1.0 PASS 802.11n40 15.44 34.99 1.24 0.0086 1.0 PASS FOR 5GWIFI Mode Output power (dBm) Output power (mW) Numeric antenna gain Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 802.11a 14.99 31.55 1.88 0.0118 1.0 PASS 802.11n20 13.59 22.86 1.88 0.0086 1.0 PASS 802.11ac20 13.65 23.17 1.88 0.0087 1.0 PASS 802.11n40 13.88 24.43 1.88 0.0091 1.0 PASS 802.11ac40 13.50 22.39 1.88 0.0084 1.0 PASS 802.11ac80 13.75 23.71 1.88 0.0089 1.0 PASS FOR 5.8GWIFI Mode Output power (dBm) Output power (mW) Numeric antenna gain Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 802.11a 13.83 24.15 1.88 0.0090 1.0 PASS 802.11n20 13.50 22.39 1.88 0.0084 1.0 PASS 802.11ac20 13.65 23.17 1.88 0.0087 1.0 PASS 802.11n40 11.81 15.17 1.88 0.0057 1.0 PASS 802.11ac40 11.29 13.46 1.88 0.0050 1.0 PASS 802.11ac80 10.76 11.91 1.88 0.0045 1.0 PASS If BT and WIFI work simultaneously BLE+2.4GWIFI, the total power density is 0.00077/1+0.0101/1=0.01087<1. BLE+5GWIFI, the total power density is 0.00077/1+0.0118/1=0.01257<1. BLE+5.8GWIFI, the total power density is 0.00077/1+0.0090/1=0.00977<1. Maximum power density=0.01257 <1.Then SAR evaluation is not require .

Shenzhen Tianweixun Wireless Technology Co., Ltd Product Product performance performance and and specification specification Tian Tian wei wei xun xun antenna antenna the the research research and and development development department department CUSTOMERNAME Shenzhen AZW Technology Co., Ltd. Android Micro Material Number：AIN antenna：14.02.036200 0AUX a n t e n n a ：14.02.03620001 PRODUCTNAME GTI14 BOARDMODEL V3 TWX-069-08 Item number 5 ClientAdmitmanufacturingparty CustomersconfirmationQualitydepartmentR&DApproval ME: RF: Date：May 25, 2024 1 Indexes 1.1Project Diagram....................................................................................................................2 1.1.1 Antenna matching diagram.. ...................................................................................................... 2 2.1 objective................................................................................................................................ 3 3.1Main antenna......................................................................................................................3 3.1.1Main antenna electrical specifications and materials.....................................................................3 3.1.2Antenna form........................................................................................................................... 3 3.1.3Antenna design working frequency band............................................................. 3 3.1.4Measurement data of the main antenna in the ETS-SG24SYSTEM 3D testing system............................................................................................................................3 3.1.5Passive standing wave and return loss of antenna.................................4 3.1.6 W I F I Actual test results of antenna..................................................................... 6 4.1P rod u c t Desi g n Dr awi n g.................................................................................5 5.1Product assembly diagram............................................................................ 8 5.1.1Antenna composition......................................................................................................... 8 5.1.2Antenna assembly............................................................................................................ 8 5.1.3The antenna assembly is shown in the diagram inside the entire machine............................................................................................................8 5.1.4 Environmental treatment diagram .....................................................................................8 2 GTI1 1.1Project Diagram 4 1.1.1 Antenna matching diagram Elementcapacitanceinductance E1(0402) E2(0402) E3(0402) E4(0402) Matching instructions: Match according to the original motherboard without any changes. 3 2.1 objective Standardize the specifications and testing methods of mobile communication terminal antenna products produced by Shenzhen Tianweixun Wireless Technology Co., Ltd. to avoid errors caused by different testing conditions and methods. 3.1 Main antenna 3.1.1 Electrical specifications and materials of the main antenna This report mainly provides the testing status of the structural performance parameters of the prototype antenna GTI14. Physical image of antenna designed by Tianwei Xun 3.1.2 Antenna form Implementation type: PIFA antenna 3.1.3 antenna design working frequency band The w orki n g f r equ e n c y ba n d of the a n t e n n a is2400MHz~ 2500MHz , 5100 MHz~ 5800MHz, 3.1.4 M ea s u re m e n t d ata o f the mai n an t e n na i n the E T S - S G 2 4 S Y S T E M 3 D t est i ng s y st e m Figure (2) ETS Testing SystemFigure (3) Three dimensional positioning device for mobile phone in darkroom 4 3.1.5 A n t e n na p a s sive standi ng w a ve and re tu rn lo s s M A I N p a s sive d ata : AUX Passive data： 5 3.1.6 WiFi Actual test results of antenna 2.4G Throughput testing 5.8G Throughput testing 信 道 （MHZ hotspo throughput t ） （40MHZ throughchann el put ） throughput （80MHZ） throughput （160MHZ） 1 20.7 636 201 313319 2 28.5 140 194 291319 3 30.6 144 150 308320 4 35.8 1 48 224 308331 5 38.6 1 52 230 312320 6 19.9 956 230 317314 7 35.5 360 240 317329 8 32.6 2 64 327 307316 9 30.5 2149 158 299 10 31.6 2 153 214 306 11 31.3 8 157 135 310 12 29.9 2165 221 293 13 17.4 2 Note: Use the GTI14 machine to connect to our Huawei Bluetooth speaker and test that music playback does not lag at a distance of 10 meters. 4.1Product Design Drawing 6 7 8 5.1 Product assembly diagram 5.1.1 Antenna composition： The antenna is a combination of FPC antenna and coaxial cable. As shown in the figure below, weld the coaxial line with the MIA port facing downwards and the AUX port facing downwards. 5.1.2 Antenna assembly FPCThe antenna is attached to the bracket as shown in the diagram. Please attach it to the middle position of the bracket as shown in the diagram, and then place the coaxial line according to the diagram. The conductive cloth of the antenna needs to be gently pressed and pasted onto the metal sheet to ensure sufficient grounding. (Note: This is for reference only. The placement method of the coaxial line can be adjusted according to the actual assembly convenience. The antenna should be pasted as close to the edge as possible. If the FPC antenna is far away from the outer edge or has a deviation position when pasting, it will affect the antenna performance.) 5.1.3 The antenna assembly is shown in the diagram inside the entire machine After attaching the antenna, install it into the entire machine according to the diagram. 9 10 1 1 12
