2A4J2-IPCAmini PC

FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/ TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Caution Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC Radiation Exposure Statement This equipment must be installed and operated in accordance with provided instructions and the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provide with antenna installation instructions and transmitter operating conditions for satisfying RF exposure com

Shenzhen AZW Technology Co., Ltd. 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – Equipment Type Company name: Shenzhen AZW Technology Co., Ltd. Address: 3th Floor, Building 11, 4th Floor, Building 18, longjun Industrial park, Longhua New District,ShenZhen,China Product Name: mini PC FCC ID: 2A4J2-IPCA Model(s): IPC-A,IPC-G,IPC-J,IPC-E,IPC-D 2.911(d)(5)(i) Equipment Type We, [Shenzhen AZW Technology Co., Ltd. ] certify that the equipment for which authorization is sought through certification is not:  Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules.  Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Jerry Huang Date: Feb.11,2023 Title and Company name: Manager / Shenzhen AZW Technology Co., Ltd. NOTE 1 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Shenzhen AZW Technology Co., Ltd. 2.911 (d)(5)(ii) Applicant Attestation v1.2 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: Shenzhen AZW Technology Co., Ltd. Address: 3th Floor, Building 11, 4th Floor, Building 18, longjun Industrial park, Longhua New District,ShenZhen,China Product Name: mini PC FCC ID: 2A4J2-IPCA Model(s): IPC-A,IPC-G,IPC-J,IPC-E,IPC-D 2.911(d)(5)(ii) Applicant filing We, [Shenzhen AZW Technology Co., Ltd. ] certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 , established pursuant to § 1.50002 of this chapter, as an entity producing covered communications equipment. Yours sincerely, Name: Jerry Huang Date: Feb.11,2023 Title and Company name: Manager / Shenzhen AZW Technology Co., Ltd. NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Shenzhen AZW Technology Co., Ltd. Section 2.911(d)(7) USA Agent for Service of Process Company name: Shenzhen AZW Technology Co., Ltd. Address: 3th Floor, Building 11, 4th Floor, Building 18, longjun Industrial park, Longhua New District,ShenZhen,China Product Name: mini PC FCC ID: 2A4J2-IPCA Model(s): IPC-A,IPC-G,IPC-J,IPC-E,IPC-D 2.911(d)(7) USA Designated Agent for Service of Process We, [Shenzhen AZW Technology Co., Ltd. ] designate [Baihetian Innovative Solutions] for the purpose of accepting service of process on behalf of the applicant. Applicant consent: We Acknowledge our consent to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address of the designated agent and acknowledge our acceptance of our obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Agent obligation: We Acknowledge our obligation to accept service of process in the United States for matters related to the applicable equipment at our physical U.S. address and email address for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. USA Agent Company name: Baihetian Innovative Solutions Address: 6837 Chase Rd. Dearborn, MI 48126 FCC ID Number: 2A4J2-IPCA Contact Name: Kenneth Young Telephone No: 313-395-3113 Email: [email protected] Applicant Company name: Shenzhen AZW Technology Co., Ltd. Address: 3th Floor, Building 11, 4th Floor, Building 18, longjun Industrial park,Longhua New District, ShenZhen,China FCC Grantee Code:2A4J2 Contact Name:Jerry Huang Telephone No: 13528413123 Email:[email protected] 2.911 (d)(7)USA Agent v1.2 Shenzhen AZW Technology Co., Ltd. Signature: Title: Manager Signature: Title: Manager Date:Feb.13,2 023Date: Feb.11,2023 NOTE 1: An applicant located in the United States may designate itself as the agent for service of process. Reference; Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against- national-security-threats-to-the-communications-supply-chain-through-the 2.911 (d)(7)USA Agent v1.2 Date: Feb.13,2023

FCC Software Configuration Control Declaration Rev1.1 ShenZhen AZW Technology CO.,LTD. FCC Software Configuration Control Declaration Date: February 6, 2023 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Attn: OET Dept. Product/ Model Number: ELECTRIC SCOOTER IPC-A, IPC-G,IPC-J,IPC-E,IPC-D Regarding FCC Country Code Selection guidelines identified in KDB 594280. “All applications for equipment authorization for transmitters that can have radio parameters, or other technical parameters, reported to the Commission set by software must have an attestation indicating that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified.” We declare that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified. Name: Jerry Huang Date: Feb.06,2023 Title: manager Signature of applicant

ShenZhen AZW Technology CO.,LTD. Agent Authorization Company: ShenZhen AZW Technology CO.,LTD. Address: 3th Floor, Building 11, 4th Floor, Building 18, longjun Industrial park,Longhua New District,ShenZhen,China Product Name: mini PC Model Number(s): IPC-A,IPC-G,IPC-J,IPC-E,IPC-D Product Description: mini PC We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: Feb.06,2023 Name: Jerry Huang Title: Manager Company: ShenZhen AZW Technology CO.,LTD.

ShenZhen AZW Technology CO.,LTD. Family models declaration letter. Date: February 6, 2023 We ShenZhen AZW Technology CO.,LTD. Of 3th Floor, Building 11, 4th Floor, Building 18, longjun Industrial park,Longhua New District,ShenZhen,China Product: mini PC Model Name: IPC-A Serial Model: IPC-G,IPC-J,IPC-E,IPC-D Difference description of series models: All the model are the same circuit and RF module, except the model names and colors. Thanks Sincerely Signature Name: Jerry Huang Date: Feb.06,2023 Title: Manager

ShenZhen AZW Technology CO.,LTD. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: February 6, 2023 Subject; Request for Confidentiality FCC ID: 2A4J2-IPCA To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Software Security Requirements for UNII devices In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Jerry Huang Title: manager

- Page 1 of 4 - ET-22120972 Product Name: mini PC Model No.: IPC-A Ext Photos - Page 2 of 4 - ET-22120972 - Page 3 of 4 - ET-22120972 - Page 4 of 4 - ET-22120972 -----END-----

Product Name: Mini PC Model: IPC Input: ��V �A FCC ID: 2A4J2-IPCA R201-206756 Lael size:55*20mm

- Page 1 of 3 - ET-22120972 Product Name: mini PC Model No.: IPC-A Internal photos 2.4G/5G WIFI Antenna BLE Antenna - Page 2 of 3 - ET-22120972 RF Module - Page 3 of 3 - ET-22120972 ------END-----

FCC ID: 2A4J2-IPCA RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. FCC ID: 2A4J2-IPCA Test Result of RF Exposure Evaluation The source of the evaluation data results is based on the test report ET-22120972E01/02/03 BT Antenna gain=1.94dBi, 2.4G WIFI Antenna gain=2.42dBi, 5G WIFI Antenna gain=4.26dBi FOR BLE Mode Output power (dBm) Output power (mW) Numeric antenna gain Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result GFSK 1.16 1.31 1.56 0.0004 1.0 PASS FOR 2.4GWIFI Mode Output power (dBm) Output power (mW) Numeric antenna gain Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 802.11b 11.33 13.58 1.75 0.0047 1.0 PASS 802.11g 14.90 30.90 1.75 0.0108 1.0 PASS 802.11n20 14.56 28.58 1.75 0.0100 1.0 PASS 802.11n40 11.48 14.06 1.75 0.0049 1.0 PASS FOR 5.2GWIFI Mode Output power (dBm) Output power (mW) Numeric antenna gain Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 802.11a 13.23 21.04 2.67 0.0112 1.0 PASS 802.11 n20 13.10 20.42 2.67 0.0109 1.0 PASS 802.11 ac20 13.14 20.61 2.67 0.0110 1.0 PASS 802.11 n40 12.07 16.11 2.67 0.0086 1.0 PASS 802.11 ac40 12.03 15.96 2.67 0.0085 1.0 PASS 802.11 ac80 9.82 9.59 2.67 0.0051 1.0 PASS FOR 5.8GWIFI Mode Output power (dBm) Output power (mW) Numeric antenna gain Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 802.11a 12.10 16.22 2.67 0.0086 1.0 PASS 802.11 n20 12.19 16.56 2.67 0.0088 1.0 PASS 802.11 ac20 12.07 16.11 2.67 0.0086 1.0 PASS 802.11 n40 10.43 11.04 2.67 0.0059 1.0 PASS 802.11 ac40 10.36 10.86 2.67 0.0058 1.0 PASS 802.11 ac80 9.37 8.65 2.67 0.0046 1.0 PASS If BLE and 2.4G WIFI operate simultaneously, Total power density=0.0004/1+0.0108/1=0.0112<1. If BLE and 5.2G WIFI operate simultaneously, Total power density=0.0004/1+0.0112/1=0.0116<1. If BLE and 5.8G WIFI operate simultaneously, Total power density=0.0004/1+0.0088/1=0.0092<1. Then SAR evaluation is not require .

Report No.: ET-22120972E03 This test report is valid for the tested samples only. It cannot be reproduced except in full without prior written consent of Shenzhen ETR Standard Technology Co., Ltd. TEST REPORT Applicant: Shenzhen AZW Technology Co., Ltd. Address of Applicant: 3th Floor, Building 11, 4th Floor, Building 18, longjun Industrial park, Longhua New District,ShenZhen,China Manufacturer/Factory: Shenzhen AZW Technology Co., Ltd. Address of Manufacturer 3th Floor, Building 11, 4th Floor, Building 18, longjun Industrial park, Longhua New District,ShenZhen,China Product Name: mini PC Model No.: IPC-A,IPC-G,IPC-J,IPC-E,IPC-D Trade Mark: N/A FCC ID: 2A4J2-IPCA Applicable standards: FCC CFR Title 47 Part 15 Subpart E Section 15.407 Date of Test: Dec.29,2022- Jan.30, 2023 Date of report issued: Feb.06, 2023 Test Result : PASS * Remark: * In the configuration tested, the EUT complied with the standards specified above. The results shown in this test report refer only to the sample(s) tested , this test report cannot be reproduced, except in full without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver Prepared By Shenzhen ETR Standard Technology Co., Ltd. Address: No.103, No.10, Phase I, Zone 3, Xinxing Industrial Park, Xinhe, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Compiled by: Reviewed by: Approved by: Project Engineer Project Manager Authorized Signature - Page 2 of 61 - Report No.: ET-22120972E03 Tel:(86-755) 85259392 Email:[email protected] Web: www.etrlab.cn No.103, No.10, Phase I, Zone 3, Xinxing Industrial Park, Xinhe, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Report Revision History Report No. Description Issue Date ET-22120972E03 Original Feb.06, 2023 - Page 3 of 61 - Report No.: ET-22120972E03 Tel:(86-755) 85259392 Email:[email protected] Web: www.etrlab.cn No.103, No.10, Phase I, Zone 3, Xinxing Industrial Park, Xinhe, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Contents Page 1 TEST SUMMARY ......................................................................................................................................4 1.1 MEASUREMENT UNCERTAINTY .............................................................................................................4 2 GENERAL INFORMATION .......................................................................................................................5 2.1 GENERAL DESCRIPTION OF EUT ..........................................................................................................5 2.2 TEST MODE .........................................................................................................................................7 2.3 DESCRIPTION OF SUPPORT UNITS ........................................................................................................8 2.4 DEVIATION FROM STANDARDS ..............................................................................................................8 2.5 ABNORMALITIES FROM STANDARD CONDITIONS ....................................................................................8 2.6 TEST FACILITY ....................................................................................................................................8 2.7 TEST LOCATION ..................................................................................................................................8 2.8 ADDITIONAL INSTRUCTIONS ..................................................................................................................8 3 TEST INSTRUMENTS LIST ......................................................................................................................9 4 TEST RESULTS AND MEASUREMENT DATA .....................................................................................10 4.1 ANTENNA REQUIREMENT ....................................................................................................................10 4.2 CONDUCTED EMISSIONS ....................................................................................................................11 4.3 CONDUCTED PEAK OUTPUT POWER ...................................................................................................14 4.4 CHANNEL BANDWIDTH .......................................................................................................................16 4.5 POWER SPECTRAL DENSITY ..............................................................................................................24 4.6 BAND EDGE .......................................................................................................................................32 4.6.1 Conducted test Method ...............................................................................................................32 4.7 SPURIOUS EMISSION .........................................................................................................................39 4.7.1 Radiated Emission Method .........................................................................................................39 4.7.2 Conducted Emission Method ......................................................................................................48 4.8 FREQUENCY STABILITY ......................................................................................................................55 5 TEST SETUP PHOTO .............................................................................................................................61 6 EUT CONSTRUCTIONAL DETAILS .......................................................................................................61 - Page 4 of 61 - Report No.: ET-22120972E03 Tel:(86-755) 85259392 Email:[email protected] Web: www.etrlab.cn No.103, No.10, Phase I, Zone 3, Xinxing Industrial Park, Xinhe, Fuhai Street, Bao'an District, Shenzhen, Guangdong, Chi…

Text truncated - open the document above for the full version.

- Page 31 of 61 - Report No.: ET-22120972E03 Tel:(86-755) 85259392 Email:[email protected] Web: www.etrlab.cn No.103, No.10, Phase I, Zone 3, Xinxing Industrial Park, Xinhe, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China (802.11ac40) PSD plot on channel 151 (802.11ac80) PSD plot on channel 155 (802.11ac40) PSD plot on channel 159 - Page 32 of 61 - Report No.: ET-22120972E03 Tel:(86-755) 85259392 Email:[email protected] Web: www.etrlab.cn No.103, No.10, Phase I, Zone 3, Xinxing Industrial Park, Xinhe, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China 4.6 Band edge 4.6.1 Conducted test Method Test Requirement: FCC Part15 C Section 15.209 and 15.205 Test Method: ANSI C63.10: 2013 Limit: All emissions shall be limited to a level of −27 dBm/MHz at 75 MHz or more above or below the band edge increasing linearly to 10 dBm/MHz at 25 MHz above or below the band edge, and from 25 MHz above or below the band edge increasing linearly to a level of 15.6 dBm/MHz at 5 MHz above or below the band edge, and from 5 MHz above or below the band edge increasing linearly to a level of 27 dBm/MHz at the band edge. Test setup: Test Procedure: 1. Check the calibration of the measuring instrument using either an internal calibrator or a known signal from an external generator. 2. Position the EUT without connection to measurement instrument. Turn on the EUT and connect its antenna terminal to measurement instrument via a low loss cable. Then set it to any one measured frequency within its operating range, and make sure the instrument is operated in its linear range. 3. Set RBW of spectrum analyzer to 1 MHz with a convenient frequency span. 4. Measure the highest amplitude appearing on spectral display and set it as a reference level. Plot the graph with marking the highest point and edge frequency. 5. Repeat above procedures until all measured frequencies were complete.. Test Instruments: Refer to section 3.0 for details Test mode: Refer to section 2.2 for details Test results: Pass Remarks:/ - Page 33 of 61 - Report No.: ET-22120972E03 Tel:(86-755) 85259392 Email:[email protected] Web: www.etrlab.cn No.103, No.10, Phase I, Zone 3, Xinxing Industrial Park, Xinhe, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China 5.180~5.240 GHz (802.11a) Band Edge, Left Side (802.11n20) Band Edge, Left Side (802.11a) Band Edge, Right Side (802.11n20) Band Edge, Right Side - Page 34 of 61 - Report No.: ET-22120972E03 Tel:(86-755) 85259392 Email:[email protected] Web: www.etrlab.cn No.103, No.10, Phase I, Zone 3, Xinxing Industrial Park, Xinhe, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China 5.180~5.240 GHz (802.11ac20) Band Edge, Left Side (802.11n40) Band Edge, Left Side (802.11ac20) Band Edge, Right Side (802.11n40) Band Edge, Right Side - Page 35 of 61 - Report No.: ET-22120972E03 Tel:(86-755) 85259392 Email:[email protected] Web: www.etrlab.cn No.103, No.10, Phase I, Zone 3, Xinxing Industrial Park, Xinhe, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China 5.180~5.240 GHz (802.11ac40) Band Edge, Left Side (802.11ac80) Band Edge (802.11ac40) Band Edge, Right Side - Page 36 of 61 - Report No.: ET-22120972E03 Tel:(86-755) 85259392 Email:[email protected] Web: www.etrlab.cn No.103, No.10, Phase I, Zone 3, Xinxing Industrial Park, Xinhe, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China 5.745~5.825 GHz (802.11a) Band Edge, Left Side (802.11n20) Band Edge, Left Side (802.11a) Band Edge, Right Side (802.11n20) Band Edge, Right Side - Page 37 of 61 - Report No.: ET-22120972E03 Tel:(86-755) 85259392 Email:[email protected] Web: www.etrlab.cn No.103, No.10, Phase I, Zone 3, Xinxing Industrial Park, Xinhe, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China 5.745~5.825 GHz (802.11ac20) Band Edge, Left Side (802.11n40) Band Edge, Left Side (802.11ac20) Band Edge, Right Side (802.11n40) Band Edge, Right Side - Page 38 of 61 - Report No.: ET-22120972E03 Tel:(86-755) 85259392 Email:[email protected] Web: www.etrlab.cn No.103, No.10, Phase I, Zone 3, Xinxing Industrial Park, Xinhe, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China 5.745~5.825 GHz (802.11ac40) Band Edge, Left Side (802.11ac80) Band Edge (802.11ac40) Band Edge, Right Side - Page 39 of 61 - Report No.: ET-22120972E03 Tel:(86-755) 85259392 Email:[email protected] Web: www.etrlab.cn No.103, No.10, Phase I, Zone 3, Xinxing Industrial Park, Xinhe, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China 4.7 Spurious Emission 4.7.1 Radiated Emission Method Test Requirement: FCC Part15 C Section 15.209, Part 15E Section 15.407(b)(4) Test Method: ANSI C63.10:2013 Test Frequency Range: 9kHz to 40GHz Test site: Measurement Distance: 3m Receiver setup: Frequency Detector RBW VBW Value 9kHz-150KHz Quasi-peak 200Hz 1kHz Quasi-peak Value 150kHz-30MHz Quasi-peak 9kHz 30kHz Quasi-peak Value 30MHz-1GHz Quasi-peak 120KHz 300KHz Quasi-peak Value Above 1GHz Peak 1MHz 3MHz Peak Value AV 1MHz 3MHz Average Value Limit: Frequency Limit (uV/m) Value Measurement Distance 0.009MHz-0.490MHz 2400/F(KHz) QP 300m 0.490MHz-1.705MHz 24000/F(KHz) QP 300m 1.705MHz-30MHz 30 QP 30m 30MHz-88MHz 100 QP 3m 88MHz-216MHz 150 QP 216MHz-960MHz 200 QP 960MHz-1GHz 500 QP Frequency Limit (dBm/MHz) Remark Above 1GHz -27.0 Peak Value Test setup: For radiated emissions from 9kHz to 30MHz For radiated emissions from 30MHz to1GHz - Page 40 of 61 - Report No.: ET-22120972E03 Tel:(86-755) 85259392 Email:[email protected] Web: www.etrlab.cn No.103, No.10, Phase I, Zone 3, Xinxing Industrial Park, Xinhe, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China For radiated emissions above 1GHz Test Procedure: 1. The EUT was placed on the top of a rotating table (0.8m for below 1GHz and 1.5 meters for above 1GHz) above the ground at a 3 meter camber. The table was rotated 360 degrees to determine the position of the highest radiation. 2. The EUT was set 3 meters away from the interference-receiving antenna, which was mounted on the top of a variable-height …

Text truncated - open the document above for the full version.

shenzhenTian wei xun wireless technology co.,ltd. Product performance and specification Indexing Project drawing ................................................................. 2 1.1.1 Antenna matching pattern ............................................................................................................... 2 Purpose ........................................................................ 3 Antenna ........................................................................ 3 3.1.1 Electrical specifications and materials of antennas..................................................................... 3 3.1.2 Antenna form ..................................................................................................................................... 3 3.1.3 Working band of antenna design .................................................................................................... 3 3.1.4 Measurement data of main Antenna in ETS-SG24SYSTEM 3D Test system ................................. 4 3.1.5 Passive standing wave and echo loss of antenna ......................................................................... 5 3.1.6 Actual test results of WIFI antenna ..................................................................................................... 6 Project drawing IPC-A 1.1.1 Antenna matching pattern Element Capacitance Inductance E1(0402) -- -- E2(0402) -- E3(0402) -- -- The match says: has the match been changed according to the original motherboard -- -- E4(0402) -- Purpose Regulate the product specifications and test methods of mobile communication terminal antennas produced by Shenzhen Tianwei Wireless Technology Co., Ltd. Fan, avoid errors caused by different test conditions and methods Antenna Electrical specifications and materials of antennas This report mainly provides the test status of the structural performance parameters of the IPC-A antenna. Physical drawing 3.1.2 Antenna form: Implementation type: PIFA antenna material: FPC+ coaxial line Working band of antenna design: The antenna operates in the frequency band 2412MHz ~ 2472MHz\ 5100MHz~5820MHz 3.1.4 Measurement data of main Antenna in ETS-SG24SYSTEM 3D Test system picture (1) ETS test system picture(2) Three-dimensional positioning device for mobile phone in darkroom Passive performance index: Main antenna AUX antenna 3.1.5 Data of main antenna measured by network analyzer Return loss SWR Main antenna SWR Return loss AUX antenna 3.1.6 Actual test results of antenna

ET-22120972 Page 1 of 2 Product Name: mini PC Test Model No.: IPC-A Test Setup Photo Radiated emissions 30MHz to1GHz Above 1GHz ET-22120972 Page 2 of 2 Conducted Emission ------End------
