2A4J2-S3Mini PC

2A4J2-S3

ShenZhen AZW Technology CO.,LTD. Agent Authorization Company: ShenZhen AZW Technology CO.,LTD. Address: 3th Floor,Building 11,4th Floor, Building 18,longjun Industrial park,Longhua New District,ShenZhen Product Name: Mini PC Model Number(s): S3, Speed S, Speed S8,Speed S10,Speed S11,Speed S12, S4,S5,S6,S7 Product Description: Mini PC We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: Mar.01,2022 Name: Jerry Huang Title: Manager Company: ShenZhen AZW Technology CO.,LTD.

FCC Software Configuration Control Declaration Rev1.1 ShenZhen AZW Technology CO.,LTD. FCC Software Configuration Control Declaration Date: March 1, 2022 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Attn: OET Dept. Product/ Model Number: Mini PC S3, Speed S, Speed S8,Speed S10,Speed S11,Speed S12,S4,S5,S6,S7 Regarding FCC Country Code Selection guidelines identified in KDB 594280. “All applications for equipment authorization for transmitters that can have radio parameters, or other technical parameters, reported to the Commission set by software must have an attestation indicating that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified.” We declare that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified. Name: Jerry Huang Date: Mar.01,2022 Title: Manager Signature of applicant

ShenZhen AZW Technology CO.,LTD. Family models declaration letter. Date: March 1, 2022 We ShenZhen AZW Technology CO.,LTD. Of 3th Floor,Building 11,4th Floor, Building 18,longjun Industrial park,Longhua New District,ShenZhen Product: Mini PC Model Name: S3 Serial Model: Speed S, Speed S8,Speed S10,Speed S11,Speed S12,S4,S5,S6,S7 Difference description of series models: All models differences are only naming method, and others are the same. Thanks Sincerely, Signature Name: Jerry Huang Date: Mar.01, 2022 Title: Manager

ShenZhen AZW Technology CO.,LTD. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: March 1, 2022 Subject; Request for Confidentiality FCC ID: 2A4J2-S3 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Software Security Requirements for UNII devices In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Jerry Huang Title: Manager

EUT PHOTO (External Photos)

Label location

EUT PHOTO (Internal Photos) BT Antenna WIFI Antenna RF Module ※※※※※ END ※※※※※

FCC ID: 2A4J2-S3 RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. Test Result of RF Exposure Evaluation For BLE: Antenna gain=2.68dBi Mode Output power (dBm) Output power (mW) Numeric antenna gain Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result BLE 3.64 2.31 1.85 0.00085 1.0 PASS For 2.4G WIFI mode: Antenna gain=2.68dBi Mode Output power (dBm) Output power (mW) Numeric antenna gain Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 802.11b 9.99 9.98 1.85 0.00367 1.0 PASS 802.11g 10.57 11.40 1.85 0.00420 1.0 PASS 802.11n(HT20) 10.38 10.91 1.85 0.00402 1.0 PASS 802.11n(HT40) 8.28 6.73 1.85 0.00248 1.0 PASS For 5.2G WIFI mode: Antenna gain=4.22dBi Mode Output power (dBm) Output power (mW) Numeric antenna gain Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 802.11a 10.62 11.53 2.64 0.00606 1.0 PASS 802.11n(HT20) 10.68 11.69 2.64 0.00614 1.0 PASS 802.11n(HT40) 8.27 6.71 2.64 0.00353 1.0 PASS 802.11ac(HT20) 10.74 11.86 2.64 0.00623 1.0 PASS 802.11ac(HT40) 8.48 7.05 2.64 0.00370 1.0 PASS 802.11ac(HT80) 4.20 2.63 2.64 0.00138 1.0 PASS For 5.8G WIFI mode: Antenna gain=4.22dBi Mode Output power (dBm) Output power (mW) Numeric antenna gain Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 802.11a 10.79 11.99 2.64 0.00630 1.0 PASS 802.11n(HT20) 10.74 11.86 2.64 0.00623 1.0 PASS 802.11n(HT40) 8.54 7.14 2.64 0.00375 1.0 PASS 802.11ac(HT20) 10.66 11.64 2.64 0.00612 1.0 PASS 802.11ac(HT40) 8.55 7.16 2.64 0.00376 1.0 PASS 802.11ac(HT80) 4.79 3.01 2.64 0.00158 1.0 PASS If BLE and 2.4G WIFI operate simultaneously, Total power density=0.00085/1+0.00420/1=0.00505<1.0 If BLE and 5.2G WIFI operate simultaneously, Total power density=0.00085/1+0.00623/1=0.00708<1.0 If BLE and 5.8G WIFI operate simultaneously, Total power density=0.00085/1+0.00630/1=0.00715<1.0
