2AA9MHC2Home Center

To start using Fibaro System Home Center 2, please connect the device to power and LAN sockets, as shown below. 1. Unscrew left side panel 3. Connect wires as shown on gure below 2. Take side panel o HC2 backHC2 front WARNING! Do not turn Home Center 2 on without RECOVERY pendrive. POWER - click to turn HC2 ON - click (when HC2 ON) to reset the device - press and hold for approx 10 seconds to turn HC2 OFF LED IndicatorsBack panel buttons POWER - power ON LAN - HC2 connected to Ethernet INTERNET - HC2 connected to Internet Z-WAVE - communication within Z-Wave network LEARN MODE [blinking slowly] - new device beeing added to the Z-Wave network LEARN MODE [blinking] - device beeing deleted from the Z-Wave network LEARN MODE [blinking quickly] - device has been added/removed. RECOVERY - Recovery Mode active UPDATE - New software version available for downlowad SERVICE - Software update in progress. RECOVERY - to enter Recovery Mode disconnect the power supply. Press and hold Recovery button when reconnecting the power supply (release the button after entering Recovery Mode)*. - click once - entering Learn Mode (add new Z-Wave device), - click twice - entering Learn Mode (delete Z-Wave device), - press and hold to set static IP: 192.168.81.1* * NOTE: after setting static IP Home Center 2 will loose the router connection. For more information go to www.baro.com Start HC2 with a POWER button and wait approx. 2 minutes for the device to start. Correct connection will be signalled by diodes 1, 2, 3 (see the glossary below). Connect power cable to the mains, and network cable to LAN socket in your router (Home Center 2 requires an outside router). 5. Start Home Center 2 4. Connect HC2 Start the HC2 Finder and click "Refresh". After the list of Home Center 2, available within your local network appears, choose the one you wish to connect and click "connect". After successful connection you will access HC2 control panel. Choose your language version, enter user name and password. Defaults are: admin / admin. Go to www.baro.com, nd Support section, download and install HC2 Finder desig- nated for your operating system. 6. Login to Home Center 2 POWER FCC ID: 2AA9MHC2 THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHOR- IZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2.This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reason- able protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help.

Fibaro Home Center 2 FCC Label

NVLAP Lab code: 100414-0 FCC 47 CFR PART 15 SUBPART C CERTIFICATION TEST REPORT FOR Home Center MODEL NUMBER: FGHC2 FCC ID: 2AA9MHC2 REPORT NUMBER: 10044158A ISSUE DATE: December 18, 2013 Prepared for Fibar Group sp. z.o.o ul. Lotnicza 1 Poznań, Poland 60-453 Prepared by UL LLC 333 Pfingsten Rd. Northbrook, IL 60062 TEL: (847) 272-8800 REPORT NO: 10044158A DATE: December 18, 2013 FCC ID: 2AA9MHC2 Page 2 of 29 UL LLC FORM NO: CCSUP4701G 333 Pfingsten Rd., Northbrook, IL 60062 TEL: (847) 272-8800 This report shall not be reproduced except in full, without the written approval of UL LLC. Revision History Rev. Issue Date Revisions Revised By -- 12/18/13 Initial Issue M.Ferrer REPORT NO: 10044158A DATE: December 18, 2013 FCC ID: 2AA9MHC2 Page 3 of 29 UL LLC FORM NO: CCSUP4701G 333 Pfingsten Rd., Northbrook, IL 60062 TEL: (847) 272-8800 This report shall not be reproduced except in full, without the written approval of UL LLC. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS ............................................................................................. 4 2. TEST METHODOLOGY .................................................................................................................. 5 3. FACILITIES AND ACCREDITATION .......................................................................................... 5 4. CALIBRATION AND UNCERTAINTY .......................................................................................... 5 4.1. MEASURING INSTRUMENT CALIBRATION ............................................................................. 5 4.2. SAMPLE CALCULATION ............................................................................................................ 5 4.3. MEASUREMENT UNCERTAINTY ............................................................................................... 5 5.5. DESCRIPTION OF TEST SETUP ................................................................................................ 7 6. TEST AND MEASUREMENT EQUIPMENT ................................................................................ 9 7. TEST RESULTS ............................................................................................................................... 10 7.1.1. 99%, 20dB BANDWIDTH ................................................................................................. 10 7.2. RADIATED EMISSIONS............................................................................................................. 13 7.2.1. HARMONICS AND SPURIOUS EMISSIONS ABOVE 1GHz ....................................... 16 7.2.2. WORST-CASE BELOW 1 GHz ........................................................................................ 17 8. AC MAINS LINE CONDUCTED EMISSIONS ............................................................................ 19 9. SETUP PHOTOS .............................................................................................................................. 24 REPORT NO: 10044158A DATE: December 18, 2013 FCC ID: 2AA9MHC2 Page 4 of 29 UL LLC FORM NO: CCSUP4701G 333 Pfingsten Rd., Northbrook, IL 60062 TEL: (847) 272-8800 This report shall not be reproduced except in full, without the written approval of UL LLC. 1. ATTESTATION OF TEST RESULTS COMPANY NAME: Fibar Group sp. z.o.o Ul. Lotnicza 1 Poznan, Poland 60-453 EUT DESCRIPTION: Home Center MODEL: HC2 SERIAL NUMBER: Prototype DATE TESTED: September 12, 2013 – December 4, 2013 APPLICABLE STANDARDS STANDARD TEST RESULTS CFR 47 Part 15 Subpart C Part 15.249 Pass INDUSTRY CANADA RSS-210 Issue 8 Annex A2.9 Pass INDUSTRY CANADA RSS-GEN Issue 3 Pass UL Verification Services Inc. tested the above equipment in accordance with the requirements set forth in the above standards. All indications of Pass/Fail in this report are opinions expressed by UL Verification Services Inc. based on interpretations and/or observations of test results. Measurement Uncertainties were not taken into account and are published for informational purposes only. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Note: The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. This document may not be altered or revised in any way unless done so by UL Verification Services Inc. and all revisions are duly noted in the revisions section. Any alteration of this document not carried out byUL Verification Services Inc. will constitute fraud and shall nullify the document. This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, any agency of the Federal Government, or any agency of any government. Approved & Released For UL CCS By: Tested By: BART MUCHA MICHAEL FERRER WiSE STAFF ENGINEER WiSE Project Lead UL Verification Services Inc. UL Verification Services Inc. REPORT NO: 10044158A DATE: December 18, 2013 FCC ID: 2AA9MHC2 Page 5 of 29 UL LLC FORM NO: CCSUP4701G 333 Pfingsten Rd., Northbrook, IL 60062 TEL: (847) 272-8800 This report shall not be reproduced except in full, without the written approval of UL LLC. 2. TEST METHODOLOGY The tests documented in this report were performed in accordance with ANSI C63.4-2003, FCC CFR 47 Part 15, RSS-GEN Issue 3, and RSS-210 Issue 8. 3. FACILITIES AND ACCREDITATION The test sites and measurement facilities used to collect data are located at 333 Pfingsten Road, Northbrook, IL 60062, USA. UL NBK is accredited by NVLAP, Laboratory Code 100414-0. 4. CALIBRATION AND UNCERTAINTY 4.1. MEASURING INSTRUMENT CALIBRATION The measuring equipment utilized to perform the tests documented in this report has been calibrated in accordance with the manufacturer's recommendations, and is traceable to recognized national standards. 4.2. SAMPLE CALCULATION Where relevant, the following sample calculation is provided: Field Strength (dBuV/m) = Measured Voltage (dBuV) +…
