MODE + SPEED + MODE SPEED BRIGHT + COLOR + BRIGHT DEMO COLOR RF Wireless Low Voltage Lighting Systems User Guide Please read this user guide before installing and using your Low Voltage Lighting Systems 1.THE COMPONENTS LIST H1> Class 2 power supply----1 pc; H2> RF control---1 pc; H3> LED control box---1 pc; H4> LED light Bar ---1 pcs; H5> Buckle ---3 pcs. 2.INSTALLATION 1>Screw the buckles onto the furniture. 2>Fit and snap the LED light bar into the buckles. 4>Connect the connecting wires between the parts. 5>Plug the Power supply plug to the socket. 6>Operate the Remote control to control the light bar (pull out the battery insulation before use). 3.SPECIFICATIONS ⚫ Power supply: Input: 100-240VAC 50/60HZ Output:12V, 2A, 24W ⚫ LED lighting: Input: DC 12V Power: Max. 24W 4.RF wireless Remote RGB LED Controller Instructions 22 Dynamic Modes RF Remote 20 Static Colors Ultra Slim Design Very Smooth Effects Dynamic Demo Mode Speed Adjustable Easy Remote Pairing Brightness Adjustable Direct Color Selecting Functions 1.Turn On/Standby Press this key to turn on unit or switch to standby mode. once power on, the Unit will automatically turn on and restore to previous status. 2/9. Adjusting Dynamic Mode Switch to dynamic mode from static color, or switch between dynamic modes. 3/10. Adjusting Dynamic Speed Adjust dynamic playing speed. Press SPEED+ to increase speed and press SPEED- to decrease. The unit will switch to dynamic mode if press this key at static color mode. 4/5. Adjusting Static Color Switch to static color mode from dynamic mode, or switch between static colors. 6.Direct Color Select Shortcut key to static colors. When press the specific color key, LED will display the same static color. The direct colors are included in ‘COLOR+’ and ‘COLOR-’ operation. 7/8. Adjusting Brightness Adjust static color brightness, press BRIGHT+ to increase brightness and press BRIGHT- to decrease. 11.Demo Mode Press this key will switch to Demo mode. At demo mode, it displays red green and blue color dynamic modes in loop. Operation Connect to LED lighting Connect to power supply MODE + SPEED + MODE - SPEED - BRIGHT + COLOR + - BRIGHT DEMO - COLOR RF Wireless 1 2 3 4 5 6 7 8 9 10 11 H1 H2 H3 H4 H5 2 1.Using Remote Controller Please pull out the battery insulate tape before using. The RF wireless remote signal can pass through barrier, so it’s not necessary to aim at the main unit when operating. For proper receiving remote signal, please do not install the main unit in closed parts. 2.Pairing New Remote The remote and main unit is 1 to 1 paired as default. Further more, main unit can be paired to 3 remote controllers and each remote controller can be paired to any main unit. Please do the following steps to pair new remote controller: 1) Plug off the power of main unit and plug in after 5 seconds. 2) Press ‘COLOR-’ and ‘BRIGHT-’ key together in 5 seconds after power on. After this operation, the main unit will recognize the new remote controller. Warning: This action cannot be undone! 3.Free Remote Pairing Mode In some specific cases, the main unit may need to be paired to any remote controllers, please do following steps for free remote pairing mode: 1) Plug off the power of main unit and plug in after 5 seconds. 2) Press ‘ON/OFF’ and ‘MODE+’ key together in 5 seconds. After this operation, the main unit will recognize any remote controller. To pair the main unit back to specific remote, please repeat the ‘Pairing New Remote’ operation. 4.Switch Output Color Sequence The controller’s default output signal sequence is Common-Green-Red-Blue. If the LED application is in different cable sequence, the direct color keys will not match the LED color. In this case, user can adjust the output signal sequence with following steps. 1) Plug off the power of main unit and plug in after 5 seconds, 2) Press ‘RED’ and ‘BLUE’ color key together in 5 seconds after power on. With this operation, the output sequence will switch between 6 possible combinations, the sequence will be memorized and it won’t change before next same operation. Specification Dynamic mode 22 modes Static color 20 colors PWM grade 256 levels Brightness grade 5 levels Speed grade 10 levels Demo mode Yes Direct color switchable Yes Output color switchable Yes, 6 options Working voltage DC 5-24V Output current 3×4A peak, 3×2A constant Remote frequency 433.92MHz Remote distance <=6m at open area 5. WARNINGS 1> Don’t connect to non-original power supply. 2> Please install following installation instruction to avoid damage. 3> Indoor use only, working ambient temperature 4°C to 36°C. 4> Dry location uses only; 5> Prevent children or animals from chewing or swallowing parts. 6> Return to the dealer for repair service if abnormal, instead of dismantle. 7> Do not install the LED controller in closed parts. 8> USE ONLY WITH CLASS 2 POWER UNIT. 9> CAUTION: The mounting means provided with this luminaire has not been evaluated for reliability. If installed where failure of the mounting means could cause injury to persons or damage to property below, supplemental means of securement should be considered. OPEN PUSH RELEASE 1 2 CR2025 LITHIUM BATTERY Pull out the battery insulation 3 Installing the battery The battery is supplied with the remote control. The first thing to do with the remote control is to remove the plastic sheet insulated the battery. For replacement battery, use lithium based CR2025 battery. Please follow the sequence below to replace the battery. □ Take out the battery bracket. □ Insert the battery with the button side into the battery bracket, making sure the battery is firmly seated. □ Press the battery bracket into the remote control, making sure it snaps into position. □ Turn the remote over and aim it towards the lighting systems unit. □ If nothing appears to happen, check to make sure the battery is installed correctly, and try again. Battery Safety Warning 1. Remove and immediately recycle or dispose of used batteries according to …
Text truncated - open the document above for the full version.
Whalen LLC dba Whalen Furniture Manufacturing Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2024-08-08 FCC ID: 2AAHD-GN7214H Ref. #1: Attestation Statements Part 2.911(d)(5)(i) Filing Whalen LLC dba Whalen Furniture Manufacturing certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Ref. #2: Attestation Statements Part 2.911(d)(5)(ii) Filing Whalen LLC dba Whalen Furniture Manufacturing certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Applicant: Whalen LLC dba Whalen Furniture Manufacturing Address: 1578 Air Wing Road San Diego,CA 92154 Contact Person: Dwayne Myers Tel.: 86-186-6513-1211 Email: [email protected] Sincerely, Signature:
Attestation Statements Date: 2024-08-21 TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for (FCC ID: 2AAHD-GN7214H) Whalen LLC dba Whalen Furniture Manufacturing, the undersigned, hereby authorize Whalen LLC dba Whalen Furniture Manufacturing to act as our designated U.S. agent for service of process, Whalen LLC dba Whalen Furniture Manufacturing accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Whalen LLC dba Whalen Furniture Manufacturing accepts the responsibility to act as designated U.S. agent for service of process. Applicant Information: Company name: Whalen LLC dba Whalen Furniture Manufacturing Contact Name: Dwayne Myers Address: 1578 Air Wing Road San Diego,CA 92154 Telephone No: 86-186-6513-1211 Email: [email protected] FRN: 0022769426 Signature: Dwayne Myers U.S. Agent Information: Company Name:Whalen LLC dba Whalen Furniture Manufacturing Address:1578 Air Wing Road San Diego,CA 92154 FRN: 0022769426 Contact Name:Dwayne Myers Telephone No: 86-186-6513-1211 Email: [email protected] Signature: Dwayne Myers
Effective Date: April 2, 2020 QSF 7.6.4-8 – Agent Authorization Letter Template Page 1 of 1 Revision Date: Revision: 0 Whalen LLC dba Whalen Furniture Manufacturing Date:2024-08-08 Product Model Number: GN7214H-24 ; GN7214H-12, GN7214H-24A FCC ID:2AAHD-GN7214H To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following: • Testing • Approval applications and procedures We declare that QAI Laboratories Ltd. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by QAI Laboratories Ltd. on our behalf shall have the same effect as acts of our own. Signature: By: Dwayne Myers Contact Listed on FCC Wesbite Title: QE Director Email: [email protected] On behalf of: Whalen LLC dba Whalen Furniture Manufacturing
Whalen LLC dba Whalen Furniture Manufacturing Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: August 21, 2024 Subject; Request for Confidentiality FCC ID: 2AAHD-GN7214H To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Dwayne Myers Title: QE Director
Whalen LLC dba Whalen Furniture Manufacturing Declaration Letter of Model Difference Date: 2024-08-08 Tested Model Number: GN7214H-24 Adding Model Number(s): GN7214H-12, GN7214H-24A All models are the same except the power supply and the length of the light bar. GN7214H-12 power supply is 12W, single light bar. GN7214H-24 power supply is 24W, three short light bars. GN7214H-24A power supply is 24W. two long light bars. Yours Sincerely, Applicant: Whalen LLC dba Whalen Furniture Manufacturing Address: 1578 Air Wing Road San Diego,CA 92154 Contact Person: Dwayne Myers Tel.: 86-186-6513-1211 Email: [email protected] Sincerely, Signature:
Page 1 of 14 Report No.: LGT24G173 Appendix - External Photographs of EUT Constructional Details Model: GN7214H-24 Photo 1 Photo 2 Page 2 of 14 Report No.: LGT24G173 Photo 3 Photo 4 Page 3 of 14 Report No.: LGT24G173 Photo 5 Photo 6 Page 4 of 14 Report No.: LGT24G173 Photo 7 Photo 8 Page 5 of 14 Report No.: LGT24G173 Photo 9 Photo 10 Page 6 of 14 Report No.: LGT24G173 Photo 11 Photo 12 Page 7 of 14 Report No.: LGT24G173 Photo 13 Photo 14 Page 8 of 14 Report No.: LGT24G173 Photo 15 Photo 16 Page 9 of 14 Report No.: LGT24G173 Photo 17 Photo 18 Page 10 of 14 Report No.: LGT24G173 Photo 19 Photo 20 Page 11 of 14 Report No.: LGT24G173 Photo 21 Photo 22 Page 12 of 14 Report No.: LGT24G173 Photo 23 Photo 24 Page 13 of 14 Report No.: LGT24G173 Photo 25 Photo 26 Page 14 of 14 Report No.: LGT24G173 Photo 27 Photo 28
Label
Page 1 of 2 Report No.: LGT24G173 Appendix - Internal Photographs of EUT Constructional Details Model: GN7214H-24 Photo 1 Photo 2 Page 2 of 2 Report No.: LGT24G173 Photo 3
The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China EMC TEST REPORT Product Name: RGB LED Lighting Set Model Name: GN7214H-24 Series Model: GN7214H-12, GN7214H-24A FCC ID: 2AAHD-GN7214H Issued For : Whalen LLC dba Whalen Furniture Manufacturing 1578 Air Wing Road San Diego,CA 92154 Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT24G173EM01 Sample Received Date: July 24, 2024 Date of Test: July 24, 2024 ~ Aug. 08, 2024 Date of Issue: Aug. 08, 2024 Report No.: LGT24G173EM01 Page 2 of 28 TEST REPORT CERTIFICATION Applicant: Whalen LLC dba Whalen Furniture Manufacturing Address: 1578 Air Wing Road San Diego,CA 92154 Manufacturer: Whalen LLC dba Whalen Furniture Manufacturing Address: 1578 Air Wing Road San Diego,CA 92154 Product Name: RGB LED Lighting Set Trademark: N/A Model Name: GN7214H-24 Series Model: GN7214H-12, GN7214H-24A Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC 47 CFR Part 15 Subpart B ANSI C63.4-2014 PASS Prepared by: Approved by: Terry Zhao Vita Li Engineer Technical Director Report No.: LGT24G173EM01 Page 3 of 28 Table of Contents 1. TEST SUMMARY 5 1.1 TEST LABORATORY 6 1.2 MEASUREMENT UNCERTAINTY 6 2. GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF THE EUT 7 2.2 DESCRIPTION OF THE TEST MODES 8 2.3 DESCRIPTION OF THE SUPPORT UNITS 8 2.4 MEASUREMENT INSTRUMENTS LIST 9 3. EMC EMISSION TEST 10 3.1 CONDUCTED EMISSION MEASUREMENT 10 3.2 RADIATED EMISSION MEASUREMENT 18 APPENDIX I - TEST SETUP 26 APPENDIX II - External Photographs of EUT Constructional Details 28 Report No.: LGT24G173EM01 Page 4 of 28 Revision History Rev. Issue Date Revisions 00 Aug. 08, 2024 Initial Issue Report No.: LGT24G173EM01 Page 5 of 28 1. TEST SUMMARY EMC Emission Standard Test Item Limit Judgement Remark FCC 47 CFR Part 15 Subpart B ANSI C63.4-2014 Conducted Emissions Class B PASS Radiated Emissions Below 1GHz Class B PASS Radiated Emissions Above 1GHz Class B PASS Note: 1 “N/A” denotes test is not applicable in this Test Report 2 If the highest frequency of the internal sources of the EUT is less than 108 MHz, the measurement shall only be made up to 1 GHz. If the highest frequency of the internal sources of the EUT is between 108 MHz and 500 MHz, the measurement shall only be made up to 2 GHz. If the highest frequency of the internal sources of the EUT is between 500 MHz and 1 GHz, measurement shall only be made up to 5 GHz. If the highest frequency of the internal sources of the EUT is above 1 GHz, the measurement shall be made up to 5 times the highest frequency or 40 GHz, whichever is less. Report No.: LGT24G173EM01 Page 6 of 28 1.1 TEST LABORATORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate A2LA Certificate No.: 6727.01 FCC Registration No.: 746540 CAB ID: CN0136 1.2 MEASUREMENT UNCERTAINTY Test Item Measurement Frequency Range MHz Uncertainty dB Conducted Emissions at AC mains power port 0.009 ~ 30 2.80 Radiated Emissions 0.009 ~ 30 2.16 Radiated Emissions 30 ~ 1000 4.40 Radiated Emissions 1000 ~ 6000 5.10 Radiated Emissions 6000 ~ 18000 5.49 Note: This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level using a coverage factor of k=2. The measurement uncertainty is not included in the test result. Report No.: LGT24G173EM01 Page 7 of 28 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name: RGB LED Lighting Set Model Name: GN7214H-24 Series Model: GN7214H-12, GN7214H-24A Model Difference: All models are the same except the power supply and the length of the light bar. GN7214H-12 power supply is 12W, single light bar. GN7214H-24 power supply is 24W, three short light bars. GN7214H-24A power supply is 24W. two long light bars. Maximum operating frequency: >108MHz Rating: AC 120V/60Hz Test voltage: AC 120V/60Hz Hardware Version: N/A Software Version: N/A Connecting I/O Port(s): Please refer to the Note 1. Note: For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. Report No.: LGT24G173EM01 Page 8 of 28 2.2 DESCRIPTION OF THE TEST MODES To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mode or test configuration mode which possibly have effect on EMI emission level. Each of these EUT operating mode(s) or test configuration mode(s) mentioned above was evaluated respectively. Pretest Mode Description Mode 1 Working Conducted Emission Test Final Test Mode Description Mode 1 Working For Radiated Emission Final Test Mode Description Mode 1 Working Note: For radiated emission test, test mode 1 was the worst case and only this mode was presented in this report. 2.3 DESCRIPTION OF THE SUPPORT UNITS The EUT has been tested as an independent unit together with other necessary accessories or support units. The following support units or accessories were used to form a representative test configuration during the tests. Accessories Equipment Description Manufacturer Model Rating Remark Adapter 1 X.L.Y ELECTRONICS LIMITED W24-120200UW Input: 100-240V AC, 50/60Hz, 0.6A MAX Output: 12V, 2.0A For Model: GN7214H-24 GN7214H-24 A Adapter 2 XING YUAN ELECTRONICS CO.,LTD …
Text truncated - open the document above for the full version.
Page 1 of 2 Report No.: LGT24G173 Set-up for Conducted Emission on AC Mains (CE) Set-up for Radiated Emission (RE), Below 1GHz Page 2 of 2 Report No.: LGT24G173 Set-up for Radiated Emission (RE), Above 1GHz
