2AAHD-RF-17Remote Control

MODE + SPEED + MODE SPEED BRIGHT + COLOR + BRIGHT DEMO COLOR RF Wireless Low Voltage Lighting Systems User Guide Please read this user guide before installing and using your Low Voltage Lighting Systems 1．THE COMPONENTS LIST H1> Class 2 power supply----1 pc; H2> RF control---1 pc; H3> LED control box---1 pc; H4> LED light Bar ---1 pcs; H5> Buckle ---3 pcs. 2．INSTALLATION 1>Screw the buckles onto the furniture. 2>Fit and snap the LED light bar into the buckles. 4>Connect the connecting wires between the parts. 5>Plug the Power supply plug to the socket. 6>Operate the Remote control to control the light bar (pull out the battery insulation before use). 3．SPECIFICATIONS ⚫ Power supply: Input: 100-240VAC 50/60HZ Output:12V, 2A, 24W ⚫ LED lighting: Input: DC 12V Power: Max. 24W 4．RF wireless Remote RGB LED Controller Instructions 22 Dynamic Modes RF Remote 20 Static Colors Ultra Slim Design Very Smooth Effects Dynamic Demo Mode Speed Adjustable Easy Remote Pairing Brightness Adjustable Direct Color Selecting Functions 1.Turn On/Standby Press this key to turn on unit or switch to standby mode. once power on, the Unit will automatically turn on and restore to previous status. 2/9. Adjusting Dynamic Mode Switch to dynamic mode from static color, or switch between dynamic modes. 3/10. Adjusting Dynamic Speed Adjust dynamic playing speed. Press SPEED+ to increase speed and press SPEED- to decrease. The unit will switch to dynamic mode if press this key at static color mode. 4/5. Adjusting Static Color Switch to static color mode from dynamic mode, or switch between static colors. 6.Direct Color Select Shortcut key to static colors. When press the specific color key, LED will display the same static color. The direct colors are included in ‘COLOR+’ and ‘COLOR-’ operation. 7/8. Adjusting Brightness Adjust static color brightness, press BRIGHT+ to increase brightness and press BRIGHT- to decrease. 11.Demo Mode Press this key will switch to Demo mode. At demo mode, it displays red green and blue color dynamic modes in loop. Operation Connect to LED lighting Connect to power supply MODE + SPEED + MODE - SPEED - BRIGHT + COLOR + - BRIGHT DEMO - COLOR RF Wireless 1 2 3 4 5 6 7 8 9 10 11 H1 H2 H3 H4 H5 2 1.Using Remote Controller Please pull out the battery insulate tape before using. The RF wireless remote signal can pass through barrier, so it’s not necessary to aim at the main unit when operating. For proper receiving remote signal, please do not install the main unit in closed parts. 2.Pairing New Remote The remote and main unit is 1 to 1 paired as default. Further more, main unit can be paired to 3 remote controllers and each remote controller can be paired to any main unit. Please do the following steps to pair new remote controller: 1) Plug off the power of main unit and plug in after 5 seconds. 2) Press ‘COLOR-’ and ‘BRIGHT-’ key together in 5 seconds after power on. After this operation, the main unit will recognize the new remote controller. Warning: This action cannot be undone! 3.Free Remote Pairing Mode In some specific cases, the main unit may need to be paired to any remote controllers, please do following steps for free remote pairing mode: 1) Plug off the power of main unit and plug in after 5 seconds. 2) Press ‘ON/OFF’ and ‘MODE+’ key together in 5 seconds. After this operation, the main unit will recognize any remote controller. To pair the main unit back to specific remote, please repeat the ‘Pairing New Remote’ operation. 4.Switch Output Color Sequence The controller’s default output signal sequence is Common-Green-Red-Blue. If the LED application is in different cable sequence, the direct color keys will not match the LED color. In this case, user can adjust the output signal sequence with following steps. 1) Plug off the power of main unit and plug in after 5 seconds, 2) Press ‘RED’ and ‘BLUE’ color key together in 5 seconds after power on. With this operation, the output sequence will switch between 6 possible combinations, the sequence will be memorized and it won’t change before next same operation. Specification Dynamic mode 22 modes Static color 20 colors PWM grade 256 levels Brightness grade 5 levels Speed grade 10 levels Demo mode Yes Direct color switchable Yes Output color switchable Yes, 6 options Working voltage DC 5-24V Output current 3×4A peak, 3×2A constant Remote frequency 433.93MHz Remote distance <=6m at open area 5. WARNINGS 1> Don’t connect to non-original power supply. 2> Please install following installation instruction to avoid damage. 3> Indoor use only, working ambient temperature 4°C to 36°C. 4> Dry location uses only; 5> Prevent children or animals from chewing or swallowing parts. 6> Return to the dealer for repair service if abnormal, instead of dismantle. 7> Do not install the LED controller in closed parts. 8> USE ONLY WITH CLASS 2 POWER UNIT. 9> CAUTION: The mounting means provided with this luminaire has not been evaluated for reliability. If installed where failure of the mounting means could cause injury to persons or damage to property below, supplemental means of securement should be considered. OPEN PUSH RELEASE 1 2 CR2025 LITHIUM BATTERY Pull out the battery insulation 3 Installing the battery The battery is supplied with the remote control. The first thing to do with the remote control is to remove the plastic sheet insulated the battery. For replacement battery, use lithium based CR2025 battery. Please follow the sequence below to replace the battery. □ Take out the battery bracket. □ Insert the battery with the button side into the battery bracket, making sure the battery is firmly seated. □ Press the battery bracket into the remote control, making sure it snaps into position. □ Turn the remote over and aim it towards the lighting systems unit. □ If nothing appears to happen, check to make sure the battery is installed correctly, and try again. Battery Safety Warning 1. Remove and immediately recycle or dispose of used batteries according to …

Text truncated - open the document above for the full version.

Whalen LLC dba Whalen Furniture Manufacturing Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2024-08-08 FCC ID: 2AAHD-RF-17 Ref. #1: Attestation Statements Part 2.911(d)(5)(i) Filing Whalen LLC dba Whalen Furniture Manufacturing certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Ref. #2: Attestation Statements Part 2.911(d)(5)(ii) Filing Whalen LLC dba Whalen Furniture Manufacturing certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Applicant: Whalen LLC dba Whalen Furniture Manufacturing Address: 1578 Air Wing Road San Diego,CA 92154 Contact Person: Dwayne Myers Tel.: 86-186-6513-1211 Email: [email protected] Sincerely, Signature:

Attestation Statements Date: 2024-08-21 TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for (FCC ID: 2AAHD-RF-17) Whalen LLC dba Whalen Furniture Manufacturing, the undersigned, hereby authorize Whalen LLC dba Whalen Furniture Manufacturing to act as our designated U.S. agent for service of process, Whalen LLC dba Whalen Furniture Manufacturing accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Whalen LLC dba Whalen Furniture Manufacturing accepts the responsibility to act as designated U.S. agent for service of process. Applicant Information： Company name: Whalen LLC dba Whalen Furniture Manufacturing Contact Name: Dwayne Myers Address: 1578 Air Wing Road San Diego,CA 92154 Telephone No: 86-186-6513-1211 Email: [email protected] FRN: 0022769426 Signature: Dwayne Myers U.S. Agent Information: Company Name:Whalen LLC dba Whalen Furniture Manufacturing Address:1578 Air Wing Road San Diego,CA 92154 FRN: 0022769426 Contact Name:Dwayne Myers Telephone No: 86-186-6513-1211 Email: [email protected] Signature: Dwayne Myers

1. Antenna Description Antenna Type PCB antenna Market name/Model name RF-17 Antenna Max. Gain 0dBi Frequency Range 433.93MHz VSWR 1.1 Manufacture Whalen LLC dba Whalen Furniture Manufacturing Address 1578 Air Wing Road San Diego,CA 92154 2. Picture of antenna

Effective Date: April 2, 2020 QSF 7.6.4-8 – Agent Authorization Letter Template Page 1 of 1 Revision Date: Revision: 0 Whalen LLC dba Whalen Furniture Manufacturing Date：2024-08-08 Product Model Number: RF-17 FCC ID：2AAHD-RF-17 To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following: • Testing • Approval applications and procedures We declare that QAI Laboratories Ltd. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by QAI Laboratories Ltd. on our behalf shall have the same effect as acts of our own. Signature: By: Dwayne Myers Contact Listed on FCC Wesbite Title: QE Director Email: [email protected] On behalf of: Whalen LLC dba Whalen Furniture Manufacturing

Whalen LLC dba Whalen Furniture Manufacturing Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: August 21, 2024 Subject; Request for Confidentiality FCC ID: 2AAHD-RF-17 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Dwayne Myers Title: QE Director

Page 1 of 3 Report No.: LGT24G174 Appendix - External Photographs of EUT Constructional Details Model: RF-17 Photo 1 Photo 2 Page 2 of 3 Report No.: LGT24G174 Photo 3 Photo 4 Page 3 of 3 Report No.: LGT24G174 Photo 5 Photo 6

Label

Page 1 of 2 Report No.: LGT24G174 Appendix - Internal Photographs of EUT Constructional Details Model: RF-17 Photo 1 Photo 2 Page 2 of 2 Report No.: LGT24G174 Photo 3 Photo 4 ANT

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China RF TEST REPORT Product Name: Remote Control Model Name: RF-17 FCC ID: 2AAHD-RF-17 Issued For : Whalen LLC dba Whalen Furniture Manufacturing 1578 Air Wing Road San Diego,CA 92154 Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT24G174HA01 Sample Received Date: July 24, 2024 Date of Test: July 24, 2024 – Aug. 07, 2024 Date of Issue: Aug. 08, 2024 Report No.: LGT24G174HA01 Page 2 of 9 TEST REPORT CERTIFICATION Applicant: Whalen LLC dba Whalen Furniture Manufacturing Address: 1578 Air Wing Road San Diego,CA 92154 Manufacture: Whalen LLC dba Whalen Furniture Manufacturing Address: 1578 Air Wing Road San Diego,CA 92154 Product Name: Remote Control Trademark: N/A Model Name: RF-17 Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC 47 CFR §2.1093 KDB 447498 D01 General RF Exposure Guidance v06 PASS Prepared by: Approved by: Zane Shan Vita Li Engineer Technical Director Report No.: LGT24G174HA01 Page 3 of 9 TABLE OF CONTENTS 1 . GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST LABORATORY 5 2 . FCC 47CFR §2.1093 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 TEST RESULT 8 APPENDIX I - PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS 9 Report No.: LGT24G174HA01 Page 4 of 9 Revision History Rev. Issue Date Revisions 00 Aug. 08, 2024 Initial Issue Report No.: LGT24G174HA01 Page 5 of 9 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name: Remote Control Trademark: N/A Model Name: RF-17 Series Model: N/A Model Difference: N/A Frequency Bands: 433.93MHz Rating: DC 3V Battery: CR2025 Rated Voltage: 3.0V Hardware Version: N/A Software Version: N/A 1.2 TEST LABORATORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate A2LA Certificate No.: 6727.01 FCC Registration No.: 746540 CAB ID: CN0136 Report No.: LGT24G174HA01 Page 6 of 9 2. FCC 47CFR §2.1093 REQUIREMENT 2.1 TEST STANDARDS The limit for Maximum Permissible Exposure (MPE) specified in KDB 447498 D01 General RF Exposure Guidance v06 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. 2.2 LIMIT Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. Report No.: LGT24G174HA01 Page 7 of 9 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] • [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz. Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Report No.: LGT24G174HA01 Page 8 of 9 2.3 TEST RESULT Turn up Result Worse case is as below: Note:The maximum Equivalent Isotropic Radiated Power : 68.01dBuV/m-95.3=-27.29dBm (refer to C63.10, section 10.3.9)(433.93MHz) Mode Turn up Power 433.93MHz -27±1dBm The MPE result of worst mode: Frequency (MHz) Max Turn up Power (dBm) Max Turn up Power (mW) Estimated SAR Limit Ratio Result 433.93 -26.00 0.0025 0.000794 3 0.00026 Pass Note: 1. The estimated SAR≤ 3.0 for 1-g SAR, Separation distance ≤ 5mm, complies with the exemption requirements. Report No.: LGT24G174HA01 Page 9 of 9 APPENDIX I - PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Note: Please see the attached RF-17_External Photos and RF-17_Internal Photos. ※※※※※END OF THE REPORT※※※※※

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China RF TEST REPORT Product Name: Remote Control Model Name: RF-17 FCC ID: 2AAHD-RF-17 Issued For : Whalen LLC dba Whalen Furniture Manufacturing 1578 Air Wing Road San Diego,CA 92154 Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT24G174RF03 Sample Received Date: July 24, 2024 Date of Test: July 24, 2024 – Aug. 07, 2024 Date of Issue: Aug. 08, 2024 Report No.: LGT24G174RF01 Page 2 of 32 TEST REPORT CERTIFICATION Applicant: Whalen LLC dba Whalen Furniture Manufacturing Address: 1578 Air Wing Road San Diego,CA 92154 Manufacture: Whalen LLC dba Whalen Furniture Manufacturing Address: 1578 Air Wing Road San Diego,CA 92154 Product Name: Remote Control Trademark: N/A Model Name: RF-17 Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC Part 15.231, Subpart C ANSI C63.10-2013 PASS Prepared by: Approved by: Zane Shan Vita Li Engineer Technical Director Report No.: LGT24G174RF01 Page 3 of 32 TABLE OF CONTENTS Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 9 2.3 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 9 2.4 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 10 2.5 EQUIPMENTS LIST 11 3. EMC EMISSION TEST 12 3.1 CONDUCTED EMISSION MEASUREMENT 12 3.2 TEST PROCEDURE 13 3.3 TEST SETUP 13 3.4 TEST RESULTS 13 4. RADIATED EMISSION MEASUREMENT 14 4.1 RADIATED EMISSION LIMITS 14 4.2 TEST PROCEDURE 16 4.3 DEVIATION FROM TEST STANDARD 16 4.4 TEST SETUP 17 4.5 EUT OPERATING CONDITIONS 18 4.6 TEST RESULTS 18 4.7 FIELD STRENGTH CALCULATION 19 5. BANDWIDTH TEST 24 5.1 LIMIT 24 5.2 TEST REQUIREMENTS 24 5.3 TEST PROCEDURE 24 5.4 TEST SETUP 24 5.5 EUT OPERATION CONDITIONS 24 5.6 TEST RESULTS 25 6. DUTY CYCLE 26 6.1 TEST PROCEDURE 26 6.2 TEST SETUP 26 6.3 EUT OPERATION CONDITIONS 26 6.4 TEST RESULTS 27 Report No.: LGT24G174RF01 Page 4 of 32 TABLE OF CONTENTS Page 7. AUTOMATICALLY DEACTIVATE 29 7.1 STANDARD REQUIREMENT 29 7.2 TEST PROCEDURE 29 8. ANTENNA REQUIREMENT 31 8.1 STANDARD REQUIREMENT 31 8.2 EUT ANTENNA 31 APPENDIX I - PHOTOS OF TEST SETUP 32 Report No.: LGT24G174RF01 Page 5 of 32 Revision History Rev. Issue Date Revisions 00 Aug. 08, 2024 Initial Issue Report No.: LGT24G174RF01 Page 6 of 32 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part 15.231, Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A -- 15.205(a)/15.209/ 15.231.(b) Radiated Spurious Emission PASS -- 15.231(a)(1)/ 15.231(b)(2) Transmission requirement PASS -- 15.231(C) 20 dB Bandwidth PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2013. Report No.: LGT24G174RF01 Page 7 of 32 1.1 TEST FACTORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate A2LA Certificate No.: 6727.01 FCC Registration No.: 746540 CAB ID: CN0136 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. Parameter Uncertainty RF Output Power, Conducted ±0.71dB Unwanted Emission, Conducted ±0.63dB Conducted emission ±2.80dB All Emissions, Radiated (0.009-30MHz) ±2.16dB All Emissions, Radiated (30MHz-1GHz) ±4.40dB All Emissions, Radiated (1GHz-18GHz) ±5.49dB Note: The measurement uncertainty is not included in the test result. Report No.: LGT24G174RF01 Page 8 of 32 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name: Remote Control Trademark: N/A Model Name: RF-17 Series Model: N/A Model Difference: N/A Frequency band: 433.93MHz Rating: DC 3V Battery: CR2025 Rated Voltage: 3.0V Modulation Type: FSK Antenna Type: PCB Antenna Antenna Gain: 0dBi Hardware version: N/A Software version: N/A Connecting I/O Port(s): Please refer to the Note 1. Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications orthe User Manual. 2. The antenna information refers to the manufacturer provide report, applicable only to the tested sample identified in the report. Due to the incorrect antenna information, a series of problems such as the accuracy of the test results will be borne by the customer. Report No.: LGT24G174RF01 Page 9 of 32 2.2 DESCRIPTION OF THE TEST MODES To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mode or test configuration mode which possible have effect on EMI emission level. Each of these EUT operation mode(s) or test configuration mode(s) mentioned above was evaluated respectively. Pretest Mode Description Mode 1 TX Mode For Radiated Emission Final Test Mode Description Mode 1 TX Mode 2.3 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED During test, Keep EUT is in continuous transmission mode, Both open button and closed button have been tested, The two keys were tested to assess and only record the worst case in the report (Open botton). E-1 EUT Repo…

Text truncated - open the document above for the full version.
