GPS-TRACKER/RASTREADORGPS/TRACEURGPS/LOCALIZZATOREGPS EN-Operatinginstructions ProductName:GPSTracker ModelName:TRKM010 Manufacture:TrackimoINC. Packcontents/productparts ............................................................. 25 Generalinformation .............................................................................. 26 Keytosymbols............................................................................................26 Properuse .......................................................................................... 28 Safety .................................................................................................. 28 Initialset-up ............................................................................................ 32 Checkingthepackcontents.....................................................................32 Installingandchargingthebattery..........................................................32 Turningthetrackeron...............................................................................33 Activatingthetracker.................................................................................33 Installingtheapp........................................................................................33 Functions ............................................................................................ 34 Checkingtheconnection..........................................................................34 Buttonfunctions.........................................................................................34 Geofencing..................................................................................................34 Speedalert..................................................................................................35 Movementalert...........................................................................................35 Lowbatteryalert.........................................................................................36 Lightsensor.................................................................................................36 GPSsignalandreception.........................................................................36 Lightandsoundmeanings.......................................................................38 Cleaning ...................................................................................... 39 Storage ............................................................................................... 39 Technicaldata .................................................................................... 40 DeclarationofConformity ............................................................... 41 Disposal ....................................................................................... 41 Disposingofthepackaging......................................................................41 Disposingofthetracker............................................................................41 Packcontents/productparts 1 On/offSOSResetbutton 2 G_sensor 3 Magneticchargingport 4 Redlight 5 Bluelight 6 Greenlight Generalinformation Theseoperating instructionsareforthe TrackimoTravelCATM1 GPSTracker,whichwill simply bereferredtoas‘tracker’inthe following.Theycontainimportant informationregardingset-upand operation.Beforeusingthetracker, pleasereadtheoperatinginstructions carefully.Thisparticularlyappliesto thesafetynotes.Failuretoadhereto theseoperatinginstructionsmay resultinsevereinjuryordamageto thetracker. Theoperatinginstructionsare basedonthestandardsandrulesin forceintheEuropeanUnion.When abroad,youmustalsoobserve country-specificguidelinesandlaws. Keeptheoperatinginstructionsfor futureuse.Ifyoupassthetrackeron tothirdparties,pleasebeabsolutely suretoincludetheseoperating instructions. Keytosymbols DeclarationofConformity (see“Declarationof Conformity”chapter): Productsmarkedwiththis symbolconformwithall applicableCommunity provisionsineffectinthe EuropeanEconomicArea. Productsmarkedwith thissymbolconformwith ProtectionClassII. TheFCClogoindicates electronicdevicesthat conformwithFCC provisionsfromthe Americanauthority,the FederalCommunications Commission.The symbolalsoguarantees compatibilitywith standards,suchas thosesetoutbythe InternationalOrganization forStandardization (abbreviatedasISO). Signalwords Thefollowingsignalwordsareused intheseoperatinginstructions: WARNING! Thissignalwordindicatesahazard withamoderatedegreeofriskthat mayleadtodeathorsevereinjuryif itisnotavoided. NOTICE! Thissignalwordwarnsagainst potentialdamagetoproperty. Properuse Thetrackerissuitableforlocating anitemorlivingbeing. Onlyusethetrackerasdescribed intheseoperatinginstructions.Any otheruseisdeemedimproperand mayresultindamagetopropertyor evenpersonalinjury.Thetrackeris notachildren’stoy. Themanufacturerandvendordo notacceptanyliabilityfordamage causedbyimproperorincorrect use. Safety WARNING! Electricshockhazard! Incorrectelectricalinstallationor usingamainsvoltagethatistoohigh canresultinanelectricshock. − Onlyconnectthetrackerand thechargingcableifthemains voltageofthepowersocket matchesthatstatedonthelabel. −Onlyconnectthemains adaptortoaneasilyaccessible powersocketsothatthe chargingcablecanbequickly disconnectedfromthemains supplyifitmalfunctions. −Donotusethetrackerifthere arevisiblesignsofdamage orifthechargingcableis defective. −Ifthechargingcableis damaged,itmustbereplaced bythemanufacturer,the manufacturer’sservice departmentorasimilarly qualifiedpersoninorderto avoidrisk. −Onlychargethebatterywith thechargingcablesupplied. − Donotopenthetrackercasing. Instead,ensureanyrepairs arecarriedoutbyspecialists. Contactaspecialistworkshop. Warrantyandguaranteeclaims cannotbemadeifrepairshave beencarriedoutindependently, orifthetrackerhasbeen incorrectlyconnectedor operated. −Onlypartsthatcorrespond withtheoriginaldevice’sdata canbeusedinrepairs.This trackercontainselectronic andmechanicalpartsthatare essentialforprotectingagainst potent…
Text truncated - open the document above for the full version.
Trackimo INC. TCBJ FORM-4 Issued by: TCB Administrator Revision 6 12/06/10 2020.09.11 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, Trackimo INC. hereby authorize (Shenzhen STS Test Services Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Name: Shlomo Shur Signature:
Trackimo INC. TCBJ FORM-4 Issued by: TCB Administrator Revision 6 12/06/10 2020.09.11 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (GPS Tracker / TRKM010 /FCC ID: 2AAI6TRKM010) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the • Schematics • Block diagram • Operation description • Tune up Procedure • Part List These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. required to be submitted with this application be permanently withheld from public review. Please contact me if there is any information you may need. Sincerely, Name: Shlomo Shur Signature:
Page 1 of 4 Report No.: STS2007202 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Page 2 of 4 Report No.: STS2007202 Photo 3 Photo 4 Page 3 of 4 Report No.: STS2007202 Photo 5 Photo 6 Page 4 of 4 Report No.: STS2007202 Photo 7
FCC Label GPS Tracker Model name: TRKM010 FCC ID: 2AAI6TRKM010 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 1 of 6 Report No.: STS2007202 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 GSM/WCDMA Antenna WIFI/GPS(RX) Antenna Page 2 of 6 Report No.: STS2007202 Photo 3 Photo 4 BT Antenna Page 3 of 6 Report No.: STS2007202 Photo 5 Photo 6 Page 4 of 6 Report No.: STS2007202 Photo 7 Photo 8 Page 5 of 6 Report No.: STS2007202 Photo 9 Photo 10 Page 6 of 6 Report No.: STS2007202 Photo 11 Photo 12
Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. ShenZhen STS Test Services Co.,Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] S T L A B S Testing Engineer : (Aaron Bu) Technical Manager : (Jason Lu) Authorized Signatory : (Vita Li) SAR Dipole Performance Measurement Report EUT Type: SAR Validation Dipole and Waveguide Model Name: DIP0G835-332 DIP1G900-333 Brand Name: SATIMO Test Conclusion: Pass Test Date: 16 Aug. 2019 Date of Issue: 17 Aug. 2019 ISSUED BY Shenzhen STS Test Services Co., Ltd. 1. Equipment List Kind of Equipment Manufacturer Type No. Serial No. Last Calibration Calibrated Until PC Acer N/A N/A N/A N/A E-Field Probe MVG SSE5 SN 14/16 EP309 2018.12.13 2019.12.12 Dielectric Probe Kit MVG SCLMP SN 32/14 OCPG67 2018.12.01 2019.11.30 Phantom1 MVG SAM SN 32/14 SAM115 N/A N/A Phantom2 MVG SAM SN 32/14 SAM116 N/A N/A Attenuator Agilent 99899 DC-18GHz N/A N/A Directional coupler Narda 4226-20 3305 N/A N/A Network Analyzer Agilent 8753ES US38432810 2019.03.02 2020.03.01 Multi Meter Keithley Multi Meter 2000 4050073 2018.10.13 2019.10.12 Signal Generator Agilent N5182A MY50140530 2018.10.16 2019.10.15 Power Amplifier DESAY ZHL-42W 9638 2018.10.13 2019.10.12 Power Meter R&S NRP 100510 2018.10.26 2019.10.25 Power Sensor R&S NRP-Z11 101919 2018.10.13 2019.10.12 Power Sensor Agilent E9301A MY41497725 2018.10.13 2019.10.12 hygrothermograph MiEO HH660 N/A 2018.10.11 2019.10.10 Thermograph Elitech RC-4 S/N EF7176501537 2018.10.15 2019.10.14 ISSUED BY Shenzhen STS Test Services Co., Ltd. 2. <Justification of the extended calibration> Referring to KDB 865664 D01, if dipoles are verified in return loss<-20dB, (within 20% of prior calibration), and in impedance (within 5 ohm of prior calibration), the annual calibration is not necessary and the calibration interval can be extended. Head 835 MHz Date of Measurement Return Loss (dB) Delta (%) Impedance Delta(ohm) 2017.08.15 -28.11 - 51.6 - 2018.08.15 -27.05 -3.77 54.69 3.09 2019.08.14 -26.41 -2.37 52.62 -2.07 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. <Dipole Verification Data> Head 835MHz ISSUED BY Shenzhen STS Test Services Co., Ltd. Head 1900 MHz Date of Measurement Return Loss (dB) Delta (%) Impedance Delta(ohm) 2017.08.15 -23.68 - 51.2 - 2018.08.16 -25.00 5.57 47.12 -4.08 2019.08.15 -23.79 -4.84 48.62 1.50 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. <Dipole Verification Data> Head 1900 MHz
Ref : ACR.345.3.20.SATU.A SHENZHEN STS TEST SERVICES CO., LTD. 1/F, BUILDING 2, ZHUOKE SCIENCE PARK, CHONGQING ROAD FUYONG, BAO’ AN DISTRICT, SHENZHEN,CHINA MVG COMOSAR DOSIMETRIC E-FIELD PROBE SERIAL NO.: SN 41/18 EPGO334 Calibrated at MVG US 2105 Barrett Park Dr. - Kennesaw, GA 30144 Calibration Date: 06/03/2020 Summary: This document presents the method and results from an accredited COMOSAR Dosimetric E-Field Probe calibration performed in MVG USA using the CALISAR / CALIBAIR test bench, for use with a COMOSAR system only. All calibration results are traceable to national metrology institutions. COMOSAR E-Field Probe Calibration Report COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.345.3.20.SATU.A Page: 2/10 This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. Name Function Date Signature Prepared by : Jérôme LUC Product Manager 6/05/2020 Checked by : Jérôme LUC Product Manager 6/05/2020 Approved by : Kim RUTKOWSKI Quality Manager 6/05/2020 Customer Name Distribution : Shenzhen STS Test Services Co., Ltd. Issue Date Modifications A 6/05/2020 Initial release COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.345.3.20.SATU.A Page: 3/10 This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. TABLE OF CONTENTS 1 Device Under Test ..................................................................................................... 4 2 Product Description ................................................................................................... 4 2.1 General Information _______________________________________________________ 4 3 Measurement Method ................................................................................................ 4 3.1 Linearity ________________________________________________________________ 4 3.2 Sensitivity _______________________________________________________________ 5 3.3 Lower Detection Limit _____________________________________________________ 5 3.4 Isotropy _________________________________________________________________ 5 3.5 Boundary Effect __________________________________________________________ 5 4 Measurement Uncertainty .......................................................................................... 5 5 Calibration Measurement Results .............................................................................. 6 5.1 Sensitivity in air __________________________________________________________ 6 5.2 Linearity ________________________________________________________________ 7 5.3 Sensitivity in liquid ________________________________________________________ 7 5.4 Isotropy _________________________________________________________________ 8 6 List of Equipment .................................................................................................... 10 COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.345.3.20.SATU.A Page: 4/10 This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. 1 DEVICE UNDER TEST Device Under Test Device Type COMOSAR DOSIMETRIC E FIELD PROBE Manufacturer MVG Model SSE2 Serial Number SN 41/18 EPGO334 Product Condition (new / used) New Frequency Range of Probe 0.45 GHz-6GHz Resistance of Three Dipoles at Connector Dipole 1: R1=0.191 M Dipole 2: R2=0.216 M Dipole 3: R3=0.197 M A yearly calibration interval is recommended. 2 PRODUCT DESCRIPTION 2.1 GENERAL INFORMATION MVG’s COMOSAR E field Probes are built in accordance to the IEEE 1528 and CEI/IEC 62209 standards. Figure 1 – MVG COMOSAR Dosimetric E field Dipole Probe Length 330 mm Length of Individual Dipoles 2 mm Maximum external diameter 8 mm Probe Tip External Diameter 2.5 mm Distance between dipoles / probe extremity 1 mm 3 MEASUREMENT METHOD The IEEE 1528 and CEI/IEC 62209 standards provide recommended practices for the probe calibrations, including the performance characteristics of interest and methods by which to assess their affect. All calibrations / measurements performed meet the fore mentioned standards. 3.1 LINEARITY The evaluation of the linearity was done in free space using the waveguide, performing a power sweep to cover the SAR range 0.01W/kg to 100W/kg. COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.345.3.20.SATU.A Page: 5/10 This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. 3.2 SENSITIVITY The sensitivity factors of the three dipoles were determined using a two step calibration method (air and tissue simulating liquid) using waveguides as outlined in the standards. 3.3 LOWER DETECTION LIMIT The lower detection limit was assessed using the same measurement set up as used for the linearity measurement. The required lower detection limit is 10 mW/kg. 3.4 ISOTROPY The axial isotropy was evaluated by exposing the probe to a reference wave from a standard dipole with the dipole mounted under the flat phantom in the test configuration suggested for system validations and checks. The probe was rotated along its main axis from 0 - 360 degrees in 15 degree steps. The hemispherical isotropy is determined by inserting the probe in a thin plastic box filled with tissue-equivalent liquid, with the plastic box illuminated with the fields from a half wave dipole. The dip…
Text truncated - open the document above for the full version.
Any reproduction of this document must be done in full. No single part of this document may bereproduced without permission from STS,All Test Data Presented in this report isonly applicable to presentedTest sample. ShenZhen STS Test Services Co.,Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] FCC SAR TEST REPORT Report No.: STS2007202H01 Issued for Trackimo INC. 450 Seventh Avenue, Suite 1408, New York, United States Product Name: GPS Tracker Brand Name: trackimo Model Name: TRKM010 Series Model: N/A FCC ID: 2AAI6TRKM010 Test Standard: ANSI/IEEE Std. C95.1 FCC 47 CFR Part 2 ( 2.1093) IEEE 1528: 2013 Max. Report SAR (1g): Body: 1.217W/kg S T L A B S Page 2 of 42 Report No.: STS2007202H01 Test Report Certification Applicant’s name ................. : Trackimo INC. Address ................................. : 450 Seventh Avenue, Suite 1408, New York, United States Manufacture's Name ............ : Trackimo INC. Address ................................. : 450 Seventh Avenue, Suite 1408, New York, United States Product description Product name ........................ : GPS Tracker Brand name ........................... : trackimo Model name ........................... : TRKM010 Series Model .......................... : N/A Standards ............................. : ANSI/IEEE Std. C95.1-1992 FCC 47 CFR Part 2 ( 2.1093) IEEE 1528: 2013 The device was tested by Shenzhen STS Test Services Co., Ltd. in accordance with themeasurement methodsand procedures specified in KDB 865664 The test results in this reportapply only to the tested sample of thestated device/equipment. Other similar device/equipmentwill not necessarily produce the same results due toproduction tolerance and measurementuncertainties. Date of Test ........................................... : Date (s) of performance of tests ............. : 20 July 2020~21 July 2020 Date of Issue .......................................... : 18 Aug. 2020 Test Result .............................................. : Pass Testing Engineer : ( Aaron Bu) Technical Manager : (Sean she) Authorized Signatory : (Vita Li) Page 3 of 42 Report No.: STS2007202H01 Table of Contents 1.General Information 5 1.1 EUT Description 5 1.2 Test Environment 6 1.3 Test Factory 6 2.Test Standardsand Limits 7 3. SAR Measurement System 8 3.1 Definition of Specific Absorption Rate (SAR) 8 3.2 SAR System 8 4. Tissue Simulating Liquids 11 4.1 Simulating Liquids Parameter Check 11 5. SAR System Validation 13 5.1 Validation System 13 5.2 Validation Result 13 6. SAR Evaluation Procedures 14 7. EUT Test Position 15 8.Uncertainty 16 8.1Measurement Uncertainty 16 8.2 System validation Uncertainty 17 9. Conducted Power Measurement 18 9.1Test Result 18 9.2SAR Test Exclusions Applied 21 10. EUT And Test Setup Photo 22 10.1 EUT Photo 22 10.2 Setup Photo 25 11. SAR Result Summary 29 11.1Body-worn SAR 29 11.2 repeated SAR measurement 30 12. Equipment List 33 Appendix A. System Validation Plots 34 Appendix B. SAR Test Plots 38 Appendix C. Probe Calibration And Dipole Calibration Report 42 Page 4 of 42 Report No.: STS2007202H01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 18 Aug. 2020 STS2007202H01 ALL Initial Issue Note: Format version of the report-V01 Page 5 of 42 Report No.: STS2007202H01 1. General Information Environmental evaluation measurements of specific absorption rate (SAR) distributions in emulated human head andbody tissues exposed to radio frequency (RF) radiation from wireless portable devices for compliance with the rules andregulations of the U.S. Federal Communications Commission (FCC). 1.1 EUT Description Product Name GPS Tracker Brand Name trackimo Model Name TRKM010 Series Model N/A Model Difference N/A Battery Rated Voltage: 3.7V Charge Limit: 4.2V Capacity: 600mAh Device Category Portable Product stage Production unit RF Exposure Environment General Population / Uncontrolled Hardware Version V2.0 Software Version V8.0 Frequency Range GSM 850:824.2~848.8MHz PCS1900:1850.2~1909.8MHz WCDMA Band II:1852.4~1907.6MHz WCDMA Band V:826.4~846.6MHz Bluetooth:2402~2480MHz Max. Reported SAR(1g): (Limit:1.6W/kg) Band Mode BodyWorn (W/kg) PCB GSM 850 0.871 PCB GSM 1900 1.174 PCB WCDMA Band II 1.217 PCB WCDMA Band V 0.670 DTS Bluetooth Note 0.011 1-g Sum SAR 1.228 FCC Equipment Class Licensed Portable Transmitter Held to Ear (PCB) Digital Transmission System (DTS) Operating Mode: GSM: GSM Voice; GPRS WCDMA:RMC,HSDPA,HSUPA Release 6 BLE Antenna Specification: GSM,WCDMA: PIFA Antenna BT: PIFA Antenna Hotspot Mode: Not Support DTM Mode: Not Support Note: 1.Bluetooth SAR was estimated 2. The EUT battery must be fully charged and checked periodically during the test to ascertain uniformpower Page 6 of 42 Report No.: STS2007202H01 1.2 Test Environment Ambient conditions in the SAR laboratory: Items Required Temperature (°C) 18-25 Humidity (%RH) 30-70 1.3 Test Factory ShenZhen STS Test Services Co.,Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration No.: 625569 IC Registration No.: 12108A A2LA Certificate No.: 4338.01 Page 7 of 42 Report No.: STS2007202H01 2. Test Standardsand Limits No. Identity Document Title 1 47 CFR Part 2 Frequency Allocations and Radio Treaty Matters; General Rules and Regulations 2 ANSI/IEEE Std. C95.1-1992 IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz 3 IEEE Std. 1528-2013 Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques 4 FCC KDB 447498 D01v06 GPS Tracker and Portable Device RF Exposure Procedures andEquipment Authorization Policies 5 FCC KDB 865664 D01v01r04 SAR M…
Text truncated - open the document above for the full version.
Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No.: STS2007202W05 Issued for Trackimo INC. 450 Seventh Avenue, Suite 1408, New York, United States Product Name: GPS Tracker Brand Name: trackimo Model Name: TRKM010 Series Model: N/A FCC ID: 2AAI6TRKM010 Test Standard: FCC Part 22H and 24E S T L A B S Page 2 of 63 Report No.: STS2007202W05 TEST RESULT CERTIFICATION Applicant’s Name ................... : Trackimo INC. Address .................................. : 450 Seventh Avenue, Suite 1408, New York, United States Manufacturer's Name ............. : Trackimo INC. Address .................................. : 450 Seventh Avenue, Suite 1408, New York, United States Product Description Product Name ........................ : GPS Tracker Brand Name ......................... : trackimo Model Name ........................... : TRKM010 Series Model .......................... : N/A Test Standards ....................... : FCC Part 22H and 24E Test Procedure ....................... : KDB 971168 D01 v03r01,ANSI C63.26( 2015) This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document may be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ................................ : Date of receipt of test item .......... : 08 July 2020 Date (s) of performance of tests . : 08 July 2020 ~ 18 Aug. 2020 Date of Issue .............................. : 18 Aug. 2020 Test Result .................................. : Pass Testing Engineer : (Chris Chen) Technical Manager : (Sean she) Authorized Signatory: (Vita Li) Page 3 of 63 Report No.: STS2007202W05 Table of Contents Page 1 INTRODUCTION 6 1.1 TEST FACTORY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 PRODUCT INFORMATION 7 4 MEASUREMENT INSTRUMENTS 9 5 TEST ITEMS 10 5.1 CONDUCTED OUTPUT POWER 10 5.2 PEAK TO AVERAGE RATIO 11 5.3 TRANSMITTER RADIATED POWER (EIRP/ERP) 12 5.4 OCCUPIED BANDWIDTH 13 5.5 FREQUENCY STABILITY 14 5.6 SPURIOUS EMISSIONS AT ANTENNA TERMINALS 15 5.7 BAND EDGE 16 5.8 FIELD STRENGTH OF SPURIOUS RADIATION MEASUREMENT 17 APPENDIX A.TESTRESULT 19 A1. CONDUCTED OUTPUT POWER 19 A2. PEAK-TO-AVERAGE RADIO 22 A3. TRANSMITTER RADIATED POWER (EIRP/ERP) 29 A4. OCCUPIED BANDWIDTH (99% OCCUPIED BANDWIDTH/26DB BANDWIDTH)31 A5. FREQUENCY STABILITY 38 A6. SPURIOUS EMISSIONS AT ANTENNA TERMINALS 42 A7. BAND EDGE 48 A8. FIELD STRENGTH OF SPURIOUS RADIATION MEASUREMENT 53 APPENDIX-PHOTOS OF TEST SETUP 63 Page 4 of 63 Report No.: STS2007202W05 Revision History Rev. Issue Date Report NO. Effect Page Contents 00 18 Aug. 2020 STS2007202W05 ALL Initial Issue Page 5 of 63 Report No.: STS2007202W05 SUMMARY OF TEST RESULTS Test procedures according to the technical standards: The radiated emission testing was performed according to the procedures of KDB 971168 D01 v03r01 and ANSI C63.26( 2015) FCC Rules Te s t D e s c r i p t i o n Te s t L i m i t Test Result Reference 2.1046 Conducted Output PowerReporting Only PASS 22.913d 24.232d Peak-to-Average Ratio < 13 dB PASS 2.1046 22.913 24.232 Effective Radiated Power/Equivalent Isotropic Radiated Power < 7 Watts max. ERP(Part 22) < 2 Watts max. EIRP(Part 24) PASS 2.1049 22.917 24.238 Occupied Bandwidth Reporting Only PASS 2.1055 22.355 24.235 Frequency Stability < 2.5 ppm (Part 22) Emission must remain in band (Part 24) PASS 2.1051 22.917 24.238 Spurious Emission at Antenna Terminals < 43+10log10(P[Watts]) PASS 2.1053 22.917 24.238 Field Strength of Spurious Radiation < 43+10log10(P[Watts]) PASS 2.1051 22.917 24.238 Band Edge < 43+10log10(P[Watts]) PASS Page 6 of 63 Report No.: STS2007202W05 1 INTRODUCTION 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The measurement uncertainties shown below were calculated in accordance with the requirements ofANSI C63.4-2014. All measurement uncertainty values are shown with a coverage factor of k = 2 toindicate a 95% level of confidence. The measurement data shown herein meets or exceeds the UCISPRmeasurement uncertainty values specified in CISPR 16-4-2 and, thus, can be compared directly tospecified limits to determine compliance. No. Item Uncertainty 1 RF output power, conducted ±0.68dB 2 Unwanted Emissions, conducted ±2.988dB 3 All emissions, radiated 30-1GHz ±5.6dB 4 All emissions, radiated 1G-6GHz ±5.5dB 5 All emissions, radiated>6G ±5.8dB 6 Conducted Emission (9KHz-150KHz) ±3.37dB 7 Conducted Emission (150KHz-30MHz) ±3.83dB Page 7 of 63 Report No.: STS2007202W05 2 PRODUCT INFORMATION Product Name GPS Tracker Trade Name trackimo Model Name TRKM010 Series Model N/A Model Difference N/A Tx Frequency: GSM/GPRS: 850: 824 MHz ~ 849MHz 1900: 1850 MHz ~ 1910MHz WCDMA: Band V: 824 MHz ~ 849 MHz Band II: 1850 MHz ~ 1910 MHz Rx Frequency: GSM/GPRS: 850: 869 MHz ~ 894 MHz 1900: 1930 MHz ~ 1990MHz WCDMA: Band V: 869 MHz ~ 894 MHz Band II: 1930 MHz ~ 1990 MHz Max RF Output Power: GSM850:32.16dBm, PCS1900:28.85dBm GPRS850(1-Slot):32.04dBm, GPRS1900(1-Slot):28.85dBm GPRS850(2-Slot):31.61dBm, GPRS1900(2-Slot):28.41dBm GPRS850(3-Slot):29.91dBm, GPRS1900(3-Slot):27.…
Text truncated - open the document above for the full version.
Page 33 of 63 Report No.: STS2007202W05 GSM1900_Low GPRS1900_Low GSM1900_Middle GPRS1900_Middle GSM1900_High GPRS1900_High Page 34 of 63 Report No.: STS2007202W05 WCDMA_Band2_Low WCDMA_Band2_Middle WCDMA_Band2_High HSDPA_Band2_Low HSDPA_Band2_Middle HSDPA_Band2_High Page 35 of 63 Report No.: STS2007202W05 HSUPA_Band2_Low HSUPA_Band2_Middle HSUPA_Band2_Hig…
Text truncated - open the document above for the full version.
