2AAI6TRKM110GPS Tracker

GPS-TRACKER / RASTREADOR GPS / TRACEUR GPS / LOCALIZZATORE GPS EN - Operating instructions Product Name: GPS Tracker Model Name: TRKM110 Manufacture: Trackimo INC. Pack contents / productparts .................................................. 25 General information .............................................................. 26 Keytosymbols ................................................................................. 26 Properuse ........................................................................... 28 Safety ................................................................................ 28 Initialset-up ........................................................................... 32 Checking thepackcontents ............................................................. 32 Installing and chargingthebattery.................................................... 32 Turning thetrackeron ...................................................................... 33 Activatingthetracker ........................................................................ 33 Installingtheapp .............................................................................. 33 Functions .............................................................................. 34 Checkingtheconnection .................................................................. 34 Buttonfunctions ............................................................................... 34 Geofencing ..................................................................................... 34 Speedalert ...................................................................................... 35 Movementalert ................................................................................ 35 Lowbatteryalert ............................................................................... 36 Lightsensor ..................................................................................... 36 GPS signalandreception ................................................................. 36 Light andsoundmeanings ............................................................... 38 Cleaning ........................................................................... 39 Storage .............................................................................. 39 Technicaldata ........................................................................ 40 DeclarationofConformity ..................................................... 41 Disposal ........................................................................... 41 Disposing ofthepackaging .............................................................. 41 Disposing ofthetracker .................................................................... 41 Pack contents / product parts 1 On/offbutton 2 Lightsensor 3 Magnetic chargingport 4 Redlight 5 Bluelight 6 Greenlight 7 Chargingcable 8 Lanyard withclip General information These operating instructions are for the TrackimoTravel3GGPS Tracker,whichwillsimply be referred to as „tracker‟ in the following. They contain important information regarding set-up and operation. Before using the tracker, pleasereadtheoperatinginstructions carefully. This particularly applies to thesafetynotes.Failuretoadhereto these operating instructions may resultinsevereinjuryordamageto thetracker. The operating instructions are basedonthestandardsandrulesin forceintheEuropeanUnion.When abroad, you must also observe country-specific guidelines and laws. Keep the operating instructions for futureuse.Ifyoupassthetrackeron to third parties, please be absolutely sure to include these operating instructions. Key to symbols Declaration of Conformity (see “Declaration of Conformity” chapter): Products marked with this symbol conform with all applicable Community provisions in effect in the European Economic Area. Products marked with this symbol conform with Protection Class II. The FCC logo indicates electronic devices that conform with FCC provisions from the American authority, the FederalCommunications Commission. The symbol also guarantees compatibility with standards, suchas those set out by the International Organization for Standardization (abbreviated as ISO). Signal words Thefollowingsignalwordsareused intheseoperatinginstructions: WARNING! Thissignalwordindicatesahazard withamoderatedegreeofriskthat mayleadtodeathorsevereinjuryif it is notavoided. NOTICE! Thissignalwordwarnsagainst potential damage toproperty. Proper use The tracker is suitable for locating an item or living being. Only use the tracker as described intheseoperatinginstructions.Any otheruseisdeemedimproperand mayresultindamagetopropertyor even personal injury. The tracker is not a children‟stoy. The manufacturer and vendor do not accept any liability for damage caused by improper or incorrect use. Safety WARNING! Electric shock hazard! Incorrect electrical installation or usingamainsvoltagethatistoohigh canresultinanelectricshock. − Only connect the tracker and the charging cable if the mains voltage of the power socket matchesthatstatedonthelabel. − Only connect the mains adaptortoaneasilyaccessible power socket so that the charging cable can be quickly disconnected from the mains supply if itmalfunctions. − Donotusethetrackerifthere are visible signs of damage or if the charging cable is defective. − If the charging cable is damaged, it must be replaced by the manufacturer, the manufacturer‟s service department or a similarly qualified person in order to avoidrisk. − Only charge the batterywith the charging cablesupplied. − Donotopenthetrackercasing. Instead, ensure any repairs are carried out by specialists. Contact a specialistworkshop. Warrantyandguaranteeclaims cannotbemadeifrepairshave been carried out independently, or if the tracker has been incorrectly connected or operated. − Only parts that correspond with the original device‟sdata can be used in repairs. This tracker containselectronic and mechanical parts that are essent…

Text truncated - open the document above for the full version.

Trackimo INC. TCBJ FORM-4 Issued by: TCB Administrator Revision 6 12/06/10 2020.07.22 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, Trackimo INC. hereby authorize (Shenzhen STS Test Services Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Name: Shlomo Shur Signature:

Trackimo INC. TCBJ FORM-4 Issued by: TCB Administrator Revision 6 12/06/10 2020.07.22 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (GPS Tracker / TRKM110 /FCC ID: 2AAI6-RKM110) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the • Schematics • Block diagram • Operation description • Tune up Procedure • Part List These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. required to be submitted with this application be permanently withheld from public review. Please contact me if there is any information you may need. Sincerely, Name: Shlomo Shur Signature:

Page 1 of 4 Report No.: STS2005254 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Page 2 of 4 Report No.: STS2005254 Photo 3 Photo 4 Page 3 of 4 Report No.: STS2005254 Photo 5 Photo 6 Page 4 of 4 Report No.: STS2005254 Photo 7

FCC Label GPS Tracker Model name: TRKM110 FCC ID: 2AAI6-TRKM110 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Page 1 of 9 Report No.: STS2005254 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 GSM/WCDMA Antenna WIFI RX Antenna BT Antenna Page 2 of 9 Report No.: STS2005254 Photo 3 Photo 4 Page 3 of 9 Report No.: STS2005254 Photo 5 Photo 6 Page 4 of 9 Report No.: STS2005254 Photo 7 Photo 8 Page 5 of 9 Report No.: STS2005254 Photo 9 Photo 10 Page 6 of 9 Report No.: STS2005254 Photo 11 Photo 12 GPS Antenna Page 7 of 9 Report No.: STS2005254 Photo 13 Photo 14 Page 8 of 9 Report No.: STS2005254 Photo 15 Photo 16 Page 9 of 9 Report No.: STS2005254 Photo 17

TRKM110_SAR Setup photo Body Front side(separation distance is 5mm) Body Back side(separation distance is 5mm) Body left side(separation distance is 5mm) Body right side(separation distance is 5mm) Body top side(separation distance is 5mm) Body Bottom side(separation distance is 5mm)

Ref : ACR.350.2.19.SATU.A SHENZHEN STS TEST SERVICES CO., LTD. 1/F, BUILDING B, ZHUOKE SCIENCE PARK, No.190, CHONGQING ROAD, FUYONG STREET BAO’ AN DISTRICT, SHENZHEN, GUANGDONG, CHINA MVG COMOSAR DOSIMETRIC E-FIELD PROBE SERIAL NO.: SN 14/16 EP309 Calibrated at MVG US 2105 Barrett Park Dr. - Kennesaw, GA 30144 Calibration Date: 12/02/ 2019 Summary: This document presents the method and results from an accredited COMOSAR Dosimetric E-Field Probe calibration performed in MVG USA using the CALISAR / CALIBAIR test bench, for use with a COMOSAR system only. All calibration results are traceable to national metrology institutions. COMOSAR E-Field Probe Calibration Report COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.350.2. 19.SATU.A Page: 2/9 This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. Name Function Date Signature Prepared by : Jérôme LUC Product Manager 12/10/2019 Checked by : Jérôme LUC Product Manager 12/10/2019 Approved by : Kim RUTKOWSKI Quality Manager 12/10/2019 Customer Name Distribution : Shenzhen STS Test Services Co., Ltd. Issue Date Modifications A 12/18/2018 Initial release COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.350.2. 19.SATU.A Page: 3/9 This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. TABLE OF CONTENTS 1 Device Under Test ..................................................................................................... 4 2 Product Description ................................................................................................... 4 2.1 General Information _______________________________________________________ 4 3 Measurement Method ................................................................................................ 4 3.1 Linearity ________________________________________________________________ 4 3.2 Sensitivity _______________________________________________________________ 5 3.3 Lower Detection Limit _____________________________________________________ 5 3.4 Isotropy _________________________________________________________________ 5 3.5 Boundary Effect __________________________________________________________ 5 4 Measurement Uncertainty .......................................................................................... 5 5 Calibration Measurement Results .............................................................................. 6 5.1 Sensitivity in air __________________________________________________________ 6 5.2 Linearity ________________________________________________________________ 7 5.3 Sensitivity in liquid ________________________________________________________ 7 5.4 Isotropy _________________________________________________________________ 8 6 List of Equipment ...................................................................................................... 9 COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.350.2. 19.SATU.A Page: 4/9 This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. 1 DEVICE UNDER TEST Device Under Test Device Type COMOSAR DOSIMETRIC E FIELD PROBE Manufacturer MVG Model SSE5 Serial Number SN 14/16 EP309 Product Condition (new / used) New Frequency Range of Probe 0.4 GHz-3GHz Resistance of Three Dipoles at Connector Dipole 1: R1=0.183 M Dipole 2: R2=0.175 M Dipole 3: R3=0.174 M A yearly calibration interval is recommended. 2 PRODUCT DESCRIPTION 2.1 GENERAL INFORMATION MVG’s COMOSAR E field Probes are built in accordance to the IEEE 1528, OET 65 Bulletin C and CEI/IEC 62209 standards. Figure 1 – MVG COMOSAR Dosimetric E field Dipole Probe Length 330 mm Length of Individual Dipoles 4.5 mm Maximum external diameter 8 mm Probe Tip External Diameter 5 mm Distance between dipoles / probe extremity 2.7 mm 3 MEASUREMENT METHOD The IEEE 1528, OET 65 Bulletin C, CENELEC EN50361 and CEI/IEC 62209 standards provide recommended practices for the probe calibrations, including the performance characteristics of interest and methods by which to assess their affect. All calibrations / measurements performed meet the fore mentioned standards. 3.1 LINEARITY The evaluation of the linearity was done in free space using the waveguide, performing a power sweep to cover the SAR range 0.01W/kg to 100W/kg. COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.350.2. 19.SATU.A Page: 5/9 This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. 3.2 SENSITIVITY The sensitivity factors of the three dipoles were determined using a two step calibration method (air and tissue simulating liquid) using waveguides as outlined in the standards. 3.3 LOWER DETECTION LIMIT The lower detection limit was assessed using the same measurement set up as used for the linearity measurement. The required lower detection limit is 10 mW/kg. 3.4 ISOTROPY The axial isotropy was evaluated by exposing the probe to a reference wave from a standard dipole with the dipole mounted under the flat phantom in the test configuration suggested for system validations and checks. The probe was rotated along its main axis from 0 - 360 degrees in 15 degree steps. The hemispherical isotropy is determined by inserting the probe in a thin plastic box filled with tissue-equivalent liqu…

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may bereproduced without permission from STS,All Test Data Presented in this report isonly applicable to presentedTest sample. ShenZhen STS Test Services Co.,Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] FCC SAR TEST REPORT Report No.: STS2005254H01 Issued for Trackimo INC. 450 Seventh Avenue, Suite 1408, New York, United States Product Name: GPS Tracker Brand Name: trackimo Model Name: TRKM110 Series Model: N/A FCC ID: 2AAI6-TRKM110 Test Standard: ANSI/IEEE Std. C95.1 FCC 47 CFR Part 2 ( 2.1093) IEEE 1528: 2013 Max. Report SAR (1g): Body: 1.321W/kg S T L A B S Page 2 of 44 Report No.: STS2005254H01 Test Report Certification Applicant’s name ................. : Trackimo INC. Address ................................. : 450 Seventh Avenue, Suite 1408, New York, United States Manufacture's Name ............ : Trackimo INC. Address ................................. : 450 Seventh Avenue, Suite 1408, New York, United States Product description Product name ........................ : GPS Tracker Brand name ........................... : trackimo Model name ........................... : TRKM110 Series Model .......................... : N/A Standards ............................. : ANSI/IEEE Std. C95.1-1992 FCC 47 CFR Part 2 ( 2.1093) IEEE 1528: 2013 The device was tested by Shenzhen STS Test Services Co., Ltd. in accordance with themeasurement methodsand procedures specified in KDB 865664 The test results in this reportapply only to the tested sample of thestated device/equipment. Other similar device/equipmentwill not necessarily produce the same results due toproduction tolerance and measurementuncertainties. Date of Test ........................................... : Date (s) of performance of tests ............. : 01 June 2020~02 June 2020 Date of Issue .......................................... : 05 June 2020 Test Result .............................................. : Pass Testing Engineer : ( Aaron Bu) Technical Manager : (Jason Lu) Authorized Signatory : (Vita Li) Page 3 of 44 Report No.: STS2005254H01 Table of Contents 1.General Information 5 1.1 EUT Description 5 1.2 Test Environment 6 1.3 Test Factory 6 2. Test StandardsAnd Limits 7 3. SAR Measurement System 8 3.1 Definition Of Specific Absorption Rate (SAR) 8 3.2 SAR System 8 4. Tissue Simulating Liquids 11 4.1 Simulating Liquids Parameter Check 11 5. SAR System Validation 13 5.1 Validation System 13 5.2 Validation Result 13 6. SAR Evaluation Procedures 14 7. EUT Antenna Location Sketch 15 7.1 SAR test exclusion consider table 16 8. EUT Test Position 17 9.Uncertainty 18 9.1 Measurement Uncertainty 18 9.2 System validation Uncertainty 19 10. Conducted Power Measurement 20 10.1 Test Result 20 10.2 SAR Test Exclusions Applied 23 11. EUT And Test Setup Photo 24 11.1 EUT Photo 24 11.2 Setup Photo 27 12. SAR Result Summary 31 12.1 Body-worn SAR 31 12.2 repeated SAR measurement 32 13. Equipment List 35 Appendix A. System Validation Plots 36 Appendix B. SAR Test Plots 40 Appendix C. Probe Calibration And Dipole Calibration Report 44 Page 4 of 44 Report No.: STS2005254H01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 05 June 2020 STS2005254H01 ALL Initial Issue Note: Format versionof the report-V01 Page 5 of 44 Report No.: STS2005254H01 1. General Information Environmental evaluation measurements of specific absorption rate (SAR) distributions in emulated human head andbody tissues exposed to radio frequency (RF) radiation from wireless portable devices for compliance with the rules andregulations of the U.S. Federal Communications Commission (FCC). 1.1 EUT Description Product Name GPS Tracker Brand Name trackimo Model Name TRKM110 Series Model N/A Model Difference N/A Battery Rated Voltage: 3.6V Charge Limit: 4.2V Capacity: 10000mAh Device Category Portable Product stage Production unit RF Exposure Environment General Population / Uncontrolled Hardware Version G01_6276_2.0(05.14) Software Version V1.0 Frequency Range GSM 850:824.2~848.8MHz PCS1900:1850.2~1909.8MHz WCDMA Band II:1852.4~1907.6MHz WCDMA Band V:826.4~846.6MHz Bluetooth:2402~2480MHz Max. Reported SAR(1g): (Limit:1.6W/kg) Band Mode BodyWorn (W/kg) PCE GSM 850 1.321 PCE GSM 1900 1.080 PCE WCDMA Band II 1.221 PCE WCDMA Band V 0.596 DSS Bluetooth Note 0.014 1-g Sum SAR 1.335 FCCEquipment Class Licensed Portable Transmitter Held to Ear (PCE) Digital Transmission System (DTS) Operating Mode: GSM: GSM Voice; GPRS WCDMA:RMC,HSDPA,HSUPA Release 6 BLE Antenna Specification: GSM,WCDMA: PIFA Antenna BT: PIFA Antenna SIM Card Only single card Hotspot Mode: Not Support DTM Mode: Not Support Note: 1.Bluetooth SAR was estimated 2. The EUT battery must be fully charged and checked periodically during the test to ascertain uniformpower Page 6 of 44 Report No.: STS2005254H01 1.2 Test Environment Ambient conditions in the SAR laboratory: Items Required Temperature (°C) 18-25 Humidity (%RH) 30-70 1.3 Test Factory ShenZhen STS Test Services Co.,Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration No.: 625569 IC Registration No.: 12108A A2LA Certificate No.: 4338.01 Page 7 of 44 Report No.: STS2005254H01 2. Test Standardsand Limits No. Identity Document Title 1 47 CFR Part 2 Frequency Allocations and Radio Treaty Matters; General Rules and Regulations 2 ANSI/IEEE Std. C95.1-1992 IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz 3 IEEE Std. 1528-2013 Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques 4 FCC KDB 447498 D01v0…

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No.: STS2005254W05 Issued for Trackimo INC. 450 Seventh Avenue, Suite 1408, New York, United States Product Name: GPS Tracker Brand Name: trackimo Model Name: TRKM110 Series Model: N/A FCC ID: 2AAI6-TRKM110 Test Standard: FCC Part 22H and 24E S T L A B S Page 2 of 63 Report No.: STS2005254W05 TEST RESULT CERTIFICATION Applicant’s Name ................... : Trackimo INC. Address .................................. : 450 Seventh Avenue, Suite 1408, New York, United States Manufacture's Name .............. : Trackimo INC. Address .................................. : 450 Seventh Avenue, Suite 1408, New York, United States Product Description Product Name ........................ : GPS Tracker Brand Name ........................... : trackimo Model Name ........................... : TRKM110 Series Model .......................... : N/A Test Standards ....................... : FCC Part 22H and 24E Test Procedure ....................... : KDB 971168 D01 v03r01,ANSI C63.26( 2015) This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document may be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ................................ : Date of receipt of test item .......... : 26 May 2020 Date (s) of performance of tests . : 26 May 2020 ~ 08 June 2020 Date of Issue .............................. : 10 June 2020 Test Result .................................. : Pass Testing Engineer : (ChrisChen) Technical Manager : (Sean she) Authorized Signatory : (Vita Li) Page 3 of 63 Report No.: STS2005254W05 Table of Contents Page 1 INTRODUCTION 6 1.1 TEST FACTORY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 PRODUCT INFORMATION 7 3 TEST CONFIGURATION OF EQUIPMENT UNDER TEST 8 4 MEASUREMENT INSTRUMENTS 9 5 TEST ITEMS 10 5.1 CONDUCTED OUTPUT POWER 10 5.2 PEAK TO AVERAGE RATIO 11 5.3 TRANSMITTER RADIATED POWER (EIRP/ERP) 12 5.4 OCCUPIED BANDWIDTH 13 5.5 FREQUENCY STABILITY 14 5.6 SPURIOUS EMISSIONS AT ANTENNA TERMINALS 15 5.7 BAND EDGE 16 5.8 FIELD STRENGTH OF SPURIOUS RADIATION MEASUREMENT 17 APPENDIX A.TESTRESULT 19 A1.CONDUCTED OUTPUT POWER 19 A2. PEAK-TO-AVERAGE RADIO 22 A3. TRANSMITTER RADIATED POWER (EIRP/ERP) 29 A4. OCCUPIED BANDWIDTH(99% OCCUPIED BANDWIDTH/26DB BANDWIDTH) 31 A5.FREQUENCY STABILITY 38 A6. SPURIOUS EMISSIONS AT ANTENNA TERMINALS 42 A7. BAND EDGE 48 A8. FIELD STRENGTH OF SPURIOUS RADIATION MEASUREMENT 53 APPENDIX-PHOTOS OF TEST SETUP 63 Page 4 of 63 Report No.: STS2005254W05 Revision History Rev. Issue Date Report NO. Effect Page Contents 00 10 June 2020 STS2005254W05 ALL Initial Issue Page 5 of 63 Report No.: STS2005254W05 SUMMARY OF TEST RESULTS Test procedures according to the technical standards: The radiated emission testing was performed according to the procedures of KDB 971168 D01 v03r01 and ANSI C63.26( 2015) FCC Rules Test Description Test Limit Test Result Reference 2.1046 Conducted OutputPower Reporting Only PASS 22.913d 24.232d Peak-to-AverageRatio < 13 dB PASS 2.1046 22.913 24.232 Effective Radiated Power/Equivalent Isotropic Radiated Power < 7 Watts max. ERP(Part 22) < 2 Watts max. EIRP(Part 24) PASS 2.1049 22.917 24.238 Occupied Bandwidth Reporting Only PASS 2.1055 22.355 24.235 Frequency Stability < 2.5 ppm (Part 22) Emission must remain in band (Part 24) PASS 2.1051 22.917 24.238 Spurious Emission at Antenna Terminals < 43+10log10(P[Watts]) PASS 2.1053 22.917 24.238 Field Strength of Spurious Radiation < 43+10log10(P[Watts]) PASS 2.1051 22.917 24.238 Band Edge < 43+10log10(P[Watts]) PASS Page 6 of 63 Report No.: STS2005254W05 1 INTRODUCTION 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District,Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The measurement uncertainties shown below were calculated in accordance with the requirements ofANSI C63.4-2014. All measurement uncertainty values are shown with a coverage factor of k = 2 toindicate a 95% level of confidence. The measurement data shown herein meets or exceeds the UCISPRmeasurement uncertainty values specified in CISPR 16-4-2 and, thus, can be compared directly tospecified limits to determine compliance. No. Item Uncertainty 1 RF output power, conducted ±0.68dB 2 Unwanted Emissions, conducted ±2.988dB 3 All emissions, radiated 30-1GHz ±6.7dB 4 All emissions, radiated1G-6GHz ±5.5dB 5 All emissions, radiated>6G ±5.8dB 6 Conducted Emission (9KHz-150KHz) ±4.43dB 7 Conducted Emission (150KHz-30MHz) ±5dB Page 7 of 63 Report No.: STS2005254W05 2PRODUCT INFORMATION ProductName GPS Tracker Trade Name trackimo Model Name TRKM110 Series Model N/A Model Difference N/A Tx Frequency: GSM/GPRS: 850: 824 MHz ~ 849MHz 1900: 1850 MHz ~ 1910MHz WCDMA: Band V: 824 MHz ~ 849 MHz Band II: 1850 MHz ~ 1910 MHz Rx Frequency: GSM/GPRS: 850: 869 MHz ~ 894 MHz 1900: 1930 MHz ~ 1990MHz WCDMA: Band V: 869 MHz ~ 894 MHz Band II: 1930 MHz ~ 1990 MHz Max RF Output Power: GSM850:31.46dBm,GSM1900:27.85dBm GPRS850(1-Slot):31.27dBm, GPRS1900(1-Slot):27.82dBm GPRS850(2-Slot):30.82dBm, GPRS1900(2-Slot):27.41dBm GPRS850(3-Slot):30.34dBm, G…

Text truncated - open the document above for the full version.

Page 1 of 1 FCC ID: 2AAI6-TRKM110 CC ID:2AAI6-TRACKIPRO3G PCB Setup photo Model name:TRKM110 PCBradiation L PCBradiation H
