ver.2J25 / NC70-0138A Quick Guide Neo smartpen A1 ● 본 제품은 필기 인식 센서가 내장된 제품으로 야외의 강한 직사광선이나 적외선 램프 아래에서 사용 시 필기 인식이 잘 되지 않을 수 있습니다. ● 필기 인식 센서를 가리지 않도록 주의해 주세요. ● 볼펜심에 강한 충격이 가해질 경우 압력 센서가 손상될 수 있습니다. ● 자기장이 심한 곳, 강한 직사광선 아래 또는 고온 근처에 장시간 제품을 둘 시 심각한 손상이 갈 수 있습니다. ● 사용하지 않을 시에는 펜캡을 닫고, 먼지나 이물질이 입력센서에 묻었을 경우 면봉 등으로 가볍게 제거해주세요. LED 표시 안내 주의사항 상태 LED 컬러 전원 on 전원 off 충전중 충전완료 배터리 부족 앱과 연결 시 저장공간 부족 펌웨어 업데이트 중 펌웨어 업데이트 실패 광학센서 또는 사용환경 점검 필요 점등 후 소등 점멸 점등 유지 후 꺼짐 점멸 점멸 점멸 점멸 점멸 점등 네오랩컨버전스는 하드웨어 제품 및 액세서리의 재료 또는 제작 과정 에서의 결함에 대하여 최초 구입일로부터 1년 동안 보증 서비스를 제공 합니다. 정상적인 마모 및 흠집, 사고 또는 남용으로 인한 파손은 보증 받을 수 없습니다. 준비하기 1) 앱 다운로드 네오스튜디오는 구글 플레이와 앱 스토어에서 다운로드 받을 수 있습니다. ‘네오스튜디오’, ‘NEO STUDIO’로 검색해 주세요. 2) 앱 환경 설정 디바이스의 ‘블루투스’와 ‘GPS(위치)’를 활성화해 주세요. 3) 앱과 펜 연결 ① 앱 실행 후 필요 권한을 허용해 주세요. *권한 허용은 앱을 원활히 사용하기 위한 필수 사항입니다. ② 화면 안내에 따라 앱과 펜을 연결하세요. (앱과 펜이 연결되면 펜 LED가 녹색으로 천천히 깜박입니다.) 전원 켜기 / 끄기 ● 완충된 상태에서 전원 버튼을 짧게 누르면 LED가 켜지며 전원이 켜집니다. ● 전원이 켜진 상태에서 전원 버튼을 2초 이상 길게 누르면 LED가 여러 색깔로 변경되며 전원이 꺼집니다. 또는 5분 이상 아무런 입력이 없으면 자동으로 전원이 꺼집니다. ● 펜을 쥐면 자동으로 전원이 켜집니다. ● 전원이 켜지지 않거나, 충전 또는 동작이 멈추었을 경우에는 전원 버튼을 10초 이상 눌러 리셋해 주세요. 앱 다운로드 & 펜 연결하기 ● 임의로 제품을 해체하고 재조립을 하는 행위는 고장으로 이어집니다. 이경우 품질 보증기간은 적용되지 않습니다. ● 반드시 해당 제품과 호환되는 권장 펜심을 사용해야 하며, 이를 지키지 않아 발생하는 고장은 당사에서 책임지지 않습니다. ● 미성년 아동이 사용할 경우 각별한 주의가 필요합니다. 상세한 고객지원 안내는 홈페이지를 참고해 주시길 바랍니다. www.neolab.kr/customer/ 제품 상담 및 A/S문의 네오랩컨버전스 고객지원실 1588-6239 평일 오전 10시~오후 6시 (점심시간 오후 12시~오후 1시) 토요일, 공휴일 제외 제품 보증 고객지원 펜충전케이블리필심(3ea)유저 가이드 기본구성품 각 부분의 이름 필기 인식 센서펜 캡 LED(상태 표시등) C-타입 충전 전원 버튼 펜 그립스토퍼펜 촉 올바른 파지 방법 볼펜심이 위를 향하도록 펜을 잡아주세요. 인식 허용 각도 90 O 수직 기준으로 -20 ~ +40에서 인식이 가능합니다. 사용하기 제품스팩 ● 필기 인식 센서의 위치는 필기 인식률에 큰 영향을 미칩니다. 필기 허용 각도를 벗어나 거나 잘못된 방향으로 펜을 쥐고 사용할 경우 인식이 되지 않을 수 있으니 주의하세요. ● 앱에 연결하지 않고 펜만으로도 자유롭게 필기가 가능합니다. 이후 앱에 연결하면 자동으로 데이터를 전송할 수 있습니다. 모델명 NWP-F151 무선 연결 Bluetooth 5.0 (LE) 배터리 충전식 Li-polymer 3.7V 130mAh 저장매체 16MB memory 정격 입력 DC 5V / 130mA 사용 시간 연속 사용 시간 9시간 크기 및 무게 길이: 139mm(펜캡 제외)/두께: 11.3~13.9mm/18.2g(펜캡 제외) 사용 환경 보관가능온도(비동작): -10도~50도 / 상대습도: ~90% 동작온도: -10~50도 사용 볼펜심 C1 Gel 0.5mm Product Name Product No. (Serial No.) Purchase Date Seller Purchase Price · Keep the product no. (serial no.) in a safe place as it is required for checking the product warranty period when requesting customer service / support. · The product no. is attached on the surface of the product package. Neo smartpen A1 Neo smartpen A1 Please contact the store where you purchased the product or NeoLAB Convergence for customer service/support. PRODUCT WARRANTY 제품명 제품번호 (Serial No.) 구입일자 구입처 구입가격 ·품목별 소비자 피해 보상규정에 따라 아래와 같이 제품에 대한 보증을 시행합니다. ·보상 여부 및 내용 통보는 요구일로부터 7일 이내, 피해 보상은 통보일로부터 14일 이내에 해결해 드립니다. ·제품 번호(Serial No.)는 A/S 신청 시 제품 보증기간을 확인하기 위해 꼭 필요한 항목이니 분실되지 않도록 주의해 주세요. ·제품 번호(Serial No.)는 제품의 제품 포장물 겉면에 부착되어 있습니다. Neo smartpen A1의 품질 보증 기간은 1년이며, 부품 보유 기간은 2년 입니다. 제품 보증서 LED indicator information /Get started / Download the App & Pen connection 1) Download the app You can download NEO STUDIO from Google Play Store and App Store. Search "NEO STUDIO." 2) App settings Enable the device's "Bluetooth" and "GPS (location)." 3) Connect the app and the pen ① Open the app, and give required permissions. *The permission allowance is required to use the app without problems. ② Follow the instructions on screen to connect the app & the pen. (Once the connection between the app and the pen has been established, the pen's LED will slowly blink in Green.) What's in the box / Part name / Optical SensorPen cap LED(status indicator) C-type charging port Power button Pen gripStopperPen point PenCharging cablePen Refills(3EA)User Guide ペン充電ケーブル 替え芯（3本）クイックガイド 製品構成ご使用の前に NEO STUDIOアプリダウンロード＆ペンの接続 各部の名称 筆記認識センサー ペンキャップ LED（ペンの状態を表示） Type-C 充電口 電源ボタン グリップストッパーペン先 1) アプリのダウンロード NEO STUDIOはGoogle PlayまたはApp Storeからダウンロードできます。 「NEO STUDIO」「ネオスタジオ」で検索してください。 2) デバイスの環境設定 デバイスのBluetoothと「GPS(位置情報)」をオンにしてください。 3) アプリとペンを接続する ① アプリを実行し、必要な権限を許可してください。 *権限を許可することでNEO STUDIOをご利用いただけます。 ② 画面の案内に従ってアプリとペンを接続してください。 (アプリとペンが接続されると、ペンLEDが緑色でゆっくり点滅します) How to use / ● The location of the optical sensor greatly affects the handwriting recognition accuracy. Please note that your handwriting may not be recognized if you hold or use the pen at an incorrect angle or in the wrong direction. ● You can use the pen without connecting it to the app. You can connect it to the app afterward to automatically transfer the data. How to hold the pen correctly Make sure the pen point is up when you hold the pen. Allowable Recognition Angle Product's acceptable recognitionangle is -20° ~ +40°. (90° verticalstandard) 正しい握り方 ペンの芯が上に来るように 握ってください。 認識可能な角度 90°垂直を基準に、-20°～+40°の範囲で 認識できます。 ● 光学センサーの位置は、手書き認識のクオリティーに大きく影響を与えます。 筆記時の適切な角度を外れたり、光学センサーの向きが紙面に向いていない場合は、 筆記した内容が認識されない場合があるのでご注意ください。 ● ペンとアプリが接続された状態でNノートに筆記してみましょう。 ● アプリが起動していない時に筆記した内容はペンに一時保存され、 後から同期させることが可能です（ペンの電源はオンにしてご利用ください） 正しいペンの握り方 & ペンで筆記 Precautions / Model name 型番 NWP-F151 Connectivity 通信方式 Bluetooth 5.0 (LE) Battery バッテリー Rechargeable Li-polymer 3.7V 130mAh 充電式 Li-polymer 3.7V 130mAh Storage メモリ 16MB memory / 16MB 内蔵メモリ Rated input 定格入力 DC 5V / 130mA Usage time 使用時間 9 hours of continuous use / 連続使用時間9時間 Size&Weight 寸法 Length : 139mm (without the pen cap) Diameter: 11.3 ~13.9mm / 18.2g (without the pen cap) 長さ：139mm(キャップを除く) 厚さ：11.3~13.9mm / 18.2g(キャップを除く) Environment 使用環境 Storage temperature : -10~50°C / Relative humidity: ~90% Operating temperature : -10~50°C 保管温度（非作動時）：-10~50°C / 相対湿度：~90％ 動作温度：-10~50°C Ink refills ボールペン芯 C1 Gel 0.5mm(Only for Neo Smartpen) C1 ゲルインキ 0.5mm （専用ペン芯はNeo smartpen公式ストアにてお求めください） Product specifications / 製品仕様 Status / ペンの状態 LED color / LEDの状態 LEDカラーのステータス Power on Power off Charging Fully charged Low battery Connecting to the app Low storage Updating firmware Firmware update failed Optical sensor or usage environment check Flashing Flashing Flashing Flashing Flashing Illuminating 色が変化した後、消灯 Illuminating Flashing then light off Illuminating and then turned off 暫く点灯後、オフ 点滅 点滅 点滅 点滅 点滅 点灯 点滅 点灯 注意事項 ● 本製品は筆記認識センサー（光学センサー）が内蔵されており、 赤外線を認識しているため直射日光や赤外線を多く発する…

Text truncated - open the document above for the full version.

#1501, Mario Tower, 28, Digital-ro 30-gil, Guro-gu, Seoul, Korea 08389 Tel No : +82-2-2284-9241 Fax No : +82-2-3462-2983 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID : 2AALG-NWP-F151 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block diagram Schematics Schematics_PCB Layout Parts list Operational description Block Diagram_NWP-F151.pdf Schematics_NWP-F151.pdf Schematics_PCB Layout_NWP-F151.pdf Part List_NWP-F151.pdf Operational Description_NWP-F151.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Cho Min-Gu / Senior Research Engineer NEOLAB CONVERGENCE

#1501, Mario Tower, 28, Digital-ro 30-gil, Guro-gu, Seoul, Korea 08389 Tel No : +82-2-2284-9241 Fax No : +82-2-3462-2983 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: November 16, 2022 SUBJECT: FCC Application for (FCC ID : 2AALG-NWP-F151) To Whom It May Concern: We, the undersigned, hereby authorize Kim Gwan-Yong at CTK on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by CTK on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, Cho Min-Gu / Senior Research Engineer NEOLAB CONVERGENCE

CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com 1 / 3 EUT External Photographs CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com 2 / 3 CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com 3 / 3

CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com EUT Internal Photographs CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com Battery Antenna

CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com Page 1 of 3 RF EXPOSURE EVALUATION Applicant NEOLAB CONVERGENCE Applicant Address #1501, Mario Tower, 28, Digital-ro 30-gil, Guro-gu, Seoul, Korea 08389 FCC ID 2AALG-NWP-F151 Product Description NWP-F151 Basic model NWP-F151 Variant Model name - Operating Frequency 2 402 MHz - 2 480 MHz Antenna type Chip Antenna Antenna gain 2.9 dBi Power Source DC 3.7 V (Battery) Number of channels 40 CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com Page 2 of 3 ** RF Exposure Evaluation** Exemption Limits for Routine Evaluation SAR Test Exclusion Thresholds for 100 MHz - 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table, The equation and threshold in Note 1 must be applied to determine SAR test exclusion. Note 1 : The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by : CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com Page 3 of 3 [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]* [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where - f(GHz) is the RF channel transmit frequency in GHz - Power and distance are rounded to the nearest mW and mm before calculation - The result is rounded to one decimal place for comparison - 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 4.1f) is applied to determine SAR test exclusion. Output Power : Mode Frequency (MHz) Measured conducted power (dBm) Power tolerance [dB] Maximum conducted power (dBm) Maximum conducted power (mW) SAR Test Exclusion Threshold (mW) Bluetooth LE 1 Mbps 2 480 7.78 + 1.5 9.28 8.472 10 Per FCC KDB 447498 D01v06, the SAR exclusion threshold for distances ≤50mm is defined by the following equation : [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]* [√f(GHz)] ≤ 3.0 Base on the maximum conducted power of the antenna to use separation distance, SAR was not required; Bluetooth LE 1 Mbps : [(8.472 / 5) * √2.480] = 2.668 (≤ 3.0) Result : As a result of the calculation above, the SAR test is exempt

TEST REPORT CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 Report No.: CTK-2022-02888 Page (1) / (33) Pages [QF-QP15-07] Ver.01 R101 1. Applicant ◦ Name : NEOLAB CONVERGENCE ◦ Address : #1501, Mario Tower, 28, Digital-ro 30-gil, Guro-gu, Seoul, Korea 08389 ◦ Date of Receipt : 2022-09-30 2. Manufacturer ◦ Name : NEOLAB CONVERGENCE ◦ Address : #1501, Mario Tower, 28, Digital-ro 30-gil, Guro-gu, Seoul, Korea 08389 3. Use of Report : For FCC Certification 4. Test Sample / Model: NWP-F151 / NWP-F151 5. Date of Test : 2022-10-31 to 2022-11-07 6. Test Standard(method) used : FCC 47 CFR part 15 subpart C 15.247 ANSI C63.10-2013 7. Testing Environment: refer to 6 page 8. Test Results : Compliance 9. Location of Test : Permanent Testing Lab On Site Testing (Address : 5, Dongbu-ro 221beon-gil, Cheoin-gu, Yongin-si, Gyeonggi-do, 17142 Korea) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This report cannot be reproduced or copied without the written consent of CTK Approval Tested by Gwanyong Kim: (Signature) Technical Manager Young-taek Lee: (Signature) Remark. This report is not related to KOLAS accreditation and relevant regulation 2022-11-14 CTK Co., Ltd. CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 Report No.: CTK-2022-02888 Page (2) / (33) Pages [QF-QP15-07] Ver.01 R101 REPORT REVISION HISTORY Date Revision Page No 2022-11-14 Issued (CTK-2022-02888) all This report shall not be reproduced except in full, without the written approval of CTK Co., Ltd. This document may be altered or revised by CTK Co., Ltd. personnel only, and shall be noted in the revision section of the document. Any alteration of this document not carried out by CTK Co., Ltd. will constitute fraud and shall nullify the document. CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 Report No.: CTK-2022-02888 Page (3) / (33) Pages [QF-QP15-07] Ver.01 R101 CONTENTS 1. General Product Description ....................................................................................... 4 1.1 Client Information ............................................................................................. 4 1.2 Product Information ........................................................................................... 4 1.3 Peripheral Devices ............................................................................................. 4 2. Accreditations .......................................................................................................... 5 2.1 Laboratory Accreditations and Listings .................................................................. 5 2.2 Calibration Details of Equipment Used for Measurement .......................................... 5 3. Test Specifications .................................................................................................... 6 3.1 Standards ........................................................................................................ 6 3.3 Mode of operation during the test ........................................................................ 7 3.4 Maximum Measurement Uncertainty .................................................................... 7 4. Technical Characteristic Test ....................................................................................... 8 4.1 6 dB Bandwidth and 99 % Bandwidth ................................................................... 8 4.2 Maximum peak Conducted Output Power ............................................................ 11 4.3 Power Spectral Density .................................................................................... 13 4.4 Band Edge & Conducted Spurious emission ......................................................... 15 4.5 Radiated Emission ........................................................................................... 19 4.6 AC Power Line Conducted Emissions................................................................... 30 5. APPENDIX A – Test Equipment Used For Tests ............................................................. 33 CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 Report No.: CTK-2022-02888 Page (4) / (33) Pages [QF-QP15-07] Ver.01 R101 1. General Product Description 1.1 Client Information Company NEOLAB CONVERGENCE Contact Point #1501, Mario Tower, 28, Digital-ro 30-gil, Guro-gu, Seoul, Korea 08389 Contact Person Name : Cho Min-Gu E-mail : [email protected] Tel : +82–70-4377-0741 Fax : +82-2-3462-2983 1.2 Product Information FCC ID 2AALG-NWP-F151 Product Description NWP-F151 Basic model NWP-F151 Variant Model name - Operating Frequency 2 402 MHz - 2 480 MHz RF Output Power 7.78 dBm (5.998 mW) Antenna type Chip Antenna Antenna gain 2.9 dBi Number of channels 40 Channel Spacing 2 MHz Type of Modulation GFSK (Bluetooth LE 1 Mbps) Power Source DC 3.7 V (Battery) Test Software Airoha Tool Kit – V2.5.4 RF Power setting in Test SW Power setting input “GC 55” 1.3 Peripheral Devices Device Manufacturer Model No. Serial No. Note Computer HP 15-bs563TU CND7253R6P AC/DC Adapter HP HSTNN-LA40 7628011101 CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 Report No.: CTK-2022-02888 Page (5) / (33) Pages [QF-QP15-07] Ver.01 R101 2. Accreditations 2.1 Laboratory Accreditations and Listings Country Agency Registration Number USA FCC 805871 CANADA ISED 8737A KOREA NRRA KR0025 2.2 Calibration Details of Equipment Used for Measurement Test equipment and test accessories are calibrated on regular basis. The maximum time between calibrations is one year or what is recommended by the manufacturer, whichever is less. All test equipment calibrations are trace…

Text truncated - open the document above for the full version.

2 Measurement Equipment NoEquipmentMakerMODEL 1Anechoic Chamber한국차폐시스템8*4*4 2Network AnalyzerAgilent8753ES -S-parameter Measurement -Antenna Gain Measurement 8753ES 2M 3 Passive Test -제조사= Airlink(한국차폐시스템) -Network Analyzer =8753ES (HP) 2M 1-1. Antenna matching value 1-2. Measured S-parameter Set condition Return Loss & VSWR Antenna matching circuit SHDA2112442A Default Default Input Default Frequency [MHz]Efficiency [%]Average gain[dBi]Peak gain [dBi] 2400 39.82-4.001.58 2442 50.21-2.992.70 2485 35.92-4.451.21 1-3. Antenna gain Antenna 1-4. Radiation pattern 2D / 3D radiation pattern @2442MHz x y z θ φ XY plane ZX plane YZ plane 2-1. Antenna matching value 2-2. Measured S-parameter Set condition Return Loss & VSWR Antenna matching circuit SHDA2112442A Default Default Input Default Frequency [MHz]Efficiency [%]Average gain[dBi]Peak gain [dBi] 2400 23.23-6.31-1.01 2442 28.89-5.390.30 2485 22.08-6.56-0.73 2-3. Antenna gain Antenna 2-4. Radiation pattern 2D / 3D radiation pattern @2442MHz x y z θ XY plane ZX plane YZ plane RevNoDateTitleContentsPage Rev. NoDateTitleContentsPage 0’09.08.27New Published 1. Specifications 1.1 Electrical Specifications 1.2 Mechanical Specifications 1.3 Appearance and Material 2. PCB Design for Test 2.1 Evaluation Board Dimension 2.2 PCB Design Guide 3. Measurement Result 3.1 Typical Measurement Result (VSWR/RL, Smithchart) 3.2 Typical Measurement Result (Gain, Radiation Pattern) 4. Reliability 4. Reliability 5. Soldering Reflow Profile 6. Packaging 6.1 Carrier Tape Dimension 6.2 Packaging Label NoItemSpec. 1Frequency Range [GHz]2.4 ~2.485 2VSWRMax 3.0:1 3Gain [dBi]typ. 2.9 [dBi]typ. -0.9 []yp typ. 82 PolarizationLinear Impedance [Ω]Nominal 50 9 9 NoSpec.Remark 1Dimensions (LxWxH)2.0x1.5x1.0 mm 3 2Unit Weighttyp. 11mg 3Operating Temperature-35 ~ +85 NoItemFunctionMaterial Marking Feeding Index Ceramic Body Ceramic 9 9 9 No Feeding GND GND No 9 Peak Gain (dBi) Avg. Gain (dBi) Efficiency (%) Azimuth -1.23 Elevation 1 -1.58 Elevation 2 -2.75 NoItemTest ConditionTest Requirements 1 Adhesive Strength of Termination 1. Applied force on SMT chip till detached point from PCB. 1. No mechanical damage by applied force 2. Strength (F) > 1 kgf 2 Thermal Shock (Cycle) 1. Step 1 : -40 ± 3, 30 min Step 2 : +125 ± 3, 30 min 2. Number of cycle : 30 1. No visual damage 2. Within electric spec (VSWR) 3 High Temperature Resistance 1. Temperature : +125 ± 5 2. Time : 1000 ± 24 hrs 1. No visual damage 2. Within electric spec (VSWR) 4 Low Temperature Resistance 1. Temperature : -40 ± 5 2. Time : 1000 ± 24 hrs 1. No visual damage 2. Within electric spec (VSWR) 5Humidity 1. Humidity : 85 % RH Temperature : +85 ± 3 2. Time : 1000 ± 24 hrs 1. No visual damage 2. Within electric spec (VSWR)
