Product Manual IBRIDGE- 4 Port Contact Closure Toggle Switch Users Manual –IBRIDGE 4Port Contact Closure Toggle Switch Page 1 www.idealindustries.com PRODUCT DESCRIPTION The Audacy IBRIDGE toggle switch is a DC powered device specially designed to allow a building occupant to turn on or off lights from an external device’s contact closure. The Toggle Switch wirelessly communicates with the light fixtures via the Audacy Smart Connector which resides at the fixture and also physically performs the corresponding control of the fixture(s). KEY FEATURES FCC and IC approved Flexible wall mounting options Small form factor with internal antenna RoHS compliant Factory configurable for custom applications PRODUCT CONTENTS The following items are included inside the package: Qty Description 1 IBRIDGE Toggle Switch 1 Instruction card Audacy®, Smart Connector® are registered trademarks of IDEAL INDUSTRIES. All other trademarks are the property of their respective owners. Product Manual IBRIDGE- 4 Port Contact Closure Toggle Switch Users Manual –IBRIDGE 4Port Contact Closure Toggle Switch Page 2 www.idealindustries.com SET-UP AND OPERATION 1. Connect DC power to the +/- input of the IBRIDGE toggle switch to activate device. 2. Mount device where desired. Avoid placing radio device near metal objects if at all possible. 3. Connect necessary contact closure inputs to an I/O input. 4. When the green LED illuminates during switch actions, the is active and transmitting radio frequency (RF) energy. Data is automatically included in the transmission and can be received by one of the Audacy line smart connectors and/or Gateway. SPECIFICATIONS Item Description Radio 915 MHz Internal Antenna Regulatory Approvals FCC Part 15 and Industry Canada Contains FCC ID: 2AAMXIBRIDGE Contains IC: 11250A-IBRIDGE Transmit Range 100 ft. indoors to an Audacy Gateway or Smart Connector in a typical commercial office building Power 9-24V DC Operating Temperature 10°C to 32°C Storage Temperature -20°C to 50°C Installation Environment Indoor use only Color White Dimensions 4.7” x 2.4” x 1.1” Weight 5 oz Warranty 1 year Product Manual IBRIDGE- 4 Port Contact Closure Toggle Switch Users Manual –IBRIDGE 4Port Contact Closure Toggle Switch Page 3 www.idealindustries.com MECHANICAL (SIDE VIEW) *Dimensions in inches MECHANICAL (TOP VIEW) *Dimensions in inches Product Manual IBRIDGE- 4 Port Contact Closure Toggle Switch Users Manual –IBRIDGE 4Port Contact Closure Toggle Switch Page 4 www.idealindustries.com SUPPORT Technical support for IDEAL INDUSTRIES products can be initiated through the following methods: Website: http://www.idealindustries.com/support/ Telephone: +1 800-435-0705 Email: [email protected] Product Manual IBRIDGE- 4 Port Contact Closure Toggle Switch Users Manual –IBRIDGE 4Port Contact Closure Toggle Switch Page 5 www.idealindustries.com COMPLIANCE STATEMENTS This device is intended for commercial and industrial applications. Changes or modifications not expressly approved by IDEAL could void the user’s authority to operate the equipment. Use and maintain device only as specified in this manual. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. WARNING! FCC and IC Radiation Exposure Statement: This equipment complies with FCC’s and IC’s RF radiation exposure limits set forth for an uncontrolled environment under the following conditions: 1. This equipment should be installed and operated such that a minimum separation distance of 20cm is maintained between the radiator (antenna) & user’s/nearby person’s body at all times. 2. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This device complied with Industry Canada licence-exempt RSS standard(s) and part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Ce dispositif conformé à Industrie Canada exempts de licence standard RSS (s) et la partie 15 des règles de la FCC. Son fonctionnement est soumis aux deux conditions suivantes: (1) cet appareil ne peut pas provoquer d'interférences, et (2) ce dispositif doit accepter toute interférence, y compris les interférences qui peuvent entraîner un mauvais fonctionnement de l'appareil. Product Manual IBRIDGE- 4 Port Contact Closure Toggle Switch Users Manual –IBRIDGE 4Port Contact Closure Toggle Switch Page 6 www.idealindustries.com IMPORTANT NOTICE Information furnished by IDEAL INDUSTRIES, INC. is believed to be accurate and reliable. No license, express or implied, to any intellectual property rights is granted by this document. No responsibility is assumed by IDEAL INDUSTRIES, INC. for its use, nor for any infringements of patents or other rights of third parties that may result from its use. IDEAL INDUSTRIES, INC. assumes no liability for misuse of this product. Speci…
