Page 1 of 2 Incipio, LLC 3347 Michelson Drive, Suite 100, Irvine CA 92612 USER’ S MANUAL Models: GP-109-BLK FCC ID: 2AAWX-GP109B Input：5V2A DC Output：5W 1. Please read the below information carefully. 2. Please do not expose to moisture. 3. The Switching mode power supply shall be installed according to specification. 4. The max ambient temperature should not exceed 25°C. 5. The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquid shall be placed on the apparatus. 6. For indoor use only. 7. This device is not intended to be repaired by service personal in case of failure or component defect. 8. This product must not be disposed together with the domestic waste. This product has to be disposed at an authorized place for recycling of electrical and electronic appliances. By collecting and recycling waste, you help save natural resources, and make sure the product is disposed in an environmental friendly and healthy way. 9. The output power source is PS2, the relevant safeguard shall be provided with end products used together. 10. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, Page 2 of 2 which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R21062212-1E01 Page 26 of 30 9 Photos of the EUT Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R21062212-1E01 Page 27 of 30 Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R21062212-1E01 Page 28 of 30 Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R21062212-1E01 Page 29 of 30

TOWC001002A0102 背面镭雕 Type C 接口方向 无线充成品外壳尺寸 96.66 mm 硅 胶 垫 尺 寸 直 径 7 7 . 0 0 m m 无线充成品外壳尺寸96.66 mm 中心线(垂直居中) 中心线（左右居中） 2 7 . 2 m m 2 7 . 2 m m 23.5mm23.5mm 3：1 备注： 1.镭雕颜色为灰色。 2.按图纸内容镭雕。 3.镭雕内容匀称清晰，不可歪斜。 4.镭雕效果参考客户回签样品。 5.用纯棉布灌满95%纯度医用酒精，包在500g专用法码上， 以40-60次/分钟的速度，20mm左右的行程，在被测物表面 来回擦试200个循环。 6.以镭雕图形不掉色为合格。 20 31 具体年份周期以实际生产日期为准，镭雕前与生产主管确认 29.8mm 2 2 . 3 5 m m 具体年份周期以实际生产日期为准， 镭雕前与生产主管确认 硅胶垫镭雕 Wireless Charging Pad Model: GP-109-BLK Input: 5.0V 2.0A Output: 5W FCC ID: 2AAWX-GP109 Made in China 2122 Wireless Charging Pad Model: GP-109-BLK Input: 5.0V 2.0A Output: 5W FCC ID: 2AAWX-GP109 Made in China 2122 Wireless Charging Pad Model: GP-109-BLK Input: 5.0V 2.0A Output: 5W FCC ID: 2AAWX-GP109 Made in China 2122 B B B

Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R21062212-1E01 Page 29 of 30 Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R21062212-1E01 Page 30 of 30 END OF REPORT

Dongguan Dongdian Testing Service Co., Ltd Report No.:DDT-R21062212-1E02 Page 1 of 11 RF EXPOSURE REPORT FOR Issued By: Dongguan Dongdian Testing Service Co., Ltd. Add.: No. 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808 Tel.: +86-0769-38826678, E-mail: [email protected], http://www.dgddt.com Applicant : Incipio, LLC Address : 3347 Michelson Drive, Suite 100, Irvine CA 92612 Equipment under Test : Wireless Charging Pad Model No. : GP-109-BLK Trade Mark : FCC ID : 2AAWX-GP109B Manufacturer : Tomax Technology (Dongguan) Co., Ltd Address : 4 th floor of Deyuxin Technology Park, No.13 of Jintang Road, Jinmei Village, Changping Town, Dongguan ■Report No.: DDT-R21062212-1E02 ■Issued Date: Aug. 09, 2021 Dongguan Dongdian Testing Service Co., Ltd Report No.:DDT-R21062212-1E02 Page 2 of 11 Table of Contents Test report declares........................................................................................................3 1. General Information ....................................................................................................... 5 1.1. Description of equipment ............................................................................................... 5 1.2. Assistant equipment used for test .................................................................................. 5 1.3. Assess laboratory ........................................................................................................... 5 2. Equipment used during test ........................................................................................... 5 3. Method of Measurement ................................................................................................ 6 3.1. Applicable standard ........................................................................................................ 6 3.2. Block diagram of test setup ............................................................................................ 6 3.3. Test procedure ............................................................................................................... 6 3.4. Equipment approval considerations: .............................................................................. 7 3.5. E and H Field Strength ................................................................................................... 8 4. Test Setup Photo............................................................................................................ 9 Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R21062212-1E02 Page 3 of 11 Test Report Declare Assess Standard Used: FCC CFR 47 part1, 1.1307(b), 1.1310; KDB680106 DR03-44118 We Declare: The equipment described above is assessed by Dongguan Dongdian Testing Service Co., Ltd and in the configuration assessed the equipment complied with the standards specified above. The assessed results are contained in this report and Dongguan Dongdian Testing Service Co., Ltd is assumed of full responsibility for the accuracy and completeness of these assess. After evaluation, our opinion is that the equipment In Accordance with above standard. Report No.: DDT-R21062212-1E02 Date of Receipt: Jul. 01, 2021 Date of Test: Jul. 01, 2021~ Aug. 09, 2021 Prepared By: Approved By: ____________________ ______________________ Johnny Wang/Engineer Damon Hu/EMC Manager Note: This report applies to above tested sample only. This report shall not be reproduced in parts without written approval of Dongguan Dongdian Testing Service Co., Ltd. Applicant : Incipio, LLC Address : 3347 Michelson Drive, Suite 100, Irvine CA 92612 Equipment under Test : Wireless Charging Pad Model No. : GP-109-BLK Trade Name : Manufacturer : Tomax Technology (Dongguan) Co., Ltd Address : 4 th floor of Deyuxin Technology Park, No.13 of Jintang Road, Jinmei Village, Changping Town, Dongguan E S T T I N N A I G D S G E N R O V D I C E N A C U O G . , G L N T O D D . Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R21062212-1E02 Page 4 of 11 Revision History Rev. Revisions Issue Date Revised By --- Initial issue Aug. 09, 2021 Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R21062212-1E02 Page 5 of 11 1. General Information 1.1. Description of equipment Note: EUT is the abbreviation of equipment under test. 1.2. Assistant equipment used for test Description of Accessories Manufacturer Model number Serial No. Other Dummy load N/A N/A N/A N/A 1.3. Assess laboratory Dongguan Dongdian Testing Service Co., Ltd. Add.: No. 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808. Tel.: +86-0769-38826678, http://www.dgddt.com, Email: [email protected]. CNAS Accreditation No. L6451; A2LA Accreditation Number: 3870.01 FCC Designation Number: CN1182, Test Firm Registration Number: 540522 Innovation, Science and Economic Development Canada Site Registration Number: 10288A Conformity Assessment Body identifier: CN0048 VCCI facility registration number: C-20087, T-20088, R-20123, G-20118 2. Equipment used during test Equipment Manufacturer Model No. Serial No. Last Cal. Cal. Interval Electric and Magnetic Field Analyzer narda EHP-200A 170WX91016 Jan. 06, 2021 1 Year EUT* Name : Wireless Charging Pad Model Number : GP-109-BLK EUT function description : Please reference user manual of this device Power supply : DC 5V 2A Wireless charging Operation frequency : 115-205KHz Antenna Type : Inductive loop coil antenna Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R21062212-1E02 Page 6 of 11 3. Method of Measurement 3.1. Applicable standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. According KDB 680106 D01: RF Exposure Wireless Charging Apps v03r01. 3.2. …
