2AAWX-IPD-346Steno Keyboard Folio for iPad Mini

HARD SHELL ULTRA-THIN BLUETOOTH KEYBOARD FOLIO Setup Guide WHAT’S IN THE BOX? _ MAIN FEATURES _ • iPad mini Bluetooth Keyboard Folio • USB to Micro-USB charging cable • User documentation • Keyboard automatically enters Stand-By mode to conserve battery when not in use. • Built-in rechargeable battery can be charged by utilizing the included Micro-USB charging cable. • Light-weight and compact design for ultimate portability. • Can be paired with up to 3 devices. (Keyboard can only connect to one device at a time) • Hard-shell dual-sided protection • Adjustable viewing angles for a comfortable user experience.. • Sliding QWERTY keyboard with optimized key spacing • Built-in magnetic closure magnets for an extra layer of protection to your devices screen. OVERVIEW: IPAD HOME SCREEN BRIGHTNESS + BRIGHTNESS -SEARCH STATUS INDICATORS POWER BUTTON IOS LANGUAGE SELECT PREVIOUS NEXT TRACK MUTEVOLUME –VOLUME + LOCK SCREEN VIRTUAL KEYBOARD TOGGLE PLAY / PAUSE BLUETOOTH CONNECT PAIRING BUTTON Blue (Blinking) pairing Blue (On) Caps lock enabled Red (Blinking)- Low battery Red (On)- Charging Blue (on)- Powered on KEY FUNCTIONS _ To access the functions on the keyboard, press and hold the Function (Fn) key and combine with the desired hotkeys on keyboard. [fn] + ~ : Return to iPad Home Screen [fn] + 1 : Decrease iPad screen brightness [fn] + 2 : Increase iPad Screen brightness [fn] + 3 : Launch iPad search function / Close iPad Search Function [fn] + 4 : Toggle Virtual keyboard On / Off [fn] + 5 : Toggle iOS Language selection [fn] + 6 : Previous track [fn] + 7 : Play / Pause [fn] + 8 : Next Track [fn] + 9 : Mute [fn] + 0 : Decrease Volume [fn] + - : Increase Volume [fn] + = : Lock iPad and Turn off Screen / Unlock iPad and Turn on Screen) CHARGING GUIDE _ BATTERY CHARGING The red LED indicator located above the will blink when your Bluetooth’s keyboard battery is low. To charge your Bluetooth keyboard, you must perform the following steps: 1. Connect the Micro-USB cable to the keyboard charging interface located on the back edge of the Bluetooth keyboard, directly behind the on and off switch. 2. Connect the USB-A connector (the larger of the two ends) to a USB power adaptor or to the USB interface on your computer. 3. The red LED indicator will be now be lit steady during the charging process and will automatically turn off once charging is complete. Your iPad mini Bluetooth keyboard can connect to 1 external device at a time and can store the last 3 paired devices’ connection information. By default, the keyboard will search for the last paired device. If your keyboard is unable to locate the last paired external device, it will automatically search and pair with the second external device, then the third one. If there has been no keyboard usage or your external device has been away from the keyboard’s operating distance for more than 10 minutes, the keyboard will enter into standby mode to preserve battery power. You can touch any key to wake the keyboard. The iPad mini Bluetooth takes approximately 2-3 seconds to wake from from standby mode. Your external device should be in the valid connecting distance before pressing a key to wake the keyboard.. BLUETOOTH OPERATION _ BLUETOOTH KEYBOARD PAIRING & CONNECTING _ To initiate the pairing and connecting process between the iPad mini Bluetooth keyboard and your device, please follow the steps outlined below: 1. Toggle on your Bluetooth keyboard by moving the switch in the upper right hand corner to the on position. The blue LED indicator located above the power icon will be lit for 3 seconds and then turn off. 2. Press the CONNECT button, the blue LED indicator above the Bluetooth Icon will begin to blink, the keyboard is now ready to connect your device. 3. Turn on and unlock your iPad mini. Click on the Settings icon . 4. Select Bluetooth from the left panel and make sure the toggle for Bluetooth shows that is turned on. 5. Your iPad mini will search for a list of available Bluetooth devices. 6. Under Devices, select Incipio iPad mini with Retina display Bluetooth keyboard begin the pairing process. 7. Your iPad mini will now bring up the device pairing prompt with the pairing password. Type the password using the Bluetooth Keyboard keys and when complete press ENTER on the keyboard to complete the pairing process. 8. Once your iPad mini Bluetooth keyboard is connected successfully, the blue LED indicator above the Bluetooth Icon on your keyboard will turn off. TROUBLESHOOTING _ UNABLE TO CONNECT 1. Make sure the power switch on your Bluetooth Keyboard is in the ON position. 2. Make sure the keyboard is within the operating distance. 3. Make sure the battery is charged. 4. Make sure the iPad mini Bluetooth is enabled. 5. Make sure Bluetooth keyboard has been paired with the iPad mini. 6. Unpair the Bluetooth Keyboard from your iPad mini by selecting the Info icon next to Incipio iPad mini Bluetooth Keyboard, and select Forget this Device. Select the device again to restart the pairing process. UNABLE TO CHARGE KEYBOARD 1. Make sure the USB power cord is connected properly to the keyboard and the power source. 2. Make sure the power source is working properly. FCC STATEMENT _ WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, used and can radiate radio frequency energy and, if not installed and used on accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to a radio or televisi…

Text truncated - open the document above for the full version.

R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:2AAWX-IPD-346 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F14212 14-1 14. PHOTOGRAPH OF EUT Figure 1 General Appearance of the EUT Figure 2 General Appearance of the EUT

--- — 346346 346 346

R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:2AAWX-IPD-346 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F14212 14-2 Figure 3 Inside of the EUT Figure 4 Battery of the EUT R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:2AAWX-IPD-346 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F14212 14-3 Figure 5 Component side of the PCB Figure 6 Component side of the PCB R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:2AAWX-IPD-346 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F14212 14-4 Figure 7 Component side of the PCB Figure 8 Component side of the PCB R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:2AAWX-IPD-346 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F14212 14-5 Figure 9 Component side of the PCB

Product Name：Steno Keyboard Folio for iPad Mini Model Number: IPD-346 FCCID: 2AAWX-IPD-346 RADIO FRREQUENCY EXPOSURE COMPLIANCE RESULT : PASS Test standard : FCC KDB Publication 447498 D01 V05 Since maximum peak output power of the transmitter is<10mW, i.e. 0.4228mW<10mW, hence the EUT is exclueded from SAR evaluation according to FCC KDB Publication 447498 D01:General RF Exposure Guidance V05.

R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:2AAWX-IPD-346 Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F14212 FCC PART 15C TEST REPORT FOR CERTIFICATION On Behalf of Incipio Technologies, Inc. Steno Keyboard Folio for iPad Mini Model Number: IPD-346 FCC ID: 2AAWX-IPD-346 Prepared for : Incipio Technologies, Inc. 6001 Oak Canyon, Irvine, CA 92618 Prepared By : Audix Technology (Shenzhen) Co., Ltd. No. 6, Ke Feng Rd., 52 Block, Shenzhen Science & Industrial Park, Nantou, Shenzhen, Guangdong, China Tel: (0755) 26639496 Report Number ： ACS-F14212 Date of Test ： Jun.20~26, 2014 Date of Report ： Jul.04, 2014 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:2AAWX-IPD-346 Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F14212 TABLE OF CONTENTS Description Page 1. SUMMARY OF STANDARDS AND RESULTS ......................................................... 1-1 1.1. Description of Standards and Results .................................................................................. 1-1 2. GENERAL INFORMATION ......................................................................................... 2-1 2.1. Description of Device (EUT) .............................................................................................. 2-1 2.2. Tested Supporting System Details ....................................................................................... 2-2 2.3. Block Diagram of connection between EUT and simulators .............................................. 2-2 2.4. Test information .................................................................................................................. 2-2 2.5. Test Facility ......................................................................................................................... 2-3 2.6. Measurement Uncertainty (95% confidence levels, k=2) .................................................... 2-4 3. POWER LINE CONDUCTED EMISSION MEASUREMENT ................................. 3-1 3.1. Test Equipment .................................................................................................................... 3-1 3.2. Block Diagram of Test Setup .............................................................................................. 3-1 3.3. Power Line Conducted Emission Test Limits ..................................................................... 3-1 3.4. Configuration of EUT on Test ............................................................................................. 3-2 3.5. Operating Condition of EUT ............................................................................................... 3-2 3.6. Test Procedure ..................................................................................................................... 3-2 3.7. Conducted Emission at Mains Terminals Test Results ....................................................... 3-2 4. RADIATED EMISSION MEASUREMENT ................................................................ 4-1 4.1. Test Equipment .................................................................................................................... 4-1 4.2. Block Diagram of Test Setup .............................................................................................. 4-2 4.3. Radiated Emission Limit Standard: FCC 15.209 ................................................................ 4-3 4.4. EUT Configuration on Test ................................................................................................. 4-3 4.5. Operating Condition of EUT ............................................................................................... 4-4 4.6. Test Procedure ..................................................................................................................... 4-4 4.7. Radiated Emission Test Results........................................................................................... 4-4 5. CONDUCTED SPURIOUS EMISSIONS ..................................................................... 5-1 5.1. Test Equipment .................................................................................................................... 5-1 5.2. Limit .................................................................................................................................... 5-1 5.3. Test Procedure ..................................................................................................................... 5-1 5.4. Test result ............................................................................................................................ 5-1 6. CARRIER FREQUENCY SEPARATION TEST ........................................................ 6-1 6.1. Test Equipment .................................................................................................................... 6-1 6.2. Limit .................................................................................................................................... 6-1 6.3. Test Results. ........................................................................................................................ 6-1 7. 20 DB BANDWIDTH TEST ........................................................................................... 7-1 7.1. Test Equipment .................................................................................................................... 7-1 7.2. Limit .................................................................................................................................... 7-1 7.3. Test Results ......................................................................................................................... 7-1 8. NUMBER OF HOPPING FREQUENCY TEST .......................................................... 8-1 8.1. Test Equipment .................................................................................................................... 8-1 8.2. Limit ........................................................…
