2AAXO-SMC2040SINGCAST MAX MIC STAND KARAOKE MACHINE

TM SMC2040 INSTRUCTION MANUAL/ MANUAL DE INSTRUCCIONES/ MODE D’EMPLOI www.singingmachine.com The Singing Machine® is a registered trademark of The Singing Machine Co., Inc. The Singing Machine® es marca registrada de The Singing Machine Co., Inc. The Singing Machine® est une marque déposée de The Singing Machine Co., Inc. — E1 — Important Safety Information 1. Read these Instructions. 2. Keep these Instructions. 3. Heed all Warnings. 4. Follow all Instructions. 5. Do not use this apparatus near water. 6. Clean only with a dry cloth. 7. Do not block any of the ventilation openings. Install in accordance with the Manufacturer’s instructions. 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. When the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. 10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. 11. Only use attachments/accessories specified by the manufacturer. 12. Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. 13. Unplug this apparatus during lightning storms or when unused for long periods of time. 14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. 15. WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. Do not place objects filled with water, such as a vase, on the apparatus. 16. The AC mains plug is used as the power disconnect device and it should remain readily accessible and operable during intended use. In order to completely disconnect the apparatus from power, the mains plug should be completely removed from the AC outlet socket. 17. CAUTION: To reduce the risk of fire or explosion, do not expose batteries to excessive heat such as sunshine, fire or other heat sources. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. DANGEROUS VOLTAGE: The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. ATTENTION: The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying this product. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN Warnings WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. DRIPPING WARNING: This product shall not be exposed to dripping or splashing, and no objects filled with liquids, such as vases, shall be placed on the product. VENTILATION WARNING: The normal ventilation of the product shall not be impeded for intended use. CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT AND FULLY INSERT. FCC WARNING: This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. The rating information is located at the bottom of the unit. WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. RF Exposure Warning Statements: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment shall be installed and operated with minimum distance 20cm between the radiator & body. — E2 — Included Please make sure that th…

Text truncated - open the document above for the full version.

— S5 — Ubicación de los controles u v y x w SUPERIOR br MICRÓFONO I NALÁMBRICO bs blas bt REVERSO bk VU al W am X an at ao ak ap aq ar bn bm bp bq bo PANTALLA 1. Soporte 2. Soportes para micrófono 3. Ajuste del poste de la cuna 4. Tapa de ajuste de altura 5. Ponente 6. Control de Navegación/ ACEPTAR 7. Cubierta de goma 8. Control de VOLUMEN DE MÚSICA / VOLUMEN MIC 9 Botón REPRODUCCIÓN (PLAYBACK) 10. Botón GRABACIÓN (RECORD) 11. Control de EFECTOS DE VOZ 12. Botón Bluetooth/ VOCALS OFF 13. / (Botón ENCENDIDO/ ESPERA/LUCES) 14. Bouton INICIO (HOME) 15. Botón de VOLVER (BACK) 16. Control de la FUERZA DE LOS EFECTOS 17. Botón TONO PERFECTO 18. Pantalla 19. Conector de entrada de CC 20. Conector para HDMI 21. Entrada para MICRÓFONO 3 22. Manija 23. Indicador de Bluetooth 24. Indicador de Bluetooth 25. Indicador de micrófono 1 (inalámbrico) 26. Indicador de micrófono 2 (inalámbrico) 27. Indicador de micrófono 3 (cableado) 28. Indicador de batería de micrófono inalámbrico 29. Botón encendido / apagado del micrófono inalámbrico — S6 — Pila Recargable Esta unidad contiene un paquete de pilas recargables que le permitirá usarla sin necesidad de enchufarla a un tomacorriente de CA. El paquete de baterías recargables NO debe ser reparado/reemplazado por el usuario. Para optimizar la vida útil de la pila, recomendamos cargar el dispositivo una vez al mes. Cuándo el indicador de batería de la pantalla parpadea lentamente, recargue el dispositivo siguiendo los pasos continuación: 1 Introduzca el cable de alimentación de CA en un tomacorriente de CA de ubicación conveniente con 120V de CA, 60Hz. 2 Deje que la unidad se cargue durante unas 8 horas para lograr la carga completa. Cuando completamente cargada, el indicador se apagará. 3 Desconecte el cable de CA y Se puede usar la unidad completamente cargada durante aproximadamente 4-10 horas dependiendo de la función elegida. ATENCIÓN: El volumen se ajustará automáticamente cuando la batería no esté cargada. Información sobre reciclaje y descarte: • No descarte los dispositivos electrónicos o ninguno de sus componentes (en especial, pilas y pantallas de LCD) en la recolección de residuos municipal. • Consulte con la autoridad local de gestión de residuos o con una organización de reciclaje como Earth911.com para saber cuál es el centro de reciclaje de aparatos electrónicos en su área. PRECAUCIÓN: Se deben reciclar o descartar correctamente las pilas recargables. Ahorro de energía (Sistema de apagado automático - APS) Si no hay reproducción de audio, la unidad se apagará automáticamente después de 30 minutos restantes. Para reanudar el uso de la unidad, presione el botón / . APS es para el ahorro de energía. . — S7 — NOTA: • Haga todas las conexiones antes de enchufar el adaptador de CA al tomacorriente. • El adaptador de CA tiene un enchufe polarizado que encaja en el tomacorriente de pared de una sola manera. Si el enchufe no cabe correctamente, gírelo y pruebe nuevamente. No fuerce y no lime ni corte la clavija ancha. • El adaptador de CA provisto solo puede usarse para cargar la batería recargable incorporada. NO lo use con otros dispositivos. Conexiones Carga de la unidad Introduzca el cable de alimentación de CA en un tomacorriente de CA de ubicación conveniente con 120V de CA, 60Hz. HDMI Jack (In) HDMI IN1 Cable de HDMI HDMI Jack (Out) 2 Parte posterior del televisor externo Conexión de la unidad a un televisor NOTAS: • Esta unidad puede utilizarse con o sin televisor, pero es altamente recomendable usar uno para aprovechar todas las funciones. • También consulte la Guía de usuario del televisor. • La entrada de audio y micrófono Bluetooth no se puede enviar a su televisor. Para generar el video de transmisión y emitiendo audio a su televisor, realice los siguientes pasos: Conecte el cable de HDMI (no incluido) en el conector de HDMI en la parte posterior de la unidad. Conecte el otro extremo del cable de HDMI en la entrada de HDMI de su televisor. — S8 — Conexiones Cambio de la batería del micrófono inalámbrico Cuando las baterías del micrófono inalámbrico estén bajas, el indicador de batería parpadeará. Cambie las pilas de la siguiente manera: 1 Desatornille la parte inferior de la conexión del micrófono inalámbrico. 2 Reemplace la batería con dos (2) baterías AA / LR6. 3 Vuelva a colocar la parte inferior del micrófono inalámbrico y vuelva a atornillarlo. u Conexión de los micrófonos inalámbricos Presione el botón / (ON/STANDBY/ LIGHTS) para encender la unidad, los indicadores Mic 1 y 2 aparecen en la pantalla y parpadean. Deslice el botón ON / MUTE / OFF del micrófono inalámbrico y cambie a la posición ON. El indicador de micrófono 1 o 2 se iluminarán sin parpadear. NOTAS: • Distancia de trabajo de hasta 10 metros medidos en espacio abierto. • Si no hay entrada de audio durante 15 minutos, la conexión de micrófonos inalámbricos se apagará automáticamente. Presione y gire el control MUSIC VOL / MIC VOL para reactivar la conexión. Precauciones sobre las pilas Se seguirán las precauciones a continuación cuando se utilicen pilas en este dispositivo: 1. Utilice sólo el tamaño y tipo de pilas especificadas. 2. Asegúrese de respetar la polaridad correcta cuando instale las pilas, según lo indicado en el compartimiento de las pilas. Las pilas al revés pueden provocar daños al dispositivo. 3. No mezcle diferentes tipos de pilas (por ejemplo alcalinas y de zinc-carbono) o pilas viejas con pilas nuevas. 4. Si no va a usarse el dispositivo durante un período prolonga do, asegúrese de quitar las pilas para prevenir daños o lesiones a causa de posibles pérdidas de las pilas. 5. No intente recargar pilas que no fueron diseñadas para ese fin; pueden recalentarse y romperse (Siga las indicaciones del fabricante de la pila). 6. Las pilas recargables se deben quitar del producto antes de la carga. 7. Las pilas recargables solo se pueden cargar bajo supervisión de un adulto. 8. Las pilas sin carga se deben quitar del producto. 9. La pila no deberá exponerse a calor…

Text truncated - open the document above for the full version.

— F9 — Connexions Support TIREZ u u Connexion du microphone filaire en option Connectez le microphone filaire (pas inclus) dans la prise micro u (si vous le souhaitez). Remarque: Un maximum de deux microphones (filaires ou sans fil) peuvent être connectés à l'unité en même temps. Après avoir inséré le microphone filaire (Mic 3), le microphone sans fil 1 (Mic 1) sera automatiquement désactivé. Mode Lumières Il existe 5 modes d'éclairage intégrés. Appuyez plusieurs fois sur les boutons / pour basculer entre les différents effets d'éclairage. — F10 — Connexions Se connecter au Wi-Fi 1 Connectez l'appareil comme décrit ci-dessus ; il doit être connecté à un téléviseur. Appuyez sur la touche / (ON / STANDBY / LIGHTS) pour allumer l’appareil. 2 UTILISEZ VOTRE APPAREIL MOBILE POUR VOUS CONNECTER À CET APPAREIL Utilisez la commande NAV/ENTER pour sélectionner l'icône SINGCAST sur l'écran de votre téléviseur. "CAS" s'affichera à l'écran. Si cet appareil n'a pas été connecté à votre réseau Wi-Fi, un code QR de l'étape 1 apparaîtra à l'écran. Utilisez votre appareil mobile pour scanner le code QR en lui laissant un moment pour se charger. Une fois que votre appareil mobile se connecte avec succès à l'unité, le code QR de l'étape 2 apparaîtra à l'écran. REMARQUE: • Tournez la commande NAV/ENTER pour naviguer, appuyez dessus pour entrer. 3 CONNECTEZ CET APPAREIL À VOTRE RÉSEAU Wi-Fi Utilisez votre appareil mobile pour scanner le code QR de l'étape 2 et laissez-le se charger. La liste Wi-Fi apparaîtra sur votre appareil mobile. Recherchez et sélectionnez votre réseau Wi-Fi domestique et saisissez votre mot de passe Wi-Fi pour terminer le processus de connexion. Si l'unité ne se connecte PAS avec succès à votre réseau Wi-Fi domestique, vérifiez votre mot de passe et la fréquence Wi-Fi et répétez les étapes ci-dessus. REMARQUES: • Cet appareil ne prend en charge que le Wi-Fi 2,4 GHz. • Assurez-vous que le réseau Wi-Fi du l'appareil mobile et l'unité utilisent le même réseau. • Les paramètres de sécurité WPA3 peuvent entraîner des problèmes de connexion. Si vous disposez de la sécurité WPA3, nous vous recommandons de passer à WPA2 ou à une version inférieure. Ou contactez-nous pour plus d'aide. u v — F11 — Connexions Se connecter au Wi-Fi (Suite) 4 Lorsque l'unité se connecte avec succès à votre Wi-Fi, "connecté" s'affichera à l'écran. Vous pouvez télécharger l'application Singing Mach ine Karaoke pour écouter votre musique de karaoké préférée et projeter la vidéo de karaoké HD sur votre téléviseur. 5 L'unité recherche et s'apparie automatiquement à un réseau Wi-Fi précédemment apparié. Si vous souhaitez vous connecter à un autre réseau Wi-Fi, vous pouvez aller dans le menu principal et sélectionner PARAMÈTRES>Paramètres WiFi>DÉCONNECTER de vous déconnecter du réseau Wi-Fi, cela vous permettra de vous connecter à un autre réseau. 6 Appuyez sur le bouton BACK pour revenir à l'écran précédent. 7 Appuyez sur le bouton HOME pour accéder au menu principal. U V SETTINGS Manually access your options MENU OPTIONS Software updateSoftware infoFactory setting WiFi setting ABC enter #+= WIFI SETTINGS Manually access your options AP DISCONNECT WIFI NETWORK SIGNAL LEVEL (%) DISCONNECT Family WiFi 85% CANCEL 12345 6 7890-/:;()$&@“.,?!‘ — F12 — Connexions Réglages 1 Appuyez sur le bouton HOME pour accéder au menu principal. À l'aide de la commande NAV/ENTER, sélectionnez l'icône RÉGLAGES ; "SEt" apparaîtra à l'écran. 2 Sélectionnez le paramètre WiFi pour vous connecter ou se déconnecter du réseau Wi-Fi et vérifiez le niveau du signal Wi-Fi. 3 Sélectionnez Mise à jour du logiciel pour mettre à jour le logiciel de l'appareil. 4 Sélectionnez Infos sur le logiciel pour vérifier dernière version du logiciel de cet appareil. 5 Sélectionnez le paramètre d'usine à supprimer toutes les données stockées dans l'unité. xwvy SETTINGS Manually access your options MENU OPTIONS Software updateSoftware infoFactory setting WiFi setting — F13 — Utilisation Utilisation de SingCast Casting 1 Connectez l'appareil comme décrit ci-dessus ; il doit être connecté à un téléviseur. Appuyez sur la touche / (ON / STANDBY / LIGHTS) pour allumer l’appareil. 2 Utilisez la commande NAV/ENTER pour sélectionner l'icône SINGCAST sur l'écran de votre téléviseur; "CAS" apparaisse à l'écran. 3 Téléchargez l'application Singing Machine Karaoke pour choisir parmi des milliers de vidéos de karaoké HD, projetez vos vidéos de karaoké préférées de votre appareil mobile vers votre téléviseur (assurez-vous que votre appareil mobile et l'appareil sont connectés au même réseau Wi- Fi). 4 Appuyez sur l'icône sur l'écran de votre appareil et sélectionnez "SingCast Ultimate" pour diffuser une vidéo de karaoké HD depuis l'application Singing Machine sur votre téléviseur. 5 Ajustez le volume à un niveau confortable en utilisant la commande de MUSIC VOL/MIC VOL. 6 Appuyez sur la touche de commande MUSIC VOL / MIC VOL ; "MIC" apparaît sur l'écran, tournez la commande MUSIC VOL / MIC VOL dans les 2 secondes pour régler le volume des deux microphones. Après quelques secondes de relâchement, il reviendra au contrôle du volume de la musique. u v y U vx — F14 — Utilisation Utilisation de SingCast Casting (suite) 7 Faites glisser le commutateur ON / OFF du micro sans fil sur la position ON. REMARQUE: Faire glisser le commutateur sur MUTE arrêtera temporairement l'entrée du microphone. 8 ENREGISTRER VOS PERFORMANCES VOCALES: Pendant la lecture de musique, appuyez sur le bouton RECORD pour enregistrer votre chant et la musique, "REC" apparaîtra en continu sur l'affichage. Appuyez à nouveau sur le bouton RECORD pour arrêter l'enregistrement, "REC" s'éteindra. Il arrêtera également l'enregistrement automatiquement après 5 minutes et "REC" s'éteindra. REMARQUE: Veuillez noter que les nouveaux enregistrements entraîneront la suppression des enregistrements précédents. 9 LISEZ VOTRE PERFORMANCE DE CHANT Pour commencer la lecture de votre enregistrement, appuyez sur le bouton PLAYBACK. "PB…

Text truncated - open the document above for the full version.

The Singing Machine Company, Inc. 6301 NW 5th Way, Suite 2900Fort Lauderdale, FL, 33309, U.S.A. Agent Authorization Company: The Singing Machine Company, Inc. Address: 6301 NW 5th Way, Suite 2900Fort Lauderdale, FL, 33309, U.S.A. Product Name: SINGCAST MAX MIC STAND KARAOKE MACHINE Model Number(s): SMC2040, SMC2030, SMC2045, SMC2030XX, SMC2040XX, SMC2045XX (XX means unit color, it can be A to Z or N/A) Product Description: SINGCAST MAX MIC STAND KARAOKE MACHINE We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: Apr. 28, 2022 Name: Gary Atkinson Title: General Manager Company: The Singing Machine Company, Inc.

The Singing Machine Company, Inc. 6301 NW 5th Way, Suite 2900Fort Lauderdale, FL, 33309, U.S.A. Apr. 28, 2022 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Subject: Explanation of differences between product types FCC ID: 2AAXO-SMC2040 Models: SMC2040, SMC2030, SMC2045, SMC2030XX, SMC2040XX, SMC2045XX (XX means unit color, it can be A to Z or N/A) To Whom It May Concern: We, The The Singing Machine Company, Inc. hereby declare that the model : SMC2040 is identical with the model : SMC2030, SMC2045, SMC2030XX, SMC2040XX, SMC2045XX (XX means unit color, it can be A to Z or N/A), The appearance color is different, the electronic circuit is the same. Except for the different above, no other modification is performed. Sincerely, The Singing Machine Company, Inc. Signature: [Gary Atkinson, General Manager]

The Singing Machine Company, Inc. 6301 NW 5th Way, Suite 2900Fort Lauderdale, FL, 33309, U.S.A. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: Apr. 28, 2022 Subject: Declaration Operating Channel Limitation FCC ID: 2AAXO-SMC2040 To Whom it may concern, This device is acting as slave/client device under the control of a master. The operating channels in 802.11 b/g/n mode for this device marketed to the US are firmware limited to channel 1 ~ 11 (2412 ~ 2462 MHz). The end-user has no possibility to select any other operating channels. If you have any questions, please feel free to contact me. Thank you. Sincerely, Signatory The Singing Machine Company, Inc. Contact person: Gary Atkinson Title: General Manager

The SingingMachineCompany,Inc. 6301 NW 5th Way, Suite 2900FortLauderdale,FL, 33309,U.S.A. Office of EngineeringTechnology FederalCommunicationsCommission 7435 OaklandMills Road Columbia,MD 21046 USA Date: Apr. 28, 2022 Subject;Requestfor Confidentiality FCC ID: 2AAXO-SMC2040 To WhomIt May Concern, Pursuantto the provisionsof the Commission’s rules Title 47 Sections§0.457 and §0.459,we are requestingthe Commissionto withholdthe followingattachment(s)as confidential documentsfrom public disclosureindefinitely. Thesedocumentscontaindetailedsystemand equipmentdescriptionsand are consideredas proprietaryinformationin operationof the equipment.The public disclosureof these documents might be harmfulto our companyand would give competitorsan unfair advantagein the market. SchematicDiagram Block Diagram OperationalDescription Parts List It is our understandingthat all measurementtest reports,FCC ID label formatand correspondenceduringthe certificationreviewprocesscannotbe grantedas confidential documentsand this informationwill be availablefor public reviewonce the grant of equipment authorizationis issued. Sincerely, Signature: Name:Gary Atkinson Title: GeneralManager

Report No.: AGC04138220301AP02 Page 1 of 4 EXTERNAL PHOTOS All VIEW OF EUT TOP VIEW OF EUT Report No.: AGC04138220301AP02 Page 2 of 4 BOTTOM VIEW OF EUT FRONT VIEW OF EUT Report No.: AGC04138220301AP02 Page 3 of 4 BACK VIEW OF EUT LEFT VIEW OF EUT Report No.: AGC04138220301AP02 Page 4 of 4 RIGHT VIEW OF EUT ****************************************End of Report****************************************

FCC ID Label Location 20mm*20mm FCC ID: 2AAXO-SMC2040 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Report No.: AGC04138220301AP02 Page 1 of 13 INTERNAL PHOTOS OPEN VIEW OF EUT (FIGURE 1) VIEW OF BATTERY Report No.: AGC04138220301AP02 Page 2 of 13 OPEN VIEW OF EUT (FIGURE 2) INTERNAL VIEW OF EUT (FIGURE 1) Report No.: AGC04138220301AP02 Page 3 of 13 INTERNAL VIEW OF EUT (FIGURE 2) INTERNAL VIEW OF EUT (FIGURE 3) BT Antenna WIFI Antenna Report No.: AGC04138220301AP02 Page 4 of 13 INTERNAL VIEW OF EUT (FIGURE 4) INTERNAL VIEW OF EUT (FIGURE 5) Report No.: AGC04138220301AP02 Page 5 of 13 INTERNAL VIEW OF EUT (FIGURE 6) INTERNAL VIEW OF EUT (FIGURE 7) Report No.: AGC04138220301AP02 Page 6 of 13 INTERNAL VIEW OF EUT (FIGURE 8) INTERNAL VIEW OF EUT (FIGURE 9) Report No.: AGC04138220301AP02 Page 7 of 13 INTERNAL VIEW OF EUT (FIGURE 10) INTERNAL VIEW OF EUT (FIGURE 11) Report No.: AGC04138220301AP02 Page 8 of 13 INTERNAL VIEW OF EUT (FIGURE 11) INTERNAL VIEW OF EUT (FIGURE 12) Report No.: AGC04138220301AP02 Page 9 of 13 INTERNAL VIEW OF EUT (FIGURE 13) INTERNAL VIEW OF EUT (FIGURE 14) Report No.: AGC04138220301AP02 Page 10 of 13 INTERNAL VIEW OF EUT (FIGURE 15) OPEN VIEW OF EUT (FIGURE 3) Report No.: AGC04138220301AP02 Page 11 of 13 INTERNAL VIEW OF EUT (FIGURE 4) INTERNAL VIEW OF EUT (FIGURE 1) Report No.: AGC04138220301AP02 Page 12 of 13 INTERNAL VIEW OF EUT (FIGURE 2) INTERNAL VIEW OF EUT (FIGURE 3) Report No.: AGC04138220301AP02 Page 13 of 13 INTERNAL VIEW OF EUT (FIGURE 4) ****************************************End of Report****************************************

RF EXPOSURE EVALUATION 1. PRODUCT INFORMATION Product Description SINGCAST MAX MIC STAND KARAOKE MACHINE Model Name SMC2040, SMC2030, SMC2045, SMC2030XX, SMC2040XX, SMC2045XX (XX means unit color, it can be A to Z or N/A) FCC ID 2AAXO-SMC2040 2. EVALUATION METHOD AND LIMIT Human exposure to RF emissions from mobile devices (47 CFR §2.1091) may be evaluated based on the MPE limits adopted by the FCC for electric and magnetic field strength and/or power density, as appropriate, since exposures are assumed to occur at distances of 20 cm or more from persons. LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE Frequency Range (MHz) E-field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) Averaging Time |E| 2 , |H| 2 or S (Minutes) 0.3 -- 1.34 614 1.63 (100)* 30 1.34 -- 30 824/f 2.19/f (180/f 2 )* 30 30 -- 300 27.5 0.073 0.2 30 300 -- 1500 -- -- f/1500 30 1500 -- 100,000 -- -- 1.0 30 *Note: 1. f= Frequency in MHz * Plane-wave Equivalent Power Density 2. The averaging time for General Population/Uncontrolled exposure to fixed transmitters is not applicable for mobile and portable transmitters. See 47 CFR §§2.1091 and 2.1093 on source-based time-averaging requirement for mobile and portable transmitters. S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna CALCULATION A minimum test separation distance ≥ 20 cm is required between the antenna and radiating structures of the device and nearby persons to apply mobile device exposure limits. The distance must be at least 20 cm and fully supported by the operating and installation configurations of the transmitter and its antenna(s), according to the source-based time-averaged maximum power requirements of § 2.1091(d)(2). In cases where cable losses or other attenuations are applied to determine compliance, the most conservative operating configurations and exposure conditions must be evaluated. BT Antenna Gain=-0.5dBi (Numeric 0.89), π=3.14 2.4G WIFI Antenna Gain=0dBi (Numeric 1.0), π=3.14 Note: 1. Only the worst case recorded. 2. The BT and 2.4GHz WIFI can not transmit simultaneously. Frequency Output Power Output Power Power Density Power Density Limit MHz dBm mW mW/cm 2 mW/cm 2 2402 6.916 4.916 0.001 1 Frequency Output Power Output Power Power Density Power Density Limit MHz dBm mW mW/cm 2 mW/cm 2 2412 16.09 40.644 0.008 1

Page 1 of 76 FCC Test Report Report No.: AGC04138220301FE03 FCC ID : 2AAXO-SMC2040 APPLICATION PURPOSE : Original Equipment PRODUCT DESIGNATION : SINGCAST MAX MIC STAND KARAOKE MACHINE BRAND NAME : Singing Machine MODEL NAME : SMC2040, SMC2030, SMC2045, SMC2030XX, SMC2040XX, SMC2045XX (XX means unit color, it can be A to Z or N/A) APPLICANT : The Singing Machine Company, Inc. DATE OF ISSUE : Apr. 28, 2022 STANDARD(S) : FCC Part 15.247 REPORT VERSION : V1.0 Attestation of Global Compliance (Shenzhen) Co., Ltd Report No.: AGC04138220301FE03 Page 2 of 76 REPORT REVISE RECORD Report Version Revise Time Issued Date Valid Version Notes V1.0 / Apr. 28, 2022 Valid Initial Release Report No.: AGC04138220301FE03 Page 3 of 76 TABLE OF CONTENTS 1. VERIFICATION OF CONFORMITY .................................................................................................................. 5 2. GENERAL INFORMATION .............................................................................................................................. 6 2.1. PRODUCT DESCRIPTION ........................................................................................................................ 6 2.2. TABLE OF CARRIER FREQUENCYS ....................................................................................................... 6 2.3. RECEIVER INPUT BANDWIDTH .............................................................................................................. 7 2.4. EXAMPLE OF A HOPPING SEQUENCY IN DATA MODE ......................................................................... 7 2.5. EQUALLY AVERAGE USE OF FREQUENCIES AND BEHAVIOUR ......................................................... 7 2.6. RELATED SUBMITTAL(S) / GRANT (S) .................................................................................................... 8 2.7. TEST METHODOLOGY ............................................................................................................................. 8 2.8. SPECIAL ACCESSORIES ......................................................................................................................... 8 2.9. EQUIPMENT MODIFICATIONS ................................................................................................................. 8 2.10. ANTENNA REQUIREMENT..................................................................................................................... 8 3. MEASUREMENT UNCERTAINTY ................................................................................................................... 9 4. DESCRIPTION OF TEST MODES ................................................................................................................. 10 5. SYSTEM TEST CONFIGURATION ................................................................................................................ 11 5.1. CONFIGURATION OF EUT SYSTEM ...................................................................................................... 11 5.2. EQUIPMENT USED IN TESTED SYSTEM .............................................................................................. 11 5.3. SUMMARY OF TEST RESULTS .............................................................................................................. 11 6. TEST FACILITY ................................................…

Text truncated - open the document above for the full version.
