mobility .com User Manual 3G BLAZE 7 2 3 User Manual 3G BLAZE 7 Introduction a. Package contents b. Safe handling of the product c. Battery instructions I.D. d. Disposal information 1. CHAPTER 1 • Basic configuration and setup 1.1. Charging your tablet 1.2. Switching your tablet on/off 2. CHAPTER 2 • Getting started 2.1. Home screen 2.2. Managing icons and several screens 3. CHAPTER 3 • Main applications 3.1. Internet access 3.2. Web browser 3.3. Email 4. CHAPTER 4 • Data transfer modes 4.1. Connection to a PC 4.2. Micro-SD card 5. CHAPTER 5 • Productivity applications 5.1. File manager 5.2. Search 5.3. Manage downloads 5.4. Clock 5.5. Calendar 6. CHAPTER 6 • Entertainment applications 6.1. Sound recorder 6.2. Music player 6.3. Camera 6.4. Camera and camcorder settings 6.5. Social applications 6.6. FM radio 6.7. FM transmission 7. CHAPTER 7 • Settings 7.1. Wireless and networks 7.2. 3G internet 7.3. GPS navigation 7.4. Device settings 7.5. Personal settings 7.6. System settings 7.7. About Tablet 8. CHAPTER 8 • Security 9. CHAPTER 9 • Backup and reset Appendix 1 Specifications Appendix 2 Troubleshooting checklist Appendix 3 FCC statement Thank you for purchasing the QUO BLAZE 7 3G Tablet. This manual guide will show you how to set up your device and use its functions. Once your tablet is up and running, you can visit www.quomobility.com to find out more about all the great features your new device has. a. Package contents • QUO BLAZE 7 3G Tablet with rechargeable lithium-ion battery • AC charger/USB sync data cable • Micro USB male to USB female adapter • Earbuds • Protective sleeve • User manual Note: If any of the listed items is missing, mismatched, damaged or broken, contact your local dealer immediately for replacement. b. Safe handling of the product • Never expose your tablet to direct sunlight or excessive heat. Avoid leaving the product inside a car with the windows closed. • Keep your tablet in a dry place. Never expose this product to rain or water. • Do not use or store your tablet in dusty, dirty areas. • Do not use harsh chemicals, soaps or detergents to clean your tablet. • Do not modify, disassemble, open, drop, crush, or puncture this product. • Never disconnect your tablet while a download or upload is in progress. • Switch off the device in restricted areas or where the use of electronic devices is prohibited. • To protect your hearing, make sure the volume level is not set too high when plugging the earbuds. c. Battery instructions • Use only the battery and battery charger specified by the manufacturer. • The battery has a limited service life so it will need replacing when it no longer holds enough charge. • Dispose of old batteries at directed places. • Do not throw batteries into a fire. • Do not force the battery when installing it. • If the battery overheats or changes color while charging it or storing it, stop using it. • Do not expose batteries to high temperatures. • Do not charge the battery for more than 24 hours. d. Disposal information Electrical and electronic products as well as batteries must not be discarded as regular household waste. As part of the company’s eco-friendly approach, we encourage you to recycle and follow all applicable local waste regulations to dispose of your used devices properly. Never dispose of batteries in a fire. CHAPTER 1 Basic setup 1.1. Charging your tablet • Fully charge the battery prior to using the tablet for the first time. Firmly insert the Micro-USB end of the supplied charger into the I/O port on the tablet, and the other end to a standard AC wall outlet or to an available USB port on your computer. • The battery must be initially charged for 5 hours and for 3 hours or so thereafter. • Let the battery drain completely, before recharging it to full capacity for a second time. From then on, allow the battery to charge until the icon on the screen becomes solid green. 1.2. Switching your tablet on/off • To turn on the tablet, press and hold the Power button for several seconds. The welcome screen will appear. • To switch off the tablet, press and hold down the Power button again. When the “Power off ” options menu comes up, select OK. The device will shut off completely. Note: make sure to follow the on-screen prompts for the initial setup of the tablet. 4 5 User Manual 3G BLAZE 7 2. Application view. A. In Desktop view, six default shortcuts will be displayed, which you can later customize based on your own particular needs and lifestyle. B. The Application view allows access to all the application available in your device. To open the main All Apps screen, touch the icon on any Home screen. Note: on the locked screen the most recent application icons will be displayed when accessing the system from either visualization mode. 2.2. Managing icons and different screens In order to see the different screens, slide your finger to the left or to the right. You may customize the home screen or any of the other screens by moving icons to another location. Just tap on the icon, drag it and drop it at the location where you want to place it. CHAPTER 3 Main applications 3.1. Internet access Configure the internet connection using your new tablet. • Go to Settings and click on Wi-Fi ON/OFF switch in order to enable the wireless Configuration on the tablet. • Choose a wireless access point, and enter your login and password • Select the Connect option on this menu to activate access to the internet. 3.2. Web browser The browser allows you to enjoy a seamless surfing experience using your new tablet. • Once you have successfully established an internet connection, you just need to tap on the Browser icon on the apps screen or the shortcut icon on a Home screen to launch this application. • At this stage, the following window will be displayed. • The user can then configure all related navigation settings based on his/her individual preferences. CHAPTER 2 Getting started 2.1. Home screen As soon as you power-on your tablet, you wil…

Text truncated - open the document above for the full version.

Cubix Latin America, LLC 2841 NW 107th Ave, Doral, FL 33172 Date: 2014-05-05 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD This letter is to ascertain that We, Cubix Latin America, LLC Product: MID Model: QD3G-710-BK, QD3G-710-WT, QD3G-710-GR FCC ID: 2ACDE- QD3G-710-BK The device is in the process of being granted under the FCC DOC. All the test will be performed at the FCC recognized test lab. If you have any question or concerns, pls. contact us. Sincerely, Signature: Title or printed name: ELIAHU SIBONI Title: Commercial Director Company Name: Cubix Latin America, LLC Address: 2841 NW 107th Ave, Doral, FL 33172

Long Term Confidentiality Request Letter 2014-5-19 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR ((MID / QD3G-710-BK,QD3G-710- WT,QD3G-710-GR AND FCC ID :2AAPW-QD3G-710-BK) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - e.g. Block Diagram - e.g. Schematics - e.g. Operational Description - e.g. Tune up Procedure required to be submitted with this application be permanently withheld from public review. SPECIFY REASON FOR REQUEST (i.e. the above documents are company proprietary information that could never get into the possession of your competition). Please contact me if there is any information you may need. Sincerely, Title or printed name: Title: Commercial Director ELIAHU SIBONI Company Name: Cubix Latin America, LLC Address: 2841 NW 107th Ave, Doral, FL 33172

Statement We Hereby that The product MID, models no. are all identical in interior structure, electrical circuits and components, and just model names are different for the marketing requirement. Your assistance on this matter is highly appreciated. Yours sincerely, Signature: Company Name: QD3G-710-BK,QD3G-710-WT,QD3G-710-GR Cubix Latin America, LLC Cubix Latin America, LLC Cubix Latin America, LLC 2841 NW 107th Ave, Doral, FL 33172

External Photo

FCC Certification Label FCC ID: 2ACDE-QD3G-710-BK Label Location on EUT EUT View/ FCC ID Label Location

MID Model: QD3G-710-BK FCC ID: 2ACDE- QD3G-710-BK Rating: 2A ,5V This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Cubix Latin America, LLC

Compliance Certification Services Inc. Report No: C140508S02-SF FCC ID: 2ACDE- QD3G-710-BK Date of Issue :May 8, 2014 Reference No: C140321S01-SF Page 1 of 42 GSM 850-Right Head Cheek Low CH128........................................................................................ 2 GSM 850-Right Head Tilted Low CH128.......................................................................................... 3 GSM 850-Left Head Cheek Low CH128........................................................................................... 4 GSM 850-Left Head Tilted Low CH128............................................................................................. 6 PCS 1900-Right Head Cheek Low CH512....................................................................................... 8 PCS 1900-Right Head Tilted Low CH512...................................................................................... 10 PCS 1900-Left Head Cheek Low CH512.........................................................................................11 PCS 1900-Left Head Tilted Low CH512......................................................................................... 12 WCDMA Band II-Right Head Cheek Low CH9262....................................................................... 13 WCDMA Band II-Right Head Tilted Low CH9262........................................................................ 15 WCDMA Band II-Left Head Cheek Low CH9262.......................................................................... 16 WCDMA Band II-Left Head Tilted Low CH9262........................................................................... 17 WCDMA Band V-Right Head Cheek Low CH4132....................................................................... 18 WCDMA Band V-Right Head Tilted Low CH4132........................................................................ 19 WCDMA Band V-Left Head Cheek Low CH4132......................................................................... 20 WCDMA Band V-Left Head Tilted Low CH4132........................................................................... 22 GPRS 850-Body Rear Low CH128.................................................................................................. 23 GPRS 850-Body-Edge 2 Low CH128.............................................................................................. 25 GPRS 850-Body-Edge 3 Low CH128.............................................................................................. 26 GPRS 850-Body-Edge 4 Low CH128.............................................................................................. 27 GPRS 1900-Body Rear Low CH512................................................................................................ 28 GPRS1900-Body-Edge 2 Low CH512............................................................................................. 30 GPRS1900-Body-Edge 3 Low CH512............................................................................................. 31 GPRS1900-Body-Edge 4 Low CH512............................................................................................. 32 WCDMA Band II-Body Rear Low CH9262..................................................................................... 33 WCDMA Band II-Body-Edge 2 Low CH9262................................................................................. 35 WCDMA Band II-Body-Edge 3 Low CH9262................................................................................. 36 WCDMA Band II-Body-Edge 4 Low CH9262................................................................................. 37 WCDMA Band V-Body Rear Low CH4132..................................................................................... 38 WCDMA Band V-Body-Edge 2 Low CH4132................................................................................ 40 WCDMA Band V-Body-Edge 3 Low CH4132................................................................................ 41 WCDMA Band V-Body-Edge 4 Low CH4132................................................................................ 42 Compliance Certification Services Inc. Report No: C140508S02-SF FCC ID: 2ACDE- QD3G-710-BK Date of Issue :May 8, 2014 Reference No: C140321S01-SF Page 2 of 42 Test Laboratory: Compliance Certification Services Inc. Date: 4/8/2014 GSM 850-Right Head Cheek Low CH128 DUT: MID; Type: QD3G-710-BK; Serial: 867008634881085 Communication System: Generic GSM; Communication System Band: GSM850; Frequency: 824.2 MHz;Duty Cycle: 1:8.30042 Medium parameters used (interpolated): f = 824.2 MHz; σ = 0.896 S/m; ε r = 41.182; ρ = 1000 kg/m 3 Room Ambient Temperature: 22°C; Liquid Temperature: 21.5°C Phantom section: Right Section Measurement Standard: DASY5 (IEEE/IEC/ANSI C63.19-2007) DASY Configuration: • Probe: EX3DV4 - SN3798; ConvF(9.16, 9.16, 9.16); Calibrated: 7/26/2013; • Sensor-Surface: 2mm (Mechanical Surface Detection) • Electronics: DAE4 Sn1245; Calibrated: 7/25/2013 • Phantom: Twin SAM Phantom; Type: QD 000 P40 CD; Serial: 1609 • DASY52 52.8.5(1059); • SEMCAD X Version 14.6.8 (7028) GSM850/Right Head Cheek Low CH128/Area Scan (10x12x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.0655 W/kg GSM850/Right Head Cheek Low CH128/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 4.160 V/m; Power Drift = 0.08 dB Peak SAR (extrapolated) = 0.0730 W/kg SAR(1 g) = 0.060 W/kg; SAR(10 g) = 0.049 W/kg Maximum value of SAR (measured) = 0.0677 W/kg Compliance Certification Services Inc. Report No: C140508S02-SF FCC ID: 2ACDE- QD3G-710-BK Date of Issue :May 8, 2014 Reference No: C140321S01-SF Page 3 of 42 Test Laboratory: Compliance Certification Services Inc. Date: 4/8/2014 GSM 850-Right Head Tilted Low CH128 DUT: MID; Type: QD3G-710-BK; Serial: 867008634881085 Communication System: Generic GSM; Communication System Band: GSM850; Frequency: 824.2 MHz;Duty Cycle: 1:8.30042 Medium parameters used (interpolated): f = 824.2 MHz; σ …
