User Manual Model Name:QSP-500D-BK Brand Name:QUO 1 Contents Safety ................................................................................................................ 3 Environment .................................................................................................... 4 1 Getting Started .............................................................................................. 5 1.1 Getting to know your touch phone................................................... 5 1.2 Installing the SIM card, battery, and storage card ............................ 5 1.3 Charging the Battery ....................................................................... 6 1.4 Starting up the device ...................................................................... 7 1.5 Status Icons ..................................................................................... 9 2 Using phone features .................................................................................. 11 2.1 Turning the phone function on and off ........................................... 11 2.2 Making a call ................................................................................ 11 2.3 Answering and Ending a call ......................................................... 12 2.4 In-call options ............................................................................... 12 2.5 Using call history .......................................................................... 13 2.6 Call settings .................................................................................. 13 3 Setting on your device................................................................................. 13 4 ActiveSync ................................................................................................... 17 5 Contacts....................................................................................................... 19 6 Exchanging Messages ................................................................................. 22 7 Internet ........................................................................................................ 26 7.1 Ways of Connecting to the Internet ................................................ 26 7.2 Browser ......................................................................................... 27 8 Experiencing Multimedia ........................................................................... 29 8.1 Camera & Picture .......................................................................... 29 8.2 Music ............................................................................................ 31 8.3 FM Radio ...................................................................................... 34 8.4 Sound record ................................................................................. 34 9 Other applications ...................................................................................... 34 2 9.1 Calendar ........................................................................................ 34 9.2 Alarm Clock .................................................................................. 35 9.3 Calculator ...................................................................................... 36 10 Play Store* ................................................................................................ 37 3 Safety Never attempt to disassemble your phone. You alone are responsible for how you use your phone and any consequences of its use. As a general rule, always switch off your phone wherever the use of a phone is prohibited. Use of your phone is subject to safety measures designed to protect users and their environment. Do not use your phone in damp areas (bathroom, swimming pool...). Protect it from liquids and other moisture. Do not expose your phone to extreme temperatures lower than - 10°C and higher than + 40°C. The physicochemical processes created by chargers impose temperature limits when charging the battery. Your phone automatically protects the batteries in extreme temperatures. Do not leave your phone within the reach of small children (certain removable parts may be accidentally ingested). Electrical safety: Only use the chargers listed in the manufacturer’s catalogue. Using any other charger may be dangerous; it would also invalidate your warranty. Line voltage must be exactly the one indicated on the charger’s serial plate. Aircraft safety: When traveling by plane, you will need to switch your phone off when so instructed by the cabin crew or the warning signs. Using a mobile phone may be dangerous to the operation of the aircraft and may disrupt the phone network. Its use is illegal and you could be prosecuted or banned from using cellular networks in the future if you do not abide by these regulations. Explosive materials: Please comply with warning signs at petrol station asking you to switch your phone off. You will need to comply with radio equipment usage restrictions in places such as chemical plants, fuel depots and at any location where blasting operations are under way. Electronic equipment: To avoid the risk of demagnetization, do not let electronic devices close to your phone for a long time. Electronic medical equipment: Your phone is a radio transmitter which may interfere with electronic medical equipment or implants, such as hearing aids, pacemakers, insulin pumps, etc. It is recommended that a minimum separation of 15 cm be maintained between the phone and an implant. Your doctor or the 4 manufacturers of such equipment will be able to give you any advice you may need in this area. Hospitals: Always make sure that your phone is switched off in hospitals when so instructed by warning signs or by medical staff. Road safety: Do not use your phone when driving. In order to give your full attention to driving, stop and park safely before making a call. You must comply with any current legislation. Distance of ope…

Text truncated - open the document above for the full version.

Differences Description We Cubix Latin America, LLC state: Product： Smart Phone Model Name： QSP-500D-BK, QSP-500D-WT;QSP-500D-BY;QSP-500D-BB; QSP-500D-BN;QSP-500D-BG; QSP-500D-BP; QSP-500D-WY;QSP-500D-WB;QSP-500D-WN QSP-500D-WG;QSP-500D-WP Trade Name: QUO FCC ID: 2ACDEQSP500DBK The electrical circuit design, layout, components used and internal wiring for above models are identical, only the model name is different. Signatory Date 2015-3-25 Signature Name: ELIAHU SIBONI Title: Commercial Director Company: Cubix Latin America, LLC Address: 2841 NW 107th Ave, Doral Florida, United States

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2Rev 5.0 Cubix Latin America, LLC 2015.3.18 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, Cubix Latin America, LLC hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): (Product description, model name): Product description: Smart Phone model name: QSP-500D-BK; QSP-500D-WT;QSP-500D-BY;QSP-500D- BB; QSP-500D-BN;QSP-500D-BG; QSP-500D-BP;QSP-500D-WY;QSP- 500D-WB;QSP-500D-WN;QSP-500D-WG;QSP-500D-WP FCC ID: 2ACDEQSP500DBK Sincerely, Client’s signature : ELIAHU SIBONI Client’s name / title: Commercial Director Applicant company：Cubix Latin America, LLC address： 2841 NW 107th Ave, Doral Florida , United States

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 Cubix Latin America, LLC 2015.3.18 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ACDEQSP500DBK We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description - Tune up Procedure - Part List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : ELIAHU SIBONI Client’s name & title : Commercial Director Contact information / address: Cubix Latin America, LLC / 2841 NW 107th Ave, Doral Florida , United States

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8 Photo 9 Photo 10 Photo 11

Label Smart Phone Model name: QSP-500D-BK Brand name: QUO FCC ID: 2ACDEQSP500DBK This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. label

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 BT/WIFI /GPS ANTENNA GSM/WCDMA ANTENNA Photo 3 Photo 4 Photo 5

FCC ID : 2CDEQSP500DBK RF EXPOSURE EVALUATION METHOD SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. FCC ID : 2CDEQSP500DBK Maximum measured transmitter power. BT The worst case frequency Maximum Peak Conducted Output Power Tune up tolerance Max Antenna Gain GHz dBm dBm dBi 2.402 3.090 3.5±1 0 2.441 3.846 3.5±1 0 2.480 4.265 3.5±1 0 Remark: The best case gain of the antenna is 0 dBi. 0 dBi logarithmic terms convert to numeric result is nearly 1 (2.402GHz) -4.5 dbm=2.8184mw (2.441GHz) -4.5 dbm=2.8184mw (2.480GHz) -4.5 dbm=2.8184mw BT: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 2.8184/5*√2.402=0.8736≤3.0 [(mid. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 2.8184/5*√2.441=0.8807≤3.0 [(min. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 2.8184/5*√2.480=0.8877≤3.0 Threshold at which no SAR required is 0.8877≤ 3.0 for 1-g SAR, Separation distance is 5mm. Conclusion: No SAR is required.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. 1/F, Building B, Zhuoke Science Park, Chongqing Road, Fuyong, Baoan District, Shenzhen, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] FCC TEST REPORT Report No: STS1503045F02 Issued for Cubix Latin America, LLC 2841 NW 107th Ave,Doral Florida，United States Product Name: Smart Phone Brand Name: QUO Model No.: QSP-500D-BK Series Model: QSP-500D-WT;QSP-500D-BY;QSP-500D-BB; QSP-500D-BN;QSP-500D-BG;QSP-500D-BP; QSP-500D-WY;QSP-500D-WB;QSP-500D-WN; QSP-500D-WG;QSP-500D-WP FCC ID: 2ACDEQSP500DBK Test Standard: FCC Part 15.247 S T L A B S Page 2 of 69 Report No.: STS1503045F02 TEST RESULT CERTIFICATION Applicant’s name ................. : Cubix Latin America, LLC Address ................................. : 2841 NW 107th Ave,Doral Florida，United States Manufacture's Name ............ : KBX GROUP Address ................................. : Avenida 1ra, Calle B y C manzana 58, France Field Colon Panama Product description Product name ........................... : Smart Phone Band name ................................ : QUO Model and/or type reference ............................. : QSP-500D-BK Ratings ................................... DC 5V/1A Standards ............................. : FCC Part 15.247 Test procedure ............................... : ANSI C63.10-2013 This device described above has been tested by STS, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document may be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ........................................... : Date (s) of performance of tests ............. : 18 Mar. 2015 ~24 Mar. 2015 Date of Issue.......................................... : 25 Mar. 2015 Test Result ............................................. : Pass Testing Engineer : (Jin Ming) Report writing : (Sunny zheng) Authorized Signatory : (Bovey Yang) Page 3 of 69 Report No.: STS1503045F02 Table of Contents Page 1. SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2. GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 9 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.5 DESCRIPTION OF SUPPORT UNITS 11 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3. EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 TEST SETUP 14 3.1.4 EUT OPERATING CONDITIONS 14 3.1.5 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 17 3.2.1 RADIATED EMISSION LIMITS 17 3.2.2 TEST PROCEDURE 18 3.2.3 DEVIATION FROM TEST STANDARD 18 3.2.4 TEST SETUP 19 3.2.5 EUT OPERATING CONDITIONS 20 3.2.6 TEST RESULTS 21 4. CONDUCTED SPURIOUS EMISSIONS 27 4.1 REQUIREMENT 27 4.2 TEST PROCEDURE 27 4.3 TEST SETUP 27 4.4 EUT OPERATION CONDITIONS 27 4.5 TEST RESULTS 28 5. NUMBER OF HOPPING CHANNEL 37 5.1 APPLIED PROCEDURES / LIMIT 37 5.2 TEST PROCEDURE 37 5.3 TEST SETUP 37 Page 4 of 69 Report No.: STS1503045F02 Table of Contents Page 5.4 EUT OPERATION CONDITIONS 37 5.5 TEST RESULTS 38 6. AVERAGE TIME OF OCCUPANCY 39 6.1 APPLIED PROCEDURES / LIMIT 39 6.2 TEST PROCEDURE 39 6.3 TEST SETUP 39 6.4 EUT OPERATION CONDITIONS 39 6.5 TEST RESULTS 40 7. HOPPING CHANNEL SEPARATION MEASUREMEN 46 7.1 APPLIED PROCEDURES / LIMIT 46 7.2 TEST PROCEDURE 46 7.3 TEST SETUP 46 7.4 EUT OPERATION CONDITIONS 46 7.5 TEST RESULTS 47 8. BANDWIDTH TEST 53 8.1 APPLIED PROCEDURES / LIMIT 53 8.2 TEST PROCEDURE 53 8.3 TEST SETUP 53 8.4 EUT OPERATION CONDITIONS 53 8.5 TEST RESULTS 54 9. PEAK OUTPUT POWER TEST 60 9.1 APPLIED PROCEDURES / LIMIT 60 9.2 TEST PROCEDURE 60 9.3 TEST SETUP 60 9.4 EUT OPERATION CONDITIONS 60 9.5 TEST RESULTS 61 10. ANTENNA REQUIREMENT 67 10.1 STANDARD REQUIREMENT 67 10.2 EUT ANTENNA 67 APPENDIX- PHOTOS OF TEST SETUP 68 Page 5 of 69 Report No.: STS1503045F02 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(a)(1) Hopping Channel Separation PASS 15.247(b)(1) Peak Output Power PASS 15.247(c) Radiated Spurious Emission PASS 15.247(d) Conducted Spurious Emission PASS 15.247(a)(iii) Number of Hopping Frequency PASS 15.247(a)(iii) Dwell Time PASS 15.247(a)(1) Bandwidth PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 69 Report No.: STS1503045F02 1.1 TEST FACILITY Shenzhen STS Test Services Co., Ltd. Add. : 1/F, Building B, Zhuoke Science Park, Chongqing Road, Fuyong, Baoan District, Shenzhen, China. FCC Registration No.: 842334; IC Registration No.: 12108A-1 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±3.18dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.71dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 69 Report No.: STS1503045F02 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Smart Phone Trade Name QUO Model Name QSP-500D-BK Serial Model QSP-500D-WT;QSP-500D-BY;QSP-500D-BB; QSP-500D-BN;QSP-500D-BG;QSP-500D-BP; QSP-500D-WY;QSP-500D-WB;QSP-500D-W; QSP-500D-WG;QSP-500D-WP Model Difference Only difference in m…
