2AD8UAWEWAB01Nokia AWEWA/AWEWB Airscale mmWave Radio 5G n260 39 GHz

Applicant: Nokia Solutions and Networks, OY -5 - FCC ID: 2AD8UAWEWAB01 Nokia Solutions and Networks, OY Federal Communications Commission Authorization and Evaluation Division Agent Authorization Letter Date: October 23, 2020 We, Nokia Solutions and Networks - OY, declare that Raymond Johnson, Walter Majkowski, Steven Gordon and Qin Yu of Nokia Global Products Compliance Laboratory (GPCL) are authorized agents to sign applications pertinent to FCC and Industry Canada applications. These employees of Nokia Global Product Compliance Laboratory are authorized to make representations to the FCC, Industry Canada and their respective Telecommunications Certified Body (TCB) agents on our behalf. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in FCC and Industry Canada's regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by the TCB, still resides with Nokia Solutions and Networks. I hereby certify on behalf of Nokia Solutions and Networks ("Applicant") that neither Applicant nor any party to the application (officers, directors, and 5% shareholders) is subject to a denial of Federal benefits that includes FCC benefits pursuant to section 5301 of the Anti-Drug Abuse Act of 198821 U.S.C. 853a. Sincerely yours, Terry Schwenk Title: R&D Engineer – Regulatory Compliance Nokia Solutions and Networks, OY TEL: 1.847.809.6952 FAX: 1.224.248.8208 E‐mail: [email protected]

Applicant: Nokia Solutions and Networks, OY -4 - FCC ID: 2AD8UAWEWAB01 Nokia Solutions and Networks, OY Federal Communications Commission Authorization and Evaluation Division Permanent Confidentiality Request Letter Date: July 20, 2021 Confidentiality Request for: FCC ID: 2AD8UAWEWAB01 To Whom It May Concern, Pursuant to FCC 47 CRF 0.457(d) and 0.459, Section 10, Nokia Solutions and Networks requests that a part of the subject FCC and/or IC application listed below be held permanently confidential and permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. • Exhibit 5 Tune-Up Procedure and Drive levels • Exhibit 6 Operating Description, Circuitry for Determining Frequency • Exhibit 7 Complete Circuit Diagrams • Exhibit 8 Instruction Book (Manual) • Exhibit 9 Internal Photographs of the Equipment • Exhibit NDA- Non-Disclosure Agreement - NDA Confidentiality of the User Manual is maintained by requiring that any party that is supplied a user manual must first sign a non-disclosure agreement. Currently only cellular system operators have access to these manuals. Internal photos are kept confidential by virtue of the fact that the end product is a non- consumer product, certified and housed in a sealed enclosure, and is only accessible by trained /approved maintenance personnel. Further, the Applicant has spent substantial effort in developing this product, some aspects of which are deemed to be trade secret and proprietary. Having the subject information easily available to our competitors in this market would negate the advantage we have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Sincerely yours, Terry Schwenk Title: R&D Engineer – Regulatory Compliance Nokia Solutions and Networks, OY TEL: 1.847.809.6952 FAX: 1.224.248.8208 E-mail: [email protected]

Nokia Solutions and Networks, OY Timco Engineering Inc. FCC Authorized Telecommunications Certification Body (TCB) Nokia, Global Product Compliance Laboratory 600-700 Mountain Avenue Room 5B-108 Murray Hill, New Jersey 07974-0636 USA July 20, 2021 Bruno Clavier- General Manager Timco Engineering Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 Dear Mr. Clavier The Nokia AWEWA/B Airscale mmWave Radio 5G n260 39 GHz base unit is the subject of this request for an initial Product Certification under FCC ID: 2AD8UAWEWAB01. This application is for the AC & DC powered base units. Product Certification of the Extension Modules will be processed under a separate application and for its own FCC ID. The AWEWA/B Airscale mmWave Radio 5G n260 39 GHz is part of our ASMR family of products. This system is composed of a base unit and up to two extension modules. The Radio Base Unit, an AWEWA (AC version) or an AWEWB (DC version) can be paired with the FA3WA Extension Modules to form a 360 degree coverage transceiver system. The Base units and Extension units incorporate identical mmWave 5G LTE / New Radio Transceiver modules. The transceiver modules implement two individually polarized 8x12 active element phased arrays. These 1400 MHz instantaneous downlink bandwidth units have a total power output capability of 52 dBm EIRP per polarization for a total combined power of 55 dBm EIRP. It can be configured to provide one to eight carriers of 97M0G7W emissions designator in the Upper Microwave Flexible Use Service spectrum (37 – 40 GHz) as allowed under 47CFR Part 30. The operational parameters allows the unit to place up to eight carriers anywhere in the US n260 spectrum. The total RF power will be divided among the one to eight carriers anywhere in the spectrum. Thus, any carrier configuration can provide up to the specified power of 52 dBm EIRP per polarization for a total combined power of 55 dBm EIRP Nokia Bell Labs, part of the Nokia family of companies, hereby requests certification for Multicarrier operation with up to eight carriers utilizing this 5G New Radio OFDM based air interface. The required hardware design information and all of the required supporting exhibits are attached. The measurement exhibits attached to this application demonstrate full compliance with FCC Part 30 following the procedural requirements specified in FCC Part 2 Subpart J – Equipment Authorization Procedures. The data, summarized below, is in the form presently used by the Commission’s Radio Equipment List. Equipment Identification: 2AD8UAWEWAB01 Rules Part Number: Part 30 Emissions Designators: 97M0G7W, 497MG7W and 797MG7W (5G-NR LTE-TDD Based) Frequency Range: Transmit/ Receive: 37 – 40 GHz Output Power: 52 dBm EIRP per polarization, 55 dBm EIRP Total Output for 2 polarizations operating in a 2x2 MIMO configuration One through Eight Carrier MIMO Operation Frequency Tolerance: ± 0.05 ppm Attached are the FCC Form 731 (Application for Equipment Authorization – Radio Frequency Devices), the required measurement data and exhibits specific to this request for authorization of the AWEWA/B Airscale mmWave Radio 5G n260 39 GHz Radio Unit This request also authorizes TIMCO Engineering Inc. to submit a KDB PAG request for processing of this filing. The technical or non-technical contact at Nokia Bell Labs will comply with any request for additional information should the need arise. The attached exhibits with the applicable FCC Rule section are assembled and presented in accordance with the Table of Contents attachment. Applicant: Nokia Solutions and Networks, OY -2 - FCC ID: 2AD8UAWEWAB01 Nokia Solutions and Networks, OY Should there be any questions or procedural issues please feel free to contact me by email and/or phone. Sincerely, Raymond J. Johnson Technical Manager FCC Compliance Test Group Nokia, Global Product Compliance Laboratory Phone: +1 908 679 6220 email: [email protected] Primary Administrative Contact Raymond J. Johnson Technical Manager FCC Compliance Test Group Nokia, Global Product Compliance Laboratory Building 5A-127 600 Mountain Avenue Murray Hill, NJ 07974 Phone: +1 908 679 6220 email: ray.johnson@ nokia-bell-labs.com Filing Engineer W. Steve Majkowski NCE Filing Lead Engineer Nokia, Global Product Compliance Laboratory Building 5B-103 600 Mountain Avenue Murray Hill, NJ 07974 Phone +1 908 608-8004 email: steve.majkowski@ nokia-bell-labs.com Att. Table of Contents for the AWEWA/B Airscale mmWave Radio 5G n260 39 GHz Product Certification Report Applicant: Nokia Solutions and Networks, OY -3 - FCC ID: 2AD8UAWEWAB01 Nokia Solutions and Networks, OY TABLE OF CONTENTS Cover Letter Permanent Confidentiality Request Letter Agent Authorization Letter Exhibit NDA- - Non Disclosure Agreement (Confidential) - Exhibit Number FCC Rule Number Description 1 Section 2.1033(a) FCC Form 731 2 Section 2.911(d) Qualifications and Certifications 3 Section 2.1033(c)(1,2, 4-7) Manufacturers, FCC Identifier, Emission, Range of RF Power & Frequency 4 Section 2.1033(c)(11) Drawing of the Identification Label 5 Section 2.1033(c)(8,9) Active Circuit Devices Drive Levels, Tune-Up procedure (Confidential) 6 Section 2.1033(c)(10,13) Block Diagram, Operational Description, Circuitry for Determining Frequency (Confidential) 7 Section 2.1033(c)(10) Complete Circuit Diagrams (Confidential) 8 Section 2.1033(c)(12,3) Instruction Book (Installation Manual or User’s Manual) (Confidential) 9 Section 2.1033(c)(12) Internal Photographs of the Equipment (Confidential) 10 Section 2.1033(c)(12) External Photographs of the Equipment 11 Section 2.1033(c)(10, 13) Description of Modulation System, 12 Section 2.1033(c)(21) Photographs of the Test Setups Test Report Section Number FCC Rule Number Description of Test Report Exhibits 4 Section 2.1033(c)(14) Listing of Required Measurements 4.1 Section 2.1046 Measurement of Radio Frequency Power Output 4.2 Section 2.1047 Measurement of Modulation Characteristics 4.3 Section 2…

Text truncated - open the document above for the full version.

Applicant: Nokia Solutions and Networks, OY -72 - FCC ID: 2AD8UAWEWAB01 Nokia Solutions and Networks, OY EXHIBIT 11: DETAILED DESCRIPTION OF THE MODULATION SYSTEM SECTION 2.1033(c) (13) For equipment employing digital modulation techniques, a detailed description of the modulation system to be use, including response characteristics of any filters provided, and a description of the modulating wavetrain, shall be submitted for the maximum rated conditions under which the equipment will be operated. Response The Nokia AWEWA/B 5G AirScale 39 GHz mmWave Radio supports the LTE Based 5G New Radio access technology defined in 3GPP, including multiple- input multiple-output (MIMO). The 5G-NR access technologies are being developed and standardized under 3GPP TS 38-x, release 15 for radio type 2-O. The latest released document detailing modulation was: 3GPP TS 38.211 V15.6.0 (2019-06) 3rd Generation Partnership Project; Technical Specification Group Radio Access Network; NR; Physical channels and modulation (Release 15) This above standard incorporates coding for QPSK, 16QAM, and 64QAM so the overall spectral appearance is similar to LTE. Additional information is in Exhibit 6 of this application.

Applicant: Nokia Solutions and Networks, OY -10 - FCC ID: 2AD8UAWEWAB01 Nokia Solutions and Networks, OY EXHIBIT 2 QUALIFICATIONS and CERTIFICATIONS October 30, 2020 Section 2.911 (d) QUALIFICATION OF ENGINEERS Section 2.911 (d) Technical test data shall be signed by the person who performed or supervised the tests. The person signing the test data shall attest to the accuracy of such data. The Commission may require such person to submit a statement showing that he is qualified to make or supervise the required measurements. Walter Steven Majkowski is a Member of Technical Staff at Nokia Global Product Compliance Laboratory which is part of Nokia Bell Laboratories. He holds a BSEE from New Jersey Institute of Technology and was trained in the FCC testing procedures. Mr. Majkowski is a Lead engineer for the filing of Wireless Base station products at Nokia Bell Laboratories. Mr. Majkowski is a NARTE certified EMC engineer, Certificate number EMC-001859-NE, and has over forty years of EMC design and testing experience. Mr. Majkowski has previously filed over sixty five different wireless products with the FCC and Canada. Raymond J. Johnson Technical Manager Nokia Bell Labs Nokia Global Products Compliance Laboratory Murray Hill, NJ 07974 Phone: +1 908 679 6220 SECTION 2.911 (e)(g) CERTIFICATION OF TECHNICAL TEST DATA Section 2.911(e) Technical test data submitted to the TCB and to the Commission shall be signed by the person who performed or supervised the tests. The person signing the test data shall attest to the accuracy of such data. The Commission or TCB may require the person signing the test data to submit a statement showing that they are qualified to make or supervise the required measurements. Section 2.911(g) Signed, as used in this section, means an original handwritten signature; however, the Office of Engineering and Technology may allow signature by any symbol executed or adopted by the applicant with the intent that such symbol be a signature, including symbols formed by computer-generated electronic impulses. I hereby certify that the test data are the results of tests performed or supervised by me. Walter Steven Majkowski NCE Member Technical Staff Nokia Bell Labs Nokia Global Products Compliance Laboratory Murray Hill, NJ 07974 Phone +1 908 608 8004 email: [email protected]

Applicant: Nokia Solutions and Networks, OY -11 - FCC ID: 2AD8UAWEWAB01 Nokia Solutions and Networks, OY Exhibit 3 FCC REQUIRED INFORMATION The following information is presented in the content and format requested by the FCC: Section 2.1033 (c)(1): The full name and mailing address of the manufacturer of the device and the applicant for certification Manufacturer: Nokia Solutions and Networks, OY 2000 Lucent Lane Naperville, Illinois 60563 Attention: Terry P. Schwenk Applicant: Nokia Solutions and Networks, OY 2000 Lucent Lane Naperville, Illinois 60563 Attention: Terry P. Schwenk Phone: (847) 809-6952 email: [email protected] Section 2.1033(c)(2): FCC Identifier: 2AD8UAWEWAB01 Section 2.1033(c)(4):Type or types of emission: 97M0G7W, 497MG7W – (a four carrier aggregate of 97M0G7W) 797MG7W – (an eight carrier aggregate of 97M0G7W) This Transceiver System supports the 3GPP 5G New Radio and other LTE technologies. The subject of this certification request is for operation using the 3GPP 5G New Radio modulation format in QPSK, 16QAM and 64QAM (LTE-TDD) for one to seven carriers. The transceiver can be configured for the various transmit configurations by varying the digital information provided from the baseband channel electronics alone without physical, hardware or circuit changes to the transceiver. Section 2.1033(c)(5): Frequency range, Transmit / Receive: 37.0-40.0 GHz Section 2.1033(c)(6): Range of operating power values or specific operating power levels, and description of any means provided for variation of operating power. Response: The Nokia AWEWA/B 5G AirScale mmWave Radio, FCC ID: 2AD8UAWEWAB01 generates two orthogonal 52 dBm EIRP transmit beams (horizontally and vertically polarized) for a total transmit power of 55 dBm EIRP. Each of the beams can be configured to provide one to eight carriers of 97M0G7W emissions designator in the Upper Microwave Flexible Use Service spectrum (37 – 40 GHz) as allowed under 47CFR Part 30. The operational parameters are one to eight 97M0G7W carriers in any 1400 MHz portion of the 37 – 40 GHz US n260 spectrum. The total RF power will be divided among one to eight carriers anywhere in the two portions of the spectrum. Thus, any carrier configuration can provide up to the specified power of 52 dBm EIRP per polarization for a total combined power of 55 dBm EIRP RF Power control of the AWEWA/B transceiver is accomplished via software control of the data stream and the RF power gain. The software controls the RF power gain through the RF transmit path with a Digital Step Attenuator (DSA) to maintain the correct RF power of the AWEWA/B over frequency and temperature. The DSA gain control has a resolution of 0.25 dB per step and an overall range of 11 dB. Separate circuitry is provided to inhibit the carrier output if a synthesizer in the transmit path loses lock. Applicant: Nokia Solutions and Networks, OY -12 - FCC ID: 2AD8UAWEWAB01 Nokia Solutions and Networks, OY Exhibit 3 FCC REQUIRED INFORMATION continued Section 2.1033(c)(7): Maximum power rating as defined in the applicable part (s) of the rules. Response: This product can produce two individual 52dBm EIRP beams (158.5 W EIRP each). The sum of these two 52 dBm EIRP beams results in the Maximum Total Power of 55 dBm EIRP (317W EIRP) The maximum continuous RF output power available is the sum of the horizontal and vertical transmit beams generated by individual 8x12 antenna assemblies. There are no antenna connections. Each antenna assembly distributes 28 dBm of RF power with an overall gain of 24 dBi. This results in a radiated power of 52dBm EIRP per antenna assembly for a Total Radiated Power of 55dBm EIRP Section 2.1033 (c)(10): A description of all circuitry and devices for determining and stabilizing frequency. Response: The Nokia AWEWA/B 5G AirScale 39 GHz mmWave Radio, FCC ID: 2AD8UAWEWAB01 is a 1400 MHz instantaneous bandwidth digital transceiver designed to operate in the Part 30 Upper Microwave Flexible Use Service spectrum. The FPGA to A/D transceiver in this product is designed to generate 50 and 100 MHz carrier emission bandwidth 5G- NR signals which are then up-converted to the n260, 37 – 40 GHz frequency band. The frequency stability of the 5G-NR carrier frequency is maintained with an accuracy better than the rated ± 0.05 ppm by reference frequency locking the phase-locked-loop (PLL) circuitry to a stable internal reference oscillator. External reference timing is provided by locking to an external frequency disciplined reference signals. Separate circuitry is provided to inhibit the carrier output if a synthesizer in the transmit path loses lock The AWEWA/B 5G AirScale 39 GHz mmWave Radio is supplied its frequency discipline synchronization for reference from the baseband information source which is GPS capable.

Applicant: Nokia Solutions and Networks, OY -68 - FCC ID: 2AD8UAWEWAB01 Nokia Solutions and Networks, OY EXHIBIT 10: EXTERNAL PHOTOGRAPHS SECTION 2.1033 (c) (12) Photographs (8"xlO") of the equipment of sufficient clarity to reveal equipment construction and layout, including meters, if any, and labels for controls and meters and sufficient views of the internal construction to define component placement and chassis assembly. Insofar as these requirements are met by photographs or drawings contained in the instruction manuals supplied with the product certification request, additional photographs are necessary only to complete the required showing. Response: The external photographs of the Nokia AWEWA/B 5G AirScale 39 GHz mmWave Radio, FCC ID: 2AD8UAWEWAB01 are below. Applicant: Nokia Solutions and Networks, OY -69 - FCC ID: 2AD8UAWEWAB01 Nokia Solutions and Networks, OY Exhibit 10 – External Photographs continued Nokia AirScale 39 GHz Radio Unit (AWEWA/B ),, FCC ID: 2AD8UAWEWAB01 Front View AWEWA/B (Base Unit) ) Back View AWEWA/B (Base Unit) Applicant: Nokia Solutions and Networks, OY -70 - FCC ID: 2AD8UAWEWAB01 Nokia Solutions and Networks, OY Exhibit 10 – External Photographs continued Right Side AWEWA/B (Base Unit) Left Side AWEWA/B (Base Unit) Applicant: Nokia Solutions and Networks, OY -71 - FCC ID: 2AD8UAWEWAB01 Nokia Solutions and Networks, OY Exhibit 10 – External Photographs continued Top View AWEWA/B (Base Unit) Bottom Views AWEWA/B (Base Unit)

1 / 15 LPITPN2I4Q5L-1109616211-1853 PUBLIC © Nokia 2021 RF exposure compliance assessment 5G Airscale mmWave Radio Solution – AWEWA/B + FA3WA US - FCC ID: 2AD8UAWEWAB01 (AWEWA/AWEWB); 2AD8UFA3WA01 (FA3WA) Canada – IC: 109D-AWEWAB01 (AWEWA/AWEWB); 109D-FA3WA01 (FA3WA) Author Kamil Bechta Owner Christophe Grangeat Organization MN RAN Arch Approver Terry Schwenk Document Type Final test report Document ID LPITPN2I4Q5L-1109616211-1853 Document location https://nokia.sharepoint.com/:f:/r/sites/EMFProductManagement/Shared%20Documents/General/Products- RF-exposure-assessment/AWEWA?csf=1&web=1&e=yegEee Change History Version Status Date Author Owner Reviewed by Reviewed date Approver Approval date Description of changes 1.0 Final 25-05-2021 K. Bechta C. Grangeat C. Grangeat 25-05-2021 T. Schwenk 16-06-2021 This material, including documentation and any related computer programs, is protected by copyright controlled by Nokia. All rights are reserved. Copying, including reproducing, storing, adapting or translating, any or all of this material requires the prior written consent of Nokia. This material also contains confidential information, which may not be disclosed to others without the prior written consent of Nokia. 2 / 15 LPITPN2I4Q5L-1109616211-1853 PUBLIC © Nokia 2021 Contents 1 General content .................................................................................................................... 4 2 References ............................................................................................................................. 4 Applicable RF exposure standards and regulations ........................................................ 4 Product and assessment method ...................................................................................... 5 3 RF exposure limits ................................................................................................................ 5 4 Description of the equipment under test (EUT) .............................................................. 6 5 RF exposure assessment method...................................................................................... 10 6 RF exposure computation results ...................................................................................... 10 Regions of application: EU/ICNIRP, Australia/NZ, Canada and US/related .................. 10 7 Conclusion and installation recommendations ................................................................ 14 List of Tables Table 1 – Applicable RF exposure levels in n260 band expressed in power density .......................... 5 Table 2 – AWEWA/B and FA3WA product general technical characteristics ......................................... 6 Table 3 - Reference system used in this report (from NGMN white paper [15]) ......................................... 7 Table 4 – Antenna pattern models for RF exposure assessment ......................................................... 8 Table 5 – Antenna gain characteristics for various beam steering directions used during EMF evaluation9 Table 6 - Validation of the antenna model at 38500 MHz ......................................................................... 10 Table 7 – AWEWA/B and FA3WA RF exposure compliance distances based on the time-averaged maximum transmitted power of 1.42 W (corresponding to 1.26 W rated max transmitted power) ...................................................................................................................................................................... 14 Table 8 – AWEWA/B and FA3WA RF exposure compliance distances based on the time-averaged actual maximum transmitted power of 0.36 W (corresponding to 1.26 W rated max transmitted power) .......................................................................................................................................................... 15 List of Figures Figure 1 – Shape of the compliance boundary used for the RF exposure compliance assessment (from [4]). ...................................................................................................................................................... 9 3 / 15 LPITPN2I4Q5L-1109616211-1853 PUBLIC © Nokia 2021 Figure 2 – Example 3D exposure with the shape of compliance boundaries.................................... 11 Figure 3 – Top view of the power density for the time-averaged maximum transmitted power of 1.42 W and the beam oriented in azimuth = 0° & elevation = 0° ....................................................... 11 Figure 4 – Top view of the power density for the time-averaged actual maximum transmitted power of 0.36 W and the beam oriented in azimuth = 0° & elevation = 0° ...................................... 11 Figure 5 – Side view of the power density for the time-averaged maximum transmitted power of 1.42 W and the beam oriented in azimuth = 0° & elevation = +20° .................................................. 12 Figure 6 – Side view of the power density for the time-averaged actual maximum transmitted power of 0.36 W and the beam oriented in azimuth = 0° & elevation = +20° ................................. 12 Figure 7 – Side view of the power density for the time-averaged maximum transmitted power of 1.42 W and the beam oriented in azimuth = 0° & elevation = -20° ................................................... 12 Figure 8 – Side view of the power density for the time-averaged actual maximum transmitted power of 0.36 W and the beam oriented in azimuth = 0° & elevation = -20° .................................. 13 Figure 9 – Top view of the power density for the time-averaged maximum transmitted power of 1.42 W and the beam oriented in azimuth = -60°/+60° & elevation = 0° ........................................ 13 Figure 10 – Top view of the power density for the time-averaged actual maximum transmitted power of 0.36 W and the beam oriented in azimuth = -60°/+60° & elevation = 0° ........................ 14 4 / 15 LPITP…

Text truncated - open the document above for the full version.

Global Product Compliance Laboratory 600-700 Mountain Avenue Room 5B-108 Murray Hill, New Jersey 07974-0636 USA TESTING NVLAP LAB CODE: 100275-0 FCC Certification Part 30 Test Report Product Evaluated AWEWA/B 5G n260 39GHz 8CC AWEWA / AWEWB FCC ID: 2AD8UAWEWAB01 Customer Nokia Solutions and Networks, OY 2000 Lucent Lane Naperville, Illinois 60563 Test Laboratory Nokia Bell Labs Nokia, Global Product Compliance Laboratory 600-700 Mountain Avenue, Rm 5B-108 Murray Hill, New Jersey 07974-0636 USA Date July 20, 2021 This report shall not be reproduced, in whole or in part without the approval of Nokia Global Product Compliance Laboratory. This report must not be used by the recipient to claim product endorsement by NVLAP or any other agency of the U.S. Government. NOKIA – Public 2 Revisions Date Revision Section Change 7/14/2021 0 Initial Release 7/20/2021 1 1.0 FCC Test Site Designations Nokia Global Product Compliance Laboratory represents to the client that testing was done in accordance with standard procedures as applicable, and that reported test results are accurate within generally accepted commercial ranges of accuracy in accordance with the scope of our NVLAP Accreditation. Nokia Global Product Compliance reports only apply to the specific samples tested. This report is the property of the client. This report shall not be reproduced except in full without the written approval of the Nokia Global Product Compliance Laboratory. Nokia Global Product Compliance Laboratory is accredited with the US Department of Commerce National Institute of Standards and Technology's National Voluntary Laboratory Accreditation Program (NVLAP) for satisfactory compliance with criteria established in Title 15, Part 7 Code of Federal Regulations for offering test services for selected test methods in Electromagnetic Compatibility; Voluntary Control Council for Interference (VCCI), Japan; Australian Communications and Media Authority (ACMA). The laboratory is ISO 9001:2008 Certified. Nokia Global Product Compliance Laboratory represents to the client that the laboratory’s accreditation or any of its calibration or test reports in no way constitutes or implies product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. Prepared & Reviewed By: W. Steve Majkowski NCE Approved By: Ray Johnson 7/20/2021 7/20/2021 Product Certification Filing Lead Nokia Bell Labs Nokia, Global Product Compliance Laboratory Technical Manager Nokia Bell Labs Nokia, Global Product Compliance Laboratory Prepared By: Ann Chang 7/20/2021 Compliance Engineer Nokia Bell Labs Nokia, Global Product Compliance Laboratory FCC Certification Test Report Nokia, Global Product Compliance Laboratory FCC ID: 2AD8UAWEWAB01 Report No. : TR-2021-0072-FCC 30 Product: AWEWA/B 5G n260 39GHz 8CC NOKIA – Public 3 Table of Contents 1. ATTESTATION OF TEST RESULTS ................................................................................................................ 5 2. SUMMARY OF THE TEST RESULTS ............................................................................................................... 6 2.1 MEASUREMENT UNCERTAINTY .......................................................................................................................... 6 3. GENERAL INFORMATION .............................................................................................................................. 7 3.1 PRODUCT DESCRIPTIONS ................................................................................................................................ 7 3.2 EIRP/ PSD COMPLIANCE AND ANTENNA INFORMATION. ...................................................................................... 7 3.3 ANTENNA FAR FIELD DETERMINATION DISTANCE ................................................................................................ 8 4. REQUIRED MEASUREMENTS AND RESULTS ................................................................................................. 9 4.1 SECTION 2.1046 MEASUREMENT REQUIRED: RF POWER OUTPUT .......................................................... 10 4.1.1 RF Power Output Measurement ..................................................................................................... 10 4.1.1.1 RF Power Output Results ............................................................................…

Text truncated - open the document above for the full version.
