2ADCB-BMODITBMODIT Bluetooth LE Module

ACUITY BRANDS LIGHTING – MUTUAL CONFIDENTIALITY AGREEMENT THIS AGREEMENT is entered into and is effective as of Insert Date (the “Effective Date”) between Acuity Brands Lighting, Inc., a Delaware corporation (“ABL”) and Insert Name of Company, a corporation/business organized under the laws of the state of Insert State or Country of Incorporation (“Company”). The parties acknowledge that ABL and Company are in discussions about a potential business relationship between them (the "Business Relationship") in connection with which certain Confidential Information (as defined below) of ABL and Company may be disclosed to the other party. In consideration of the mutual covenants set forth below, ABL and Company each agree as follows: 1. Confidential Information. As used in this Agreement, the term “Confidential Information” means all information, whether or not reduced to writing, related to the potential business relationship or to the business of either party or its Affiliates (as defined below) that (a) is disclosed by one party or its Representatives (as defined below) (the “Disclosing Party”) to the other party (the "Recipient ") or observed by the Recipient on the Disclosing Party’s premises, and (b) is identified as confidential or with other similar designation(s) by the Disclosing Party, or would otherwise reasonably be understood to be confiden tial under the circumstances. Confidential Information includes but is not limited to data (technical and non-technical), formulas, patterns, compilations (including compilations of customer information), programs (including models), devices, methods (including design methods), techniques, drawings (including equipment drawings), processes, financial information (including sales forecasts), pricing, lists of actual or potential customers or suppliers (including identifying information about those customers), operational information, planning or strategy information, research and development information, information about existing and future products, and information about personnel matters of the Disclosing Party or its Affiliates. Confidential Information also includes information disclosed by a third party that otherwise meets the foregoing definition, and the fact that negotiations are taking place hereunder. An “Affiliate” means any legal entity that one of the parties hereto owns, that owns one of the parties or that is under common control with one of the parties. “Control” and “own” mean possessing a 50% or greater interest in an entity or the right to direct the management of the entity. 2. Exclusions. For purposes of this Agreement, the term “Confidential Information” does not include any data or information which: (a) the Recipient can establish was already known by the Recipient at the time of disclosure hereunder by the Disclosing Party; (b) is or becomes generally known to the public other than as a result of a disclosure by the Recipient; (c) is received by the Recipient from a third party, without restriction on disclosure, and without breaching any obligation of confidentiality about which the Recipient knew or should have known; or (d) is independently developed by the Recipient without use or reliance on, directly or indirectly, of Confidential Information received from Disclosing Party, as demonstrated from the written records of the Recipient. 3. Confidentiality and Non-Use of Confidential Information. Each of the parties hereto and its Representatives (a) must use the same care and discretion as it employs with its own confidential and proprietary information (but in no event less than reasonable care and discretion) to maintain in confidence, and prevent disclosures of, the Confidential Information of the other party, and (b) must not use the Confidential Information of the other party except to further the Business Relationship or as otherwise specifically authorized in writing by the Disclosing Party. Under no circumstances, except as expressly set forth below, shall the Recipient reproduce, distribute or otherwise provide, directly or indirectly, any Confidential Information of the other party to any person or entity outside of this Agreement without the consent of the Disclosing Party. Each party understands that in addition to its obligations to the other party under this Agreement, it may not use any Confidential Information of the other party in violation of any federal or state securities laws governing insider trading. Each party understands and will inform its Representatives that such laws prohibit any person, directly or indirectly, from buying or selling securities of any company while in possession of material non-public information regarding that company. 4. Permitted Disclosures. Disclosures of the Confidential Information of the Disclosing Party may be made only to Affiliates, employees, agents, advisors or independent contractors of the Recipient who are directly involved in performing or evaluating the Business Relationship, and who have a specific need to know such information, and who are obligated to hold the information in confidence and otherwise to comply with the terms of this Agreement (collectively, “Representatives ”). The Recipient agrees to instruct each of its Representatives to maintain the confidentiality of all of the Confidential Information, and shall be liable for any unauthorized disclosures of Confidential Information by the Recipient's Representatives. Neither party shall directly or indirectly contact, or discuss the Business Relationship contemplated under this Agreement, with any person who is not a designated Representative of the other party. 5. Mandatory Disclosure. If Confidential Information is required to be produced by law, court order or governmental authority, the Recipient must promptly notify the Disclosing Party of that obligation. The Recipient shall not produce or disclose any such Confidential Information until the Disclosing Party has (a) requested protection fr…

Text truncated - open the document above for the full version.

Figure 1: BMODIT Module with PIFA Antenna Figure 2: BMODIT Module with Flag Antenna Figure 3: BMODIT Module with Stubby Monopole Antenna Figure 4: BMODIT Module with NiTi Monopole Antenna

BMODIT Labeling Requirements Module Label A label will be stamped to the shield cover. The size of this label will be no greater than 16x16mm. And will contain the following text: The label can also contain information related to manufacturing identification. The above information is the only required information. Final Specification: FCC ID: 2ADCB-BMODIT IC: 6715C-BMODIT Acuity Brands Lighting Inc. BMODIT Module Label Picture Host Label A label will be affixed to the host device with the following text: The label will be properly sized to fit the application. If the host device is smaller than the palm of a hand, the label will be: The label will be properly sized to fit the application. Contains FCC ID: 2ADCB-BMODIT Contains IC: 6715C-BMODIT Acuity Brands Lighting Inc. BMODIT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Contains FCC ID: 2ADCB-BMODIT Contains IC: 6715C-BMODIT Acuity Brands Lighting Inc. BMODIT Example: User Manual: The BMODIT user manual will contain all information required to create a label.

5945 Cabot Parkway Suite 100 Alpharetta, GA 30005 USA Certification Exhibit FCC ID: 2ADCB-BMODIT FCC Rule Part: 47 CFR Part 2.1091 Project Number: 72156965 Manufacturer: Acuity Brands Lighting, Inc. Model: BMODIT RF Exposure Model(s): BMODITFCC ID: 2ADCB-BMODIT Report: AT72156965-2C0Page 2 General Information: Applicant: Acuity Brands Lighting, Inc. Device Category: Mobile Environment: General Population/Uncontrolled Exposure Technical Information: Antenna Type: Multiple Antenna Gains: Surface Mount Chip / 3dBi (Molex, P/N: 0479480001) PCB Trace / 3.2dB (Acuity, Custom) External PCB / 1.5dBi (Pulse, P/N: W3525BXXX) External Monopole / 3.1dB (Pulse, P/N: W9032) External Whip / 3dBi (Pulse, P/N: W1990WSA) Maximum Transmitter Conducted Power: 5.3dBm, 3.39mW Maximum System EIRP: 8.5dBm, 7.08mW Exposure Conditions: Greater than 20 centimeters MPE Calculation The Power Density (mW/cm 2 ) is calculated as follows: S = 2 4R PG  Where: S = power density (in appropriate units, e.g. mW/cm2) P = power input to the antenna (in appropriate units, e.g., mW) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) Table 1: MPE Calculation Antenna Transmit Frequency (MHz) Radio Power (dBm) Power Density Limit (mW/cm 2 ) Radio Power (mW) Antenna Gain (dBi) Antenna Gain (mW eq.) Distance (cm) Power Density (mW/cm 2 ) Chip 2402 5.3 1.00 3.39 3 1.995 20 0.001 Trace 2402 5.3 1.00 3.39 3.2 2.089 20 0.001 Ext PCB 2402 5.3 1.00 3.39 1.5 1.413 20 0.001 Monopole 2402 5.3 1.00 3.39 3.1 2.042 20 0.001 Whip 2402 5.3 1.00 3.39 3 1.995 20 0.001 Note: The device does not support simultaneous transmissions

5945 Cabot Pkwy, Suite 100, Alpharetta, GA 30005 Test Report FCC ID: 2ADCB-BMODIT IC: 6715C-BMODIT FCC Rule Part: 15.247 ISED Canada Radio Standards Specification: RSS-247 Report Number: AT72156965-1C0 Manufacturer: Acuity Brands Lighting, Inc. Model: BMODIT Test Begin Date: January 28, 2020 Test End Date: February 4, 2020 Report Issue Date: February 25, 2020 FOR THE SCOPE OF ACCREDITATION UNDER Certificate Number: 2955.09 This report must not be used by the client to claim product certification, approval, or endorsement by A2LA, NIST, or any agency of the Federal Government. Prepared By:Reviewed by: Jeremy PickensRyan McGann Senior Wireless EngineerTeam Leader TÜV SÜD America Inc.TÜV SÜD America Inc. This test report shall not be reproduced except in full. This report may be reproduced in part with prior written consent of TÜV SÜD America Inc. The results contained in this report are representative of the sample(s) submitted for evaluation. This report contains 31 pages 5945 Cabot Pkwy, Suite 100, Alpharetta, GA 30005 TABLE OF CONTENTS 1GENERAL ...................................................................................................................................... 3 1.1PURPOSE ....................................................................................................................................... 3 1.2APPLICANT INFORMATION ............................................................................................................ 3 1.3PRODUCT DESCRIPTION ................................................................................................................ 3 1.4TEST METHODOLOGY AND CONSIDERATIONS ............................................................................... 3 2TEST FACILITIES ....................................................................................................................... 5 2.1LOCATION ..................................................................................................................................... 5 2.2LABORATORY ACCREDITATIONS/RECOGNITIONS/CERTIFICATIONS .............................................. 5 2.3RADIATED EMISSIONS TEST SITE DESCRIPTION ............................................................................ 6 2.3.1Semi-Anechoic Chamber Test Site – Chamber A ..................................................................... 6 2.3.2Semi-Anechoic Chamber Test Site – Chamber B ..................................................................... 7 2.4CONDUCTED EMISSIONS TEST SITE DESCRIPTION ......................................................................... 8 2.4.1Conducted Emissions Test Site ................................................................................................. 8 3APPLICABLE STANDARD REFERENCES ............................................................................. 9 4LIST OF TEST EQUIPMENT ..................................................................................................... 9 5SUPPORT EQUIPMENT.............................................................................................................10 6EQUIPMENT UNDER TEST SETUP BLOCK DIAGRAM ....................................................10 7SUMMARY OF TESTS................................................................................................................11 7.1ANTENNA REQUIREMENT –FCC:15.203 .....................................................................................11 7.2POWER LINE CONDUCTED EMISSIONS –FCC:15.207,ISEDCANADA:RSS-GEN 8.8 .................11 7.2.1Measurement Procedure .........................................................................................................11 7.2.2Measurement Results ..............................................................................................................11 7.36DB/99%BANDWIDTH –FCC:15.247(A)(2),ISEDCANADA:RSS-2475.2(A),RSS-GEN6.7 .13 7.3.1Measurement Procedure .........................................................................................................13 7.3.2Measurement Results ..............................................................................................................13 7.4FUNDAMENTAL EMISSION OUTPUT POWER –FCC:15.247(B)(3),ISEDCANADA:RSS-2475.4(D) .....................................................................................................................................................16 7.4.1Measurement Procedure .........................................................................................................16 7.4.2Measurement Results ..............................................................................................................16 7.5EMISSION LEVELS ........................................................................................................................17 7.5.1Emissions into Non-restricted Frequency Bands – FCC: 15.247(d); ISED Canada: RSS-247 5.5 ............................................................................................................................................17 7.5.2Emissions into Restricted Frequency Bands – FCC: 15.205, 15.209; ISED Canada: RSS-Gen 8.9 / 8.10..................................................................................................................................20 7.6MAXIMUM POWER SPECTRAL DENSITY IN THE FUNDAMENTAL EMISSION –FCC:15.247(E)ISED CANADA:RSS-2475.2(B) ............................................................................................................24 7.6.1Measurement Procedure .........................................................................................................24 7.6.2Measurement Results ..............................................................................................................24 8ESTIMATION OF MEASUREMENT UNCERTAINTY .........................................................26 9CONCLUSION .............................................................................................…

Text truncated - open the document above for the full version.

5945 Cabot Parkway Suite 100 Alpharetta, GA 30005 USA Certification Exhibit FCC ID: 2ADCB-BMODIT IC: 6715C-BMODIT FCC Rule Part: 15.247 ISED Canada Radio Standards Specification: RSS-247 Project Number: 72156965 Manufacturer: Acuity Brands Lighting, Inc. Model: BMODIT Test Setup Photos Model(s): BMODITFCC ID: 2ADCB-BMODITIC: 6715C-BMODIT Project: 72156965Page 2 Figure 1: Equipment Under Test – Antenna Port Conducted Measurements Figure 2: Equipment Under Test – Radiated Emissions <30MHz Model(s): BMODITFCC ID: 2ADCB-BMODITIC: 6715C-BMODIT Project: 72156965Page 3 Figure 3: Equipment Under Test – Radiated Emissions <1GHz Figure 4: Equipment Under Test – Radiated Emissions <1GHz Model(s): BMODITFCC ID: 2ADCB-BMODITIC: 6715C-BMODIT Project: 72156965Page 4 Figure 5: Equipment Under Test – Radiated Emissions >1GHz Figure 6: Equipment Under Test – Radiated Emissions >1GHz Model(s): BMODITFCC ID: 2ADCB-BMODITIC: 6715C-BMODIT Project: 72156965Page 5 Figure 7: Equipment Under Test – AC Conducted Emissions Figure 8: Equipment Under Test – AC Conducted Emissions Model(s): BMODITFCC ID: 2ADCB-BMODITIC: 6715C-BMODIT Project: 72156965Page 6 Figure 9: Equipment Under Test – Chip Antenna Figure 10: Equipment Under Test – Trace Antenna Model(s): BMODITFCC ID: 2ADCB-BMODITIC: 6715C-BMODIT Project: 72156965Page 7 Figure 11: Equipment Under Test – External PCB Antenna Figure 12: Equipment Under Test – External Monopole Antenna Model(s): BMODITFCC ID: 2ADCB-BMODITIC: 6715C-BMODIT Project: 72156965Page 8 Figure 13: Equipment Under Test – External Whip Antenna
