2ADCB-PLSSSAPush-to-Lock Sensor SensorSwitch Air

PLS - SSA Sensor Installation PLS - SSA Sensor is simple to install and remove, featuring a push ‑ to ‑ lock, push ‑ to ‑ release de sign for quick, easy installation and removal. 1. Push the cov er located on the trim of the luminaire to remove it. 2. Orient and push the se nsor to lock it into place. 3. Follow the same push motion to remove the sensor . Out-of-the-Box Defaults Create a Group Using IWP - IR After PLS - SSA Sensor is inserted without a group assignment, it will operate as a standalone device per its defaults. • Hold time 10-minutes (7.5 minute s 100% t o 10% and 2.5 minutes 10% to off) • Daylighting is Off • Security is Off PLS - SSA Sensor “ Push-to-Lock Sensor SensorSwitch Air ” Installation Instructions When the sensor is placed inside the luminair e and powe red , assign the group number using the IWP remote. • From the main menu, navigat e t o “Programmer Setting” and choose IR • Return to main menu and choose “Write Behaviors” and open “Group ID” • Use the number pad to “Assign the same group number to all the sensors that should operate together.” • A group will auto-form with the defaults shownin the out-of-box. Limit 40 devices n a group . Create a Group Using IWP - Bouetooth Securing the Group • From the main menu, navigate to “ SSAIR Commands” • Scroll and access to Secure Option • Use number pad to input a 6-digit PIN and send the value to a group sensor. • Allow 2 to 3 minutes for securing to complete. • IMPORTANT - If a group is not secure, itwill secure itself after 48 hours. A powercycle will be required to regain entry. While the sensor is unpowered (but not inserted) or still in it s p ackaging, assign the group number using the IWP remote. PLS - SSA Sensor devices utilize Bluetooth® mesh wireless communication. To connect using a mobile device, enable Bluetooth®, open the Clairity+ application, and follow the Sensor Switch AIR setup instructions. Startup, security, grouping, and lighting control functions may also be performed using the IWP Infrared Wireless Programmer." Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does causeharmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna.-Increase the separation between the equipment and receiver.-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. Any Changes expressly or modifications not approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment . This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment should be installed and operated with minimum distance 20cm between the radiator &you body.This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. ISEDC RSS warning This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions:(1) This device may not cause interference.(2) This device must accept any interference, including interference that may cause undesired operation of the device.Cet appareil contient un ou plusieurs émetteurs/récepteurs exempts de licence conformes aux normes RSS exemptes de licence d’Innovation, Sciences et Développement économique Canada. Son fonctionnement est soumis aux deux conditions suivantes :(1) Cet appareil ne doit pas causer d’interférences.(2) Cet appareil doit accepter toute interférence, y compris les interférences pouvant entraîner un fonctionnement indésirable. ISEDC Radiation Exposure Statement: This equipment complies with ISEDC RF radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment should be installed and operated with minimum distance 20cm between the radiator& your body.IC exposition aux radiations:Cet équipement est conforme aux limites d’exposition aux rayonnements RF de l’isedc établies pour un environnement non contrôlé.Cet émetteur ne doit pas être co-localisés ou fonctionner en conjonction avec une autre antenne ou émetteur.Cet équipement doit être installé et utiliséavec une distance minimale de 20cm entre leradiateur & votre corps.
