Prüfbericht - Produkte Test Report - Products Prüfbericht - Nr.: Test Report No. 60429423 001 Seite 26 von 27 Page 26 of 27 6 Safety Human Exposure 6.1 Radio Frequency Exposure Compliance 6.1.1 Electromagnetic Fields RESULT: Pass Test Specification Test standard : CFR47 FCC Part 2: Section 2.1093 CFR47 FCC Part 1: Section 1.1310 FCC KDB Publication 447498 D01 v06 Hence the EUT is excluded from SAR evaluation according to FCC KDB Publication 447498 D01 General RF Exposure Guidance v06. The maximum peak output power of the transmitter is -14.20dBm (0.038 mW), which is far below the SAR exclusion threshold level 10 mW.

TUV Rheinland (Guangdong) Ltd. No.199 Kezhu Road, Guangzhou Science City, Guangzhou 510663, Guangdong Province P.R. China Mail: [email protected] Web: www.tuv.com Test Report - Products Test report no.: 60429423 001 Auftrags-Nr.: Order no.: 170109889 Seite 1 von 27 Page 1 of 27 Kunden-Referenz-Nr.: Client Reference No.: 1458770 Auftragsdatum: Order date.: 2019.05.14 Auftraggeber: Client: Adam Hall GmbH Adam-Hall-Str. 1, 61267 Neu-Anspach, Germany Test item: Loudspeaker System Bezeichnung / Typ-Nr.: Identification / Type No.: CURV500S Auftrags-Inhalt: Order content: FCC approval Test specification: CFR47 FCC Part 15: Subpart C Section 15.247 CFR47 FCC Part 15: Subpart C Section 15.207 CFR47 FCC Part 15: Subpart C Section 15.209 CFR47 FCC Part 2: Section 2.1091 Wareneingangsdatum: Date of sample receipt: 2019.11.05 Test sample No.: A000974947 001-002 Testing period: Refer to test report Place of testing: (Guangdong) Ltd. Testing laboratory: (Guangdong) Ltd. Test result*: Pass tested by: genehmigt von: authorized by: Datum: 2021.01.29 Date: Datum: 2021.02.02 Date: Stellung/Position: Webb Luo/Assistant PE Stellung/Position: Amy Wang/TC Sonstiges / Other: Condition of the test item at delivery: dig und unbeschdigt Test item complete and undamaged * Legende: 1 = sehr gut 2 = gut 3 = befriedigend 4 = ausreichend 5 = mangelhalt N/A = nicht anwendbar N/T = nicht getestet Legend: 1 = very good 2 = good 3 = satisfactory 4 = sufficient 5 = poor P(ass) = passed a.m. test specifications(s) F(ail) = failed a.m. test specifications(s) N/A = not applicable N/T = not tested This test report only relates to the a. m. test sample. Without permission of the test center this test report is not permitted to be duplicated in extracts. This test report does not entitle to carry any test mark. Test Report - Products Test Report No. 60429423 001 Seite 2 von 27 Page 2 of 27 Test Summary 5.1.1 A NTENNA R EQUIREMENT RESULT: Pass 5.1.2 M AXIMUM P EAK C ONDUCTED O UTPUT P OWER RESULT: Pass 5.1.3 C ONDUCTED P OWER S PECTRAL D ENSITY RESULT: Pass 5.1.4 6 D B B ANDWIDTH RESULT: Pass 5.1.5 C ONDUCTED S PURIOUS E MISSIONS M EASURED IN 100 K H Z B ANDWIDTH RESULT: Pass 5.1.6 R ADIATED S PURIOUS E MISSION RESULT: Pass 5.1.7 20 D B B ANDWIDTH RESULT: Pass 5.1.8 C ARRIER F REQUENCY S EPARATION RESULT: Pass 5.1.9 N UMBER OF H OPPING F REQUENCY RESULT: Pass 5.1.10 T IME OF O CCUPANCY RESULT: Pass 5.1.11 C ONDUCTED E MISSION ON AC M AINS RESULT: Pass 6.1.1 E LECTROMAGNETIC F IELDS RESULT: Pass Test Report - Products Test Report No. 60429423 001 Seite 3 von 27 Page 3 of 27 Contents 1G ENERAL R EMARKS ........................................................................................................................... 5 1.1 C OMPLEMENTARY M ATERIALS ............................................................................................................ 5 2T EST S ITES ........................................................................................................................................ 5 2.1 T EST F ACILITIES ................................................................................................................................. 5 2.2 L IST OF T EST AND M EASUREMENT I NSTRUMENTS ................................................................................. 6 2.3 T RACEABILITY .................................................................................................................................... 6 2.4 C ALIBRATION ..................................................................................................................................... 6 2.5 M EASUREMENT U NCERTAINTY ............................................................................................................. 6 2.6 L OCATION OF O RIGINAL D ATA ............................................................................................................. 7 2.7 S TATUS OF F ACILITY U SED FOR T ESTING ............................................................................................. 7 3G ENERAL P RODUCT I NFORMATION ...................................................................................................... 8 3.1 P RODUCT F UNCTION AND I NTENDED U SE ............................................................................................. 8 3.2 R ATINGS AND S YSTEM D ETAILS .......................................................................................................... 8 3.3 I NDEPENDENT O PERATION M ODES ....................................................................................................11 3.4 N OISE G ENERATING AND N OISE S UPPRESSING P ARTS .......................................................................11 3.5 S UBMITTED D OCUMENTS ...................................................................................................................11 4T EST S ET - UP AND O PERATION M ODES ..............................................................................................12 4.1 P RINCIPLE OF C ONFIGURATION S ELECTION .......................................................................................12 4.2 T EST O PERATION AND T EST S OFTWARE ............................................................................................12 4.3 S PECIAL A CCESSORIES AND A UXILIARY E QUIPMENT ..........................................................................12 4.4 C OUNTERMEASURES TO A CHIEVE EMC C OMPLIANCE ........................................................................12 4.5 T EST S ETUP D IAGRAM ......................................................................................................................13 5T EST R ESULTS .................................................................................................................................15 5.1 T RANSMITTER R EQUIREMENT & T EST S UITES ....................................................................................15 Antenna Requirement .....................…

Text truncated - open the document above for the full version.

Prüfbericht - Produkte Test Report - Products Appendix B 60429423 001 Page 1 of 76 Appendix B: Test Results APPENDIX B: TEST RESULTS .......................................................................................................................................... 1 APPENDIX B.1: MEASUREMENT EQUIPMENT LIST ....................................................................................................................... 3 APPENDIX B.2: CONDUCTED POWER SPECTRAL DENSITY ............................................................................................................. 4 BLE Low channel ........................................................................................................................................................... 4 BLE Middle channel ....................................................................................................................................................... 4 BLE High channel .......................................................................................................................................................... 5 APPENDIX B.3: 6DB BANDWIDTH ............................................................................................................................................ 6 BLE Low channel ........................................................................................................................................................... 6 BLE Middle channel ....................................................................................................................................................... 6 BLE high channel ........................................................................................................................................................... 7 APPENDIX B.4: 20DB BANDWIDTH .......................................................................................................................................... 7 BDR Low channel .......................................................................................................................................................... 7 BDR Middle channel ...................................................................................................................................................... 8 BDR High channel ......................................................................................................................................................... 8 EDR Low channel........................................................................................................................................................... 9 EDR Middle channel ...................................................................................................................................................... 9 EDR High channel ........................................................................................................................................................ 10 APPENDIX B.5: CARRIER FREQUENCY SEPARATION ................................................................................................................... 11 BDR mode ................................................................................................................................................................... 11 EDR mode ................................................................................................................................................................... 11 APPENDIX B.6: NUMBER OF HOPPING FREQUENCY .................................................................................................................. 12 BDR mode ................................................................................................................................................................... 12 EDR mode ................................................................................................................................................................... 12 APPENDIX B.7: TIME OF OCCUPANCY, WORST-CASE ................................................................................................................. 13 Low Channel of BDR mode, DH1 ................................................................................................................................. 13 Middle Channel of BDR mode, DH1 ............................................................................................................................ 14 High Channel of BDR mode, DH1 ................................................................................................................................ 15 Low Channel of EDR mode, DH5 ................................................................................................................................. 16 Middle Channel of EDR mode,DH5 ............................................................................................................................. 17 High Channel of EDR mode,DH5 ................................................................................................................................. 18 APPENDIX B.8: CONDUCTED SPURIOUS EMISSIONS MEASURED IN 100 KHZ BANDWIDTH ............................................................... 19 Low Channel of BDR mode .......................................................................................................................................... 19 Middle Channel of BDR mode ..................................................................................................................................... 19 High Channel of BDR mode ......................................................................................................................................... 20 Low Channel of EDR mode .......................................................................................................................................... 20 Middle Channel of EDR mode …

Text truncated - open the document above for the full version.

Prüfbericht - Produkte Test Report - Products Appendix A 60429423 001 Page 1 of 3 Appendix A: Photographs of the Test Set-Up APPENDIX A: PHOTOGRAPHS OF THE TEST SET-UP ....................................................................................................... 1 PHOTOGRAPH 1: SET-UP FOR RADIATED SPURIOUS EMISSION, 30MHZ - 1GHZ ................................................................................ 2 PHOTOGRAPH 2: SET-UP FOR RADIATED SPURIOUS EMISSION, ABOVE 1GHZ .................................................................................... 2 PHOTOGRAPH 3: SET-UP FOR CONDUCTED EMISSION ON AC MAINS ............................................................................................... 3 Prüfbericht - Produkte Test Report - Products Appendix A 60429423 001 Page 2 of 3 Photograph 1: Set-up for Radiated Spurious Emission, 30MHz - 1GHz Photograph 2: Set-up for Radiated Spurious Emission, Above 1GHz Prüfbericht - Produkte Test Report - Products Appendix A 60429423 001 Page 3 of 3 Photograph 3: Set-up for Conducted Emission on AC Mains
