2AG69MVAC35MVAC 3.5

UTP 1.0 INSTALLATION & VERIFICATION INSTRUCTIONS OBDII ONLY AND 2017 HYUNDAI ACCENT FOB EMULATION UTP 1.0 Installation & Verification Instructions I.D. Systems Confidential and Proprietary 1 055-00000889 Rev B Copyright © 2018 I.D. Systems, Incorporated. All Rights Reserved. The material contained in this document is protected by the copyright and trade secret laws of the United States and other countries. It may not be reproduced, distributed, or altered in any fashion by any entity (either internal or external to I.D. Systems, except in accordance with applicable agreements, contracts, or licensing, without the express written consent of the Brand or Marketing Communications Director or the business management owner of the material. Disclaimer and Limitations of Liability The information contained in this Guide is subject to change without notice and should not be construed as a specification. NOTICE: This device complies with Part 15 of the FCC Rules and with Industry Canada license-exempt RSS standard(s)]. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. NOTICE: Changes or modifications made to this equipment not expressly approved by I.D. Systems may void the FCC authorization to operate this equipment. To comply with FCC/IC RF exposure limits for general population / uncontrolled exposure, the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. La distance entre l'utilisateur et de produits ne devrait pas être inférieure à 20cm UTP 1.0 Installation & Verification Instructions I.D. Systems Confidential and Proprietary 2 055-00000889 Rev B I.D. Systems www.id-systems.com/ Customer Support: 888-855-0913 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by : one or more of the following measures . Reorient or relocate the receiving antenna . Increase the separation between the equipment and receiver . Connect the equipment into an outlet on a circuit different from that to which the receiver is connected . Consult the dealer or an experienced radio/TV technician for help UTP 1.0 Installation & Verification Instructions I.D. Systems Confidential and Proprietary 3 055 -00000889 Rev B Table of Contents 1. OVERVIEW ..................................................................................................................................................... 4 2. UTP 1.0 COMPONENTS .................................................................................................................................. 4 3. REQUIRED TOOLS (NOT PROVIDED) ............................................................................................................... 5 4. OBDII ONLY VS. OBDII AND KEY FOB TRAINING ............................................................................................. 6 5. OBD ONLY INSTALLATION AND VERIFICATION WORKFLOW .......................................................................... 7 6. OBD AND KEY FOB TRAINING INSTALLATION AND VERIFICATION WORKFLOW ............................................. 8 7. OBDII ONLY INSTALLATION STEPS ................................................................................................................. 9 8. OBDII ONLY LED INDICATORS ...................................................................................................................... 16 9. HYUNDAI ACCENT OBDII AND KEY FOB TRAINING INSTALLATION STEPS ..................................................... 17 10. OBDII AND FOB TRAINING LED INDICATORS ............................................................................................ 27 11. INSTALLING ON MULTIPLE VEHICLES AT THE SAME TIME (OBDII ONLY VEHICLES) ................................... 32 12. REINSTALL AND VERIFY UTP 1.0 AFTER OBDII PORT MAINTENANCE ....................................................... 33 13. UNINSTALLING THE UTP 1.0 .................................................................................................................... 35 14. TRAIN FOBS TO VEHICLE AFTER UTP DE-INSTALLATION (2017 HYUNDAI ACCENT ONLY) ......................... 37 UTP 1.0 Installation & Verification Instructions I.D. Systems Confidential and Proprietary 4 055 -00000889 Rev B 1. Overview  This document details UTP 1.0 (remote vehicle monitoring and control hardware) installation and verification process.  Two main installation processes are documented; 1 – OBD Port Only and 2 – OBD Port and Key Fob Training  Failure to follow the installation and verification processes may result in improper device operation and/or payment dispute for installation services.  Contact Avis Budget Group customer support at xxxxx…

Text truncated - open the document above for the full version.

* the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. Powerfleet Inc. U.S. Agent Designation for Service of Process - Certification Attestation Letter Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: 2AG69MVAC35 FRN of applicant: 0025175696 Per section 2.911(d)(7) of the FCC rules, Powerfleet Inc. certifies that the equipment for which authorization is sought is designated to the following U.S. agent* for service of process: Company Name: Powerfleet Inc. FCC Registration Number (FRN): 0025175696 Physical U.S. Company Address: 123 Tice Boulevard,Suite 101,Woodcliff Lake, NJ 07677, United States Contact Person: Lior Musi Agent Email Address: [email protected] The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Signed: Printed name: Lior Musi Title: V.P R&D Company Name: Powerfleet Inc. Date: 11/21/2023 Agent Signed: Signed: Printed name: Lior Musi Title: V.P R&D Company Name: Powerfleet Inc. Date: 11/21/2023

Powerfleet Inc. Covered Equipment Certification Attestation Letter Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: 2AG69MVAC35 Powerfleet Inc. certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. Powerfleet Inc. certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Signed: Printed name: Lior Musi Title: V.P R&D Company Name: Powerfleet Inc. Date: 11/21/2023

DATE : 2023-11-21 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Jason Wu of Global United Technology Services Co., Ltd.and No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Powerfleet Inc. and 123 Tice Boulevard,Suite 101,Woodcliff Lake, NJ 07677, United States Signature: Name: Lior Musi Title: V.P R&D Company: Powerfleet Inc.

Powerfleet Inc. DATE : 2023-11-21 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AG69MVAC35 Product Name: MVAC 3.5 Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: • Schematics • Block diagram • Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Pursuant to Sections 0.457 and 0.459 of the commission rules, and in accordance with the FCC Public notice dated June 15, 2004 (DA 04-1705), we hereby request short-term confidentiality for the following items prior to marketing the device.: • Test Setup Photos • External Photos • Internal Photos • User Manual The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Signature: Name: Lior Musi Title: V.P R&D Company: Powerfleet Inc.

Page 1 of 3 Page 2 of 3 Page 3 of 3

Powerfleet LB000084_REV D Page 2 of 3 1.Material: 2 MIL MATTE CHROME POLYESTER TC cut and rolled per IDS P/N LB000084 LABEL,UNIT ID, MVAC3.5, ROHS, S8025 (or equiv) ADHESIVE MAT'L 1.05 in. H X 3.05 in. W 2.Artwork: See Label Matrix file LB000084.btw. 3.Notes: a)Labels may be printed using Label Matrix software and Label Matrix file LB000084.btw, or Powerfleet approved equivalent. b)HW ID format is H (label matrix application prints it as (H) with parenthesis) i)Where (1)H is UCC/EAN-128 prefix for Hardware ID bar code (2)12 characters represent the 6 Bytes of the Bluetooth MAC address without “:” delimiters (3)Example for MAC address 2C:BE:08:9E:42:5B is H2CBE089E425B (prints on the label as “(H) 2CBE089E425B”) c)Serial Number format is SYY-PPWWXXXX-LLL i)Where (1)S is UCC/EAN-128 prefix for serial number bar code (2)YY is the last two digits of year of manufacture. (3)Dash (4)PP is the 2-digit code representing the Product type (MV for MVAC3.0) (5)WW is the week of manufacture (01 = first week per ISO-8601 standard) (6)XXXX is a unique sequential number for the Product Type during the manufacturing period (starting with 0) (7)Dash (8)LLL is the manufacturing location code assigned by Powerfleet (ISR) (9)Example: S23-MV020027-ISR (prints on the label as “(S) 23-MV140053- ISR”). S/N referenced above reflects 53 rd MVAC 3.0 device that was manufactured in 2023 during the 2nd week at ISR. Sample Label – Contents shown are for reference purposes only, Boarder for reference only and not to be printed, Not to Scale FCC ID: 2AG69MVAC35 IC: 9975A-MVAC35 Contains : IC: 10224A-2020BG95M5 Label Dimension and Tolerance

Page 1 of 5 Page 2 of 5 Page 3 of 5 Page 4 of 5 Page 5 of 5

FCC ID: 2AG69MVAC35 Contains FCC ID:XMR202005BG95M5 RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. FCC ID: 2AG69MVAC35 Contains FCC ID:XMR202005BG95M5 Test Result of RF Exposure Evaluation SRD Channel Output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm2) Limit (mW/cm2) Result 315MHz 1.74 1.49 0 0.21 PASS 433.92 MHz -27.96 0.0016 0 0.29 PASS 315MHz antenna gain: -27.8dBi 433.92MHz antenna gain: -2.67dBi according to ANSI C63.10 30MHz＜F＜1GHz: EIRP (dBm)=E(dBuv/m)-95.2-4.7 So Output power=EIRP-antenna gain Mode Antenna gain (dBi) Output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm2) Result BLE 0.5 1.54 1.43 0.00032 1.000 PASS GSM850 2.53 25.97 395.367 0.142 0.566 PASS GSM1900 1.59 22.97 198.153 0.057 1.000 PASS LTE-B2 1.59 25 316.228 0.091 1.000 PASS LTE-B4 2.00 25 316.228 0.099 1.000 PASS LTE-B5 2.53 25 316.228 0.113 0.566 PASS LTE-B12 3.26 25 316.228 0.133 0.477 PASS LTE-B13 4.45 25 316.228 0.176 0.525 PASS LTE-B25 1.59 25 316.228 0.091 1.000 PASS LTE-B26 3.19 25 316.228 0.131 0.566 PASS LTE-B66 2.00 25 316.228 0.099 1.000 PASS LTE-B85 3.26 25 316.228 0.133 0.477 PASS NB-IOT-B2 1.59 25 316.228 0.091 1.000 PASS NB-IOT-B4 2.00 25 316.228 0.099 1.000 PASS NB-IOT-B5 2.53 25 316.228 0.113 0.566 PASS NB-IOT-B12 3.26 25 316.228 0.133 0.477 PASS NB-IOT-B13 4.45 25 316.228 0.176 0.525 PASS NB-IOT-B25 1.59 25 316.228 0.091 1.000 PASS NB-IOT-B66 2.00 25 316.228 0.099 1.000 PASS NB-IOT-B71 1.66 25 316.228 0.092 0.465 PASS NB-IOT-B85 3.26 25 316.228 0.133 0.477 PASS FCC ID: 2AG69MVAC35 Contains FCC ID:XMR202005BG95M5 BLE and cellular Simultaneous Transmission: BLE + LTE =(0.00032/1)+(0.176/0.525)=0.336<1 BLE + GSM =(0.00032/1)+(0.142/0.566)=0.251<1 The max power density is less than MPE exempt limit, so it is compliance.

Global United Technology Services Co., Ltd. Report No.: GTS2023080072F02 Authorized Signature: Robinson Luo Laboratory Manager This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 32 TEST REPORT Applicant: Powerfleet Inc. Address of Applicant: 123 Tice Boulevard,Suite 101,Woodcliff Lake, NJ 07677, United States Manufacturer: Powerfleet Inc. Address of Manufacturer: 123 Tice Boulevard,Suite 101,Woodcliff Lake, NJ 07677, United States Equipment Under Test (EUT) Product Name: MVAC 3.5 Model No.: MVAC 3.5 FCC ID: 2AG69MVAC35 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.231 Date of sample receipt: August 07, 2023 Date of Test: August 07, 2023-November 09, 2023 Date of report issued: November 10, 2023 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTS2023080072F02 Page 2 of 32 2 Version Version No. Date Description 00 November 10, 2023 Original Prepared By: Date: November 10, 2023 Project Engineer Check By: Date: November 10, 2023 Reviewer Report No.: GTS2023080072F02 Page 3 of 32 3 Contents Page 1 COVER PAGE ............................................................................................................................................ 1 2 VERSION .................................................................................................................................................. 2 3 CONTENTS .............................................................................................................................................. 3 4 TEST SUMMARY ..................................................................................................................................... 4 4.1 MEASUREMENT UNCERTAINTY ............................................................................................................ 4 5 GENERAL INFORMATION ...................................................................................................................... 5 5.1 GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.2 TEST MODE ........................................................................................................................................ 6 5.3 TEST FACILITY .................................................................................................................................... 6 5.4 TEST LOCATION ................................................................................................................................. 6 5.5 DESCRIPTION OF SUPPORT UNITS ....................................................................................................... 6 5.6 DEVIATION FROM STANDARDS ............................................................................................................. 6 5.7 ABNORMALITIES FROM STANDARD CONDITIONS ................................................................................... 6 5.8 OTHER INFORMATION REQUESTED BY THE CUSTOMER ......................................................................... 6 6 TEST INSTRUMENTS LIST ..................................................................................................................... 7 7 TEST RESULTS AND MEASUREMENT DATA ...................................................................................... 9 7.1 ANTENNA REQUIREMENT ..................................................................................................................... 9 7.2 CONDUCTED EMISSIONS ................................................................................................................... 10 7.3 RADIATED EMISSION METHOD ........................................................................................................... 15 7.3.1 Field Strength of The Fundamental Signal ................................................................................ 17 7.3.2 Spurious emissions .................................................................................................................... 19 7.4 OCCUPY BANDWIDTH ........................................................................................................................ 26 7.5 DWELL TIME ..................................................................................................................................... 28 7.6 SILENT PERIOD ................................................................................................................................. 30 8 TEST SETUP PHOTO ............................................................................................................................ 32 9 EUT CONSTRUCTIONAL DETAILS ..................................................................................................... 32 Report No.: GTS2023080072F02 Page 4 of 32 4 Test Summary Test Item Section in Result Antenna requirement CFR 47 15.203 Pass Conduction Emission CFR 47 15.207 Pass Field strength of the fundamental signal CFR 47 15.231(e) Pass Spurious emissions CFR 47 15.231(e) &15.209 Pass Occupy Bandwidth CFR 47 15.231(c) Pass Dwell time CFR 47 15.231(e) Pass Pass: The EUT complies with the essential requirements in the standard. N/A: Not applicable. 4.1 Measurement Uncertainty Test Item Frequency Range Measurement Uncertainty Notes Radiated Emission 30MHz-200MHz 3.8039dB (1) Radiated Emission 200MHz-1GHz 3.9679dB (1) Radiated Emission 1GHz-18GHz 4.29dB (1) Radiated Emission 18GHz-40GHz 3.30dB (1) AC Power Line Conducted Emission 0.15MHz ~ 30MHz 3.44dB (1) Note (1): The measurement uncertainty is for coverage factor of k=2 and a level of confidence of 95%. Report No.: GTS2023080072F02 Page 5 of 32 5 General Information …

Text truncated - open the document above for the full version.

This document contains proprietary information that is the sole property of POINTER Telocation Systems Ltd. The document is submitted to the recipient for his use only. By receiving this document, the recipient undertakes not to duplicate or to disclose, in part or the whole, any of the information contained herein; to any third party; without a-priory written permission from POINTER Telocation Systems Ltd. RFTESTFORMVAC3.5REV.C Revision Prepared by Approvedby Date Remarks 1.0 Refael Yakobov 3/09/2023 Basedonallpreviousdocuments, meetings and development group sessions 1.1 Itamar Gohary 26/12/2023 SRDantennaGainaadAntennapattern 1. Document purpose: RFtest(VSWR)forMVACLTE,BLE,433MHz,GPSantennas. TRP,TIS test. ConfirmMVAC 3.5. 2. TestEquipmentanddevicesundertest:  HPNetworkanalyzer.  MVAC3.5.  HPNetwork analyzer.  Base station.  Chamber. 1. 433MHzantennaforMVAC Antenna dimensions: 13.70038mm x 7.15901 mm Frequency(MHz) VSWR 388 4 410 1.88 433 3.53 437 4 SDRAntennaGainAndPattern: 433Mhz: Horizontal Vertical 433Mhz 315Mhz MaxANT Gain -2.67dBi -27.8dBi 315Mhz: Horizontal: Vertical:

Page 1 of 2 Radiated Emission Page 2 of 2 Conducted Emissions
