2AHAF-MDT86Tablet

MDT1060/1065/865 Quick Start Guide Accessories highlights 1. Plastic Tape for cradle back connector if not used 2. Metal Stand (Be a desktop dock station) 3. Keys and Screws 4. Cable used for vehicle cradle, it can connect to cradle bottom side 5. Metal Mount 6. Type C cable for home adapter 7. NFC Card 8. Vehicle cradle or desktop dock station 9. Cradle extension cable (connected to new cable for power supply) Item 3 Item 2 Item 5 Item 7 Item 8 Item 9 Item 4 Item 1 Item 6 2 in 1 full features cradle (desktop dock station or vehicle cradle) 1. To be desktop dock station - Metal plate at the bottom - Mainly use the connector (type C for charging) at the back. Please note that the adapter needs to be high power (Support PD fast charging) 2. To be vehicle cradle - No metal plate at the bottom - Use the molex connector at the bottom. The LAN (RJ45) connector and other connector at the back is optional. If not used, it can be closed by a plastic tape, see below Without metal plate Lock the Molex connector to the cradle by screw Bottom Cable Cradle cable(CAB-MB-FULL) cradle extension cable (CAB-EX-FULL) camera hub cable(CAB-EX-HUB) Bottom cradle cable can offer below function in full features cradle - Vehicle Input: DC 9V to 36V, ignition control with optional switch in the cradle - Serial port: RS485 x 1, RS232 x 2 - Support one channel video input (Support AHD 720P, 1080P and Analog camera) - Support four channels video input, connect to Camera Hub by extension cable (Refer to the Camera Hub manual), with 4 trigger input - I/O: Analog input ADC x 1, Digital input x 2, Digital output x 1 Cable pin assignment overview Cable specification below P2 Power and serial port connector Pin Definition 1 RS485-A 2 GND 3 RXD (CPU) 4 TXD (USB) 5 RXD (USB) 6 DC 12V Ignition 7 RS485-B 9 GND 10 TXD (CPU) 11 DC 9-36V input P3 Camera Hub connector Pin Definition 1 DM- 2 DP+ 4 GND P5 GPIO Wires Wires color Definition Red Video input trriger DC12V Yellow GPIO-1 (Input 1) Orange GPIO-2 (Input 2) Bule GPIO-3 (output) Brown GPIO-4 (ADC) GPIO Demo APK CRD1060GPIO_demo20220419.apk and surce code link: https://drive.google.com/file/d/1ZLEyXAlZxOo0EjTW6ks7oMGjwnLiYcrQ /view?usp=sharing Power and Serial port extension cable P6 Connector connect to the P2 connector P7 Connect the Vcc (red wire), ignition (green wire) and GND (black wire) to the power supply (DC9V-36V) P8 serial port RS232 and RS485 wires Wires color Definition White RXD (CPU) Purple TXD (CPU) Orange RXD (USB) Yellow TXD (USB) Blue RS485-A Brown RS485-B RS232 purple/white is from CPU, it’s same as mdt860 and mdt760, it can work even no external power supply. RS232 orange/yellow and RS485 blue/brown are converted from USB Hub and will only work if there is an external power supply. Serial port demo APK SerialPort_20220712.apk and surce code link: https://drive.google.com/file/d/1Pm7TZcbzJ6jzWnTNwdlV8jliVyC1haT3/view?usp=sharing Device tty port option: RS232 purple/white is ttyUser RS232 orange/yellow is ttyUSB0 RS485 blue/brown is ttyUSB1 When installing in the vehicle, pls use below metal parts, it has 2 purposes 1. let the cable to the toward the back side 2. It can use for supporting as the device is quite heavy. It will not shake even the car has vibration. There are few options. If there are supporting at the bottom or at the back (with angle), you can make different installation (see below 2 video) It can be changed the length from 50mm to 80mm https://drive.google.com/file/d/1ybp_Ji3AL1t94PQ_KVtJO9mk_J8UiY8Q /view?usp=sharing https://drive.google.com/file/d/1etWxYVJcbXDs8J-GP0dq8IVuBiYc0t3S/view?usp=sharing Basics vehicle cradle only 1xRS232, 1x OTG and vehicle Vcc (12-24V) input, Ignition, NO type C charging even plug to tablet all connector at the back will be closed Bottom cable CRD1060 basic cable (CAB-MB-BASIC) Extension cable (CAB-EX-BASIC) Basic Cable specification below P2 Connector Pin Definition 2 GND 3 RXD (CPU) 6 DC 12V Ignition 9 GND 10 TXD (CPU) 11 DC 9-36V input P3 Connector Pin Definition 1 Vbus 5V 2 D- 3 D+ 4 GND Extension cable specification below P2 Wires Colour Definition Black GND White RXD (CPU) Green DC 12V Ignition Black GND Purple TXD (CPU) Red DC 9-36V input Caution: Use the Product in the environment with the temperature Between -10°C and 40°C; Otherwise, it may damage your product. Products can only be used below 2000m altitude For the following equipment: Product Name: Tablet Brand Name: -- Model No.: MDT865, PaceBlade MDT-801, OBC865, M865A, M865B, MDT865D TOPICON HK LIMITED E-mail: [email protected] hereby declares that this [Name: Tablet, Model: MDT865, PaceBlade MDT-801, OBC865, M865A, M865B, MDT865D] is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. Adapter shall be installed near the equipment and shall be easily accessible. Only can use adapter as below: Power Adapter Model: GS-W20A0938 Input: 100- 240Va.c. 50/60Hz 0.6A Max Output: 5Vd.c. 3A or 9Vd.c. 2.22A or 12Vd.c. 1.67A Shenzhen Good-she technology Co., Ltd The plug considered as disconnect device of adapter. RED Article 10 2 -This product can be used across EU member states RED Article 10 10 -The product is class 1 product, No restrictions The RF distance between body and product is 0mm 2G Frequency Range: GSM900: Tx: 880-915MHz, Rx: 925-960MHz DCS1800: Tx: 1710-1785MHz, Rx: 1805-1880MHz RF Output Power: GSM900: 32.80dBm, GSM1800: 31.06dBm EDGE900: 26.89dBm, EDGE1800: 26.97dBm 3G Frequency Range: WCDMA Band 1: Tx: 1920-1980MHz, Rx: 2110-2170MHz WCDMA Band 8: Tx: 880-915MHz, Rx: 925-960MHz RF Output Power: WCDMA Band 1: 24.03dBm, WCDMA Band 8: 22.95dBm 4G Frequency Range: FDD-LTE Band 1: Tx: 1920-1980MHz, Rx: 2110-2170MHz FDD-LTE Band 3: Tx: 1710-1785MHz, Rx: 1805-1880MHz FDD-LTE Band 7: Tx: 2500-2570MHz, Rx: 2620-2690MHz FDD-LTE Band 8: Tx: 880-915MHz, Rx: 925-960MHz FDD-LTE Band 20: Tx: 832-862MHz, Rx: 791-821MHz FDD-LTE Band 28: Tx: 703-748MHz, Rx: 758-803MHz TDD-LTE Band 38: Tx: 2570-2620MHz, Rx: 25…

Text truncated - open the document above for the full version.

TOPICONHKLIMITED Room2314-2316,TowerC,HuangduPlaza,YitianRoad,FutianDistrict,Shenzhen,China Date:2024-01-03 FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Ref:AttestationStatementsPart2.911(d)(5)(i)Filing SUBJECT:FCCApplicationforFCCID:2AHAF-MDT86 ToWhomItMayConcern: TOPICONHKLIMITEDcertifiesthattheequipmentforwhichauthorizationissoughtisnot“covered” equipmentprohibitedfromreceivinganequipmentauthorizationpursuanttosection2.903oftheFCCrules. Sincerely, Signatory [kellersin,salesdirector]

TOPICONHKLIMITED Room2314-2316,TowerC,HuangduPlaza,YitianRoad,FutianDistrict,Shenzhen,China Date:2024-01-03 FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Ref:AttestationStatementsPart2.911(d)(5)(ii)Filing SUBJECT:FCCApplicationforFCCID:2AHAF-MDT86 ToWhomItMayConcern: TOPICONHKLIMITEDcertifiesthat,asofthedateofthefilingoftheapplication,theapplicantisnotidentified ontheCoveredList(asaspecificallynamedentityoranyofitssubsidiariesoraffiliates)asanentityproducing “covered”equipment. Sincerely, Signatory [kellersin,salesdirector]

TOPICONHKLIMITED Room2314-2316,TowerC,HuangduPlaza,YitianRoad,FutianDistrict,Shenzhen,China Date:2024-01-03 FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA FCCID:2AHAF-MDT86 ApplicantFRN:0025168154 USAgent–AttestationStatement/Part2.911(d)(7) TOPICONHKLIMITEDcertifiesthat,asof2024-01-03,wehavedesignatedFCCUSAgent, LLCtoacceptserviceofprocessonourbehalfforFCCID:2AHAF-MDT86. TOPICONHKLIMITED,acceptstomaintainanagentofserviceofprocessintheUnited Statesfornolessthanoneyearaftereitherthegranteehaspermanentlyterminatedall marketingandimportationoftheapplicableequipmentwithintheU.S.,ortheconclusionofany Commission-relatedadministrativeorjudicialproceedinginvolvingtheequipment,whicheveris later. FCCUSAgent,LLC,acceptsasofthedateofthefilingofthisapplication,theobligationof beingthedesignatedagentforthepurposeofacceptingserviceofprocessonbehalfof TOPICONHKLIMITEDforFCCID:2AHAF-MDT86. DesignatedAgentInformation: CompanyName:FCCUSAgent,LLC U.S.AgentFRN:0033402884 Address:3722IllinoisAvenue,SaintCharles,IL,60174,USA ContactPerson:TimPayne Phone:708-571-3148 Email:[email protected] Sincerely, Company:TOPICONHKLIMITEDDesignatedAgent:FCCUSAgent,LLC CompanyRepresentative:kellersinDesignatedAgentRepresentative:TimPayne Signature:Signature:

TOPICONHKLIMITED Room2314-2316,TowerC,HuangduPlaza,YitianRoad,FutianDistrict,Shenzhen,China Date:2024-01-03 FEDERALCOMMUNICATIONSCOMMISSION AUTHORIZATIONANDEVALUATIONDIVISION 7435OAKLANDMILLSROAD COLUMBIA,MD21046 SUBJECT:FCCApplicationforFCCID:2AHAF-MDT86 ConfidentialityRequest Towhomitmayconcern, PursuanttotheprovisionsoftheCommission’srulesTitle47Sections§0.457and§0.459,wearerequestingthe Commissiontowithholdthefollowingattachment(s)asconfidentialdocumentsfrompublicdisclosureindefinitely. ☒ BlockDiagram ☒ Tune-UpInformation ☒ OperationalDescription ☐ SecurityInformation ☒ Schematics ☐ SoftwareDefinedRadio(SDR)Information ☒ PartsList Theabovematerialscontaintradesecretsandproprietaryinformationnotcustomarilyreleasedtothepublic.The publicdisclosureofthesematerialsmaybeharmfultotheapplicantandprovideunjustifiedbenefitstoits competitors. Inadditionaltoabovementioneddocuments,inordertocomplywiththemarketingregulationsinTitle47CFR §2.803andtheimportationrulesinTitle47CFR§2.1204,whileensuringthatbusinesssensitiveinformation remainsconfidentialuntiltheactualmarketingofnewlyauthorizeddevices,werequestShortTermConfidentiality ofthefollowingattachment(s); ☐ ExternalPhotos ☐ TestSetupPhotos ☐ InternalPhotos ☐ UserManual ☐For45days,pursuanttoPublicNoticeDA04-1705. or ☐For180dayspursuanttoKDB726920D01. TheapplicantunderstandsthatpursuanttoSection0.457oftheRules,disclosureofthisapplicationandall accompanyingdocumentationwillnotbemadebeforethedateoftheGrantforthisapplication. Sincerely, Signatory [kellersin,salesdirector]

TOPICONHKLIMITED Room2314-2316,TowerC,HuangduPlaza,YitianRoad,FutianDistrict,Shenzhen,China Date:2024-01-03 FEDERALCOMMUNICATIONSCOMMISSION AUTHORIZATIONANDEVALUATIONDIVISION 7435OAKLANDMILLSROAD COLUMBIA,MD21046 SUBJECT:FCCID:2AHAF-MDT86 ModelDeclarationLetter DearRegulatoryAuthority, Model(s):Blaxtair5,PaceBladeMDT-801,OBC865,M865A,M865B,MDT865D,MDT880aresametothe modelMDT865,thesemodelsaresamePCBLayout,Schematics,BOM.Onlyfordifferentmodelnameand appearancesfordifferentmarketrequire. Sincerely, Signatory [kellersin,salesdirector]

TOPICONHKLIMITED Room2314-2316,TowerC,HuangduPlaza,YitianRoad,FutianDistrict,Shenzhen,China Date:2024-01-03 FEDERALCOMMUNICATIONSCOMMISSION AUTHORIZATIONANDEVALUATIONDIVISION 7435OAKLANDMILLSROAD COLUMBIA,MD21046 SUBJECT:FCCApplicationforFCCID:2AHAF-MDT86 POWEROFATTORNEY ToWhomItMayConcern: We,theundersigned,herebyauthorizeWaltekTestingGroup(Shenzhen)Co.,Ltd.JandySoonourbehalf,to applytotheFederalCommunicationsCommissiononourequipment.AnyandallactscarriedoutbyWaltek TestingGroup(Shenzhen)Co.,Ltd.JandySoonourbehalfshallhavethesameeffectasactsofourown. ThisistoadvisethatweareinfullcompliancewiththeAnti-DrugAbuseAct.We,TOPICONHKLIMITEDare notsubjecttoadenialoffederalbenefitspursuanttoSection5301oftheAnti-DrugActof1988,21USC853a, andnopartytotheapplicationissubjecttoadenialoffederalbenefitspursuanttothatsection. Sincerely, Signatory [kellersin,salesdirector]

TOPICONHKLIMITED Room2314-2316,TowerC,HuangduPlaza,YitianRoad,FutianDistrict,Shenzhen,China Date:2024-01-03 FEDERALCOMMUNICATIONSCOMMISSION AUTHORIZATIONANDEVALUATIONDIVISION 7435OAKLANDMILLSROAD COLUMBIA,MD21046 SUBJECT:FCCApplicationforFCCID:2AHAF-MDT86 ToWhomItMayConcern: I,theundersigned,herebystatesthisequipmenthasbeentestedandfoundtocomplywiththelimitsfora ClassBdigitaldevice,pursuanttopart15oftheFCCRules,andwillapplytheSupplier'sDeclarationof ConformityproceduretothePart15ClassBDigitalandreceiversthatoperateintherangebetween30 and960MHzofthiscompositedevice.IunderstandthefollowingFCCrequirements: 1.DevicessubjecttotheSDoCprocedurearerequiredtobetestedtoshowcompliancewiththeFCC technicalregulationsbyarecognizedaccreditedtestinglaboratory.Thetestinglaboratorymustbe accreditedbyaCommissionapprovedaccreditationbodyordesignatedunderthetermsofa government-to-governmentMutualRecognitionAgreement(MRA).Alistingofthoseaccreditedtesting laboratoriesthathavebeenrecognizedbytheCommissionispublishedontheFCCWebpage: https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm(Selectthe"accredited"optiontosearchfor FCCrecognizedaccreditedtestfirms.) 2.Pt2.1077containsthelistofinformationthatmustbeincludedintheSupplier'sDeclarationof Conformity,whichmustbesuppliedwitheachproductsold.TheSDoCcomplianceinfoshallbeincluded intheUser’sManualorasaseparatesheet.Theinfomustcontainthename,address,andphone numberoftheresponsibleparty,whichmustbelocatedwithintheUnitedStates.Accordingto 2.909(b),theresponsiblepartyiseithertheManufactureroriftheproductisimportedtheImporter. Sincerely, Signatory [kellersin,salesdirector]

Reference No.: WTX23X11250989W001/002/003/004/005/006 Page 2 of 16 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 2 - EUT EXTERNAL PHOTOGRAPHS EUT View 1 EUT View 2 Reference No.: WTX23X11250989W001/002/003/004/005/006 Page 3 of 16 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 3 EUT View 4 Reference No.: WTX23X11250989W001/002/003/004/005/006 Page 4 of 16 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 5 EUT View 6 Reference No.: WTX23X11250989W001/002/003/004/005/006 Page 5 of 16 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 7 EUT View 8 Reference No.: WTX23X11250989W001/002/003/004/005/006 Page 6 of 16 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 9 EUT View 10

Reference No.: WTX23X11250989W001/002/003/004/005/006 Page 1 of 16 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn ANNEX EXHIBIT 1 - PRODUCT LABELING Proposed FCC ID Label Format FCC ID: 2AHAF-MDT86 Specifications: The label shall be securely affixed to a permanently attached part of the device, in a location where it is visible or easily accessible to the user, and shall not be readily detachable. The label shall be sufficiently durable to remain fully legible and intact on the device in all normal conditions of use throughout the device’s expected lifetime. Proposed Label Location on EUT FCC ID Label Location

Reference No.: WTX23X11250989W001/002/003/004/005/006 Page 7 of 16 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 3 - EUT INTERNAL PHOTOGRAPHS EUT Housing and Board View 1 EUT Housing and Board View 2 Reference No.: WTX23X11250989W001/002/003/004/005/006 Page 8 of 16 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 1 Solder Board-Component View 2 Reference No.: WTX23X11250989W001/002/003/004/005/006 Page 9 of 16 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 3 Solder Board-Component View 4 Reference No.: WTX23X11250989W001/002/003/004/005/006 Page 10 of 16 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 5 Solder Board-Component View 6 Reference No.: WTX23X11250989W001/002/003/004/005/006 Page 11 of 16 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 7 Solder Board-Component View 8 Reference No.: WTX23X11250989W001/002/003/004/005/006 Page 12 of 16 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 9 Solder Board-Component View 10 Reference No.: WTX23X11250989W001/002/003/004/005/006 Page 13 of 16 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Antenna View 1 Antenna View 2 NFC Ant LTE RX Ant. Wi-Fi/BT Ant GPS Ant GSM/WCDMA/LTE Ant.

COMOSAR E-Field Probe Calibration Report Ref: ACR.197.12.23.BES.A WALTEK TESTING GROUP (SHENZHEN) CO., LTD 1庙、.，ROOM 101, BUILDING 1, HONGWEI INDUSTRIAL PARK‘LIUXIAN 2ND ROAD‘BLOCK70 BAO' AN DISTRICT, SHENZHEN, GUANGDONG , CIDNA MVG COMOSAR DOSIMETRIC E-FIELD PROBE SERIAL NO.: SN 18/21 EPG0356 Calibrated at MVG Z.I. de la pointe du diable Technopôle Brest Il'oise -295 avenue Alexis de Rocholl 29280 PLOUZANE -FRANCE Calibration date: 07/07/2023 dI;;2%ωkω 二三〉七二乞3三-τ......吃Z ~事三五2句P L。τ二号飞~..;~型L...... 〈久/，飞.\.~，.~ .".... "，川AJZ丽丽在 Accreditations #2-6789 Scope available 011 ~坠应些丘坐立 Thc usc of thc Cofl'l1c bl'and and thc acc，'εditation I'CfCl'fnCfS is pl'ohibited fl'om ally "Clll'oductioll, SU111111αry: This document presents the method and results from an accredited COMOSAR E-Field Probe calibration performed at MVG, using the CALIPROBE t巳stbench, for use with a MVG COMOSAR system only. The test results covered by accreditation are traceable to the International System of Units (SI), Pαge: 1/11 Prepαred by.' Checked by.' Approved by : Issue A COMOSAR E-FIELD PROBE CALIllRATION REPORT Nαme Function Jérδme Le Gall Measurement Responsible Jérôme Luc Yann Toutain Distribution .' Technical Manager Laboratory Director Customer Name Waltek Testing Group (Shenzhen) Co. , Ltd Dafe 7/7/2023 7 /7/2023 7 /7/2023 Ref: ACR.197.12.23.BES.A SÌJ!l1ature < ?若7 7山市ιmtrlAl Signature Ya n n numérique de Yann Toutain ID Toutain ID Date:2023.07.07 08:53:35 +01 '00' Name Date Modi[ìcafiol1s JérδmeLuc 7/7/2023 lnitial release Page: 2/11 TellψlrtttLA CR.DDD.N.YXAJVCB.ISSUE-COAIOSAR Probe vI ηlis doc1Imel1l slwlll10l be repl'Od1lced.由cepl川f1l1101' il1 parl. lI'ilh01l1lhe lI'rillel1 appl'Ovall叭.fVG.The il1formaliol1 cOl1lail1ed hereil1 isωbe 1Ised ol1ly f or Ihe pwpose.for lI'hich il is s1lb川ifledal1d is 110110 be released川lI'holeorparl川的oulll'rillel1appl'Ol'all扩MVG COMOSAR E-FIELD PROBE CALlBRA TION REPORT Ref: ACR.197.12.23.BES.A TABLE OF CONTENTS Oevice Under Test ........................................ .............................................................4 2 Product Description ............ .......................................................................................4 2.1 General Information 4 3 Measurement Method ........川..... 川.......川........ .......川.......川.......川........ ...... .. .......川.......川.......川........ ...... .. .......川.......川........ .......川........ .......川........ .......川.......川.......川........ .......川........ ...... .. ...... .. .......川........ ...... .. ...... .. .......川.......川........ ...... .. ...... .. .......川........ .......川.......川........ ...... .. ...... .. .......川........ .......川.......川........ ...... .. ...... .. ...... .. ...... .. .......川........ .......川........ ...... .. .......川.......川.......川........ .......川.......川........ .......川........ .......川.......川........ ...... .. ...... .. ...... .. .......川........ ...... .. .......川.......川.......川........ ...... .. .......川........ .......川.......川.......川........ ...... .. .......川........ ...... .. .....4 3.1 Linearity 4 3.2 Sensitivity 5 3.3 Lower Detection Limit 5 3 .4 Isotropy 5 3.1 Boundary Effect 5 4 Measurement Uncertainty....... . ..................................................................................6 5 Calibration Measurement Reslllts .. ............................................................................ 6 5.1 Sensitivity in air 5.2 Linearity 5.3 Sensitivity in liqllid 5.4 Isotropy rO 叮 foony 6 List ofEqllipn1ent ..................................... ...............................................................10 Pα'ge: 3/ /1 TemplalιACR.DDD.N. Y}~II1VGB.ISSUιCOilIOSAR Prabe 1'1 This dOClflllell1 shallllOl be reprodllced. excepl ill f llll Or ill parl. lI'ilholll Ihe川.illellapprol'Ol 0/ MVG. The iliforlllalioll cOlllailled hereill is 10 be IIsed olll)'for Ihe pwpose/or lI'hich it is SlIblllitted alld is 1101 1 0 be released ill1l'h ole o r parl 1I'ilholll 11'川Ilellapprol'ol (扩MVG. COMO SAR E-FIELD PROBE C ALIBRATION REPORT Ref: ACR. 197. 12.23.BES.A 1 DEVICE UNDER TEST Oevice Under Test Device Type COMOSAR DOSI1\咀~TRICE FIELD PROBE Manu也cturer MVG Model SSE2 Serial Number SN 18/21 EPG0356 Product Condition (new / used) New Frequency Range of Probe 0.15 GHz-6GHz Resistance ofThree Dipoles at Connector Dipole 1: Rl=0.221 MQ Dipole 2: R2=0.197 MQ Dipole 3: R3=0.195 MQ 2 PRODUCT DESCRIPTION 2.1 GENERAL INFOR.r..ι生TION MVG's COMOSAR E fteld Probes are built in accordance to the IEEE 1528, FCC KDB865664 DO 1, CENELEC EN62209 and CEI/IEC 62209 standards. Figure 1 -JvIVG COMOSA R Dosimel.ric E卢eldDipole Probe Length 330mm Length of Individual Dipoles 2mm Maximum external diameter 8mm Probe Tip External Diameter 2.5mm Distance between dipoles / probe extremity lmm 3 MEASUREMENT METHOD The IEEE 1528, FCC KDB865664 DOI, CENELEC EN62209 and CEIIIEC 62209 standards provide recommended practices for the probe calibrations , including the performance characteristics of interest and methods by which to assess their affect. All calibrations / measurements performed meet the fore mentioned standards. 3.1 LlNEARITY The evaluation of the linearity was done in白.'eespace using the waveguide, performing a power sweep to cover the SAR range 0. 01 W /kg to I OOW /kg. Page: 4/11 Tel1lplatιACR.DDD.N. YY.fI1VGB.lSSUE二COiHOSARProbe叶 This doclIlllel1l sholll1ol be reprodllced. excepl ill[1I11 01' il1 parl. 11'ilhollllhe lI'r i/lel1 opp ro1'O/ o[ MVG. The il1[orlllOliol1 COI1Iαilled hereil1 is 10 be IIsed 0 11/)'[01' Ihe plllpose[orll'hich il is Sl削li/ledal1d is 110110 be 阿/easedil1l1'ho/e 01' parlll'il/101I1呐illel1apprOl'a / o[MVG COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.197. 12.23.BES.A 3.2 SENSITIVITY The sensitiv川it印yt臼actorsof the th阳ueedi怡po叶le臼swe町redete创rm and tiss饥sues剑1mη111川l川la创川tingliqu川id均)u山singwavegu山idesas outlined in the standards. 3 .3 LOWER DETECTION LIMIT The lower detection limit was assessed using the same measurement set up as used for the linearity measurem…

Text truncated - open the document above for the full version.

Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 1 of 143 TEST REPORT Reference No. .................... : WTX23X11250989W008 FCC ID ................................ : 2AHAF-MDT86 Applicant ........................... : TOPICON HK LIMITED Address ............................. : Room 2314-2316, Tower C, Huangdu Plaza, Yitian Road, Futian District, Shenzhen, China Manufacturer ..................... The same as Applicant Address ............................. The same as Applicant Product Name ................... : Tablet Model No. ........................... : MDT865 Standards .......................... : FCC Part 2.1093 IEEE Std C95.1: 2019 IEEE Std C95.3: 2002 + Rev. 2008 IEC/IEEE 62209-1528 Ed. 1.0 (2020-10) Date of Receipt sample .... : 2023-11-24 Date of Test........................ : 2023-12-29 to 2024-01-02 Date of Issue ..................... : 2024-01-02 Test Report Form No. ....... : WTX_IEEE_1528W Test Result ......................... : Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of approver. Prepared By: Waltek Testing Group (Shenzhen) Co., Ltd. Address: 1/F., Room 101, Building 1, Hongwei Industrial Park, Liuxian 2nd Road, Block 70 Bao'an District, Shenzhen, Guangdong, China Tel.: +86-755-33663308 Fax.: +86-755-33663309 Email: [email protected] Tested by: Approved by: Jack Sun Silin Chen Reference No.: WTX23X11250989W008 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 2 of 143 TABLE OF CONTENTS 1. General Information ................................................................................................................................................... 4 1.1 Product Description for Equipment Under Test (EUT) ......................................................................................... 4 1.2 Test Standards .................................................................................................................................................... 7 1.3 Test Methodology ................................................................................................................................................ 7 1.4 Test Facility ......................................................................................................................................................... 7 2. Summary of Test Results .......................................................................................................................................... 8 3. Specific Absorption Rate (SAR) ................................................................................................................................ 9 3.1 Introduction .......................................................................................................................................................... 9 3.2 SAR Definition ..................................................................................................................................................... 9 4. SAR Measurement System ...................................................................................................................................... 10 4.1 The Measurement System ................................................................................................................................ 10 4.2 Probe ................................................................................................................................................................. 10 4.3 Probe Calibration Process ................................................................................................................................. 12 4.4 Phantom ............................................................................................................................................................ 13 4.5 Device Holder .................................................................................................................................................... 13 4.6 Test Equipment List ........................................................................................................................................... 14 5. Tissue Simulating Liquids ....................................................................................................................................... 15 5.1 Composition of Tissue Simulating Liquid ........................................................................................................... 15 5.2 Tissue Dielectric Parameters for Head and Body Phantoms ............................................................................. 16 5.3 Tissue Calibration Result ................................................................................................................................... 17 6. SAR Measurement Evaluation ................................................................................................................................ 19 6.1 Purpose of System Performance Check ............................................................................................................ 19 6.2 System Setup .................................................................................................................................................... 19 6.3 Validation Results .............................................................................................................................................. 21 7. EUT Testing Position ............................................................................................................................................... 22 7.1 Define Two Imaginary Lines on The Handset .................................................................................................... 22 7.2 Chee…

Text truncated - open the document above for the full version.

Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 1 of 36 TEST REPORT Reference No. .................... : WTX23X11250989W001 FCC ID ................................ : 2AHAF-MDT86 Applicant ........................... : TOPICON HK LIMITED Address ............................. : Room 2314-2316, Tower C, Huangdu Plaza, Yitian Road, Futian District, Shenzhen, China Manufacturer ..................... : The same as Applicant Address ............................. : The same as Applicant Product Name ................... : Tablet Model No... ......................... : MDT865 Standards .......................... : FCC Part 22H, FCC Part 24E, FCC Part 27 Date of Receipt sample .... : 2023-11-24 Date of Test........................ : 2023-11-24 to 2023-12-25 Date of Issue ..................... : 2023-12-25 Test Report Form No. ....... : WTX_Part 22_Part 24_Part 27W Test Result ......................... : Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of approver. Prepared By: Waltek Testing Group (Shenzhen) Co., Ltd. Address: 1/F., Room 101, Building 1, Hongwei Industrial Park, Liuxian 2nd Road, Block 70 Bao'an District, Shenzhen, Guangdong, China Tel.: +86-755-33663308 Fax.: +86-755-33663309 Email: [email protected] Tested by: Approved by: Mike Shi Silin Chen Reference No.: WTX23X11250989W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 2 of 36 TABLE OF CONTENTS 1. GENERAL INFORMATION ................................................................................................................................... 4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ............................................................................... 4 1.2 TEST STANDARDS ..............................................................................................................................................…

Text truncated - open the document above for the full version.
