2AL8S-0231C1KUFast Lane Guard Parts

Remote Control Quick Guide V1.00 1 1 Packing List Contact your local dealer if the package is damaged or incomplete. The package contents may vary with device model. The remote control consists of two separate parts: a transmitter and a receiver, which must be used together. Please purchase separately.  Transmitter 1 Transmitter 1 PCS 2 Product documents 1 Set  Receiver 1 Receiver 1 PCS 2 Cable 1 PCS 3 Screw components 1 Set 4 Product documents 1 Set 2 Product Overview The appearance, structure, and dimensions may vary with device model. The figures below are for illustrative purpose only.  Transmitter ① Indicator Blinks once when you press a button. ② Button Used to open or close the barrier. ③ Toggle switch 2  Receiver ① Cable connector ② Learning mode button  Long press to restore factory defaults;  Used to pair with the transmitter (see 4 Pairing for details). ③ Indicator  Steady on: Normal.  Blinks once: Entering the pairing mode (the indicator will then blink rapidly when the pairing is full).  Blinks twice: Restored to factory defaults. 3 Install the Receiver The receiver can be installed on the middle pedestal or the right pedestal. It is recommended to install the receiver on the side close to the control board on the gate. Before installation, please make sure the installation position and holes (see 0 Product Overview for details) have been reserved on the gate panel to be installed. The following takes the installation on the OFG8501 series swing barrier as an example. The installation steps may vary with the gate model. WARNING! Please make sure the gate is disconnected from power before installation. 1. Remove the 4 hex bolts under the top cover, and then detach the top cover. 3 2. Remove the 2 screws on the panel cover, and then detach the panel cover. 3. Remove the 3 screws on the fixing panel, and then detach the panel. 4. Fix the receiver onto the panel with one screw. 5. Connect the larger end of the supplied cable to the REMOTE port on the gate’s control board (see the silkscreen on the control board). Lead the other end from the inside of the gate through the hole on the panel (see the figure below), and then connect the cable to the connector on the receiver. 6. Reinstall the panel, panel’s top cover, and gate’s top cover back in place in sequence. 4 4 Pairing One receiver can be paired with up to 32 transmitters. 1. After installing the receiver, power up the gate. 2. Press the learning mode button once. The indicator will blink once and the receiver will enter the paring mode. NOTE! If more than one receiver is in the pairing mode at the same time, a transmitter can be paired with multiple receivers simultaneously. 3. Press and hold the two buttons on the transmitter simultaneously. When the receiver’s indicator blinks 5 times rapidly, release the button to complete the pairing and exit the pairing mode. 4. To pair with multiple transmitters, repeat the steps above. 5 How to Use Transmitter The transmitter supports two operating modes: Momentary mode and remain open mode. To switch the operating mode, you need to slide down the rear cover of the transmitter, and then use the toggle to switch.  Momentary mode: Toggle the switch up. Press either button on the transmitter to open the barrier. The barrier will close automatically after a person passes through.  Remain open mode: Toggle the switch down. Press the upper or lower button on the transmitter (which cannot be the same as the last button used) to open the barrier. After a person passes through, press the other button to close the barrier; otherwise, the barrier will remain open (unless a barrier opening signal is received, such as after a successful face recognition). 5 Disclaimer and Safety Warnings Copyright Statement No part of this manual may be copied, reproduced, translated or distributed in any form or by any means without prior consent in writing from our company (referred to as us hereafter). The product described in this manual may contain proprietary software owned by our company and its possible licensors. Unless permitted, no one is allowed to copy, distribute, modify, abstract, decompile, disassemble, decrypt, reverse engineer, rent, transfer, or sublicense the software in any form or by any means. Export Compliance Statement Our company complies with applicable export control laws and regulations worldwide, including that of the People's Republic of China and the United States, and abides by relevant regulations relating to the export, re-export and transfer of hardware, software and technology. Regarding the product described in this manual, our company asks you to fully understand and strictly abide by the applicable export laws and regulations worldwide. Privacy Protection Reminder Our company complies with appropriate privacy protection laws and is committed to protecting user privacy. You may want to read our full privacy policy at our website and get to know the ways we process your personal information. Please be aware, using the product described in this manual may involve the collection of personal information such as face, fingerprint, license plate number, email, phone number, GPS. Please abide by your local laws and regulations while using the product. About This Manual  This manual is intended for multiple product models, and the photos, illustrations, descriptions, etc, in this manual may be different from the actual appearances, functions, features, etc, of the product.  This manual is intended for multiple software versions, and the illustrations and descriptions in this manual may be different from the actual GUI and functions of the software.  Despite our best efforts, technical or typographical errors may exist in this manual. Our company cannot be held responsible for any such errors and reserves the right to change the manual without prior notice.  Users are fully responsible for the damages and losses that arise due to improper operation.  Our company reser…

Text truncated - open the document above for the full version.

ZheJiangUniviewTechnologies Co.,Ltd. U.S. Agent Designationfor Serviceof Process (Applicant and U.S.Agentare SeparateParties) TO:FederalCommunications Commission 7435OaklandMillsRoad Columbia,MD 21046 ATTENTION:FCC Certification– Section2.911(d)(7) Information DesignatedU.S. Agent CompanyName:United ConsultingTechnologyServicesCo., Ltd. FRN:0033495714 Contact Name: DavidWu StreetAddress: 17800CASTLETONST STE665 CITYOF INDUSTRY City/Province/Zip:CA91748 Telephone No: (626) 217-4022 Email:[email protected] This letter is toconfirmthat we (“the DesignatedU.S. Agent)haveacceptedthe responsibility toact as the DesignatedU.S. Agent forServiceof Processas requiredbysection47 CFR2.911(d)(7)on behalfof the Applicantnotedbelow. U .S. AgentSignature: Date:2024-07-17 Signed by(Printed Name/Title):DavidWu/ CEO The Applicant acknowledgesthat theymustmaintainan agentfor noless than one year after terminating all marketing andimportationOR the conclusionofany Commission-relatedproceedinginvolving the equipment.The applicantfurtheracknowledgestheir responsibility toinformthe FCCwheneverthe DesignatedU.S. Agentinformationabove changes. A pplicant Companyname: ZheJiangUniviewTechnologies Co.,Ltd. Grantee Code:2AL8S FCCID: 2AL8S-0231C1KU Contact Name:FengXu StreetAddress: No. 369, XietongRoad,Xixing Sub-district, Binjiang District City/Province/Zip:HangzhouCity, ZhejiangProvince, 310051, China Telephone No: 18106582562 Email:[email protected] Applicant Signature: Date:2024-07-17 Signed by(Printed Name/Title):Feng Xu,Manager

Applicant Declaration QSF27-14-04 Rev 1.0 Rev. Feb 6, 2023 Page 1 of 1 Original Issue: Jan. 4, 2021 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name Zhejiang Uniview Technologies Co., Ltd. Address No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, Zhejiang Province, China Grantee Code 2AL8S FCC ID 2AL8S-0231C1KU Authorized Contact Name Xu Feng Contact Email [email protected] Contact Phone 18106582562 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a)in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b)in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1)labeling the equipment with the exact FCC ID as specified in this application, (2)compliance statement labeling pursuant to the applicable rules, (3)compliance of the equipment with the applicable technical rules, c)if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d)in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e)in accordance with ISO 17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1)the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2)the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3)the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f)neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g)the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Link to the Covered List: Covered List Zhejiang Uniview Technologies Co., Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Zhejiang Uniview Technologies Co., Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [ is not] identified on the Covered list, established pursuant to §1.50002, as an entity producing “covered” equipment. Applicant Signature: Date:2024/5/21 Print Name: Xu Feng Title: Manager *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

ZheJiang Uniview Technologies Co.,Ltd. Current Date 2024-07-17 To: SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. No. 588 West Jindu Road, Songjiang District, Shanghai, China. 201612 Dear Sir/Madam, Subject: Declaration Letter about Identity of Products *WE ZheJiang Uniview Technologies Co.,Ltd., HEREBY DECLARED THAT Product Description: Fast Lane Guard Parts Model No.: OEP-B53-T-xxxxxxxx-yyyyyyyy-zzz (“x”,”y”,”z” can be 0-9,A-Z,a-z or blank;”-” may be blank) Manufacturer’s Name: ZheJiang Uniview Technologies Co.,Ltd. Manufacturer’s Address: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China *Except that the model number and appearance deviation, are identical with the original product as follows: Note: The definition of identical should be “electrically identical”. A device will be considered to be electrically identical if no changes are made to the devices’ schematics, board layouts, component layouts, chip sets, resistors and all other electrical aspects of the device are identical with the model which has been tested by SGS. Model No.: OEP-B53-T-NB Manufacturer’s Name: ZheJiang Uniview Technologies Co.,Ltd. Manufacturer’s Address: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Sincerely, Signature: Printed Name : Feng Xu Position/Title : Manager Contact Number: 18106582562

Zhejiang Uniview Technologies Co., Ltd. Date: 2024/5/21 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: 2AL8S-0231C1KU To whom it may concern: We, the undersigned, hereby authorize Parlam Zhan to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with Zhejiang Uniview Technologies Co., Ltd. . This authorization is valid until further written notice from the applicant. Name (Printed): Xu Feng Title: Manager Signature: On behalf of Company: Zhejiang Uniview Technologies Co., Ltd. Telephone:18106582562

Zhejiang Uniview Technologies Co., Ltd. To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States From: Zhejiang Uniview Technologies Co., Ltd. No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, Zhejiang Province, China Regarding: Confidentiality Request regarding application for FCC ID 2AL8S- 0231C1KU LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. Sincerely, Signature: Printed Name (on file with the FCC associated with the Grantee Code): Xu Feng Title: Manager Company Name: Zhejiang Uniview Technologies Co., Ltd.

Compliance Certification Services (Kunshan) Inc. Page: 1 of 2 External Photos for KSCR2405000906AT Test Model No.: OEP-B53-T-NB Compliance Certification Services (Kunshan) Inc. Page: 2 of 2 EUT Constructional Details (EUT Photos)

Compliance Certification Services (Kunshan) Inc. Page: 1 of 3 Internal Photos for KSCR2405000906AT Test Model No.: OEP-B53-T-NB Compliance Certification Services (Kunshan) Inc. Page: 2 of 3 EUT Constructional Details (EUT Photos) Compliance Certification Services (Kunshan) Inc. Page: 3 of 3

Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240500090602 Page: 1 of 9 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-Conditions/Terms-e-Document.aspx. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 30 days only. Member of the SGS Group (SGS SA) 1 Cover Page RF Exposure Evaluation Report Application No.: KSCR2405000906AT FCC ID: 2AL8S-0231C1KU Applicant: Zhejiang Uniview Technologies Co., Ltd. Address of Applicant: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Manufacturer: Zhejiang Uniview Technologies Co., Ltd. Address of Manufacturer: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Factory: Zhejiang Uniview Systems Technology Co., Ltd. Address of Factory: No.1277 South Qingfeng South Road, Tongxiang City, Jiaxing City, Zhejiang Province, China Equipment Under Test (EUT): EUT Name: Fast Lane Guard Parts Model No.: OEP-B53-T-NB;OEP-B53-T-xxxxxxxx-yyyyyyyy-zzz (“x”,”y”,”z” can be 0- 9,A-Z,a-z or blank;”-” may be blank) Standard(s) : FCC Rules 47 CFR §2.1093 KDB 447498 D04 interim General RF Exposure Guidance v01 Date of Receipt: 2024-05-21 Date of Test: 2024-06-01 to 2024-06-28 Date of Issue: 2024-07-04 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240500090602 Page: 2 of 9 Revision Record Version Description Date Remark 00 Original 2024-07-04 / Authorized for issue by: Tested By Maker Qi /Project Engineer Approved By Terry Hou /Reviewer Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240500090602 Page: 3 of 9 2 Contents Page 1 Cover Page ........................................................................................................................................ 1 2 Contents ............................................................................................................................................ 3 3 General Information .......................................................................................................................... 4 3.1 General Description of E.U.T. .................................................................................................... 4 3.2 Details of E.U.T. ......................................................................................................................... 4 3.3 Test Location .............................................................................................................................. 5 3.4 Test Facility ................................................................................................................................ 5 4 FCC Radiofrequency radiation exposure limits ............................................................................ 6 4.1 Blanket 1 mW Blanket Exemption .............................................................................................. 6 4.2 MPE-based Exemption .............................................................................................................. 6 4.3 SAR-based Exemption ............................................................................................................... 7 5 Measurement and Calculation ......................................................................................................... 9 5.1 Maximum transmit power ........................................................................................................... 9 5.2 RF Exposure Calculation ........................................................................................................... 9 Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240500090602 Page: 4 of 9 3 General Information 3.1 General Description of E.U.T. Power supply: Remote control battery: DC 3V,0.05A Test voltage: DC 3V Product Type: Portable device Mobile device Fixed device 3.2 Details of E.U.T. 433MHz Operation Frequency 433.92MHz Channel Numbers: 1 Modulation Type: FSK Antenna Type: Internal antenna Transmitter type: Manually 3.3 Separation Distance Separation distance between the antenna to person (R): ＜5mm Remark: This minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander. Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240500090602 Page: 5 of 9 3.4 Test Location Compliance Certification Services (Kunshan) Inc. N…

Text truncated - open the document above for the full version.

Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240500090601 Page: 1 of 24 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-Conditions/Terms-e-Document.aspx. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 30 days only. Member of the SGS Group (SGS SA) TEST REPORT Application No.: KSCR2405000906AT FCC ID: 2AL8S-0231C1KU Applicant: Zhejiang Uniview Technologies Co., Ltd. Address of Applicant: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Manufacturer: Zhejiang Uniview Technologies Co., Ltd. Address of Manufacturer: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Factory: Zhejiang Uniview Systems Technology Co., Ltd. Address of Factory: No.1277 South Qingfeng South Road, Tongxiang City, Jiaxing City, Zhejiang Province, China Equipment Under Test (EUT): EUT Name: Fast Lane Guard Parts Model No.: OEP-B53-T-NB;OEP-B53-T-xxxxxxxx-yyyyyyyy-zzz (“x”,”y”,”z” can be 0-9,A- Z,a-z or blank;”-” may be blank)  Please refer to section 2 of this report which indicates which model was actually tested and which were electrically identical. Standard(s) : 47 CFR Part 15, Subpart C 15.231 Date of Receipt: 2024-05-21 Date of Test: 2024-06-01 to 2024-06-28 Date of Issue: 2024-07-04 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240500090601 Page: 2 of 24 Revision Record Version Description Date Remark 00 Original 2024-07-04 / Authorized for issue by: Tested By Maker Qi /Project Engineer Approved By Terry Hou /Reviewer Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240500090601 Page: 3 of 24 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.231 N/A 47 CFR Part 15, Subpart C 15.203 Pass Radio Spectrum Matter Part Item Standard Method Requirement Result 20dB Bandwidth 47 CFR Part 15, Subpart C 15.231 ANSI C63.10 (2013) Section 6.9 47 CFR Part 15, Subpart C 15.231(c) Pass Dwell Time (15.231(a)) ANSI C63.10 (2013) Section 7.5 47 CFR Part 15, Subpart C 15.231(a) Pass Field Strength of the Fundamental Signal (15.231(b)) ANSI C63.10 (2013) Section 6.5 47 CFR Part 15, Subpart C 15.231(b) Pass Radiated Emissions below 1GHz ANSI C63.10 (2013) Section 6.4&6.5 47 CFR Part 15C Section 15.231(b) and 15.209 Pass Radiated Emissions above 1GHz ANSI C63.10 (2013) Section 6.6 47 CFR Part 15C Section 15.231(b) and 15.209 Pass Declaration of EUT Family Grouping: There are series models mentioned in this report and they are the Identical in electrical and electronic characters. Only the model OEP-B53-T-NB was tested since their differences were the model number and appearance. Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240500090601 Page: 4 of 24 3 Contents Page 1 COVER PAGE ............................................................................................................................................ 1 2 Test Summary .................................................................................................................................................. 3 3 Contents ........................................................................................................................................................... 4 4 General Information ........................................................................................................................................ 5 4.1 Details of E.U.T. ........................................................................................................................................ 5 4.2 Description of Support Units ..................................................................................................................... 5 4.3 Measurement Uncertainty ......................................................................................................................... 5 4.4 Test Location ............................................................................................................................................ 6 4.5 Test Facility ............................................................................................................................................... 6 4.6 Deviation from Standards ......................................................................................................................... 6 4.7 Abnormalities from Standard Conditions .................................................................................................. 6 5 Equipment List ..............…

Text truncated - open the document above for the full version.

Justification statement for Antenna To: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: 2AL8S-0231C1KU Dear Sir/Madam, Only radiated measurements are used for EUT with FCC ID: 2AL8S-0231C1KU to show compliance with FCC limits for fundamental and spurious emissions. All measurements were performed radiated and therefore additional antenna gain documentation is not required. The detailed information for antenna as below shows: Design Specifications Typical Antenna Type Internal antenna Working Frequency 433.92MHz

Compliance Certification Services (Kunshan) Inc. Page: 1 of 2 Appendix Photographs of Test Setup for KSCR2405000906AT Test Model No.: OEP-B53-T-NB Compliance Certification Services (Kunshan) Inc. Page: 2 of 2 Test Setup Photo Radiated Emissions below 1GHz Radiated Emissions above 1GHz
