Network PTZ Dome Cameras Quick Guide V1.00 1 Waterproof Requirements Please waterproof cables in accordance with the following instructions. User shall assume all responsibility for device damage caused by water due to improper waterproof measures. NOTE!  Before you start, connect all the needed cables and cut off the copper wires for the cables that you don't use.  Please use self-adhesive waterproof tape (supplied with some products) to protect the cables.  Use waterproof components to protect the network cable. Waterproof the power cable separately if you don’t use it. The video cable does not need waterproof treatment. 1. Use insulation tape (not included in the package) to insulate the connection part of each cable. 2. Waterproof the cables with self-adhesive waterproof tape. (1) Fully stretch the waterproof tape at both ends. (2) Wrap the connection part and the cable ends tightly with waterproof tape. Make sure the tape is fully stretched during the process. (3) Tighten the tape at both ends to prevent water leakage. Connection part Insulation tape 2 3. Install the supplied waterproof components to the network cable in sequence. CAUTION! You need to mount the rubber ring onto the network cable interface first. 4. If your camera has a DC cable and you will not use it, insert the plug into the interface. 5. (Optional) After the waterproof treatment is completed, put the cables into a waterproof junction box (purchased separately). CAUTION!  The cable connector must not be exposed and must be kept away from water.  Restore and fasten the device after dismounting.  Place the power adapter in a power distribution box. W r a p t h e u n u s e d c a b l e s t o g e t h e r i n t o a b u n d l e T i g h t e n T i g h t e n W a t e r p r o o f t a p e T i g h t e n D C i n t e r f a c e P l u g 3 1 Packing List Contact your local dealer if the package is damaged or incomplete. The attachments may vary with models, please see the actual model for details. No. Name Qty Unit 1 Camera 1 PCS 2* Waterproof components（1） 1 Set 3* Screw components（2） 1 Set 4* Mount accessory （3） 1 Set 5 User manual 1 Set Remarks: * means optional and supplied with certain models only. (1)Including one or more waterproof components such as tape and plug. (2)Including one or more accessories such as screws and hex key. (3)Including one or more items from drilling template, bracket adapter, anti-static gloves, etc. 2 Safety Instructions Installation and removal of the unit and its accessories must be carried out by qualified personnel. You must read all of the safety instructions before installation and operation. 2.1 Installation  Use a power adapter or a PoE device that meets requirements. Otherwise, the device may be damaged.  Make sure the length of the power cable between the power adapter and the camera is not too long, otherwise the voltage of the camera is lowered, causing the camera to work abnormally. If it is required to lengthen the power cable, lengthen the cable between the power adapter and the mains.  Do not overbend the cables during the installation, otherwise, poor cable contact may cause malfunction.  When connecting to an external interface, use an existing connection terminal, and ensure that the cable terminal (latch or clamp) is in good condition and 4 properly fastened. Ensure that the cable is not tense during mounting, with a proper margin reserved to avoid poor port contact or loosening caused by shock or shake.  During transportation, special attention is required to protect the transparent dome cover from friction, scratch and stain, etc. Do not remove the protective film from the cover until mounting is finished. Remove the protective film before powering on the device.  Contact professionals for maintenance information. Do not attempt to dismantle the device by yourself. We shall not assume any responsibility for problems caused by unauthorized repair or maintenance. 2.2 Maintenance  If there is grease or a dust stain on the front glass surface, clean the glass surface gently from the center outward using anti-static gloves or an oil-free cloth. If the grease or the stain still remains, use anti-static gloves or an oil-free cloth dipped with detergent and clean the glass surface gently until it is clean.  If there is dust on the front glass surface, remove the dust gently using an oil- free brush or a rubber dust blowing ball.  Do not use organic solvents (benzene, alcohol, etc) to clean the camera. 3 Appearance 3.1 Dimensions The following figure shows device dimensions. The appearance may vary with device model. 151 . 0 mm ( 5 . 9 ") 248 . 0 mm ( 9 . 8 ") 133.0mm (5.2") 185.0mm (7.3") 5 3.2 Cable Connection The appearance and tail cable may vary with device model. 4 Mount Your Camera 4.1 (Optional) Insert Micro SD Card You need to install a Micro SD card first if you want to save video on an on-board SD card. You need to open the back cover of the camera first. Before you insert or remove the Micro SD card, be sure to disconnect power and wait till the camera stops operation; otherwise, the camera or the Micro SD card may be damaged. For recommended SD card specifications, please contact your dealer or technical support. Make sure the sealing ring is in place when you install the back cover; otherwise, waterproof performance may be affected. IP Network Power cable Network cable Reset button Remove the back cover Insert the SD card 6 4.2 Wall Mount Please mount the camera onto the wall. Make sure the wall is strong enough to support the weight of the camera. Please prepare the installation tools in advance. 1. Locate the positions of the holes. Paste installation positioning stickers on the wall and align the cross center to the hole in the wall. 2. Drill holes on the wall. Use a φ6-6.5mm drill bit to drill 30mm-depth guide holes according to the positions marked by the sticker. 3. Mount the plastic rivets of self-tapping screws. Knock the plastic rivets into the guide …
