Smart Wireless Cube Cameras Quick Guide V1.00 1 1 Packing List Contact your local dealer if the package is damaged or incomplete. The attachments may vary with models, please see the actual model for details. No. Name Qty Unit 1 Camera 1 PCS 2 Power adapter 1 PCS 3* Screw components（1） 1 Set 4* Mount accessory （2） 1 Set 5 User manual 1 Set Remarks: * means optional and supplied with certain models only. (1)Including one or more accessories such as screws and hex key. (2)Including one or more items from drilling template, bracket adapter, anti-static gloves, etc. 2 Safety Instructions Installation and removal of the unit and its accessories must be carried out by qualified personnel. You must read all of the safety instructions before installation and operation.  Contact professionals for maintenance information. Do not attempt to dismantle the device by yourself. We shall not assume any responsibility for problems caused by unauthorized repair or maintenance.  If there is dust on the front glass surface, remove the dust gently using an oil- free brush or a rubber dust blowing ball.  If there is grease or a dust stain on the front glass surface, clean the glass surface gently from the center outward using anti-static gloves or an oil-free cloth. If the grease or the stain still remains, use anti-static gloves or an oil-free cloth dipped with detergent and clean the glass surface gently until it is clean.  Do not use organic solvents (such as benzene and alcohol) to clean the transparent dome cover. 2 3 Appearance The following figure shows device dimensions. The appearance may vary with device model. 77 mm ( 3 . 0 ") 125 mm ( 4 . 9 ") 42 mm ( 1 . 7 ") Φ 83 mm Φ ( 3 . 3 ") 77 mm ( 3 . 0 ") Microphone Indicator Lens Micro SD card slot 3 NOTE! Use the reset button to restore factory defaults. When the camera is operating, press and hold the reset button for at least 10 seconds, and wait for the camera to restart. Factory default settings are restored when the camera is restarted. Speaker Adjustable bracket RESET button Power interface Network interface 4 NOTE! Use the adjustable bracket to adjust monitoring direction. 4 Mount Your Camera 4.1 (Optional) Insert the Micro SD Card You need to install a Micro SD card first if you want to save video on an on-board SD card. Insert the Micro SD card into the side card slot. Before you insert or remove the Micro SD card, be sure to disconnect power and wait till the camera stops operation; otherwise, the camera or the Micro SD card may be damaged. 4.2 Wall Mount The camera base, pre-installed with magnet, attaches to magnetic surfaces. If wall mounting is adopted, make sure the surface of the wall is flat and clean. Fix the iron plate to the wall before mounting the camera. The detailed steps are as follows. 1. Fix the provided iron plate to the wall, mark the positions of holes on the plate, and drill 5.8mm-5.9mm guide holes on the wall according to the positions. Micro SD card slot 5 2. Insert the plastic expansion bolts, knock them into the wall with a rubber hammer, and make sure that they are tightened up. 3. Screw the iron plate to the wall. 4. Attach the camera to the plate. 5 Startup After you have installed the device, connect one end of the power adapter to power supply, and then connect the other end to the power interface to start up the device. 6 6 Access Your Camera 1. Open your Web browser, enter the camera's IP address in the address bar, and then press Enter. The default IP is 192.168.1.13. 2. In the login page, enter the default username and password (admin/123456), then click Login. NOTE!  DHCP is enabled by default. If a DHCP server is used in your network, your camera may be assigned an IP address, and you need to use the assigned IP address to log in.  You may need to install a plug-in at your first login. Please follow the on-screen instructions to complete the installation and then open the browser again to log in.  The default password is intended only for your first login. To ensure security, please change the password after your first login. You are strongly recommended to set a strong password of at least nine characters including all three elements: digits, letters and special characters.  If the password has been changed, please use the new password to log in. 7 Disclaimer and Safety Warnings Copyright Statement ©2020 Zhejiang Uniview Technologies Co., Ltd. All rights reserved. No part of this manual may be copied, reproduced, translated or distributed in any form by any means without prior content in writing from Zhejiang Uniview Technologies Co., Ltd (referred to as Uniview or us hereafter). The product described in this manual may contain proprietary software owned by Uniview and its possible licensors. Unless permitted by Uniview and its licensors, no one is allowed to copy, distribute, modify, abstract, decompile, disassemble, decrypt, reverse engineer, rent, transfer, or sublicense the software in any form by any means. Trademark Acknowledgements are trademarks or registered trademarks of Uniview. All other trademarks, products, services and companies in this manual or the product described in this manual are the property of their respective owners. Export Compliance Statement Uniview complies with applicable export control laws and regulations worldwide, including that of the People's Republic of China and the United States, and abides by relevant regulations relating to the export, re-export and transfer of hardware, software and technology. Regarding the product described in this manual, Uniview asks you to fully understand and strictly abide by the applicable export laws and regulations worldwide. Privacy Protection Reminder Uniview complies with appropriate privacy protection laws and is committed to protecting user privacy. You may want to read our full privacy policy at our website and get to know the ways we process your personal information. Please be aware, using the product described in this manu…

Text truncated - open the document above for the full version.

Applicant Declaration SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name ZHEJIANG UNIVIEW TECHNOLOGIES CO LTD Address 88 JIANGLING ROAD BINJIANG DISTRICT,HANGZHOU,China Grantee Code 2AL8S FCC ID 2AL8S-0235C54W Authorized Contact Name Feng Xu Contact Email [email protected] Contact Phone +86 18106582562 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Applicant Signature: Date: 2021-01-25 Print Name: Feng Xu Title: Certification Engineer Applicant Declaration Rev:0. 0 Applicant Declaration SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database Applicant Declaration Rev:0. 0

Zhejiang Uniview Technologies Co.,Ltd Current Date 2021/02/02 To: Compliance Certification Services Inc. No. 10, Weiye Rd, Innovation Park, Eco&Tec Development Zone, Kunshan, Jiangsu Dear Sir/Madam, Subject: Declaration Letter about Identity of Products *WE Zhejiang Uniview Technologies Co.,Ltd. HEREBY DECLARED THAT Our product: Product Description: IP Camera And the models below : Model No.: C1L-xxxxxxxx-yyyyyyyy-zzz (x,y,z are variables, can be "0-9", "A-Z","a-z" or blank, the differences of the basic function. "-" is optional) Manufacturer’s Name: Zhejiang Uniview Technologies Co.,Ltd. Manufacturer’s Address: 88 JIANGLING ROAD BINJIANG DISTRICT,HANGZHOU,China with the model(s) below which samples we chose to be tested by SGS Model No.: C1L-2WN-G Manufacturer’s Name: Zhejiang Uniview Technologies Co.,Ltd. Manufacturer’s Address: 88 JIANGLING ROAD BINJIANG DISTRICT,HANGZHOU,China *Except that the model number and appearance deviation, are identical with the original product as follows: Note: The definition of identical should be “electrically identical”. A device will be considered to be electrically identical if no changes are made to the devices’ schematics, board layouts, component layouts, chip sets, resistors and all other electrical aspects of the device are identical. Sincerely, Signature: Printed Name : Feng Xu Position/Title : Certification Engineer Contact Number: +86 18106582562

ZHEJIANG UNIVIEW TECHNOLOGIES CO LTD Date: 2020/01/25 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: 2AL8S-0235C54W To whom it may concern: We, the undersigned, hereby authorize Parlam Zhan to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with ZHEJIANG UNIVIEW TECHNOLOGIES CO LTD. This authorization is valid until further written notice from the applicant. Name (Printed): Xu Feng Title: Certification Engineer Signature: On behalf of Company: ZHEJIANG UNIVIEW TECHNOLOGIES CO LTD Telephone: +86 18106582562

ZHEJIANG UNIVIEW TECHNOLOGIES CO LTD To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States From: ZHEJIANG UNIVIEW TECHNOLOGIES CO LTD 88 JIANGLING ROAD BINJIANG DISTRICT 310051 HANGZHOU China Regarding: Confidentiality Request regarding application for FCC ID: 2AL8S-0235C54W LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. Sincerely, Signature: Printed Name (on file with the FCC associated with the Grantee Code): Feng Xu Title:Certification Engineer Company Name: ZHEJIANG UNIVIEW TECHNOLOGIES CO LTD

Compliance Certification Services (Kunshan) Inc. Page: 1 of 4 Page 1 of 4 External Photos Applicant: Zhejiang Uniview Technologies Co., Ltd. Address of Applicant: 88 Jiangling Road, Xixing Town, Binjiang District, Hangzhou City Equipment Under Test (EUT): Product Name: IP Camera Model No.: C1L-2WN-G Compliance Certification Services (Kunshan) Inc. Page: 2 of 4 Page 2 of 4 Compliance Certification Services (Kunshan) Inc. Page: 3 of 4 Page 3 of 4 Compliance Certification Services (Kunshan) Inc. Page: 4 of 4 Page 4 of 4 End

Label location

Compliance Certification Services (Kunshan) Inc. Page: 1 of 5 Internal Photos Applicant: Zhejiang Uniview Technologies Co., Ltd. Address of Applicant: 88 Jiangling Road, Xixing Town, Binjiang District, Hangzhou City Equipment Under Test (EUT): Product Name: IP Camera Model No.: C1L-2WN-G Compliance Certification Services (Kunshan) Inc. Page: 2 of 5 Compliance Certification Services (Kunshan) Inc. Page: 3 of 5 Compliance Certification Services (Kunshan) Inc. Page: 4 of 5 Compliance Certification Services (Kunshan) Inc. Page: 5 of 5 End

Compliance Certification Services (Kunshan) Inc. Report No.: KSEM210100008102 Page: 1 of 8 Eric Lin EMC Lab Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. 1 Cover Page RF Exposure Evaluation Report Application No.: KSEM2101000081CR FCC ID: 2AL8S-0235C54W Applicant: Zhejiang Uniview Technologies Co., Ltd. Address of Applicant: 88 Jiangling Road, Xixing Town, Binjiang District, Hangzhou City Manufacturer: Zhejiang Uniview Technologies Co., Ltd. Address of Manufacturer: 88 Jiangling Road, Xixing Town, Binjiang District, Hangzhou City Factory: Zhejiang Uniview Systems Technology Co., Ltd. Address of Factory: No.1277 South Qingfeng South Road, Tongxiang City, Jiaxing City, Zhejiang Province, China Equipment Under Test (EUT): EUT Name: IP Camera Model No.: C1L-2WN-G Add Model No.: C1L-xxxxxxxx-yyyyyyyy-zzz (x,y,z are variables, can be "0-9", "A-Z","a-z" or blank, the differences of the basic function. "-" is optional) Standard(s) : FCC Rules 47 CFR §2.1091 KDB447498 D01 General RF Exposure Guidance v06 Date of Receipt: 2021-01-15 Date of Test: 2021-01-18 to 2021-01-29 Date of Issue: 2021-02-01 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Compliance Certification Services (Kunshan) Inc. Report No.: KSEM210100008102 Page: 2 of 8 Revision Record Version Description Date Remark 00 Original 2021-02-01 / Authorized for issue by: Damon zhou / Project Engineer Eric Lin / Reviewer Compliance Certification Services (Kunshan) Inc. Report No.: KSEM210100008102 Page: 3 of 8 2 Contents Page 1 COVER PAGE................................................................................................................................................. 1 2 CONTENTS ..................................................................................................................................................... 3 3 GENERAL INFORMATION .......................................................................................................................... 4 3.1 GENERAL DESCRIPTION OF E.U.T. ................................................................................................................ 4 3.2 TECHNICAL SPECIFICATIONS ......................................................................................................................... 4 3.3 TEST LOCATION ............................................................................................................................................. 5 3.4 TEST FACILITY .............................................................................................................................................. 5 4 TEST STANDARDS AND LIMITS ............................................................................................................... 6 4.1 FCC RADIOFREQUENCY RADIATION EXPOSURE LIMITS: ................................................................................ 6 5 MEASUREMENT AND CALCULATION .................................................................................................... 7 5.1 MAXIMUM TRANSMIT POWER ........................................................................................................................ 7 5.2 MPE CALCULATION ...................................................................................................................................... 8 Compliance Certification Services (Kunshan) Inc. Report No.: KSEM210100008102 Page: 4 of 8 3 General Information 3.1 General Description of E.U.T. Power supply: DC 5V by adapter 3.2 Technical Specifications 2.4G WiFi Antenna Gain: 3.5dBi Antenna Type: PCB Antenna Channel Spacing: 5MHz Modulation Type: 802.11b: DSSS (CCK, DQPSK, DBPSK) 802.11g/n: OFDM (64QAM, 16QAM, QPSK, BPSK) Number of Channels: 802.11b/g/n(HT20):11 802.11n(HT40):7 Operation Frequency: 802.11b/g/n(HT20): 2412MHz to 2462MHz 802.11n(HT40): 2422MHz to 2452MHz Compliance Certification Services (Kunshan) Inc. Report No.: KSEM210100008102 Page: 5 of 8 3.3 Test Location All tests were performed at: Compliance Certification Services (Kunshan) Inc. No.10 Weiye Rd, Innovation park, Eco&Tec, Development Zone, Kunshan City, Jiangsu, China. Tel: +86 512 5735 5888 Fax: +86 512 5737 0818 No tests were sub-contracted. 3.4 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • CNAS (No. CNAS L4354) CNAS has accredited Compliance Certification Services (Kunshan) Inc. to ISO/IEC 17025:2017 General Requirements for the Competence of Testing and Calibration Laboratories (CNAS-CL01 Accreditation Criteria for the Competence of Testing and Calibration Laboratories) for the competence in the field of testing. • A2LA (Certificate No. 2541.01) Compliance Certification Services (Kunshan) Inc. is accredited by the American Association for Laboratory Accreditation (A2LA). Certificate No. 2541.01. • FCC –Designation Number: CN1172 Compliance Certification Services Inc. has been recognized as an accredited testing laboratory. Designation Number: CN1172. Test Firm Registration Number: 995260. • ISED (CAB identifier: CN0072) Compliance Certification Services (Kunshan) Inc. has been recognized by Innovation, Science and Economic Development Canada (ISED) as an accredited testing laboratory. CAB Identifier: CN0072. • VCCI (Member No.: 1938) The 3m and 10m Semi-anechoic chamber and Shielded Room of Compliance Certification Services (Kunshan) Inc. has been registered in accor…

Text truncated - open the document above for the full version.

Compliance Certification Services (Kunshan) Inc. Appendix A for KSEM210100008101 1. Duty Cycle 1.1 Test Result Test Mode Channel Frequency(M Hz) TX Type ANT No. T_on (ms) Period (ms) Duty Cycle (%) Duty Cycle Correction Factor (dB) 802.11b 2412 SISO 1 12.410 12.560 98.81 0.05 2437 SISO 1 12.420 12.580 98.73 0.06 2462 SISO 1 12.420 12.530 99.12 0.04 802.11g 2412 SISO 1 2.038 2.198 92.72 0.33 2437 SISO 1 2.036 2.160 94.26 0.26 2462 SISO 1 2.036 2.204 92.38 0.34 802.11n(HT20) 2412 SISO 1 1.920 2.064 93.02 0.31 2437 SISO 1 1.920 2.073 92.62 0.33 2462 SISO 1 1.919 2.090 91.82 0.37 802.11n(HT40) 2422 SISO 1 0.916 1.047 87.49 0.58 2437 SISO 1 0.917 1.048 87.50 0.58 2452 SISO 1 0.916 1.082 84.66 0.72 1.2 Test Graph Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. 2. Bandwidth 2.1 Test Result Test Mode Frequency (MHz) TX Type ANT No. 6dB Bandwidth Verdict Test Result (MHz) 802.11b 2412 SISO 1 9.092 PASS 2437 SISO 1 9.102 PASS 2462 SISO 1 9.092 PASS 802.11g 2412 SISO 1 16.126 PASS 2437 SISO 1 16.364 PASS 2462 SISO 1 16.385 PASS 802.11n(HT20) 2412 SISO 1 17.241 PASS 2437 SISO 1 17.577 PASS 2462 SISO 1 17.207 PASS 802.11n(HT40) 2422 SISO 1 35.470 PASS 2437 SISO 1 35.836 PASS 2452 SISO 1 35.529 PASS Compliance Certification Services (Kunshan) Inc. Test Mode Frequency (MHz) TX Type ANT No. 99% Occupied Bandwidth Test Result (MHz) 802.11b 2412 SISO 1 14.561 Only for Report Use 2437 SISO 1 14.576 Only for Report Use 2462 SISO 1 14.162 Only for Report Use 802.11g 2412 SISO 1 17.167 Only for Report Use 2437 SISO 1 16.927 Only for Report Use 2462 SISO 1 16.952 Only for Report Use 802.11n(HT20) 2412 SISO 1 18.021 Only for Report Use 2437 SISO 1 18.061 Only for Report Use 2462 SISO 1 17.946 Only for Report Use 802.11n(HT40) 2422 SISO 1 37.015 Only for Report Use 2437 SISO 1 36.836 Only for Report Use 2452 SISO 1 36.930 Only for Report Use 2.2 Test Graph - 6dB Bandwidth Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. 2.3 Test Graph - 99% Occupied Bandwidth Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. 3. Maximum Conducted Output Power 3.1 Test Result Test Mode Frequency (MHz) Tx Type Measured Peak Output Power (dBm) Limits (dBm) Verdict Ant 1 802.11b 2412 SISO 17.34 30 PASS 2437 SISO 17.57 30 PASS 2462 SISO 16.75 30 PASS 802.11g 2412 SISO 17.72 30 PASS 2437 SISO 17.28 30 PASS 2462 SISO 16.57 30 PASS 802.11n(HT20) 2412 SISO 16.95 30 PASS 2437 SISO 17.64 30 PASS 2462 SISO 16.93 30 PASS 802.11n(HT40) 2422 SISO 17.78 30 PASS 2437 SISO 17.97 30 PASS Compliance Certification Services (Kunshan) Inc. 2452 SISO 17.66 30 PASS 3.2 Test Graph Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. Compliance Certification Services (Kunshan) Inc. 4. Maximum Power Spectral Density (PSD) 4.1 Test Result Test Mode Frequency (MHz) Tx Type Maximum Power Spectral Density (dBm/3KHz) Limits (dBm/3kHz) Verdict Ant 1 802.11b 2412 SISO -8.16 ≤8 PASS 2437 SISO -7.99 ≤8 PASS 2462 SISO -7.83 ≤8 PASS 802.11g 2412 SISO -11.87 ≤8 PASS 2437 SISO -15.64 ≤8 PASS 2462 SISO -15.90 ≤8 PASS 802.11n(HT20) 2412 SISO -15.92 ≤8 PASS 2437 SISO -15.22 ≤8 PASS 2462 SISO -16.73 ≤8 PASS 802.11n(HT40) 2422 SISO -16.70 ≤8 PASS 2437 SISO -16.58 ≤8 PASS 2452 SISO -16.82 ≤8 PASS Compliance Certification Services (Kunshan) Inc. 4.2 Test Graph

Compliance Certification Services (Kunshan) Inc. Report No.: KSEM210100008101 Page: 1 of 75 Eric Lin EMC Lab Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. TEST REPORT Application No.: KSEM2101000081CR FCC ID: 2AL8S-0235C54W Applicant: Zhejiang Uniview Technologies Co., Ltd. Address of Applicant: 88 Jiangling Road, Xixing Town, Binjiang District, Hangzhou City Manufacturer: Zhejiang Uniview Technologies Co., Ltd. Address of Manufacturer: 88 Jiangling Road, Xixing Town, Binjiang District, Hangzhou City Factory: Zhejiang Uniview Systems Technology Co., Ltd. Address of Factory: No.1277 South Qingfeng South Road, Tongxiang City, Jiaxing City, Zhejiang Province, China Equipment Under Test (EUT): EUT Name: IP Camera Model No.: C1L-2WN-G, C1L-xxxxxxxx-yyyyyyyy-zzz (x,y,z are variables, can be "0-9", "A-Z","a-z" or blank, the differences of the basic function. "-" is optional)¤ ¤ Please refer to section 2 of this report which indicates which model was actually tested and which were electrically identical. Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2021-01-15 Date of Test: 2021-01-18 to 2021-01-29 Date of Issue: 2021-02-01 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Compliance Certification Services (Kunshan) Inc. Report No.: KSEM210100008101 Page: 2 of 75 Revision Record Version Description Date Remark 00 Original 2021-02-01 / Authorized for issue by: Damon Zhou / Project Engineer Eric Lin / Reviewer Compliance Certification Services (Kunshan) Inc. Report No.: KSEM210100008101 Page: 3 of 75 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Minimum 6dB Bandwidth 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Conducted Peak Output Power 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 11.9.1 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Power Spectrum Density 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 11.10.2 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 11.13.3.2 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass Radiated Emissions which fall in the restricted bands 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.209 & 15.247(d) Pass Radiated Spurious Emissions 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.4,6.5,6.6 47 CFR Part 15, Subpart C 15.209 & 15.247(d) Pass Declaration of EUT Family Grouping: Note: There are series models mentioned in this report, and they are the similar in electrical and electronic characters. Only the model DC1L-2WN-G was tested since their differences were the model number and appearance. Compliance Certification Services (Kunshan) Inc. Report No.: KSEM210100008101 Page: 4 of 75 3 Contents Page 1 COVER PAGE ............................................................................................................................................. 1 2 TEST SUMMARY ......................................................................................................................................... 3 3 CONTENTS .................................................................................................................................................. 4 4 GENERAL INFORMATION ......................................................................................................................... 5 4.1 DETAILS OF E.U.T. ..............................…
