2AL8S-0235C76TFace Recognition Access Control Terminal

Face Recognition Access Control Terminal Quick Guide V1.00 1 1 Packing List The package contents may vary with device model and version. No. Name Qty Unit 1 Face recognition access control terminal 1 PCS 2 Wall mount bracket 1 PCS 3 Tail cable 1 PCS 4 Screw pack 2 Set 5 Drill template 1 PCS 6 Product document 1 Set 2 Introduction The face recognition access control terminal (hereinafter referred to as terminal) features high performance and high reliability. It can control door opening by face recognition based authentication to implement efficient access control. 2.1 Appearance and Dimensions The appearance and dimensions may vary with device model. The figures below are only for illustrative purpose. 2.2 Structure The structure may vary with device model. The figures below are only for illustrative 23mm [0.9"] 49mm [1.9"] 91mm [3.6"] 116mm [4.6"] 116mm [4.6"] 2 purpose. 1. Camera 2. Display screen 3. IR illuminator 4. Doorbell button 5. QR code button 6. Tamper-proof button 7. Cover 8. Tail cable interface 3 Installation 3.1 Wiring Before installation, plan wiring for power cable, network cable, door lock cable, RS485 cable, etc. The number of cables depends on the actual networking conditions. See the figures below for wiring between the terminal and other devices. NOTE! For wiring terminals of the devices connected to the terminal, see the operation manual of the corresponding devices or consult the device manufacturer. 1 2 3 5 6 7 8 4 3 Figure 3-1 Wiring schematic diagram (without security module) Figure 3-2 Wiring schematic diagram (with security module) 3.2 Tools • Phillips screwdriver • ESD wrist strap or gloves • Electric drill • Tape measure • Marker 4 3.3 Installation Steps 3.3.1 Wall Mount 1. (Optional) Install a temperature measurement module onto the cover of the terminal by the clip. 2. Determine the position of the 86*86mm junction box. The two installation holes on the box should be parallel to the ground during actual installation. NOTE: If no junction box has been buried in the wall, skip to step 3. 3. Paste the drill template. • With junction box: Align the two holes (A) on the drill template with the two installation holes on the junction box. See the left figure below. • Without junction box: Paste the drill template on the wall with the arrow perpendicular to the ground. Use a Ø6-6.5mm drill bit to drill two 30 mm-depth holes on the A position (be careful not to damage cables in the wall), then insert the expansion bolts. See the right figure below. Attach the module onto the cover 5 4. Mount the bracket. Align bracket holes with installation holes of the junction box on the wall, and tighten the screws to fasten the bracket by using the Phillips screwdriver. NOTE: If no junction box, you need to drill the bracket holes on the wall. 5. Fasten the terminal to the bracket hook. 6. Use the screwdriver to tighten the tamper-proof screw at the bottom of the terminal. 6 3.3.2 Desktop Mounting 1. (Optional) Install the temperature measurement module onto the cover of the terminal by the clip. 2.Insert the bracket into the holes on the back of the terminal. 3. Place the terminal on the horizontal desktop. 4.To remove the bracket, press the bottom of the bracket and then withdraw backwards. 4 Startup After the terminal is installed correctly, connect one end of the power adapter (user- purchased or prepared) to the power interface of the terminal and the other end to the mains supply to start it up. The display screen lights up and live video is displayed when the terminal is started successfully. 5 Appendix 5.1 Face Photo Collection Requirements ⚫General requirement: Facing the camera without wearing a hat, cap, etc. ⚫Range requirement: The photo should show both ears and the complete part from the top of the head (including hair) to the bottom of the neck of the person. ⚫Color requirement: True color photo. ⚫Makeup requirement: Heavy makeup is not allowed, including eyebrow makeup and eyelash makeup. cover 7 ⚫ Background requirement: A solid color such as white or blue is acceptable. ⚫ Light requirement: Not too dark or too bright, and not partially dark and partially bright. 5.2 Face Recognition Requirements ⚫ Facial Expression To ensure the collection quality and comparison accuracy of face photos, keep a natural facial expression during face collection and comparison. ⚫ Head Pose To ensure face collection quality, keep your face in the center of the recognition window and avoid incorrect poses shown below. Correct Tilt Side Raise Bow 8 Disclaimer and Safety Warnings Copyright Statement ©2023 Zhejiang Uniview Technologies Co., Ltd. All rights reserved. No part of this manual may be copied, reproduced, translated or distributed in any form or by any means without prior consent in writing from Zhejiang Uniview Technologies Co., Ltd (referred to as Uniview or us hereafter). The product described in this manual may contain proprietary software owned by Uniview and its possible licensors. Unless permitted by Uniview and its licensors, no one is allowed to copy, distribute, modify, abstract, decompile, disassemble, decrypt, reverse engineer, rent, transfer, or sublicense the software in any form or by any means. Trademark Acknowledgements are trademarks or registered trademarks of Uniview. All other trademarks, products, services and companies in this manual or the product described in this manual are the property of their respective owners. Export Compliance Statement Uniview complies with applicable export control laws and regulations worldwide, including that of the People's Republic of China and the United States, and abides by relevant regulations relating to the export, re-export and transfer of hardware, software and technology. Regarding the product described in this manual, Uniview asks you to fully understand and strictly abide by the applicable export laws and regulations worldwide. EU Authorised Representative UNV Technology EUROPE B.V. Room 2945,3rd Floor,Randsta…

Text truncated - open the document above for the full version.

ZheJiangUniviewTechnologies Co.,Ltd. U.S. Agent Designationfor Serviceof Process (Applicant and U.S.Agentare SeparateParties) TO:FederalCommunications Commission 7435OaklandMillsRoad Columbia,MD 21046 ATTENTION:FCC Certification– Section2.911(d)(7) Information DesignatedU.S. Agent CompanyName:United ConsultingTechnologyServicesCo., Ltd. FRN:0033495714 Contact Name: DavidWu StreetAddress: 17800CASTLETONST STE665 CITYOF INDUSTRY City/Province/Zip:CA91748 Telephone No: (626) 217-4022 Email:[email protected] This letter is toconfirmthat we (“the DesignatedU.S. Agent)haveacceptedthe responsibility toact as the DesignatedU.S. Agent forServiceof Processas requiredbysection47 CFR2.911(d)(7)on behalfof the Applicantnotedbelow. U .S. AgentSignature: Date:2023-05-15 Signed by(Printed Name/Title):DavidWu/CEO The Applicant acknowledgesthat theymustmaintainan agentfor noless than one year after terminating all marketing andimportationOR the conclusionofany Commission-relatedproceedinginvolving the equipment.The applicantfurtheracknowledgestheir responsibility toinformthe FCCwheneverthe DesignatedU.S. Agentinformationabove changes. A pplicant Companyname: ZheJiangUniviewTechnologies Co.,Ltd. Grantee Code:2AL8S FCCID: 2AL8S-0235C76T Contact Name:FengXu StreetAddress: No. 369, XietongRoad,Xixing Sub-district, Binjiang District City/Province/Zip:HangzhouCity, ZhejiangProvince, 310051, China Telephone No: 18106582562 Email:[email protected] Applicant Signature: Date:2023-05-15 Signed by(Printed Name/Title):Feng Xu,Manager

Applicant Declaration QSF27-14-04 Rev 1.0 Rev. Feb 6, 2023 Page 1 of 1 Original Issue: Jan. 4, 2021 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name ZheJiang Uniview Technologies Co.,Ltd. Address No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Grantee Code 2AL8S FCC ID 2AL8S-0235C76T Authorized Contact Name Feng Xu Contact Email [email protected] Contact Phone 18106582562 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO 17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Link to the Covered List: Covered List [ZheJiang Uniview Technologies Co.,Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. [ZheJiang Uniview Technologies Co.,Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered list, established pursuant to §1.50002, as an entity producing “covered” equipment. Applicant Signature: Date: 2023-05-15 Print Name: Feng Xu Title: Manager *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

ZheJiang Uniview Technologies Co.,Ltd. Current Date 2023-05-15 To: SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. No. 588 West Jindu Road, Songjiang District, Shanghai, China. 201612 Dear Sir/Madam, Subject: Declaration Letter about Identity of Products *WE ZheJiang Uniview Technologies Co.,Ltd., HEREBY DECLARED THAT Product Description: Face Recognition Access Control Terminal Model No.: OET-542B-H-W-xxxxxxxx-yyyyyyyy-zzz("x","y";"z" can be 0-9;A-Z;a-z or blank;"- "may be blank) Manufacturer’s Name: ZheJiang Uniview Technologies Co.,Ltd. Manufacturer’s Address: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China *Except that the model number and appearance deviation, are identical with the original product as follows: Note: The definition of identical should be “electrically identical”. A device will be considered to be electrically identical if no changes are made to the devices’ schematics, board layouts, component layouts, chip sets, resistors and all other electrical aspects of the device are identical with the model which has been tested by SGS. Model No.: OET-542B-H-W-R Manufacturer’s Name: ZheJiang Uniview Technologies Co.,Ltd. Manufacturer’s Address: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Sincerely, Signature: Printed Name : Feng Xu Position/Title : Manager Contact Number: 18106582562

ZheJiang Uniview Technologies Co.,Ltd. Date: 2023-05-15 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: 2AL8S-0235C76T To whom it may concern: We, the undersigned, hereby authorize Parlam Zhan to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with ZheJiang Uniview Technologies Co.,Ltd.. This authorization is valid until further written notice from the applicant. Name (Printed): Feng Xu Title: Manager Signature: On behalf of Company: ZheJiang Uniview Technologies Co.,Ltd. Telephone: 18106582562

ZheJiang Uniview Technologies Co.,Ltd. To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States From: ZheJiang Uniview Technologies Co.,Ltd. No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Regarding: Confidentiality Request regarding application for FCC ID: 2AL8S-0235C76T LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. Sincerely, Signature: Printed Name (on file with the FCC associated with the Grantee Code): Feng Xu Title: Manager Company Name: ZheJiang Uniview Technologies Co.,Ltd.

Compliance Certification Services (Kunshan) Inc. Page: 1 of 5 External Photos for KSCR2304000673AT Test Model No: OET-542B-H-W-R Compliance Certification Services (Kunshan) Inc. Page: 2 of 5 EUT Constructional Details (EUT Photos) Compliance Certification Services (Kunshan) Inc. Page: 3 of 5 Compliance Certification Services (Kunshan) Inc. Page: 4 of 5 Compliance Certification Services (Kunshan) Inc. Page: 5 of 5

Compliance Certification Services (Kunshan) Inc. Page: 1 of 6 Internal Photos for KSCR2304000673AT Test Model No: OET-542B-H-W-R Compliance Certification Services (Kunshan) Inc. Page: 2 of 6 EUT Constructional Details (EUT Photos) Compliance Certification Services (Kunshan) Inc. Page: 3 of 6 Compliance Certification Services (Kunshan) Inc. Page: 4 of 6 Compliance Certification Services (Kunshan) Inc. Page: 5 of 6 Compliance Certification Services (Kunshan) Inc. Page: 6 of 6

Compliance Certification Services (Kunshan) Inc. Report No.: KSCR230400067302 Page: 1 of 11 Eric Lin Laboratory Manager 1 Cover Page RF Exposure Evaluation Report Application No.: KSCR2303000673AT FCC ID: 2AL8S-0235C76T Applicant: Zhejiang Uniview Technologies Co., Ltd. Address of Applicant: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Manufacturer: Zhejiang Uniview Technologies Co., Ltd. Address of Manufacturer: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Factory: Zhejiang Uniview Systems Technology Co., Ltd. Address of Factory: No.1277 South Qingfeng South Road, Tongxiang City, Jiaxing City, Zhejiang Province, China Equipment Under Test (EUT): EUT Name: Face Recognition Access Control Terminal Model No.: OET-542B-H-W-R,OET-542B-H-W-xxxxxxxx-yyyyyyyy-zzz("x","y";"z" can be 0-9;A-Z;a-z or blank;"- "may be blank) Standard(s) : FCC Rules 47 CFR §2.1091 KDB 447498 D04 interim General RF Exposure Guidance v01 Date of Receipt: 2023-04-19 Date of Test: 2023-04-25 to 2023-05-04 Date of Issue: 2023-05-06 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Compliance Certification Services (Kunshan) Inc. Report No.: KSCR230400067302 Page: 2 of 11 Revision Record Version Description Date Remark 00 Original 2023-05-06 / Authorized for issue by: Damon_Zhou/Project Engineer Eric Lin /Reviewer Compliance Certification Services (Kunshan) Inc. Report No.: KSCR230400067302 Page: 3 of 11 2 Contents Page 1 COVER PAGE .................................................................................................................................... 1 2 CONTENTS ........................................................................................................................................ 3 3 GENERAL INFORMATION ................................................................................................................ 4 3.1 GENERAL DESCRIPTION OF E.U.T. ................................................................................................ 4 3.2 DETAILS OF E.U.T. ....................................................................................................................... 4 3.3 TEST LOCATION ............................................................................................................................ 5 3.4 TEST FACILITY .............................................................................................................................. 5 4 FCC RADIOFREQUENCY RADIATION EXPOSURE LIMITS .......................................................... 6 4.1 BLANKET 1 MW BLANKET EXEMPTION ........................................................................................... 6 4.2 MPE-BASED EXEMPTION .............................................................................................................. 6 4.3 SAR-BASED EXEMPTION ............................................................................................................... 7 5 MEASUREMENT AND CALCULATION .......................................................................................... 10 5.1 MAXIMUM TRANSMIT POWER ....................................................................................................... 10 5.2 RF EXPOSURE CALCULATION ...................................................................................................... 10 Compliance Certification Services (Kunshan) Inc. Report No.: KSCR230400067302 Page: 4 of 11 3 General Information 3.1 General Description of E.U.T. Power supply: DC 12V,1.0A 3.2 Details of E.U.T. Operation Frequency: 802.11b/g/n(HT20): 2412MHz to 2462MHz; 802.11n(HT40): 2422MHz to 2452MHz Modulation Type: 802.11b: DSSS (CCK, DQPSK, DBPSK); 802.11g/n: OFDM (64QAM, 16QAM, QPSK, BPSK) Number of Channels: 802.11b/g/n(HT20):11;802.11n(HT40):7 Channel Spacing: 5MHz Antenna Type: FPC Antenna Antenna Gain: 1.99dBi (Provided by the manufacturer) Compliance Certification Services (Kunshan) Inc. Report No.: KSCR230400067302 Page: 5 of 11 3.3 Test Location Compliance Certification Services (Kunshan) Inc. No.10 Weiye Rd, Innovation park, Eco&Tec, Development Zone, Kunshan City, Jiangsu, China. Tel: +86 512 5735 5888 Fax: +86 512 5737 0818 Note: 1.SGS is not responsible for wrong test results due to incorrect information (e.g. max. clock frequency, highest internal frequency, antenna gain, cable loss, etc ) is provided by the applicant. (if applicable). 2.SGS is not responsible for the authenticity, integrity and the validity of the conclusion based on results of the data provided by applicant. (if applicable) 3.4 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • A2LA Compliance Certification Services (Kunshan) Inc. is accredited by the American Association for Laboratory Accreditation (A2LA). Certificate No. 2541.01. • FCC Compliance Certification Services (Kunshan) Inc. has been recognized as an accredited testing laboratory. Designation Number: CN1172. • ISED Compliance Certification Services (Kunshan) Inc. has been recognized by Innovation, Science and Economic Development Canada (ISED) as an accredited testing laboratory. Company Number: 2324E • VCCI The 3m and 10m Semi-anechoic chamber and Shielded Room of Compliance Certification Services (Kunshan) Inc. has been registered in accordance with the Regulations for Voluntary Control Measures with Registration No.: R-20134, R-11600, C-11707, T-11499, G-10216 respectively. Compliance Certification Services (Kunshan) Inc. Report No.: KSCR230400067302 Page: 6 of 11 4 FCC Radiofrequency radiation exposure limits Test exemptions apply for devices used in general population/uncontrolled exposure environments, according to the SAR-based, or MPE-based exemption thresholds. 4.1 Blanket 1 mW Blanket Exemption The 1 mW Blanket Exemption of §1.1307(b)(3)(i)(A) applies for s…

Text truncated - open the document above for the full version.

Compliance Certification Services (Kunshan) Inc. Report No.: KSCR230400067301 Page: 1 of 132 Eric Lin Laboratory Manager TEST REPORT Application No.: KSCR2304000673AT FCC ID: 2AL8S-0235C76T Applicant: Zhejiang Uniview Technologies Co., Ltd. Address of Applicant: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Manufacturer: Zhejiang Uniview Technologies Co., Ltd. Address of Manufacturer: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Factory: Zhejiang Uniview Systems Technology Co., Ltd. Address of Factory: No.1277 South Qingfeng South Road, Tongxiang City, Jiaxing City, Zhejiang Province, China Equipment Under Test (EUT): EUT Name: Face Recognition Access Control Terminal Model No.: OET-542B-H-W-R,OET-542B-H-W-xxxxxxxx-yyyyyyyy-zzz("x","y";"z" can be 0-9;A-Z;a-z or blank;"- "may be blank)   Please refer to section 2 of this report which indicates which model was actually tested and which were electrically identical. Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2023-04-19 Date of Test: 2023-04-25 to 2023-05-04 Date of Issue: 2023-05-06 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Compliance Certification Services (Kunshan) Inc. Report No.: KSCR230400067301 Page: 2 of 132 Revision Record Version Description Date Remark 00 Original 2023-05-06 / Authorized for issue by: Damon_Zhou/Project Engineer Eric Lin /Reviewer Compliance Certification Services (Kunshan) Inc. Report No.: KSCR230400067301 Page: 3 of 132 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Conducted Peak Output Power ANSI C63.10 (2013) Section 11.9.2 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Minimum 6dB Bandwidth ANSI C63.10 (2013) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Power Spectrum Density ANSI C63.10 (2013) Section 11.10.2 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement ANSI C63.10 (2013) Section 11.13.3.2 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions ANSI C63.10 (2013) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass Radiated Emissions which fall in the restricted bands ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Below 1GHz ANSI C63.10 (2013) Section 6.4,6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Above 1GHz ANSI C63.10 (2013) Section 6.6 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Declaration of EUT Family Grouping: Note: There are series models mentioned in this report, and they are identical in electrical and electronic characters. Only the model OET-542B-H-W-R was tested since their differences were the model number and appearance. Compliance Certification Services (Kunshan) Inc. Report No.: KSCR230400067301 Page: 4 of 132 3 Contents Page 1 COVER PAGE ............................................................................................................................................ 1 2 TEST SUMMARY ....................................................................................................................................... 3 3 CONTENTS ................................................................................................................................................ 4 4 GENERAL INFORMATION ........................................................................................................................ 6 4.1 DETAILS OF E.U.T. ............................................................................................................................... 6 4.2 DESCRIPTION OF SUPPORT UNITS ......................................................................................................... 6 4.3 MEASUREMENT UNCERTAINTY .............................................................................................................. 7 4.4 TEST LOCATION .................................................................................................................................... 8 4.5 TEST FACILITY ...................................................................................................................................... 8 4.6 DEVIATION FROM STANDARDS ............................................................................................................... 8 4.7 ABNORMALITIES FROM STANDARD CONDITIONS ..................................................................................... 8 5 EQUIPMENT LIST ...................................................................................................................................... 9 6 RADIO SPECTRUM TECHNICAL REQUIREMENT ............................................................................... 11 6.1 ANTENNA REQUIREMENT .................................................................................................................... 11 6.1.1 Test Requirement: ....................................................................................................................... 11 6.1.2 Conclusion ................................................................................................................................... 11 7 RADIO SPECTRUM MATTER TEST RESULTS ..................................................................................... 12 7.1 CONDUCTED EMISSIONS AT AC POWER LINE (150KHZ-30MHZ) ........................................................... 12 7.1.1 E.U.T. Operation .......................................................................…

Text truncated - open the document above for the full version.

ANTENNA DATA SHEET Product Name: 2.4G FPC Antenna Model Number: Address: UB01NF1D897A Manufacturer Name: Dongguan Youbi Electronics Co., Ltd Building 79, New Sun Industrial City, Lincun Community, Tangxia Town, Dongguan City Design Specifications Typical 天线类型（Antenna Type） FPC Antenna 工作频率（Working Frequency） 2400-2500MHz 最大增益（Peak Gain） 1.99 dBi 平均效率（Average Efficiency） 48.5% 电压驻波比（ VSWR ） ＜ 3 极化方式（ Ploriaztion ） Linear polarization 轴比（Axial Ratio） ＼ 辐射方向（Radiation pattern） Omnidirectional 馈电阻抗（impedance） 50 ohm 功率容量（ Power handling ） 1W 天线接口（ Interface ） DIP 天线尺寸（ Overal dimensions ） 29.0*18.4mm 重量（Weight）\ 工作温度（Operatin Temp）-20°C~+70°C 储存温度（Storing Temp）-20°C~+70°C 1.Specifications: 2. Dimensions: Unit: mm 3.Antenna Gain&Efficiency: Frequency / MHzEfficiency / dBEfficiency / %Gain/ dBi 2400-3.6343.351.09 2410-3.5943.751.13 2420-3.5444.261.48 2430-3.5444.261.6 2440-3.4844.871.68 2450-3.5244.461.7 2460-3.5144.571.79 2470-3.4145.61.99 2480-3.4545.191.71 2490-3.2846.991.91 2500-3.4645.081.7 4. 2D、3D Raditation Pattern 2400MHz2450MHz 2500MHzPhi 0 Phi 90Thrta 90 5.Antenna installation Location

Compliance Certification Services (Kunshan) Inc. Page: 1 of 3 Appendix Photographs of Test Setup for KSCR2304000673AT Test Model No.: OET-542B-H-W-R Compliance Certification Services (Kunshan) Inc. Page: 2 of 3 Test Setup Photo Conducted Emissions at AC Power Line (150kHz-30MHz) Conducted Test setup Compliance Certification Services (Kunshan) Inc. Page: 3 of 3 Radiated Spurious Emissions Above 1GHz Radiated Spurious Emissions Below 1GHz
