2AL8S-0235C7Q1HD PT Camera

Pan&Tilt Wi‐Fi Camera Quick Guide EN/ES/DE/FR/IT/PL Instagram : uniarch_global Youtube : Uniarch Global Facebook : Uniarch LinkedIn : uniarch_global English.......................................................................1 Spanish.....................................................................7 German....................................................................13 French......................................................................19 Italian.......................................................................25 Polish....................................................................... 31 Disclaimer and Safety Warnings.............................37 See more For more information, please visit https://www.uniarch.cn/Support/ Contents √ √ √ Packing List The package contents may vary with device model and version. Screw components Mounting plate Camera Power adapter USB cable Quick guideWarning sticker 1/EN Speaker *Network interface (available to certain devices) Power interface Appearance Micro SD card slot Reset button 10s Indicator CAUTION Do not insert or remove the Micro SD card while power is connected; it may damage the camera and the SD card. Steady red: Connected to power Flashing red: Waitingforconfiguration Steady blue: Connected to Wi‐Fi Flashing blue: Playing live video or connecting to network 2/EN 4. Add the camera to uniarch. Tap , and follow the on‐screen instructions to proceed. + + Add Device to Uniarch 3. Download and install uniarch. A：Scan QR code B：Search in app stores 1. Ensure that your router supports a 2.4G Hz Wi‐Fi network. 5G 2.4G Hz Wi‐Fi only 2. Connect the camera to power. 3/EN 1. Connect the camera to power and a router. (Optional) Web Login 2. Log in to the Web interface. Default IP: 192.168.1.13 Username: admin Password: 123456 4/EN Installation Environment Thick or insulated walls can greatly reduce the Wi‐Fi signal strength even if your router is nearby. Therefore, before installing the camera, ensure that the live video can be played smoothly. 5/EN 1 Drill holes Mount Your Camera 1. Tools Rotate to tighten 3. Mount the camera. Take ceiling mount as an example. 2. Accessories 2Fix the mounting plate 3 Attach the camera to the plate 6/EN √ √ √ 7/ES Lista de embalaje El contenido del paquete puede variar según el modelo y la versión del dispositivo. TornillosPlaca de montajeCámara Adaptador de corriente Cable USB Guía rápida Adhesivo de advertencia Altavoz *Conector de red (disponible en algunos dispositivos) Interfaz de alimentación Aspecto Ranuraparala tarjeta microSD Botón Restablecer 10s Indicador Precaución No inserte ni retire la tarjeta microSD mientras el dispositivo esté conectado a la alimentación; ya que podría dañar la cámara y la tarjeta SD. Rojo fijo: conectado a la alimentación Rojo intermitente: esperando para configurar Azul fijo: conectado a la red wifi Azul intermitente: reproduciendo vídeo en directo o conectándose a una red 8/ES 4. Añada la cámara a uniarch. Pulse y siga las instrucciones que aparecen en la pantalla para continuar. + 5G Solo red wifi 2,4 de GHz Añadir el dispositivo a uniarch 3. Descargue e instale uniarch. 1. Asegúrese de que su rúter admita la red wifi de 2,4 GHz. 2. Conecte la cámara a la alimentación. A: Escanee el código QR B: Busque en las tiendas de aplicaciones 9/ES 1. Conecte la cámara a la alimentación y a un rúter. 10/ES (Opcional) Acceso a la Web 2. Inicie sesión en la interfaz web. IP predeterminada: 192.168.1.13 nombre de usuario: admin Contraseña: 123456 Entorno de instalación Las paredes gruesas o aisladas pueden reducir mucho la potencia de la señal wifi, aunque el rúter esté cerca. Por ello, antes de instalar la cámara, asegúrese de que el vídeo en directo se reproduzca de forma fluida. 11/ES 1 Taladre los agujeros 12/ES 2 Fije la placa de montaje 3 Sujete la cámara en la placa Montar la cámara 1. Herramientas Gire para apretar 3. Monte la cámara. Tome el techo o el montaje en pared como ejemplo. 2. Accesorios √ √ √ 13/DE Lieferumfang Der Verpackungsinhalt kann je nach Gerätemodell und Version variieren. KameraSchraubkomponentenMontageplatte NetzteilUSB‐KabelKurzanleitungWarnaufkleber Lautsprecher *Netzwerkschnittstelle (bei bestimmten Geräten verfügbar) Stromanschluss Erscheinungsbild microSD‐ Kartensteckplatz Reset‐Taste 10s Anzeige Die SD‐Karte nicht einsetzen oder entfernen, wenn das Gerät an die Vorsicht Stromversorgung angeschlossen ist, da dies die Kamera und die SD‐Karte beschädigen kann. Leuchtet rot: Mit der Stromversorgung verbunden Blinkt rot: Warten auf die Konfiguration Leuchtet blau: Mit WLAN verbunden Blinkt blau: Live‐Video wiedergeben oder mit dem Netzwerk verbinden 14/DE 4. Fügen Sie die Kamera zu uniarch hinzu. Tippen Sie auf und folgen Sie den Anweisungen auf dem Bildschirm, um fortzufahren. + 5G Nur 2,4‐GHz‐WLAN Gerät zu Uniarch hinzufügen 3. Laden Sie Uniarch herunter und installieren Sie die Software. A: QR‐Code scannenB: In App‐Stores suchen 1. Stellen Sie sicher, dass Ihr Router 2,4‐GHz‐WLAN unterstützt. 2. Schließen Sie die Kamera an die Stromversorgung an. 15/DE 1. Verbinden Sie die Kamera mit der Stromversorgung und einem Router. 16/DE (Optional) Web‐Anmeldung 2. Melden Sie sich an der Weboberfläche an. Standard‐IP: 192.168.1.13 Benutzername: admin Passwort: 123456 Installationsumgebung Dicke oder gedämmte Wände können die WLAN‐Signalstärke erheblich reduzieren, auch wenn der Router in der Nähe ist. Vergewissern Sie sich daher vor der Montage der Kamera, dass Live‐Video reibungslos wiedergegeben werden kann. 17/DE 1 Löcher bohren 18/DE 2 Befestigen Sie die Montageplatte 3 Befestigen Sie die Kamera auf der Platte Montieren der Kamera 1. Werkzeuge Zum Festziehen drehen 3. Montieren Sie die Kamera. Hier nehmen wir als Beispiel die Decken‐/Wandmontage. 2. Zubehör √ √ √ 19/FR Contenu de l’emballage Le contenu de l’emballage peut varier selon le modèle et la version de l’appareil. Éléments à visserPlaque de fixationCaméra Adaptateur d’alimentation C…

Text truncated - open the document above for the full version.

ZheJiangUniviewTechnologies Co.,Ltd. U.S. Agent Designationfor Serviceof Process (Applicant and U.S.Agentare SeparateParties) TO:FederalCommunications Commission 7435OaklandMillsRoad Columbia,MD 21046 ATTENTION: FCC Certification – Section 2.911(d)(7) Information Designa ted U.S. Ag ent Company Na me: United Consulting Tec h nology Services Co., Ltd. FRN: 0 033495714 Cont act Na me: Da v id Wu Str eet Address: 1 7800 CASTLETON ST STE 665 CITY OF IND UST RY City/Province/Zip: CA 91748 Teleph one No: (626) 217-402 2 Email: [email protected] This letter is to confirm that we (“the Designated U.S. Agent) hav e accepted the responsibility to act as the Designated U.S. Agent for Service of Pr ocess as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted belo w. U.S. Agent Signature: Da te:2023-8-25 Signed by (Printed Name/Title): David Wu/CEO T he Applicant acknowledgesthat theymustmaintainan agentfor noless than one year after terminating all marketing andimportationOR the conclusionofany Commission-relatedproceedinginvolving the equipment.The applicantfurtheracknowledgestheir responsibility toinformthe FCCwheneverthe DesignatedU.S. Agentinformationabove changes. A pplicant Companyname: ZheJiangUniviewTechnologies Co.,Ltd. Grantee Code:2AL8S FCCID: 2AL8S-0235C7Q1 Contact Name:FengXu StreetAddress: No. 369, XietongRoad,Xixing Sub-district, Binjiang District City/Province/Zip:HangzhouCity, ZhejiangProvince, 310051, China Telephone No: 18106582562 Email:[email protected] Applicant Signature: Date:2023-08-25 Signed by(Printed Name/Title):Feng Xu,Manager

Applicant Declaration QSF27-14-04 Rev 1.0 Rev. Feb 6, 2023 Page 1 of 1 Original Issue: Jan. 4, 2021 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name ZheJiang Uniview Technologies Co.,Ltd. Address No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Grantee Code 2AL8S FCC ID 2AL8S-0235C7Q1 Authorized Contact Name Feng Xu Contact Email [email protected] Contact Phone 18106582562 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO 17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Link to the Covered List: Covered List [ZheJiang Uniview Technologies Co.,Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. [ZheJiang Uniview Technologies Co.,Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered list, established pursuant to §1.50002, as an entity producing “covered” equipment. Applicant Signature: Date: 2023-08-25 Print Name: Feng Xu Title: Manager *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

ZheJiang Uniview Technologies Co.,Ltd. Current Date 2023-08-25 To: SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. No. 588 West Jindu Road, Songjiang District, Shanghai, China. 201612 Dear Sir/Madam, Subject: Declaration Letter about Identity of Products *WE ZheJiang Uniview Technologies Co.,Ltd., HEREBY DECLARED THAT Product Description: HD PT Camera Model No.: Uho-S2,Uho-S2-NB,Uho-S2E-NB,Uho-S2xxxxxxxx-yyyyyyyy-zzz(‘x' can be 0-9,A-Z,a-z,@, or blank, denoting difference in interface; 'y' can be 0-9,A-Z,a-z,@, or blank, denoting difference in interface; 'z' can be 0-9,A-Z,a-z,@, or blank, denoting difference in interface;' -' may be blank) Manufacturer’s Name: ZheJiang Uniview Technologies Co.,Ltd. Manufacturer’s Address: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China *Except that the model number and appearance deviation, are identical with the original product as follows: Note: The definition of identical should be “electrically identical”. A device will be considered to be electrically identical if no changes are made to the devices’ schematics, board layouts, component layouts, chip sets, resistors and all other electrical aspects of the device are identical with the model which has been tested by SGS. Model No.: Uho-S2E Manufacturer’s Name: ZheJiang Uniview Technologies Co.,Ltd. Manufacturer’s Address: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Sincerely, Signature: Printed Name : Feng Xu Position/Title : Manager Contact Number: 18106582562

ZheJiang Uniview Technologies Co.,Ltd. Date: 2023-08-25 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: 2AL8S-0235C7Q1 To whom it may concern: We, the undersigned, hereby authorize Parlam Zhan to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with ZheJiang Uniview Technologies Co.,Ltd. This authorization is valid until further written notice from the applicant. Name (Printed): Feng Xu Title: Manager Signature: On behalf of Company: ZheJiang Uniview Technologies Co.,Ltd. Telephone: 18106582562

ZheJiang Uniview Technologies Co.,Ltd. To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States From: ZheJiang Uniview Technologies Co.,Ltd. No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Regarding: Confidentiality Request regarding application for FCC ID: 2AL8S-0235C7Q1 LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. Sincerely, Signature: Printed Name (on file with the FCC associated with the Grantee Code): Feng Xu Title: Manager Company Name: ZheJiang Uniview Technologies Co.,Ltd.

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 1 of 7 External Photos for SHCR2308001625AT Test Model No.: Uho-S2E SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 2 of 7 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 3 of 7 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 4 of 7 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 5 of 7 Adapter model 1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 6 of 7 Adapter model 2 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 7 of 7

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 1 of 7 Internal Photos for SHCR2308001625AT Test Model No.: Uho-S2E SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 2 of 7 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 3 of 7 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 4 of 7 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 5 of 7 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 6 of 7 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 7 of 7

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230800162502 Page: 1 of 10 Parlam Zhan Laboratory Manager 1 Cover Page RF Exposure Evaluation Report Application No.: FCC ID: Applicant: Address of Applicant: Manufacturer: Address of Manufacturer: Equipment Under Test (EUT): EUT Name: Model No.: Standard(s) : Date of Receipt: Date of Test: Date of Issue: SHCR2308001625AT 2AL8S-0235C7Q1 Zhejiang Uniview Technologies Co., Ltd. No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Zhejiang Uniview Technologies Co., Ltd. No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China HD PT Camera Uho-S2,Uho-S2E,Uho-S2-NB,Uho-S2E-NB,Uho-S2xxxxxxxx-yyyyyyyy- zzz(‘x' can be 0-9,A-Z,a-z,@, or blank, denoting difference in interface; 'y' can be 0-9,A-Z,a-z,@, or blank, denoting difference in interface; 'z' can be 0-9,A-Z,a-z,@, or blank, denoting difference in interface;' - ' may be blank) FCC Rules 47 CFR §2.1091 KDB 447498 D04 interim General RF Exposure Guidance v01 2023-07-20 2023-07-27 to 2023-07-29 2023-08-14 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230800162502 Page: 2 of 10 Revision Record Version Description Date Remark 00 Original 2023-08-14 / Authorized for issue by: Micheal_Niu/Project Engineer Parlam Zhan/Reviewer SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230800162502 Page: 3 of 10 2 Contents Page 1 COVER PAGE .................................................................................................................................... 1 2 CONTENTS ........................................................................................................................................ 3 3 GENERAL INFORMATION ................................................................................................................ 4 3.1 GENERAL DESCRIPTION OF E.U.T. ................................................................................................ 4 3.2 DETAILS OF E.U.T. ....................................................................................................................... 4 3.3 TEST LOCATION ............................................................................................................................ 5 3.4 TEST FACILITY .............................................................................................................................. 5 4 FCC RADIOFREQUENCY RADIATION EXPOSURE LIMITS .......................................................... 6 4.1 BLANKET 1 MW BLANKET EXEMPTION ........................................................................................... 6 4.2 MPE-BASED EXEMPTION .............................................................................................................. 6 4.3 SAR-BASED EXEMPTION ............................................................................................................... 7 5 MEASUREMENT AND CALCULATION ............................................................................................ 9 5.1 MAXIMUM TRANSMIT POWER ......................................................................................................... 9 5.2 RF EXPOSURE CALCULATION ...................................................................................................... 10 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230800162502 Page: 4 of 10 3 General Information 3.1 General Description of E.U.T. Power supply: DC 5V,1A Adapter model 1: TPA-98B050100CU01 INPUT:100-240V,50/60Hz,0.15A OUTPUT:5V,1A Adapter model 2: TPA-141A050150UU01 INPUT:100-240V,50/60Hz,0.3A OUTPUT:5V,1.5A 3.2 Details of E.U.T. 2.4G WiFi Operation Frequency: 802.11b/g/n(HT20): 2412MHz to 2462MHz Modulation Type: 802.11b: DSSS (CCK, DQPSK, DBPSK);802.11g/n: OFDM (64QAM, 16QAM, QPSK, BPSK) Number of Channels: 802.11b/g/n(HT20):11 Channel Spacing: 5MHz Antenna Type: PCB Antenna Antenna Gain: 2.29dBi (Provided by the manufacturer) SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230800162502 Page: 5 of 10 3.3 Test Location All tests were performed at: SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. E&E Lab 588 West Jindu Road, Xinqiao, Songjiang, 201612 Shanghai, China Tel: +86 21 6191 5666 Fax: +86 21 6191 5678 No tests were sub-contracted. Note: 1.SGS is not responsible for wrong test results due to incorrect information (e.g. max. clock frequency, highest internal frequency, antenna gain, cable loss, etc ) is provided by the applicant. (if applicable). 2.SGS is not responsible for the authenticity, integrity and the validity of the conclusion based on results of the data provided by applicant. (if applicable). 3.4 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • A2LA (Certificate No. 6332.01) SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. is accredited by the American Association for Laboratory Accreditation(A2LA). • FCC (Designation Number: CN1301) SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. has been recognized as an accredited testing laboratory. • ISED (CAB Identifier: CN0020) SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. EMC Laboratory has been recognized by Innovation, Science and Economic Development Canada (ISED) as an accredited testing laboratory. Company Number: 8617A • VCCI (Member No.: 3061) The 3m Semi-anechoic chamber and Shielded Room of SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. has been registered in accordance with the Regulations for Voluntary Control Measures with Registration No.: R-13868, C-14336, T-12221, G-10830 respectively. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230800162502 Page: 6 of 10 …

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230800162501 Page: 1 of 116 Parlam Zhan Laboratory Manager TEST REPORT Application No.: SHCR2308001625AT FCC ID: 2AL8S-0235C7Q1 Applicant: Zhejiang Uniview Technologies Co., Ltd. Address of Applicant: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Manufacturer: Zhejiang Uniview Technologies Co., Ltd. Address of Manufacturer: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Equipment Under Test (EUT): EUT Name: HD PT Camera Model No.: Uho-S2,Uho-S2E,Uho-S2-NB,Uho-S2E-NB,Uho-S2xxxxxxxx-yyyyyyyy- zzz(‘x' can be 0-9,A-Z,a-z,@, or blank, denoting difference in interface; 'y' can be 0-9,A-Z,a-z,@, or blank, denoting difference in interface; 'z' can be 0- 9,A-Z,a-z,@, or blank, denoting difference in interface;' -' may be blank)   Please refer to section 2 of this report which indicates which model was actually tested and which were electrically identical. Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2023-07-20 Date of Test: 2023-07-27 to 2023-07-29 Date of Issue: 2023-08-14 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230800162501 Page: 2 of 116 Revision Record Version Description Date Remark 00 Original 2023-08-14 / Authorized for issue by: Micheal_Niu/Project Engineer Parlam Zhan/Reviewer SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230800162501 Page: 3 of 116 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Customer Declaration Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Conducted Peak Output Power ANSI C63.10 (2013) Section 11.9.2 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Minimum 6dB Bandwidth ANSI C63.10 (2013) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Power Spectrum Density ANSI C63.10 (2013) Section 11.10.2 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement ANSI C63.10 (2013) Section 11.13.3.2 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions ANSI C63.10 (2013) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass Radiated Emissions which fall in the restricted bands ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Below 1GHz ANSI C63.10 (2013) Section 6.4,6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Above 1GHz ANSI C63.10 (2013) Section 6.6 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Declaration of EUT Family Grouping: Note: There are series models mentioned in this report, and they are the Identical in electrical and electronic characters. Only the model Uho-S2E was tested since their differences were the model number and appearance. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230800162501 Page: 4 of 116 3 Contents Page 1 COVER PAGE ............................................................................................................................................ 1 2 Test Summary ........................................................................................................................................... 3 3 Contents .................................................................................................................................................... 4 4 General Information .................................................................................................................................. 5 4.1 Details of E.U.T. ................................................................................................................................. 5 4.2 Description of Support Units .............................................................................................................. 5 4.3 Measurement Uncertainty .................................................................................................................. 6 4.4 Test Location ...................................................................................................................................... 7 4.5 Test Facility ........................................................................................................................................ 7 4.6 Deviation from Standards ................................................................................................................... 7 4.7 Abnormalities from Standard Conditions ........................................................................................... 7 5 Equipment List .......................................................................................................................................... 8 6 Radio Spectrum Technical Requirement ............................................................................................. 10 6.1 Antenna Requirement ...................................................................................................................... 10 7 Radio Spectrum Matter Test Results .................................................................................................... 11 7.1 Conducted Emissions at AC Power Line (150kHz-30MHz) ............................................................. 11 7.2 Conducted Peak Output Power........................................................................................................ 15 7.3 Minimum 6dB Bandwidth ................................................................................................…

Text truncated - open the document above for the full version.

Antenna Data Sheet Antenna Manufacturer: Zhejiang Uniview Technologies Co., Ltd. Address: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Product Name: 2.4G PCB on-board an tenna Model Number: 0302C56V --------------------------------------------------------------------------------- --------------------------------------------------------------------------------- --------------------------------------------------------------------------------- --------------------------------------------------------------------------------- 1、规格表(Specifications) 主要技术指标 Main technical specifications 频率范围(MHz) 2400~2500 Frequency Range (MHZ) 2400~2500 特性阻抗(Ω) 50 Impedance(Ω) 50 峰值增益(dBi) 2.29 Peak Gain(dBi) 2.29 反射系数(dB) ≤-10 S11(dB) ≤-10 物理性能 Physical Properties 天线本体材料 PCB Antenna Base PCB 1 2、成品图(Antenna Drawing) Dimension：13.5mm*11.5mm 3、测试报告(Test Report) 3.1 网络分析仪测试报告(Network Analyzer Test Report) 2 3.2 天线数据 (Antenna Data) 3.2.1 效率及增益 (Efficiency&Gain) Frequency / MHz Efficiency / % Gain/ dB 2400 57.15 1.2 2410 56.49 1.54 2420 56.36 1.75 2430 57.28 1.7 2440 58.48 1.79 2450 58.75 1.72 2460 57.81 1.89 2470 57.28 2.15 2480 55.85 2.2 2490 54.95 2.29 2500 52.12 1.78 3.2.2 2D、3D Raditation Pattern 2400MHz PHI=0 2D 2450MHz PHI=90 2D 3 2500MHz THETA=90 2D 4
