IP Cameras Quick Guide V2.03 1 Waterproof Requirements Please waterproof cables in accordance with the following instructions. User shall assume all responsibility for device damage caused by water due to improper waterproof measures. NOTE!  Before you start, connect all the needed cables and cut off the copper wires for the cables that you don't use.  Please use self-adhesive waterproof tape (supplied with some products) to protect the cables.  Use waterproof components to protect the network cable. Waterproof the power cable separately if you don’t use it. The video cable does not need waterproof treatment. 1. Use insulation tape (not included in the package) to insulate the connection part of each cable. 2. Waterproof the cables with self-adhesive waterproof tape. (1) Fully stretch the waterproof tape at both ends. (2) Wrap the connection part and the cable ends tightly with waterproof tape. Make sure the tape is fully stretched during the process. (3) Tighten the tape at both ends to prevent water leakage. Connection part Insulation tape Wrap the unused cables together into a bundle TightenTighten Waterproof tape Tighten 2 3. Install the supplied waterproof components to the network cable in sequence. CAUTION! You need to mount the rubber ring onto the network cable interface first. 4. If your camera has a DC cable and you will not use it, insert the plug into the interface. 5. (Optional) After the waterproof treatment is completed, put the cables into a waterproof junction box (purchased separately). CAUTION!  The cable connector must not be exposed and must be kept away from water.  Restore and fasten the device after dismounting.  Place the power adapter in a power distribution box. D C i n t e r f a c e P l u g 3 1 Packing List Contact your local dealer if the package is damaged or incomplete. The package contents may vary with device model. Item Quantity Camera 1 User document 1 Accessory pack 1 Remarks: * means optional and supplied with certain models only. (1) Including one or more waterproof components such as tape and plug. (2) Including one or more items from screws, hex key, etc. (3) Including one or more items from drill template, bracket adapter, antistatic gloves, etc. 2 Safety and Compliance Information 2.1 Installation  Make sure the camera operates in an environment where the temperature and humidity meet requirements. Keep the camera from excessive pressure, vibration, moisture, dust, and intensive electromagnetic radiation.  Use a power adapter or a PoE device that meets requirements. Otherwise, the device may be damaged.  Make sure the length of the power cable between the power adapter and the camera is not too long, otherwise the voltage of the camera is lowered, causing the camera to work abnormally. If it is required to lengthen the power cable, lengthen the cable between the power adapter and the mains.  Do not hold the tail cable by hand for weight bearing. Otherwise, the cable connector of the camera could be loosened.  When connecting to an external interface, use an existing connection terminal, and ensure that the cable terminal (latch or clamp) is in good condition and properly fastened. Ensure that the cable is not tense during mounting, with a proper margin reserved to avoid poor port contact or loosening caused by shock or shake. 4  During the process of transportation, special attention is required for the protection of the glass window to prevent friction, scratch and contamination, etc. In order to keep the cover clean, do not remove the protective film on the cover during mounting. After mounting is finished, remove the film before the device is powered on.  Contact professionals for maintenance information. Do not attempt to dismantle the device by yourself. We shall not assume any responsibility for problems caused by unauthorized repair or maintenance. 2.2 Maintenance  Caution: There will be risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions.  If there is dust on the glass window surface, remove the dust gently using an oil- free brush or a rubber dust blowing ball.  If there is grease or a dust stain on the glass window surface, clean the glass window surface gently from the center outward using lens cleaning cloth. If the grease or the stain still cannot be removed, use lens cleaning cloth dipped with detergent and clean the glass window surface gently until it is removed.  Do not use organic solvents, such as benzene or ethanol when cleaning the transparent dome cover.  Make sure the lens cleaning cloth is clean itself.  Never look at the transmit laser while the power is on. Never look directly at the fiber ports and the fiber cable ends when they are powered on.  Use of controls or adjustments to the performance or procedures other than those specified herein may result in hazardous laser emissions. 3 Appearance 3.1 Dimensions The figures in the manual are for your reference only. The actual appearance may vary with the product model. 5 3.2 Cable Connection The appearance and tail cable may vary with device model. NOTE! For specifications, see the latest product datasheet. 4 Mount Your Camera 4.1 (Optional) Insert Micro SD Card To use the local storage function, you need to install a Micro SD card into the camera. The SD card is installed inside the camera. To install the SD card, you need to remove the back cover of the camera first. Do not hot plug the Micro SD card after it is inserted. Otherwise the camera or the SD card might be damaged. Contact your dealer for the recommended specifications of the Micro SD card. ∅ 1 2 9 . 0 m m ( 5 . 1 " ) S 1 0 0 . 0 m m ( 3 . 9 " ) 1 4 3 . 6 m m ( 5 . 7 " ) ø 108 . 5 mm ( 4 . 3 ") 3 - 4 . 0 mm ( 0 . 16 ") 1 /4 - UNC - 2B ø 6 4.2 Ceiling Mount You may adopt ceiling mount or wall mount as needed. Prepare hardware accessories by yourself. The following part takes ceiling mount as an example. Wall mount is similar…

Text truncated - open the document above for the full version.

ZheJiangUniviewTechnologies Co.,Ltd. U.S. Agent Designationfor Serviceof Process (Applicant and U.S.Agentare SeparateParties) TO:FederalCommunications Commission 7435OaklandMillsRoad Columbia,MD 21046 ATTENTION:FCC Certification– Section2.911(d)(7) Information DesignatedU.S. Agent CompanyName:United ConsultingTechnologyServicesCo., Ltd. FRN:0033495714 Contact Name: DavidWu StreetAddress: 17800CASTLETONST STE665 CITYOF INDUSTRY City/Province/Zip:CA91748 Telephone No: (626) 217-4022 Email:[email protected] This letter is toconfirmthat we (“the DesignatedU.S. Agent)haveacceptedthe responsibility toact as the DesignatedU.S. Agent forServiceof Processas requiredbysection47 CFR2.911(d)(7)on behalfof the Applicantnotedbelow. U .S. AgentSignature: Date:2024-08-27 Signed by(Printed Name/Title):DavidWu/ CEO The Applicant acknowledgesthat theymustmaintainan agentfor noless than one year after terminating all marketing andimportationOR the conclusionofany Commission-relatedproceedinginvolving the equipment.The applicantfurtheracknowledgestheir responsibility toinformthe FCCwheneverthe DesignatedU.S. Agentinformationabove changes. A pplicant Companyname: ZheJiangUniviewTechnologies Co.,Ltd. Grantee Code:2AL8S FCCID: 2AL8S-0235C8T7 Contact Name:FengXu StreetAddress: No. 369, XietongRoad,Xixing Sub-district, Binjiang District City/Province/Zip:HangzhouCity, ZhejiangProvince, 310051, China Telephone No: 18106582562 Email:[email protected] Applicant Signature: Date:2024-08-27 Signed by(Printed Name/Title):Feng Xu,Manager

Applicant Declaration QSF27-14-04 Rev 1.0 Rev. Feb 6, 2023 Page 1 of 1 Original Issue: Jan. 4, 2021 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name Zhejiang Uniview Technologies Co., Ltd. Address No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, Zhejiang Province, China Grantee Code 2AL8S FCC ID 2AL8S-0235C8T7 Authorized Contact Name Xu Feng Contact Email [email protected] Contact Phone 18106582562 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO 17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Link to the Covered List: Covered List Zhejiang Uniview Technologies Co., Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Zhejiang Uniview Technologies Co., Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered list, established pursuant to §1.50002, as an entity producing “covered” equipment. Applicant Signature: Date: 2024/8/27 Print Name: Xu Feng Title: Manager *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

ZheJiang Uniview Technologies Co.,Ltd. Current Date 2024-09-04 To: SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. No. 588 West Jindu Road, Songjiang District, Shanghai, China. 201612 Dear Sir/Madam, Subject: Declaration Letter about Identity of Products *WE ZheJiang Uniview Technologies Co.,Ltd., HEREBY DECLARED THAT Product Description: IP Camera Model No.: IPC6215SRa-xxxxWxxxx-yyyyyyyy-zzz, "x" can be 0-9, A-Z, a-z or blank, denoting difference in interface, "y" can be 0-9,A-Z,a-z or blank, denoting performance difference, "z" can be 0-9,A-Z,a-z or blank, denoting target regional, "-" is optional  Manufacturer’s Name: ZheJiang Uniview Technologies Co.,Ltd. Manufacturer’s Address: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China *Except that the model number and appearance deviation, are identical with the original product as follows: Note: The definition of identical should be “electrically identical”. A device will be considered to be electrically identical if no changes are made to the devices’ schematics, board layouts, component layouts, chip sets, resistors and all other electrical aspects of the device are identical with the model which has been tested by SGS. Model No.: IPC6215SR-X5PAEW-VG Manufacturer’s Name: ZheJiang Uniview Technologies Co.,Ltd. Manufacturer’s Address: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Sincerely, Signature: Printed Name : Feng Xu Position/Title : Manager Contact Number: 18106582562

Zhejiang Uniview Technologies Co., Ltd. Date: 2024/8/27 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: 2AL8S-0235C8T7 To whom it may concern: We, the undersigned, hereby authorize Parlam Zhan to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with Zhejiang Uniview Technologies Co., Ltd. . This authorization is valid until further written notice from the applicant. Name (Printed): Xu Feng Title: Manager Signature: On behalf of Company: Zhejiang Uniview Technologies Co., Ltd. Telephone:18106582562

Zhejiang Uniview Technologies Co., Ltd. To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States From: Zhejiang Uniview Technologies Co., Ltd. No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, Zhejiang Province, China Regarding: Confidentiality Request regarding application for FCC ID: 2AL8S-0235C8T7 LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. Sincerely, Signature: Printed Name (on file with the FCC associated with the Grantee Code): Xu Feng Title: Manager Company Name: Zhejiang Uniview Technologies Co., Ltd.

Compliance Certification Services (Kunshan) Inc. Page: 1 of 4 External Photos for KSCR2408001515AT Test Model No.: IPC6215SR-X5PAEW-VG Compliance Certification Services (Kunshan) Inc. Page: 2 of 4 EUT Constructional Details (EUT Photos) Compliance Certification Services (Kunshan) Inc. Page: 3 of 4 Compliance Certification Services (Kunshan) Inc. Page: 4 of 4

1 / 1

Compliance Certification Services (Kunshan) Inc. Page: 1 of 8 Internal Photos for KSCR2408001515AT Test Model No.: IPC6215SR-X5PAEW-VG Compliance Certification Services (Kunshan) Inc. Page: 2 of 8 EUT Constructional Details (EUT Photos) Compliance Certification Services (Kunshan) Inc. Page: 3 of 8 Compliance Certification Services (Kunshan) Inc. Page: 4 of 8 Compliance Certification Services (Kunshan) Inc. Page: 5 of 8 Compliance Certification Services (Kunshan) Inc. Page: 6 of 8 Compliance Certification Services (Kunshan) Inc. Page: 7 of 8 Compliance Certification Services (Kunshan) Inc. Page: 8 of 8

Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240800151502 Page: 1 of 10 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-Conditions/Terms-e-Document.aspx. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 30 days only. Member of the SGS Group (SGS SA) 1 Cover Page RF Exposure Evaluation Report Application No.: KSCR2408001515AT FCC ID: 2AL8S-0235C8T7 Applicant: Zhejiang Uniview Technologies Co., Ltd. Address of Applicant: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Manufacturer: Zhejiang Uniview Technologies Co., Ltd. Address of Manufacturer: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Factory: Zhejiang Uniview Systems Technology Co., Ltd. Address of Factory: No.1277 South Qingfeng South Road, Tongxiang City, Jiaxing City, Zhejiang Province, China Equipment Under Test (EUT): EUT Name: IP Camera Model No.: IPC6215SR-X5PAEW-VG,IPC6215SRa-xxxxWxxxx-yyyyyyyy-zzz, "x" can be 0-9, A-Z, a-z or blank, denoting difference in interface, "y" can be 0-9,A-Z,a-z or blank, denoting performance difference, "z" can be 0-9,A-Z,a-z or blank, denoting target regional, "-" is optional Standard(s) : FCC Rules 47 CFR §2.1091 KDB 447498 D04 interim General RF Exposure Guidance v01 Date of Receipt: 2024-08-06 Date of Test: 2024-08-07 to 2024-08-19 Date of Issue: 2024-08-20 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240800151502 Page: 2 of 10 Revision Record Version Description Date Remark 00 Original 2024-08-20 / Authorized for issue by: Tested By Maker_Qi/Project Engineer Approved By Terry Hou /Reviewer Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240800151502 Page: 3 of 10 2 Contents Page 1 Cover Page ........................................................................................................................................ 1 2 Contents ............................................................................................................................................ 3 3 General Information .......................................................................................................................... 4 3.1 General Description of E.U.T. .................................................................................................... 4 3.2 Technical Specifications ............................................................................................................. 4 3.3 Separation Distance ................................................................................................................... 4 3.4 Test Location .............................................................................................................................. 5 3.5 Test Facility ................................................................................................................................ 5 4 RF Exposure Test Exemptions ........................................................................................................ 6 4.1 FCC RF Exposure Test Exemptions for single RF sources ....................................................... 6 4.2 RF Exposure Test Exemptions for Simultaneous Transmission ................................................ 8 5 Measurement and Calculation ....................................................................................................... 10 5.1 Maximum transmit power ......................................................................................................... 10 5.2 RF Exposure Calculation ......................................................................................................... 10 Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240800151502 Page: 4 of 10 3 General Information 3.1 General Description of E.U.T. Power supply: DC 12V/1.5A; POE 48V/0.5A 3.2 Technical Specifications 2.4GHz WiFi Operation Frequency: 802.11b/g/n(HT20)/ax(HEW20):2412MHz to 2462MHz;802.11n(HT40)/ax(HEW40):2422MHz to 2452MHz Modulation Type: 802.11b: DSSS (CCK, DQPSK, DBPSK), 802.11g/n: OFDM (64QAM, 16QAM, QPSK, BPSK), 802.11ax: OFDMA (BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024-QAM) Data rate: 802.11b: 1/2/5.5/11Mbps 802.11g: 6/9/12/18/24/36/48/54Mbps 802.11n/ax: MCS0-MCS7 Number of Channels: 802.11b/g/n(HT20)/ax(HEW20):11;802.11n(HT40)/ax(HEW40):7 Channel Spacing: 5MHz Antenna Type: Internal antenna Antenna Gain: 3.94dBi(Provided by the manufacturer) 3.3 Separation Distance Separation distance between the antenna to person (R): ＞20cm Remark: This minimum test separation d…

Text truncated - open the document above for the full version.

Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240800151501 Page: 1 of 185 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-Conditions/Terms-e-Document.aspx. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 30 days only. Member of the SGS Group (SGS SA) TEST REPORT Application No.: KSCR2408001515AT FCC ID: 2AL8S-0235C8T7 Applicant: Zhejiang Uniview Technologies Co., Ltd. Address of Applicant: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Manufacturer: Zhejiang Uniview Technologies Co., Ltd. Address of Manufacturer: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Factory: Zhejiang Uniview Systems Technology Co., Ltd. Address of Factory: No.1277 South Qingfeng South Road, Tongxiang City, Jiaxing City, Zhejiang Province, China Equipment Under Test (EUT): EUT Name: IP Camera Model No.: IPC6215SR-X5PAEW-VG,IPC6215SRa-xxxxWxxxx-yyyyyyyy-zzz, "x" can be 0-9, A-Z, a-z or blank, denoting difference in interface, "y" can be 0-9,A-Z,a-z or blank, denoting performance difference, "z" can be 0-9,A-Z,a-z or blank, denoting target regional, "-" is optional   Please refer to section 2 of this report which indicates which model was actually tested and which were electrically identical. Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2024-08-06 Date of Test: 2024-08-07 to 2024-08-19 Date of Issue: 2024-08-20 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240800151501 Page: 2 of 185 Revision Record Version Description Date Remark 00 Original 2024-08-20 / Authorized for issue by: Tested By Maker_Qi/Project Engineer Approved By Terry Hou /Reviewer Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240800151501 Page: 3 of 185 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Customer Declaration Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Radiated Emissions which fall in the restricted bands ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Below 1GHz ANSI C63.10 (2013) Section 6.4,6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Above 1GHz ANSI C63.10 (2013) Section 6.6 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Conducted Average Output Power ANSI C63.10 (2013) Section 11.9.2 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Minimum 6dB Bandwidth ANSI C63.10 (2013) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Power Spectrum Density ANSI C63.10 (2013) Section 11.10.2 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement ANSI C63.10 (2013) Section 11.13.3.2 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions ANSI C63.10 (2013) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass Model No.: IPC6215SR-X5PAEW-VG,IPC6215SRa-xxxxWxxxx-yyyyyyyy-zzz, "x" can be 0-9, A-Z, a-z or blank, denoting difference in interface, "y" can be 0-9,A-Z,a-z or blank, denoting performance difference, "z" can be 0-9,A-Z,a-z or blank, denoting target regional, "-" is optional Note: There are series models mentioned in this report, and they are identical in electrical and electronic characters. Only the model IPC6215SR-X5PAEW-VG was tested since their differences were the model number and appearance. Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240800151501 Page: 4 of 185 3 Contents Page 1 COVER PAGE ............................................................................................................................................ 1 2 Test Summary .................................................................................................................................................. 3 3 Contents ........................................................................................................................................................... 4 4 General Information ........................................................................................................................................ 5 4.1 Details of E.U.T. ........................................................................................................................................ 5 4.2 Power level setting using in test: ....…

Text truncated - open the document above for the full version.

Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240800151501 Page: 139 of 185 802.11ax(HEW40)_MCH_2437MHz_RU484_Left_Ant1 (SISO)_NTNV 802.11ax(HEW40)_HCH_2452MHz_RU484_Left_Ant1 (SISO)_NTNV Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240800151501 Page: 140 of 185 3. Maximum Conducted Output Power 3.1 Test Result 3.1.1 Power Mode TX Type Frequency (MHz) RU RU Pos Maximum Average Conducted Output Power (dBm) Verdict ANT1 Limit 802.11b SISO 2412 / / 14.37 <=30 Pass 2437 / / 14.09 <=30 Pass 2462 / / 13.42 <=30 Pass 802.11g SISO 2412 / / 13.52 <=30 Pass 2437 / / 13.19 <=30 Pass 2462 / / 12.55 <=30 Pass 802.11n (HT20) SISO 2412 / / 13.20 <=30 Pass 2437 / / 13.01 <=30 Pass 2462 / / 12.32 <=30 Pass 802.11n (HT40) SISO 2422 / / 14.66 <=30 Pass 2437 / / 14.46 <=30 Pass 2452 / / 14.08 <=30 Pass 802.11ax (HEW20) SISO 2412 RU242 Left 13.01 <=30 Pass 2437 RU242 Left 12.67 <=30 Pass 2462 RU242 Left 12.00 <=30 Pass 802.11ax (HEW40) SISO 2422 RU484 Left 14.64 <=30 Pass 2437 RU484 Left 14.42 <=30 Pass 2452 RU484 Left 13.12 <=30 Pass Note1: Antenna Gain: Ant1: 3.94dBi; Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240800151501 Page: 141 of 185 3.2 Test Graph 3.2.1 Power 802.11b_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11b_MCH_2437MHz_Ant1 (SISO)_NTNV Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240800151501 Page: 142 of 185 802.11b_HCH_2462MHz_Ant1 (SISO)_NTNV 802.11g_LCH_2412MHz_Ant1 (SISO)_NTNV Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240800151501 Pag…
