2AL8S-0235C8YQIntelligent Recognition Access Control Terminal

V1.00 Intelligent Recognition Access Control Terminal Quick Guide 1 1 Packing List Contact your local dealer if the package is damaged or incomplete. The package contents may vary with device model. No. Name Qty Unit 1 Intelligent recognition access control terminal 1 PCS 2 Screw components 2 Set 3 Wall mount bracket 1 PCS 4 T10 screwdriver 1 PCS 5 Drill template 1 PCS 6 Tail cable 1 PCS 7 Cover 1 PCS 8 Product documents 1 Set 2 Product Introduction The appearance, dimensions, structure, and tail cables may vary with device models. 2.1 Dimensions • Model 1 • Model 2 2 2.2 Structure The intelligent recognition access control terminal includes intelligent recognition terminal and pluggable verification module.  Intelligent recognition terminal  Pluggable verification module  Model 1  Model 2 1. Microphone 2. Camera 3. Display screen 4. Illuminator 5. Reset button 6. Cable interface 7. Speaker 8. Network interface 9. Tamper proof button 10. Pass-through indicator 11. Card reading area 12. QR code reading area 3 2.3 Cable Name Color Description Door magnetic input Light green Door magnetic, button, and door lock cables Button input Yellow/Black Door lock_NC Pink Door lock_COM White/Yellow Door lock_NO White/Green GND Black RS485_A Orange RS485, Wiegand input, and Wiegand output cables RS485_B Yellow GND Black Wiegand input_D0 Blue Wiegand input_D1 White Wiegand output_D0 Brown Wiegand output_D1 Green Alarm input_1 Purple Alarm input and alarm output cables Alarm input_2 White/Purple Alarm output_NC Gray Alarm output_COM White/Orange Alarm output_NO White/Blue 12V power input Red Power cable GND Black 4 3 Device Installation 1. Paste the drill template on the wall with the arrow facing upward. Use a Ø6-6.5mm drill bit to drill two 30mm-depth holes on the A position, and then insert expansion bolts. Be careful not to damage cables in the wall. 2. Place the bracket straight up with the arrow facing outward. Knock the expansion bolts into the holes with the pointed tail screws. 3. Connect all cables. (1) Connect one end of the network cable (user-prepared) to the network interface on the rear panel, and the other end to the switch or other network device. 5 (2) Connect one end of the integrated cables to the corresponding cable interface on the rear panel, and the other end to the door sensor, alarm, and other devices according to the actual networking. 4. Fasten the cover to the access control terminal with three short Phillips screws. 5. Secure the access control terminal to the bracket. (1) Use a T10 screwdriver to loosen the tamper proof screws on both sides of the device that fix the pluggable verification module in the counterclockwise direction (the bottom module is designed with an allowance, and the screws will not fall off after loosening, as shown in the left figure). (2) Align the hook on the bracket with the groove on the terminal, and secure the terminal to the bracket (as shown in the right figure). (3) Tighten the two tamper proof screws again. 6 4 Startup After the device is installed correctly, connect one end of the power adapter (user-purchased or prepared) to the power interface of the device and the other end to the mains supply. 5 Web Login Default IP address 192.168.1.13 Default username/password admin/123456 Note: For security, please set a strong password of at least nine characters including uppercase and lowercase letters, digits, and special characters. You are strongly recommended to regularly change the device password and keep it secure to ensure that only authorized users can log in. 6 Recognition Requirements 6.1 Photo Collection Requirements General requirement: Facing the camera without wearing a hat, cap, etc. Range requirement: The photo should show both ears and the complete part from the top of the head (including hair) to the bottom of the neck of the person. Color requirement: True color photo. Makeup requirement: Heavy makeup is not allowed, including eyebrow makeup and eyelash makeup. Background requirement: A solid color such as white or blue is acceptable. Light requirement: Not too dark or too bright, and not partially dark and partially bright. 7 6.2 Recognition Position The correct recognition position is shown in the figure below. Please avoid person in the area 1 or area 2. 6.3 Expression and Posture 6.3.1 Expression Keep a natural expression as shown below. 6.3.2 Posture The correct and incorrect poses are as shown below. Correct Tilt Side RaiseBow 8 Disclaimer and Safety Warnings Copyright Statement ©2024 Zhejiang Uniview Technologies Co., Ltd. All rights reserved. No part of this manual may be copied, reproduced, translated or distributed in any form or by any means without prior consent in writing from Zhejiang Uniview Technologies Co., Ltd (referred to as Uniview or us hereafter). The product described in this manual may contain proprietary software owned by Uniview and its possible licensors. Unless permitted by Uniview and its licensors, no one is allowed to copy, distribute, modify, abstract, decompile, disassemble, decrypt, reverse engineer, rent, transfer, or sublicense the software in any form or by any means. Trademark Acknowledgements are trademarks or registered trademarks of Uniview. All other trademarks, products, services and companies in this manual or the product described in this manual are the property of their respective owners. Export Compliance Statement Uniview complies with applicable export control laws and regulations worldwide, including that of the People's Republic of China and the United States, and abides by relevant regulations relating to the export, re-export and transfer of hardware, software and technology. Regarding the product described in this manual, Uniview asks you to fully understand and strictly abide by the applicable export laws and regulations worldwide. EU Authorised Representative UNV Technology EUROPE B.V. Room 2945,3rd Floor,Randstad 21-05 G,1314 BD,Almere,Netherlands. Privacy Protection R…

Text truncated - open the document above for the full version.

Applicant Declaration QSF27-14-04 Rev 1.0 Rev. Feb 6, 2023 Page 1 of 1 Original Issue: Jan. 4, 2021 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name Zhejiang Uniview Technologies Co., Ltd. Address No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, Zhejiang Province, China Grantee Code 2AL8S FCC ID 2AL8S-0235C8YQ Authorized Contact Name Xu Feng Contact Email [email protected] Contact Phone 18106582562 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO 17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Link to the Covered List: Covered List Zhejiang Uniview Technologies Co., Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Zhejiang Uniview Technologies Co., Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered list, established pursuant to §1.50002, as an entity producing “covered” equipment. Applicant Signature: Date: 2024/7/17 Print Name: Xu Feng Title: Manager *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

ZheJiang Uniview Technologies Co.,Ltd. Current Date 2024-08-24 To: SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. No. 588 West Jindu Road, Songjiang District, Shanghai, China. 201612 Dear Sir/Madam, Subject: Declaration Letter about Identity of Products *WE ZheJiang Uniview Technologies Co.,Ltd., HEREBY DECLARED THAT Product Description: Intelligent Recognition Access Control Terminal Model No.: OET-573B-HM-Z-xxxxxxxx-yyyyyyyy-zzz (“x”,”y”,”z” can be 0-9,A-Z,a-z or blank;”-” may be blank) Manufacturer’s Name: ZheJiang Uniview Technologies Co.,Ltd. Manufacturer’s Address: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China *Except that the model number and appearance deviation, are identical with the original product as follows: Note: The definition of identical should be “electrically identical”. A device will be considered to be electrically identical if no changes are made to the devices’ schematics, board layouts, component layouts, chip sets, resistors and all other electrical aspects of the device are identical with the model which has been tested by SGS. Model No.: OET-573B-HM-Z-R Manufacturer’s Name: ZheJiang Uniview Technologies Co.,Ltd. Manufacturer’s Address: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Sincerely, Signature: Printed Name : Feng Xu Position/Title : Manager Contact Number: 18106582562

Zhejiang Uniview Technologies Co., Ltd. Date: 2024/7/17 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: 2AL8S-0235C8YQ To whom it may concern: We, the undersigned, hereby authorize Parlam Zhan to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with Zhejiang Uniview Technologies Co., Ltd. . This authorization is valid until further written notice from the applicant. Name (Printed): Xu Feng Title: Manager Signature: On behalf of Company: Zhejiang Uniview Technologies Co., Ltd. Telephone:18106582562

Zhejiang Uniview Technologies Co., Ltd. To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States From: Zhejiang Uniview Technologies Co., Ltd. No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, Zhejiang Province, China Regarding: Confidentiality Request regarding application for FCC ID: 2AL8S-0235C8YQ LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. Sincerely, Signature: Printed Name (on file with the FCC associated with the Grantee Code): Xu Feng Title: Manager Company Name: Zhejiang Uniview Technologies Co., Ltd.

Compliance Certification Services (Kunshan) Inc. Page: 1 of 5 External Photos for KSCR2407001378AT Test Model No.: OET-573B-HM-Z-R Compliance Certification Services (Kunshan) Inc. Page: 2 of 5 EUT Constructional Details (EUT Photos) Compliance Certification Services (Kunshan) Inc. Page: 3 of 5 Compliance Certification Services (Kunshan) Inc. Page: 4 of 5 Compliance Certification Services (Kunshan) Inc. Page: 5 of 5

Compliance Certification Services (Kunshan) Inc. Page: 1 of 7 Internal Photos for KSCR2407001378AT Test Model No.: OET-573B-HM-Z-R Compliance Certification Services (Kunshan) Inc. Page: 2 of 7 EUT Constructional Details (EUT Photos) Compliance Certification Services (Kunshan) Inc. Page: 3 of 7 Compliance Certification Services (Kunshan) Inc. Page: 4 of 7 Compliance Certification Services (Kunshan) Inc. Page: 5 of 7 Compliance Certification Services (Kunshan) Inc. Page: 6 of 7 Compliance Certification Services (Kunshan) Inc. Page: 7 of 7

Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240700137802 Page: 1 of 9 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-Conditions/Terms-e-Document.aspx. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 30 days only. Member of the SGS Group (SGS SA) 1 Cover Page RF Exposure Evaluation Report Application No.: KSCR2407001378AT FCC ID: 2AL8S-0235C8YQ Applicant: Zhejiang Uniview Technologies Co., Ltd. Address of Applicant: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Manufacturer: Zhejiang Uniview Technologies Co., Ltd. Address of Manufacturer: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Factory: Zhejiang Uniview Systems Technology Co., Ltd. Address of Factory: No.1277 South Qingfeng South Road, Tongxiang City, Jiaxing City, Zhejiang Province, China Equipment Under Test (EUT): EUT Name: Intelligent Recognition Access Control Terminal Model No.: OET-573B-HM-Z-R, OET-573B-HM-Z-xxxxxxxx-yyyyyyyy-zzz (“x”,”y”,”z” can be 0-9,A-Z,a-z or blank;”-” may be blank) Standard(s) : FCC Rules 47 CFR §2.1091 KDB 447498 D04 interim General RF Exposure Guidance v01 Date of Receipt: 2024-07-16 Date of Test: 2024-07-17 to 2024-08-06 Date of Issue: 2024-08-15 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Compliance Certification Services (Kunshan) Inc. CSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240700137802 Page: 2 of 9 Revision Record Version Description Date Remark 00 Original 2024-08-15 / Authorized for issue by: Tested By Maker_Qi/Project Engineer Approved By Terry Hou /Reviewer Compliance Certification Services (Kunshan) Inc. CSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240700137802 Page: 3 of 9 2 Contents Page 1 Cover Page ........................................................................................................................................ 1 2 Contents ............................................................................................................................................ 3 3 General Information .......................................................................................................................... 4 3.1 General Description of E.U.T. .................................................................................................... 4 3.2 Technical Specifications ............................................................................................................. 4 3.3 Test Location .............................................................................................................................. 5 3.4 Test Facility ................................................................................................................................ 5 4 FCC Radiofrequency radiation exposure limits ............................................................................ 6 4.1 Blanket 1 mW Blanket Exemption .............................................................................................. 6 4.2 MPE-based Exemption .............................................................................................................. 6 4.3 SAR-based Exemption ............................................................................................................... 7 5 Measurement and Calculation ......................................................................................................... 9 5.1 RF Exposure Calculation ........................................................................................................... 9 Compliance Certification Services (Kunshan) Inc. CSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240700137802 Page: 4 of 9 3 General Information 3.1 General Description of E.U.T. Power supply: DC 12V/2.0A 3.2 Technical Specifications Operation Frequency: 13.56MHz Modulation Type: ASK Number of Channels: 1 Antenna Type: FPC Antenna Compliance Certification Services (Kunshan) Inc. CSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240700137802 Page: 5 of 9 3.3 Test Location All tests were performed at: Compliance Certification Services (Kunshan) Inc. No.10 Weiye Rd, Innovation park, Eco&Tec, Development Zone, Kunshan City, Jiangsu, China. Tel: +86 512 5735 5888 Fax: +86 512 5737 0818 No tests were sub-contracted. Note: 1.SGS is not responsible for wrong test results due to incorrect information (e.g., max. internal working frequency, antenna gain, cable loss, etc) is provided by the applicant. (If applicable). 2.SGS is not responsible for the authenticity, integrity and the validity of the conclusion based on results of the data provided by applicant. (If applicable). 3. Sample source: sent by customer. 3.4 Test Facility The test facility is…

Text truncated - open the document above for the full version.

Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240700137801 Page: 1 of 28 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-Conditions/Terms-e-Document.aspx. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 30 days only. Member of the SGS Group (SGS SA) TEST REPORT Application No.: KSCR2407001378AT FCC ID: 2AL8S-0235C8YQ Applicant: Zhejiang Uniview Technologies Co., Ltd. Address of Applicant: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Manufacturer: Zhejiang Uniview Technologies Co., Ltd. Address of Manufacturer: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Factory: Zhejiang Uniview Systems Technology Co., Ltd. Address of Factory: No.1277 South Qingfeng South Road, Tongxiang City, Jiaxing City, Zhejiang Province, China Equipment Under Test (EUT): EUT Name: Intelligent Recognition Access Control Terminal Model No.: OET-573B-HM-Z-R, OET-573B-HM-Z-xxxxxxxx-yyyyyyyy-zzz (“x”,”y”,”z” can be 0-9,A-Z,a-z or blank;”-” may be blank)   Please refer to section 2 of this report which indicates which model was actually tested and which were electrically identical. Standard(s) : 47 CFR Part 15, Subpart C 15.225 Date of Receipt: 2024-07-16 Date of Test: 2024-07-17 to 2024-08-06 Date of Issue: 2024-08-15 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240700137801 Page: 2 of 28 Revision Record Version Description Date Remark 00 Original 2024-08-15 / Authorized for issue by: Tested By Maker_Qi/Project Engineer Approved By Terry Hou /Reviewer Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240700137801 Page: 3 of 28 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.225 N/A 47 CFR Part 15, Subpart C 15.203 Customer Declaration Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at Mains Terminals (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.225 ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass 20dB Bandwidth ANSI C63.10 (2013) Section 6.9 47 CFR Part 15, Subpart C 15.215 Pass Emission Mask ANSI C63.10 (2013) Section 6.4 47 CFR Part 15, Subpart C 15.225(a)&(b)&(C ) Pass Frequency tolerance ANSI C63.10 (2013) Section 6.8 47 CFR Part 15, Subpart C 15.225(e) Pass Radiated Emissions (9kHz-30MHz) ANSI C63.10 (2013) Section 6.4&6.5 47 CFR Part 15, Subpart C 15.225(d) & 15.209 Pass Radiated Emissions (30MHz-1GHz) ANSI C63.10 (2013) Section 6.4&6.5 47 CFR Part 15, Subpart C 15.225(d) & 15.209 Pass Declaration of EUT Family Grouping: Note: There are series models mentioned in this report, and they are identical in electrical and electronic characters. Only the model OET-573B-HM-Z-R was tested since their differences were the model number and appearance. Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240700137801 Page: 4 of 28 3 Contents Page 1 COVER PAGE ............................................................................................................................................ 1 2 Test Summary .................................................................................................................................................. 3 3 Contents ........................................................................................................................................................... 4 4 General Information ........................................................................................................................................ 5 4.1 Details of E.U.T. ........................................................................................................................................ 5 4.2 Description of Support Units ..................................................................................................................... 5 4.3 Measurement Uncertainty ......................................................................................................................... 5 4.4 Test Location ............................................................................................................................................ 6 4.5 Test Facility ............................................................................................................................................... 6 4.6 Deviation from Standards ......................................................................................................................... 6 4.7 Abnormalities from S…

Text truncated - open the document above for the full version.

一、Product Structure Drawing（mm） 标记 位置更 改 内 容版本签名日期 18 ±0.5 CK-NFC-AD4818-A0 48 ±0.5 金属孔 55 ±3 1.25间距插座 （白色）3PIN 带锁扣 黑线*2 点黑胶 黑色套管 厚度0.12 （不含离型纸） 10 ±2 20±3 二、 Physical product 三、Antenna technical parameters DesignSpecificationsTypical Antenna type 内置天线 (FPC) 工作频率 (WorkingFrequency)13.56MHz 增益（Gain）/ 天线效率（ Antennaefficiency ） / 电压驻波比（ VSWR ） / 极化方式(Ploriaztion)/ 辐射方向(Radiationpattern)/ 馈电阻抗(Impedance)/ 天线接口(Interface)3pin1.25mm间距白插 天线尺寸 (Overaldimensions) 48x18x0.12mm 工作温度 (OperatinTemp)-40 °C ~80 °C 储存温度(StoringTemp)15°C~30°C

Compliance Certification Services (Kunshan) Inc. Page: 1 of 3 Appendix Photographs of Test Setup for KSCR2407001378AT Test Model No.: OET-573B-HM-Z-R Compliance Certification Services (Kunshan) Inc. Page: 2 of 3 Test Setup Photo Conducted Emissions at Mains Terminals (150kHz-30MHz) Radiated Emissions (9kHz-30MHz) Compliance Certification Services (Kunshan) Inc. Page: 3 of 3 Radiated Emissions (30MHz-1GHz)
