2AL8S-0235C9C5IP Camera

Outdoor Pan&Tilt Wi-Fi Camera Quick Guide The following contents are for quick installation instructions only. For detailed disclaimer and safety information, please scan the QR code below. Packing List Note:Contact your local dealer if the package is damaged or incomplete. The package contents may vary with device model. Device Installation The following part shows the interfaces of two typical models./The illustrations are for reference only. The actual device may vary. Learn More To view the complete materials, please scan the QR code with your phone. CameraQuick guide Screw components Waterproof components Power adapter Drill template Warning sticker Install Micro SD Card Micro SD card slot Reset button 1. Make sure the camera is powered off before installation. 2. Rotate the camera downwards until the Micro SD/SIM card cover is fully exposed. 3. Use a Phillips screwdriver to loosen the screws on the card cover, and remove the cover. 4. Insert a Micro SD or SIM card into the slot. 5. Check that the sealing ring is in position. 6. Replace the card cover and tighten with screws. 1. Paste the drill template to locate holes,and drill holes according to the positions marked on the template. 2. Knock plastic expansion bolts into the holes. 3 .Insert self-tapping screws into the holes. 4.Align the gear of the camera with the bracket gear and push it to secure on the bracket. Mount Your Camera NOTE:The shooting direction can be adjusted by manually rotating the camera or using the PTZ control panel on the app or the Web interface. Disclaimer and Safety Warnings Copyright StatementAvertissement de l’utilisation de la batterie About This Manual This product complies with the European Low Voltage Directive 2014/35/EU and EMC Directive 2014/30/EU. The product this manual ref ers to is covered by the Waste Electrical & Electronic Equipment (WEEE) Directive and must be disposed of in a responsible manner. Battery in the product complies with the European Battery Regulation (EU) 2023/1542. For proper recycling, return the battery to your supplier or to a designated collection point. LVD/EMC Directive WEEE Directive–2012/19/EU Battery Regulation- (EU) 2023/1542 Regulatory Compliance No part of this manual may be copied, reproduced, translated or distributed in any form or by any means without prior consent in writing from our company by our company and its possible licensors. Unless permitted, no one is allowed to copy, distribute, modify, abstract, decompile, disassemble, decrypt, r everse means. This manual is intended for multiple product models, and the photos, illustrations, descriptions, etc, in this manual may be different from the actual appearances, functions, features, etc, of the product. and descriptions in this manual may be different from the actual GUI and Despite our best efforts, technical or typographical errors may exist in this manual. Our company cannot be held responsible for any such errors and reserves the right to change the manual without prior notice. Users are fully responsible for the damages and losses that arise due to improper operation. Our company reserves the right to change any information in this manual without any prior notice or indication. Due to such reasons as product version upgrade or regulatory requirement of relevant regions, this manual will be periodically updated. Safety Warnings The device must be installed, serviced and maintained by a trained professional with necessary safety knowledge and skills. Before you start using the device, please read through this guide caref ully and make sure all applicable requirements are met to avoid danger and loss of property. Storage, Transportation, and Use Store or use the device in a proper environment that meets environmental requirements, including and not limited to, t emperature, humidity, dust, corrosive gases, electromagnetic radiation, etc. Make sure the device is securely installed or placed on a flat surface to prevent falling. Unless otherwise specified, do not stack devices. Ensure good ventilation in the operating environment. Do not cover the vents on the device. Allow adequate space for ventilation. Protect the device from liquid of any kind. Make sure the power supply provides a stable voltage that meets the power requirements of the device. Make sure the power supply's output power exceeds the total maximum power of all the connected devices. Verify that the device is properly installed before connecting it to power . Do not remove the seal from the device body without consulting our company first . Do not attempt to service the product yourself. Contact a tr ained professional for maintenance. Always disconnect the device from power befor e attempting to move the device. Take proper waterproof measures in accordance with requirements before using the device outdoors. Install and use the device in strict accordance with your local electrical safety regulations. Use a UL certified power supply that meets LPS requirements if an adapter is used. Use the recommended cordset (power cord) in accordance with the specified ratings. Only use the power adapter supplied with your device. Use a mains socket outlet with a protective earthing (grounding) connection. Ground your device properly if the device is intended to be grounded. Power Requirements Lorsque utiliser la batterie, évitez: Température et pression d'air extrêmement élevées ou basses pendant l'utilisation, le stockage et le transport. Remplacement de la batterie. Utilisez la batterie correctement. Mauvaise utilisation de la batterie comme celles mentionnées ici, peut entraîner des risques d’incendie, d’explosion ou de fuite liquide de gaz inflammables. Remplacer la batterie par un type incorrect. Disposer d’une batterie dans le feu ou un four chaud, écraser mécaniquement ou couper la batterie. Disposer la batterie utilisée conformément à vos règlements locaux ou aux instructions du fabricant de la batterie. FCC Statements This device complies …

Text truncated - open the document above for the full version.

ZheJiangUniviewTechnologies Co.,Ltd. U.S. Agent Designationfor Serviceof Process (Applicant and U.S.Agentare SeparateParties) TO:FederalCommunications Commission 7435OaklandMillsRoad Columbia,MD 21046 ATTENTION:FCC Certification– Section2.911(d)(7) Information DesignatedU.S. Agent CompanyName:United ConsultingTechnologyServicesCo., Ltd. FRN:0033495714 Contact Name: DavidWu StreetAddress: 17800CASTLETONST STE665 CITYOF INDUSTRY City/Province/Zip:CA91748 Telephone No: (626) 217-4022 Email:[email protected] This letter is toconfirmthat we (“the DesignatedU.S. Agent)haveacceptedthe responsibility toact as the DesignatedU.S. Agent forServiceof Processas requiredbysection47 CFR2.911(d)(7)on behalfof the Applicantnotedbelow. U .S. AgentSignature: Date:2024-09-11 Signed by(Printed Name/Title):DavidWu/ CEO The Applicant acknowledgesthat theymustmaintainan agentfor noless than one year after terminating all marketing andimportationOR the conclusionofany Commission-relatedproceedinginvolving the equipment.The applicantfurtheracknowledgestheir responsibility toinformthe FCCwheneverthe DesignatedU.S. Agentinformationabove changes. A pplicant Companyname: ZheJiangUniviewTechnologies Co.,Ltd. Grantee Code:2AL8S FCCID: 2AL8S-0235C9C5 Contact Name:FengXu StreetAddress: No. 369, XietongRoad,Xixing Sub-district, Binjiang District City/Province/Zip:HangzhouCity, ZhejiangProvince, 310051, China Telephone No: 18106582562 Email:[email protected] Applicant Signature: Date:2024-09-11 Signed by(Printed Name/Title):Feng Xu,Manager

Applicant Declaration QSF27-14-04 Rev 1.1 Jan 17, 2024 Page 1 of 1 Original Issue: Jan. 4, 2021 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name ZheJiang Uniview Technologies Co.,Ltd. Address No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China FRN 0033495714 Grantee Code 2AL8S FCC ID 2AL8S-0235C9C5 Authorized Contact Name Feng Xu Contact Email [email protected] Contact Phone 18106582562 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO 17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Link to the Covered List: Covered List [Insert applicant name] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. [Insert applicant name] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [ is not] identified on the Covered list, established pursuant to §1.50002, as an entity producing “covered” equipment. Applicant Signature: Date: 2024/09/11 Print Name: Feng Xu Title: Certification Engineer *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

ZheJiang Uniview Technologies Co.,Ltd. Current Date 2024-09-29 To: SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. No. 588 West Jindu Road, Songjiang District, Shanghai, China. 201612 Dear Sir/Madam, Subject: Declaration Letter about Identity of Products *WE ZheJiang Uniview Technologies Co.,Ltd., HEREBY DECLARED THAT Product Description: IP Camera Model No.: Uho-P2A-xxxxxxxx-yyyyyyyy-zzzz ("x" can be 0-9, A-Z, a-z or blank, denoting difference in interface, "y" can be 0-9,A-Z,a-z or blank, denoting performance difference, "z" can be 0-9, A-Z,a-z or blank, denoting target regional, "-" is optional ) Manufacturer’s Name: ZheJiang Uniview Technologies Co.,Ltd. Manufacturer’s Address: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China *Except that the model number and appearance deviation, are identical with the original product as follows: Note: The definition of identical should be “electrically identical”. A device will be considered to be electrically identical if no changes are made to the devices’ schematics, board layouts, component layouts, chip sets, resistors and all other electrical aspects of the device are identical with the model which has been tested by SGS. Model No.: Uho-P2A-M3F4D Manufacturer’s Name: ZheJiang Uniview Technologies Co.,Ltd. Manufacturer’s Address: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Sincerely, Signature: Printed Name : Feng Xu Position/Title : Manager Contact Number: 18106582562

ZheJiang Uniview Technologies Co.,Ltd. Date: 2024-09-11 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: 2AL8S-0235C9C5 To whom it may concern: We, the undersigned, hereby authorize Parlam Zhan to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with ZheJiang Uniview Technologies Co.,Ltd. This authorization is valid until further written notice from the applicant. Name (Printed): Feng Xu Title: Certification Engineer Signature: On behalf of Company: ZheJiang Uniview Technologies Co.,Ltd. Telephone: 18106582562

ZheJiang Uniview Technologies Co.,Ltd. To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States From: Zhejiang Uniview Technologies Co., Ltd. No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Regarding: Confidentiality Request regarding application for FCC ID: 2AL8S-0235C9C5 LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. Sincerely, Signature: Printed Name (on file with the FCC associated with the Grantee Code): Feng Xu Title: Certification Engineer Company Name: ZheJiang Uniview Technologies Co.,Ltd.

Compliance Certification Services (Kunshan) Inc. Page: 1 of 4 External Photos for KSCR2409001756AT Test Model No.: Uho-P2A-M3F4D Compliance Certification Services (Kunshan) Inc. Page: 2 of 4 EUT Constructional Details (EUT Photos) Compliance Certification Services (Kunshan) Inc. Page: 3 of 4 Compliance Certification Services (Kunshan) Inc. Page: 4 of 4

Compliance Certification Services (Kunshan) Inc. Page: 1 of 6 Internal Photos for KSCR2409001756AT Test Model No.: Uho-P2A-M3F4D Compliance Certification Services (Kunshan) Inc. Page: 2 of 6 EUT Constructional Details (EUT Photos) Compliance Certification Services (Kunshan) Inc. Page: 3 of 6 Compliance Certification Services (Kunshan) Inc. Page: 4 of 6 Compliance Certification Services (Kunshan) Inc. Page: 5 of 6 Compliance Certification Services (Kunshan) Inc. Page: 6 of 6

Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240900175602 Page: 1 of 10 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-Conditions/Terms-e-Document.aspx. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 30 days only. Member of the SGS Group (SGS SA) 1 Cover Page RF Exposure Evaluation Report Application No.: KSCR2409001756AT FCC ID: 2AL8S-0235C9C5 Name of Testing Laboratory preparing the Report: Compliance Certification Services (Kunshan) Inc. Address of Testing Laboratory preparing the Report: No.10 Weiye Rd, Innovation park, Eco&Tec, Development Zone, Kunshan City, Jiangsu, China. Applicant: Zhejiang Uniview Technologies Co., Ltd. Address of Applicant: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Manufacturer: Zhejiang Uniview Technologies Co., Ltd. Address of Manufacturer: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Factory: Zhejiang Uniview System Technology Co., Ltd. Address of Factory: No.1277 Qingfeng South Road(South), Tongxiang Economic Development Zone, Tongxiang City, Jiaxing City, 314500, Zhejiang, China Equipment Under Test (EUT): EUT Name: IP Camera Model No.: Uho-P2A-M3F4D,Uho-P2A-xxxxxxxx-yyyyyyyy-zzzz ("x" can be 0-9, A- Z, a-z or blank, denoting difference in interface, "y" can be 0-9,A-Z,a- z or blank, denoting performance difference, "z" can be 0-9,A-Z,a- z or blank, denoting target regional, "-" is optional ) Standard(s) : FCC Rules 47 CFR §2.1091 KDB 447498 D04 interim General RF Exposure Guidance v01 Date of Receipt: 2024-09-05 Date of Test: 2024-09-12 to 2024-09-13 Date of Issue: 2024-09-23 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240900175602 Page: 2 of 10 Revision Record Version Description Date Remark 00 Original 2024-09-23 / Authorized for issue by: Tested By Damon_Zhou/Project Engineer Approved By Terry Hou /Reviewer Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240900175602 Page: 3 of 10 2 Contents Page 1 Cover Page ........................................................................................................................................ 1 2 Contents ............................................................................................................................................ 3 3 General Information .......................................................................................................................... 4 3.1 General Description of E.U.T. .................................................................................................... 4 3.2 Details of E.U.T. ......................................................................................................................... 4 3.3 Separation Distance ................................................................................................................... 5 3.4 Test Location ............................................................................................................................ 6 3.5 Test Facility ............................................................................................................................... 6 4 FCC Radiofrequency radiation exposure limits ............................................................................ 7 4.1 Blanket 1 mW Blanket Exemption .............................................................................................. 7 4.2 MPE-based Exemption .............................................................................................................. 7 4.3 SAR-based Exemption ............................................................................................................... 8 5 Measurement and Calculation ....................................................................................................... 10 5.1 Maximum transmit power ......................................................................................................... 10 5.2 RF Exposure Calculation ......................................................................................................... 10 Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240900175602 Page: 4 of 10 3 General Information 3.1 General Description of E.U.T. Power supply: DC 12V,1A 3.2 Details of E.U.T. 2.4GHz WiFi Operation Frequency: 802.11b/g/n(HT20): 2412MHz to 2462MHz; Modulation Type: 802.11b: DSSS (CCK, DQPSK, DBPSK), 802.11g: OFDM (64QAM, 16QAM, QPSK, BPSK) 802.11n: OFDM (64QAM, 16QAM, QPSK, BPSK) Data Rate: 802.11b: 1Mbps,5.5Mbps,11Mbps 802.11g: 6…

Text truncated - open the document above for the full version.

Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240900175601 Page: 1 of 93 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-Conditions/Terms-e-Document.aspx. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 30 days only. Member of the SGS Group (SGS SA) TEST REPORT Application No.: KSCR2409001756AT FCC ID: 2AL8S-0235C9C5 Name of Testing Laboratory preparing the Report: Compliance Certification Services (Kunshan) Inc. Address of Testing Laboratory preparing the Report: No.10 Weiye Rd, Innovation park, Eco&Tec, Development Zone, Kunshan City, Jiangsu, China. Applicant: Zhejiang Uniview Technologies Co., Ltd. Address of Applicant: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Manufacturer: Zhejiang Uniview Technologies Co., Ltd. Address of Manufacturer: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Factory: Zhejiang Uniview System Technology Co., Ltd. Address of Factory: No.1277 Qingfeng South Road(South), Tongxiang Economic Development Zone, Tongxiang City, Jiaxing City, 314500, Zhejiang, China Equipment Under Test (EUT): EUT Name: IP Camera Model No.: Uho-P2A-M3F4D,Uho-P2A-xxxxxxxx-yyyyyyyy-zzzz ("x" can be 0-9, A- Z, a-z or blank, denoting difference in interface, "y" can be 0-9,A-Z,a- z or blank, denoting performance difference, "z" can be 0-9,A-Z,a- z or blank, denoting target regional, "-" is optional )   Please refer to section 2 of this report which indicates which model was actually tested and which were electrically identical. Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2024-09-05 Date of Test: 2024-09-12 to 2024-09-13 Date of Issue: 2024-09-23 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240900175601 Page: 2 of 93 Revision Record Version Description Date Remark 00 Original 2024-09-23 / Authorized for issue by: Tested By Damon_Zhou/Project Engineer Approved By Terry Hou /Reviewer Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240900175601 Page: 3 of 93 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Pa rt 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Radiated Emissions which fall in the restricted bands ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Below 1GHz ANSI C63.10 (2013) Section 6.4,6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Above 1GHz ANSI C63.10 (2013) Section 6.6 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Conducted Average Output Power ANSI C63.10 (2013) Section 11.9.2 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Minimum 6dB Bandwidth ANSI C63.10 (2013) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Power Spectrum Density ANSI C63.10 (2013) Section 11.10.2 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement ANSI C63.10 (2013) Section 11.13.3.2 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions ANSI C63.10 (2013) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass Model No.: Uho-P2A-M3F4D,Uho-P2A-xxxxxxxx-yyyyyyyy-zzzz ("x" can be 0-9, A-Z, a-z or blank, denoting difference in interface, "y" can be 0-9,A-Z,a-z or blank, denoting performance difference, "z" can be 0-9,A-Z,a-z or blank, denoting target regional, "-" is optional ) Only the model Uho-P2A-M3F4D was tested. There are series models mentioned in this report, and they are identical in electrical and electronic characters. Only the model Uho-P2A-M3F4D was tested since their differences were the model number and appearance. Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240900175601 Page: 4 of 93 3 Contents Page 1 COVER PAGE ............................................................................................................................................ 1 2 Test Summary .................................................................................................................................................. 3 3 Contents ........................................................................................................................................................... 4 4 General Information ..................................................................…

Text truncated - open the document above for the full version.

一、Product Structure Drawing（mm） 标记位置更 改 内 容 版本 签名/日期 GK-F0040-A3 手撕口 IPEX RF1.13 80±3 40±0.5 10±0.5 FPC 二、 Product physical picture 三、Antenna technical parameters DesignSpecificationsTypical 天线形式(Antennaform)2.4G内置天线 工作频率(workingFrequency)2400-2500MHz 增益（Gain）3.94dBi（均值）、4.59dBi（峰值）@2400-2500MHz 天线效率（Antennaefficiency）≥60% 电压驻波比（VSWR）≤1.5 极化方式(Ploriaztion) Linear polarization 辐射方向(Radiationpattern) omnidirectional 馈电阻抗(impedance)50Ω 天线尺寸(Overaldimensions)40x10mm 重量(Weight)0.5g 工作温度(OperatinTemp)-40°C~80°C 四、 Antenna performance testing 1 、Return loss&standing wave ratio 3 、Direction diagram（ 2D 及 3D 图） 4 、Efficiency curve chart 5 、Gain curve graph

Compliance Certification Services (Kunshan) Inc. Page: 1 of 3 Appendix Photographs of Test Setup for KSCR2409001756AT Test Model No.: Uho-P2A-M3F4D Compliance Certification Services (Kunshan) Inc. Page: 2 of 3 Test Setup Photo Conducted Emissions at AC Power Line (150kHz-30MHz) Radiated Spurious Emissions Below 1GHz Compliance Certification Services (Kunshan) Inc. Page: 3 of 3 Radiated Spurious Emissions Above 1GHz Conducted Peak Output Power
