2AL8S-9801C24GWireless Bridge

Quick Guide V1.0 1 1 Packing List No. Name Qty Unit 1 Equipment host 2 PCS 2 Power cable 2 PCS 3 Power adapter 2 PCS 4 Hoop 4 PCS 5 Quick Guide 1 PCS 2 Product Overview 2.1 Specifications H a r d w a r e Dimensions(mm) 288x88x45mm Weight(kg) 0.3kg Installation Pole mounting Diameter≤75mm Protection Level IP65 Antenna Gain 15dBi Beam Width H：40°，V：15° Power Supply 24V Passive POE Max Power Consumption(W) 8W Average Power Consumption(W) 5W CPU AR9344 DDR & Memory 64MB DDR2,8MB Flash Physical Interface 2*10/100Mbps Indicator Light 1*Power Indicator 1*WLAN Indicator 1*LAN Indicator 3* Signal strength indicator Working Temperature -40°C~65°C Storage Temperature -40°C~85°C Working Humidity 5%~95%RH Non-condensing 2 Surge POE/GE: CM 4KV , DM 2KV ESD Protection Contact 6KV , Air 8KV Wind Survivability 134km/h S o f t w a r e Protocol 802.11a/n Frequency （India） 5160~5340MHz、5480~5720MHz、 5180~5320MHz、5745~5825MHz（China） 5180~ 5240MH z、5745~5825MHz（United States） 5160~5340MHz、5480~5720MHz、5745~5865MHz 5745~5825MHz （United Arab Emirates） 5745~5805MHz（Indonesia） Operating Mode AP, Station, WDS AP, WDS Station Security WPA2-PSK, Hidden SSID, IP/MAC Filtering Network Mode Bridge/ Router Management Support Web/AC/SNMP Other Timed restart，Support VLAN，QoS, Watchdog 2.2 Dimension 3 2.3 Interface Indicator Color Indication POWER Green power light LAN Green Network connection lamp The light is on, indicating that the LAN port of POE power supply is connected to IPC or other network equipment, and flashes when there is data WLAN Green Wireless indicator light The light is on to indicate wireless access and flashes when data is available Red Signal strength indicator light Device POE port: Connect with the POE port with its own power supply LAN2 port: reserved network port, can be connected with IPC and other front-end network equipment Device Reset:When the device is working, please press the reset button for 10 seconds and wait for 2~3 minutes to restore the default factory settings POE POE port: Connect with the POE port of the device LAN port: Connect with IPC and other front-end network devices 4 Yellow Only the red light is on, indicating a weak signal or no signal Only yellow and red lights are on, indicating moderate signal strength The yellow, red and green lights are all on, indicating high signal strength Green 3 Installation 4 Software configuration 4.1.1 Configuration and debugging Default factory settings transmitter device IP address: 192.168.1.35 Username: root Password: admin 1. Wireless Transmission Device 2. POE Adaptor 3. Metal cable tie 4. The LAN2 port on the main device can be connected with the other devices 5. The LAN port of POE adaptor can be connected with the other devices *The actual installation height needs to be determined according to the transmission distance and the installation environment, and there is no obstruction between the two points. 5 receiver equipment IP address: 192.168.1.36 Username: root Password: admin Device reset When the device is working, please press the reset button for 10 seconds and wait for 2~3 minutes to restore the default factory Settings Troubleshooting methods for network failure and excessive delay 1) Confirm that the devices are aligned and visible, and there are no obstructions in the middle; 2) Confirm that the various indicator lights of the equipment are working normally, and the signal strength indicator is in the medium or above indication condition; 3) There may be interference from other frequencies. Adjust the working frequency of the device away from the interference frequency. 4.1.2 Prepare Step 1 Use a network cable to connect the computer to the LAN interface of the device or PoE power supply to prepare the device. First, you need to configure the computer IP address and the device's default IP address to be on the same network segment. Take the Windows 7 system as an example. Click the network logo in the lower right corner of the desktop and click Open Network & Internet settings- Network and Sharing Center. As shown below. Step 2 Click “Local Area Connection” on the right and click “Properties”. As shown below. Step 3 Double-click Internet Protocol Version 4 (TCP/IPv4). As shown below. 6 4.1.3 Configuratio Step 1 Make sure that the IP address of the computer is inconsistent with the default IP address of the device. On the same network segment, use a browser to log in to the device, open a browser（The default IP address for the AP is 192.168.1.35, and the default IP address for the client is 192.168.1.36） Step 2 Go to the device page, click "Wizard" in the upper right corner of the page to configure the IP address. The IP address must be ensured not to cause conflicts. After configuring, click "Next". Step 3 Enter the country code configuration, select the country/region where the device is located, and click "Next" after configuring Step 4 Enter the wireless configuration page, where you can modify wireless-related parameters. The AP side should be configured as Access Point (WDS), while the client side should be configured as Client (WDS). The SSID needs to be unique and consistent between the access point and the client. In access point mode, the channel width should be set to 40MHz, while other parameters remain default. In client mode, the SSID should be the same as the access point, and the channel width should be configured as 20/40MHz, while other parameters remain default. If the encryption and key method are modified, they should be consistent between the access point and the client. Click "Next" after completing the configuration. 7 Step 5 Go to the Setup “Wizard – Finish” page and click “Complete” to save the configuration. Disclaimer and Safety Warnings Copyright Statement ©2021 Zhejiang Uniview Technologies Co., Ltd. All rights reserved. No part of this manual may be copied, reproduced, translated or distributed in any form or by any means without prior consent in writing from Zhejiang Uniview Technologies Co.,…

Text truncated - open the document above for the full version.

Applicant Declaration QSF27-14-04 Rev 1.0 Rev. Feb 6, 2023 Page 1 of 1 Original Issue: Jan. 4, 2021 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name ZheJiang Uniview Technologies Co.,Ltd. Address No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Grantee Code 2AL8S FCC ID 2AL8S-9801C24G Authorized Contact Name Feng Xu Contact Email [email protected] Contact Phone 18106582562 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO 17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Link to the Covered List: Covered List [ZheJiang Uniview Technologies Co.,Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. [ZheJiang Uniview Technologies Co.,Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered list, established pursuant to §1.50002, as an entity producing “covered” equipment. Applicant Signature: Date: 2023-05-30 Print Name: Feng Xu Title: Manager *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

ZheJiangUniviewTechnologies Co.,Ltd. U.S. Agent Designationfor Serviceof Process (Applicant and U.S.Agentare SeparateParties) TO:FederalCommunications Commission 7435OaklandMillsRoad Columbia,MD 21046 ATTENTION:FCC Certification– Section2.911(d)(7) Information DesignatedU.S. Agent CompanyName:United ConsultingTechnologyServicesCo., Ltd. FRN:0033495714 Contact Name: DavidWu StreetAddress: 17800CASTLETONST STE665 CITYOF INDUSTRY City/Province/Zip:CA91748 Telephone No: (626) 217-4022 Email:[email protected] This letter is toconfirmthat we (“the DesignatedU.S. Agent)haveacceptedthe responsibility toact as the DesignatedU.S. Agent forServiceof Processas requiredbysection47 CFR2.911(d)(7)on behalfof the Applicantnotedbelow. U .S. AgentSignature: Date:2023-05-30 Signed by(Printed Name/Title):DavidWu/CEO The Applicant acknowledgesthat theymustmaintainan agentfor noless than one year after terminating all marketing andimportationOR the conclusionofany Commission-relatedproceedinginvolving the equipment.The applicantfurtheracknowledgestheir responsibility toinformthe FCCwheneverthe DesignatedU.S. Agentinformationabove changes. A pplicant Companyname: ZheJiangUniviewTechnologies Co.,Ltd. Grantee Code:2AL8S FCCID: 2AL8S-9801C24G Contact Name:FengXu StreetAddress: No. 369, XietongRoad,Xixing Sub-district, Binjiang District City/Province/Zip:HangzhouCity, ZhejiangProvince, 310051, China Telephone No: 18106582562 Email:[email protected] Applicant Signature: Date:2023-05-30 Signed by(Printed Name/Title):Feng Xu,Manager

ZheJiang Uniview Technologies Co.,Ltd. Current Date 2023-05-30 To: SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. No. 588 West Jindu Road, Songjiang District, Shanghai, China. 201612 Dear Sir/Madam, Subject: Declaration Letter about Identity of Products *WE ZheJiang Uniview Technologies Co.,Ltd., HEREBY DECLARED THAT Product Description: Wireless Bridge Model No.: WLN-EB5E-IN-NB,WLN-EB5E,WLN-EB5E-xxxxxxxx-yyyyyyyy-zzz(where x y z may be 0-9 A-Z a-z or blank, or -. "-" is optional. The differences no impact safety related constractions and EMC). Manufacturer’s Name: ZheJiang Uniview Technologies Co.,Ltd. Manufacturer’s Address: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China *Except that the model number deviation, are identical with the original product as follows: Note: The definition of identical should be “electrically identical”. A device will be considered to be electrically identical if no changes are made to the devices’ schematics, board layouts, component layouts, chip sets, resistors and all other electrical aspects of the device are identical with the model which has been tested by SGS. Model No.: WLN-EB5E-IN Manufacturer’s Name: ZheJiang Uniview Technologies Co.,Ltd. Manufacturer’s Address: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Sincerely, Signature: Printed Name : Feng Xu Position/Title : Manager Contact Number: 18106582562

ZheJiang Uniview Technologies Co.,Ltd. Date: 2023-05-30 Declaration Letter about Limited Use To whom it may concern, WE (ZheJiang Uniview Technologies Co.,Ltd.) HEREBY DECLARED THAT Our product Product Description: Wireless Bridge Model No: WLN-EB5E-IN FCC ID: 2AL8S-9801C24G The Frequency Band 5250-5350MHz and 5470-5725MHz of 5G Wi-Fi function integrated in chip AR9344 in this device has been disabled by software. Any modification will be highlighted on the release letter, and the impact analysis will also have a review. Verification procedure and verification results will be performed based on the release letter and impact analysis report. Name (Printed): Feng Xu Signature: Title: Manager On behalf of Company: ZheJiang Uniview Technologies Co.,Ltd. Telephone: 18106582562

ZheJiang Uniview Technologies Co.,Ltd. Date: 2023-05-30 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: 2AL8S-9801C24G To whom it may concern: We, the undersigned, hereby authorize Parlam Zhan to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with ZheJiang Uniview Technologies Co.,Ltd.. This authorization is valid until further written notice from the applicant. Name (Printed): Feng Xu Title: Manager Signature: On behalf of Company: ZheJiang Uniview Technologies Co.,Ltd. Telephone: 18106582562

ZheJiang Uniview Technologies Co.,Ltd. To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States From: ZheJiang Uniview Technologies Co.,Ltd. No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Regarding: Confidentiality Request regarding application for FCC ID: 2AL8S-9801C24G LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions NII Software Security Info The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. Sincerely, Signature: Printed Name (on file with the FCC associated with the Grantee Code): Feng Xu Title: Manager Company Name: ZheJiang Uniview Technologies Co.,Ltd.

Compliance Certification Services (Kunshan) Inc. Page: 1 of 4 Appendix Photographs of External Photos for KSCR2305000762AT Test Model No.: WLN-EB5E-IN Compliance Certification Services (Kunshan) Inc. Page: 2 of 4 EUT Constructional Details (EUT Photos) Compliance Certification Services (Kunshan) Inc. Page: 3 of 4 Compliance Certification Services (Kunshan) Inc. Page: 4 of 4

Compliance Certification Services (Kunshan) Inc. Page: 1 of 5 Appendix Photographs of Internal Photos for KSCR2305000762AT Test Model No.: WLN-EB5E-IN Compliance Certification Services (Kunshan) Inc. Page: 2 of 5 EUT Constructional Details (EUT Photos) Compliance Certification Services (Kunshan) Inc. Page: 3 of 5 Compliance Certification Services (Kunshan) Inc. Page: 4 of 5 Compliance Certification Services (Kunshan) Inc. Page: 5 of 5

Compliance Certification Services (Kunshan) Inc. Report No.: KSCR230500076202 Page: 1 of 11 Eric Lin Laboratory Manager 1 Cover Page RF Exposure Evaluation Report Application No.: KSCR2305000762AT FCC ID: 2AL8S-9801C24G Applicant: Zhejiang Uniview Technologies Co., Ltd. Address of Applicant: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Manufacturer: Zhejiang Uniview Technologies Co., Ltd. Address of Manufacturer: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Factory: Zhejiang Uniview System Technology Co., Ltd. Address of Factory: No.1277 Qingfeng South Road(South), Tongxiang Economic Development Zone, Tongxiang City, Jiaxing City, 314500, Zhejiang, China Equipment Under Test (EUT): EUT Name: Wireless Bridge Model No.: WLN-EB5E-IN,WLN-EB5E-IN-NB,WLN-EB5E,WLN-EB5E-xxxxxxxx- yyyyyyyy-zzz(where x y z may be 0-9 A-Z a-z or blank, or -. "-" is optional. The differences no impact safety related constractions and EMC). Standard(s) : FCC Rules 47 CFR §2.1091 KDB 447498 D04 interim General RF Exposure Guidance v01 Date of Receipt: 2023-05-04 Date of Test: 2023-05-10 to 2023-05-14 Date of Issue: 2023-05-18 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Compliance Certification Services (Kunshan) Inc. Report No.: KSCR230500076202 Page: 2 of 11 Revision Record Version Description Date Remark 00 Original 2023-05-18 / Authorized for issue by: Damon Zhou/Project Engineer Eric Lin/Reviewer Compliance Certification Services (Kunshan) Inc. Report No.: KSCR230500076202 Page: 3 of 11 2 Contents Page 1 COVER PAGE .................................................................................................................................... 1 2 CONTENTS ........................................................................................................................................ 3 3 GENERAL INFORMATION ................................................................................................................ 4 3.1 GENERAL DESCRIPTION OF E.U.T. ................................................................................................ 4 3.2 DETAILS OF E.U.T. ....................................................................................................................... 4 3.3 TEST LOCATION ............................................................................................................................ 5 3.4 TEST FACILITY .............................................................................................................................. 5 4 FCC RADIOFREQUENCY RADIATION EXPOSURE LIMITS .......................................................... 6 4.1 BLANKET 1 MW BLANKET EXEMPTION ........................................................................................... 6 4.2 MPE-BASED EXEMPTION .............................................................................................................. 6 4.3 SAR-BASED EXEMPTION ............................................................................................................... 7 5 MEASUREMENT AND CALCULATION .......................................................................................... 10 5.1 MAXIMUM TRANSMIT POWER ....................................................................................................... 10 5.2 RF EXPOSURE CALCULATION ...................................................................................................... 11 Compliance Certification Services (Kunshan) Inc. Report No.: KSCR230500076202 Page: 4 of 11 3 General Information 3.1 General Description of E.U.T. Power supply: DC 24V,0.5A POE 3.2 Details of E.U.T. 5G WiFi Operation Frequency/Number of channels (20MHz): U-NII-1: 5180-5240MHz (4 Channels); U-NII-3: 5745-5825MHz (5 Channels) Operation Frequency/Number of channels/(40MHz): U-NII-1: 5190-5230MHz (2 Channels); U-NII-3: 5755-5795MHz (2 Channels) Modulation Type: 802.11a: OFDM (64QAM, 16QAM, QPSK, BPSK); 802.11n: OFDM (BPSK, QPSK, 16QAM, 64QAM) Channel Spacing: 802.11a/n(HT20): 20MHz; 802.11n(HT40): 40MHz DFS Function: Without DFS function Antenna Type: PCB Antenna Antenna Gain: Antenna 1: 15dBi (Provided by the manufacturer) Antenna 2: 15dBi (Provided by the manufacturer) Directional gain: 18.01 (Provided by the manufacturer) Compliance Certification Services (Kunshan) Inc. Report No.: KSCR230500076202 Page: 5 of 11 3.3 Test Location All tests were performed at: Compliance Certification Services (Kunshan) Inc. No.10 Weiye Rd, Innovation park, Eco&Tec, Development Zone, Kunshan City, Jiangsu, China. Tel: +86 512 5735 5888 Fax: +86 512 5737 0818 No tests were sub-contracted. Note: 1.SGS is not responsible for wrong test results due to incorrect information (e.g. max. clock frequency, highest internal frequency, antenna gain, cable loss, etc ) is provided by the applicant. (if applicable). 2.SGS is not responsible for the authenticity, integrity and the validity of the conclusion based on results of the data provided by applicant. (if applicable). 3.4 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • A2LA Compliance Certification Services (Kunshan) Inc. is accredited by the American Association for Laboratory Accreditation (A2LA). Certificate No. 2541.01. • FCC Compliance Certification Services (Kunshan) Inc. has been recognized as an accredited testing laboratory. Designation Number: CN1172. • ISED Compliance Certification Services (Kunshan) Inc. has been recognized by Innovation, Science and Economic Development Canada (ISED) as an accredited testing laboratory. Company Number: 2324E • VCCI The 3m and 10m Semi-anechoic chamber and Shielded Room of Compliance Certification Services (Kunshan) Inc. has been registered in accordance with the Regulations for Voluntary Control Measures with Registration No.: R-201…

Text truncated - open the document above for the full version.

Compliance Certification Services (Kunshan) Inc. Report No.: KSCR230500076201 Page: 1 of 177 Eric Lin Laboratory Manager TEST REPORT Application No.: KSCR2305000762AT FCC ID: 2AL8S-9801C24G Applicant: Zhejiang Uniview Technologies Co., Ltd. Address of Applicant: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Manufacturer: Zhejiang Uniview Technologies Co., Ltd. Address of Manufacturer: No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China Factory: Zhejiang Uniview System Technology Co., Ltd. Address of Factory: No.1277 Qingfeng South Road(South), Tongxiang Economic Development Zone, Tongxiang City, Jiaxing City, 314500, Zhejiang, China Equipment Under Test (EUT): EUT Name: Wireless Bridge Model No.: WLN-EB5E-IN ,WLN-EB5E-IN -NB,WLN-EB5E,WLN-EB5E-x xxxxxxx- yyyyyyyy-zzz(where x y z may be 0-9 A-Z a-z or blank, or -. "-" is optional. The differences no impact safety related constractions and EMC). ♣ ♣ Please refer to section 2 of this report which indicates which model was actually tested and which were electrically identical. Standard(s) : 47 CFR Part 15, Subpart E 15.407 Date of Receipt: 2023-05-04 Date of Test: 2023-05-10 to 2023-05-14 Date of Issue: 2023-05-18 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Compliance Certification Services (Kunshan) Inc. Report No.: KSCR230500076201 Page: 2 of 177 Revision Record Version Description Date Remark 00 Original 2023-05-18 / Authorized for issue by: Damon Zhou /Project Engineer Eric Lin /Reviewer Compliance Certification Services (Kunshan) Inc. Report No.: KSCR230500076201 Page: 3 of 177 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart E 15.407 N/A 47 CFR Part 15, Subpart C 15.203 Pass Transmission in the Absence of Data N/A 47 CFR Part 15, Subpart E 15.407 (c) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart E 15.407 ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 & Subpart E 15.407 b(9) Pass Duty Cycle KDB 789033 II B 1 KDB 789033 D02 II B 1 Pass 99% Bandwidth KDB 789033 II D N/A Pass 26dB Emission bandwidth KDB 789033 D02 II C 1 47 CFR Part 15, Subpart E 15.407 (a) Pass Minimum 6 dB bandwidth (5.725- 5.85 GHz band) KDB 789033 D02 II C 2 47 CFR Part 15, Subpart E 15.407 (e) Pass Maximum Conducted output power KDB 789033 D02 II E 47 CFR Part 15, Subpart E 15.407 (a) Pass Peak Power spectrum density KDB 789033 D02 II F 47 CFR Part 15, Subpart E 15.407 (a) Pass Radiated Emissions (Above 1GHz) KDB 789033 D02 II G 47 CFR Part 15, Subpart C 15.209 & Subpart E 15.407(b) Pass Radiated Emissions which fall in the restricted bands KDB 789033 D02 II G 47 CFR Part 15, Subpart C 15.209 & Subpart E 15.407(b) Pass Frequency Stability ANSI C63.10 (2013) Section 6.8 47 CFR Part 15, Subpart E 15.407 (g) Pass Radiated Emissions (Below 1GHz) KDB 789033 D02 II G 47 CFR Part 15, Subpart C 15.209 & Subpart E 15.407(b) Pass Declaration of EUT Family Grouping: There are series models mentioned in this report and they are the Identical in electrical and electronic characters. Only the model WLN-EB5E-IN was tested since their differences were the model number. Compliance Certification Services (Kunshan) Inc. Report No.: KSCR230500076201 Page: 4 of 177 3 Contents Page 1 COVER PAGE ............................................................................................................................................ 1 2 TEST SUMMARY ....................................................................................................................................... 3 3 CONTENTS ................................................................................................................................................ 4 4 GENERAL INFORMATION ........................................................................................................................ 6 4.1 DETAILS OF E.U.T. ............................................................................................................................... 6 4.2 DESCRIPTION OF SUPPORT UNITS ......................................................................................................... 6 4.3 POWER LEVEL SETTING USING IN TEST ................................................................................................... 7 4.4 MEASUREMENT UNCERTAINTY .............................................................................................................. 8 4.5 TEST LOCATION .................................................................................................................................... 9 4.6 TEST FACILITY ...................................................................................................................................... 9 4.7 DEVIATION FROM STANDARDS ............................................................................................................... 9 4.8 ABNORMALITIES FROM STANDARD CONDITIONS ..................................................................................... 9 5 EQUIPMENT LIST .................................................................................................................................... 10 6 RADIO SPECTRUM TECHNICAL REQUIREMENT ............................................................................... 12 6.1 ANTENNA REQUIREMENT .................................................................................................................... 12 6.1.1 Test Requirement: ....................................................................................................................... 12 6.1.2 Conclusion ............................................................................................................................…

Text truncated - open the document above for the full version.

HL T ronics (Kunshan) Co.,Ltd. Manufacturer: HL Tronics (Kunshan) Co., Ltd. TEL:+86-512-36877209 Address: Bu ilding 2, No.328 ShengXi Road, Economic Development Zone, KunShan, JiangSu, China. Vendor HL Tronics Model Number 1N9A120 Version A Customer ZheJiang Uniview Technologies Co.,Ltd. ANT1 ANT2 HL T ronics (Kunshan) Co.,Ltd. Specification Electrical Specifications Frequency Range(MHz) 5150MHz-5850MHz Bandwidth (MHz) 700MHz Ploarization Vertical and horizontal Gain(dBi) 15 HPBW(degree) H Beamwidth 40 V Beamwidth 15 Isolation(dB) >=20dB Impedance(Ω) 50 VSWR <=2.0 Mechanical Specifications Size(mm) 189*69*0.6 Weight(KG) 0.05 Manufacturer: HL Tronics (Kunshan) Co., Ltd. TEL:+86-512-36877209 Address: Building 2 , No.328 ShengXi Road, Economic Development Zone, KunShan, JiangSu, China. HL Tronics (Kunshan) Co.,Ltd. Antenna1 Pol ar Plots Horizontal Vertical Manufacturer: HL Tronics (Kunshan) Co., Ltd. TEL:+86-512-36877209 Address: Building 2 , No.328 ShengXi Road, Economic Development Zone, KunShan, JiangSu, China. HL Tronics (Kunshan) Co.,Ltd. Antenna2 Polar Plots Horizontal Vertical Manufacturer: HL Tronics (Kunshan) Co., Ltd. T…

Text truncated - open the document above for the full version.
